Contro l4 C4-DM201-Z User manual

™
Load Symbols
Warnings and Considerations
WARNING! Install in accordance with all national and local electrical
codes.
WARNING! Improper use or installation can cause SERIOUS INJURY,
DEATH or LOSS/DAMAGE OF PROPERTY.
WARNING! If you are unsure about any part of these instructions, consult
a qualified electrician.
WARNING! If you are not sure which wires are Live, Load, Neutral, or
Earth/Ground, have a trained electrician perform the installation.
CAUTION! Do not install to control a receptacle.
IMPORTANT! Using this product in a manner other than outlined in this
document voids your warranty. Further, Control4 is NOT liable for any
damage incurred with the misuse of this product.
IMPORTANT! Changes or modifications not expressly approved by
Control4 could void the user’s authority to operate the equipment.
Installation Instructions
NOTE: The Puck Module can be wired and installed several dierent
ways. Please follow the instructions below that are appropriate for your
installation.
1 Ensure that the location and intended use meet the following criteria:
• The range and performance of the wireless control system is highly
dependent on: (1) distance between devices; (2) layout of the home; (3)
walls separating the devices; and (4) electrical equipment located near the
devices.
• DO NOT exceed the maximum load rating of the device (see the previous
section, “Specifications and Supported Fixtures”).
WARNING! Disconnect the power before installing or servicing this
device.
2 Switch o and isolate the mains power at the main consumer unit or fusebox
before starting any installation or maintenance.
3 Strip each wire’s insulation back 4.5 mm (3/16 in.) from the wire end.
4 If the Puck Module will be mounted to the wallbox using the yoke plate or will
be installed “floating” in the box rather than mounted to it, snap o the Puck
Module mounting ears with a pair of pliers (see Figure 1).
Figure 1. Puck Module with Removable Mounting Ears
Supported Models
• C4-DM201-Z Wireless Puck Dimmer
• C4-SM201-Z Wireless Puck Switch
Box Contents
• Wireless Puck Module
• Warranty Card
• WirelessPuckDimmerandSwitchModuleInstallationGuide (this document)
Specifications and Supported Fixtures
Power: 220-240VAC 50/60 Hz
C4-DM201-Z
Dimmer
C4-SM201-Z
Switch
Supported Load Types: Incandescent; Halogen;
Magnetic Low Voltage
(MLV); Electronic Low
Voltage (ELV); Phase-cut
dimmable: Fluorescent,
Compact Fluorescent,
and LED fixtures.
Incandescent; Halogen;
Magnetic Low Voltage
(MLV); Electronic Low
Voltage (ELV); Fluores-
cent; Compact Fluores-
cent; LED fixtures; and
Motors (ceiling fan and
exhaust fan).
Maximum Load*
(@240V)
Incandescent: 400W
Halogen: 400W
Fluorescent: 250W
CFL: 250W
LED: 250W
Incandescent: 400W
Halogen: 400W
Fluorescent: 250W
CFL: 250W
LED: 250W
Motor: 1/4 HP
Minimum Load* with
Neutral
(@240V)
Incandescent: 5W
Halogen: 5W
Fluorescent: 10W
CFL: 10W
LED: 10W
None
Minimum Load* with-
out Neutral
(@240V)
Incandescent: 10W
Halogen: 10W
Fluorescent: N/A
CFL: N/A
LED: N/A
N/A
Auxiliary LEDs 220-240VAC
Operating
Temperature:
All load ratings are based on an ambient temperature
of 25 degrees Celsius.
Communications: IEEE 802.15.4, 2.4 GHz, 15-channel, spread spectrum
radio
* Notes: The maximum and minimum load requirements for fluorescent, CFL and LED loads can
vary greatly depending upon the specific fixture and/or bulb being used. At higher wattages,
these load types have significant in-rush current which can trip the protection circuitry on the
device. At low wattages, some CFL and LED loads will not be able to completely shut o.
In both cases, the quality and performance of these load types varies greatly from manufacturer
to manufacturer. When using these load types, we recommend testing in advance. If problems
are found, simply changing to a dierent bulb manufacturer may solve the problem.
Additionally, we do not recommend the use of fluorescent, CFL, or LED loads without a neutral
connected to the Dimmer due to the capacitive nature of these load types.
Wireless Puck
Dimmer and
Switch Module
Installation Guide
Wiring
1 Identify and connect the Line, Load, and Neutral (if applicable) wires to the
screw terminals on the Puck Module according to the relevant wiring diagram
(see Figures 2, 3, 4, or 5). The Puck Module does not require an earth ground.
NOTE:Wiring configurations can dier depending upon how the fixture
was wired by the electrician.
2 If applicable, identify and connect the external keypad/switch wires to the
screw terminals on the Puck Module according to the relevant wiring diagram
(see Figures 2, 3, 4, or 5).
WARNING! The LED1 and LED2 Terminals provide line voltage to the
indicator LEDs. Remove power from the device before servicing.
Mounting the Puck Module to the Wallbox or the Wall with the
Mounting Ears
NOTE: The mounting ears are designed for wallboxes that utilize
mounting holes which are 60mm apart. They can also be used to mount
the Puck Module directly to the wall surrounding the wallbox if the wallbox
does not have mounting holes.
1 Ensure that the Control4 logo on the Puck Module is facing up (see Figure 1).
2 Fit the wires back into the wallbox. Fold the wires into a zigzag pattern so
that they easily fold into the wallbox.
3 Secure the Puck Module to the wallbox (or wall) using the mounting screws
appropriate for the wallbox or wall material. The Control4 logo should be
horizontal.
Installing the Puck Module Inside the Wallbox in a ‘Floating’
Position
NOTE: If local electrical code allows it, the Puck Module can be installed
inside the wallbox in a free floating manner. If the wallbox is deep enough,
this allows an external switch/keypad to be mounted to the wallbox in
front of the Puck Module.
1 Remove the Puck Module mounting ears (see Figure 1).
2 Fit the wires back into the wallbox. Fold the wires into a zigzag pattern so
that they easily fold into the wallbox
3 Push the Puck Module into the wallbox.
Finishing the Installation
1 When the wiring and installation are complete, turn on the mains power.
2 Test the Puck Module to see if it is working properly (see “Operation and
Configuration” on Page 2).
Sample Wiring Configurations
Figures 2, 3, 4, and 5 show wiring for a single or multiple locations.
—Load wire.
L—Line wire.
N—Neutral wire.
Aux 1, Aux 2—Auxiliary switch(es). Use Composer Pro to define the behavior.
LED 1, LED 2—220-240V indicator LEDs (lamps) on auxiliary switches. Use
Composer to define the behavior.
Figure 2. Single Location, Power at Wallbox
Figure 3. Single Location, Power at Light
Incandescent Lamp
Electronic Step-Down Converter
Electronic Ballast Fluorescent Lamp
Iron Core Transformer
Motors
(DO NOT use with Switch Puck or with fluorescent, CFL, or LED Loads)

™
