AC70 BATTERY CHARGER
The AC70 Battery Charger can charge up to four BAT70 lithium-ion
batteries at the same time. LEDs at the charging ports indicate bat-
tery status. Charge time is two hours. The AC70 can be used on a
desktop or mounted on a wall.
TOOLS/EQUIPMENT REQUIRED (for wall mounting only)
• Drill and drill bits (~ 3/16th inch (4.76 mm))
• Screwdriver (Phillips #2)
• Safety Glasses
INSTALLATION AND SETUP
Note: The AC70 is wireless and requires close physical proximity to
communicate with the Base Station/Remote Transceiver.
Desktop instructions:
1. Place the AC70 on a level desktop or shelf.
2. Connect the power adapter to a wall outlet, and the other end to
the power connector on the AC70 (Fig. 1).
Wall mount instructions:
1. Drill two holes two inches apart along a vertical axis on the wall
(avoid electrical or plumbing obstructions).
2. Install the provided hardware but do not tighten, leave a gap (~
¹/8th inch (3.2 mm)) between the screw heads and wall.
3. Align the AC70 mounting holes with the two screws (Fig. 2).
4. Mount the AC70 over the screw heads until flush against the
wall, then slide it down onto the screws to secure it in place.
OPERATION
1. Connect the power adapter to a wall outlet, and the other end to
the power connector on the AC70 (Fig. 1).
2. Position the BAT70 battery correctly for insertion into the AC70.
3. Insert the BAT70 battery into a vacant port to begin charging.
LED activity indicates battery status (see table below).
Battery Charger LED Reference Table
LED Color Status/Description
Green Flashing Green = Charging
Solid Green = Fully charged
Red Flashing Red = Incompatible battery
Red/Yellow Flashing Red & Yellow (alternating)= Fault condition
Mounting Holes
/Slots
Power Connector
AC70 BATTERY CHARGER
REAR VIEW
Fig. 2
Fig. 1
1 2 3 4
HME
WALL OUTLETAC70 BATTERY CHARGER
FRONT VIEW
POWER ADAPTER
Note: Only use the HME
approved Power Adapter
provided with your AC70
*Batteries shown in image
are not included

©2020 HM Electronics, Inc. All rights reserved.
2
REGULATORY AND SAFETY
CHANGING POWER SUPPLY ADAPTER
1. Replace a power adapter to match your coun-
try's outlet by using your thumb and forefinger to
squeeze in on both sides of the latch (see Fig. 3).
2. Continue squeezing latch and slide the adapter
out, away from the power supply to remove.
3. Release the latch and slide another adapter on until
it bottoms out and the latch clicks to secure it in
place.
TECHNICAL SPECIFICATIONS
Power Supply: Wall plug with switchable adapters
Input Voltage: 100 - 240VAC nominal
Output Voltage: 5V; 4A
MTBF (min.): 300,000 hours demonstrated
AC70 Battery Charger
Input Voltage: 5V; 4A
Charge Output: ~ 3W per port
Temperature
Operating: 32°F - +122°F (0°C - +50°C)
Storage: -40°F - +176°F (-40°C - +80°C)
Humidity: 0 - 95%, non-condensing
Press in here on both
sides of latch to release
Slide in these directions
to remove and replace
Latch
Adapter
Fig. 3
Dimensions
5.0in L x 3.5in W x 1.8in H
(127mm x 88.9mm x 45.72mm)
Weight
0.373lb (0.169kg)
Wireless PAN
2.4GHz Wireless Technology

REGULATORY COMPLIANCE
Applicant Name: HMElectronics, Inc.
Applicant Address: 2848 Whiptail Loop, Carlsbad CA92010, United States
Manufacturer Name: HMElectronics, Inc.
Manufacturer Address: 2848 Whiptail Loop, Carlsbad CA92010, United States
Country ofOrigin: USA
Brand: HME
Model: AC70
Caution: All products are compliant with regulatory requirements detailed in this document when the
user follows all installation instructions andoperating conditions per HME specifications.
Caution: Useof accessories andperipherals other than those recommended byHME may void the
product’s compliance as well as the user’s authority tooperate the equipment.
Caution: All products are designed foruse with the standard, integral or dedicated (external) antenna(s)
that are shipped together with the equipment. Any product changes or modifications will invalidate all
applicable regulatory certifications andapprovals.
Caution: The use of software orfirmware not supported/provided byHME products may result that the
equipment isnolonger compliant with the regulatory requirements.
Warning: The power adapteristhe equipment’s disconnection device. The power outlet must be
located nearby the equipment and its access must beeasy.
FCC NOTICE
This device complies with Part 15of the FCC rules. Operation is subject tothe following two conditions:
(1) This device may not cause harmful interference, and(2) This device must accept anyinterference
received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found tocomply with the limits for a Class A digital device,
pursuant toPart 15of the FCC rules. These limits are designed toprovide reasonable protection against
harmful interference when the equipment isoperated ina commercial environment. This equipment
generates, uses andcan radiate radio frequency energy and, if not installed andused in accordance with
the instruction manual, may cause harmful interference toradio communication. Operation of this
equipment in a residential area is likely tocause harmful interference, in which case the user will be
required tocorrect the interference at his own expense.
Changes ormodifications not expressly approved byHME could void the user’s authority to operate this
equipment.
FCC/IC/EC RFEXPOSURE WARNING
This product complies with FCC/IC/EC radiation exposure limits set forth for an uncontrolled
environment.
