Control-A-Door Controll-A-Door ShedMaster User manual

OWNERS COPY
Installation Instructions
WARNING
It is vital for the safety of persons to follow all
instructions. Failure to comply with the installation
instructions and the safety warnings may result in
serious personal injury and/or property and remote
control opener damage.
Please save these instructions for future reference.
AUTOMATIC ROLLING GARAGE DOOR OPENER
Acr4D.pdf 24/05/2006 11:19:41 AM

TABLE OF CONTENTS
Important Safety Instructions...................................
Features....................................................................
Operating Controls......................................................
Package Contents.....................................................
Before Installation....................................................
Mounting the Opener...............................................
Setting Limits...........................................................
Setting Obstruction Force Margin............................
Coding Transmitters.................................................
Connecting Photo Electric Beam.............................
Parameters: Door Status Indicators..........................
Default Settings/Specifications................................
Trouble Shooting......................................................
Spare Parts Listing...................................................
Warranty..................................................................
3
4
5 - 6
7
8
9 - 10
11
12
13
14
15
16
17
18
19 - 20
B&D Doors to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or otherwise which
may be implied by laws as conditions or warranties of purchase of an B&D Doors Rolling Garage Door Opener. B&D Doors hereby further
expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any person as a result whether
directly or indirectly from failure to install the B&D Doors Rolling Garage Door Opener in accordance with these installation instructions.

IMPORTANT SAFETY INSTRUCTIONS
3
For ADDITIONAL SAFETY protection we
STRONGLY recommend the fitting of a Photo Electric
Beam. In most countries Photo Electric Beams are
mandatory on all garage doors fitted with automatic
openers. For a small additional outlay we recommend
that Photo Electric Beams be installed with the
automatic opener ensuring additional safety and peace
of mind.
DO NOT operate the garage door opener unless the
garage door is in full view and free from objects such as
cars and children/people. Make sure that the door has
finished moving before entering or leaving the garage.
DO NOT operate the garage door opener when
children/persons are near the door. Children must be
supervised near the garage door at all times when the
door opener is in use. SERIOUS PERSONAL
INJURY and/or property damage can result from failure
to follow this warning.
DO NOT allow children to operate the garage door
opener. SERIOUS PERSONAL INJURY and/or
property damage can result from failure to follow this
warning.
Regularly check to make sure that the SAFETY
OBSTRUCTION FORCE is working correctly, and is
TESTED and set as per the Installation Instructions
Manual. Failure to follow the manual could result in
SERIOUS PERSONAL INJURY and/or property
damage. This test must be repeated at regular intervals
and the necessary adjustments made as required.
DO NOT disengage the door opener to manual
operation with children/persons or any other objects
including motor vehicles within the doorway.
Install the wall mounted transmitter in a location where
it is out of reach of children and the garage door is
visible.
The door opener is not intended for use by young
children or infirm persons without adequate supervision.
Children should be supervised to ensure that they do not
play with the remote transmitters or the opener.
Keep hands and loose clothing CLEAR of the door and
door opener at all times.
Warning - It is vital for the safety of persons to follow all instructions. Failure to comply
with the following Safety Rules may result in serious personal injury and/or property damage.
The unit is rated to IP24, however, it should be installed
so that it is protected from the elements. Where possible
it should not be exposed to water or rain. It is not to be
immersed in water or sprayed directly by a hose or other
water carrying device.
The garage door must be WELL BALANCED.
Sticking or binding doors must be repaired by a
qualified garage door installer prior to installation of the
opener.
Frequently examine the installation, in particular
cables, springs and mountings for signs of wear,
damage or imbalance. DO NOT use if repair or
adjustment is needed since a fault in the installation or
an incorrectly balanced door may cause injury. DO
NOT attempt to repair the door yourself as hardware is
under extreme tension.
REMOVE OR DISENGAGE all garage door locks
and mechanisms prior to installation of the opener.
Connect the garage door opener to a properly
EARTHED general purpose 240V mains power outlet
installed by a qualified electrical contractor. The outlet
(and opener) must be positioned so that it is easily
accessible.
DISCONNECT THE POWER CORD from mains
power before making any repairs or removing covers.
Only EXPERIENCED service personnel should
remove covers from the garage door opener.
When using auto close mode, a PHOTO ELECTRIC
BEAM must be fitted correctly and tested for operation
at regular intervals. EXTREME CAUTION is
recommended when using auto close mode. ALL
SAFETY RULES must be followed.
In order for the garage door opener to SENSE an object
obstructing the door way, some FORCE must be
exerted on the object. As a result the object, door and/or
person may suffer DAMAGE or INJURY.
If the power supply cord is damaged, it MUST be
replaced by an B&D service agent or suitably qualified
person.
Make sure that the door is fully open before driving in
or out of the garage and fully closed before leaving the
driveway.
Make sure that remote controls are kept out of reach of
children.
©Copyright 2006 B&D Doors

4
FEATURES
OPERATION
To open or close the door simply press
the hand held transmitter or the wall
mounted transmitter for two seconds
During an open or close cycle the door
can be stopped by pressing the button
while the door is in motion.
The next actuation will move the door
in the opposite direction.
SECURITY CODE STORE
The Shed Master Garage Door Opener
uses state of the art technology in
storing your selected transmitter
security code. Up to six unique
transmitters can be stored in the openers
memory, plus one dipswitch unit and an
entry keypad.
WEATHERPROOF DESIGN
The opener’s control board is housed in
a weather-proof enclosure rated to IP24.
This offers protection from rain
however the unit should not be sprayed
by a hose or any other water carrying
device.
AUTOMATIC LIMITS
POSITIONING
The limits system automatically
calculates the doors’ travel limits and
stores it in memory. If the door is
moved manually within the travel limits
during a power failure, it will recognise
this once the power is restored and stop
at the correct limit position if the door is
activated.
INTELLIGENT FORCE MARGIN
SAFETY OBSTRUCTION SYSTEM
While the door is performing a close
cycle, should it hit an obstacle or be
restricted in some manner, it will
automatically reverse. The amount of
force the door should encounter before
reversing is automatically adjusted by
the doors control system during the
initialisation of the automatic door
opener. The door will also stop if
restricted whilst opening. The Safety
Obstruction Force should be checked at
least once a month. See installation
manual for instructions.
LOCKABLE CONTROL PANEL
The control panel can be locked and
disabled to prevent tampering. This is
useful if the opener is to be mounted on
an exposed carport or a perimeter door.
Locking the control panel will prevent
operating the door via the Operate
button, re profiling, clearing limits,
clearing transmitters, changing force
margins, and coding transmitters.
OVER LOAD INDICATOR
When the maximum opening and
closing capacity of the opener is
exceeded an audible beeper will sound
to indicate that an overload has
occurred.
PHOTO ELECTRIC BEAM
(OPTIONAL)
The opener has an input for a photo
electric beam to be connected for extra
safety protection and use of the auto
close mode.
MANUAL OPERATION
The opener is equipped with a unique
patented manual disengaging device. If
the power to the opener is disrupted for
any reason the door can be put into
manual mode by pulling down on the
string handle, then releasing. This will
allow you to manually open or close the
door. When power is restored, by
pulling down on the string handle and
releasing, the opener is put back into
automatic mode.
SECURITY LOCK FOR MANUAL
RELEASE HANDLE (OPTIONAL)
For added security the manual release
handle can be locked out or disabled.
This is ideal if the opener is to be
mounted on a perimeter door in an
exposed carport.
©Copyright 2006 B&D Doors
Thank you for purchasing the B&D
Controll-A-Door® ShedMaster Automatic
Rolling Garage Door Opener. This opener
is designed to suit vertical operating
continuous curtain rolling doors. The
components and materials used in this
opener are of the latest technology and
highest quality. Listed below are some of
the many features.

5
OPERATING CONTROLS
P. E. SHUNT. The shunt has to be
removed when connecting a Photo
Electric Beam.
NOTE: P.E. SHUNT must not be
removed otherwise the opener will
not function correctly. Remove
only when a P.E beam is to be
connected.
STATUS LED (Yellow) indicates
when the datum adjustment screw
has reached correct position.
DATUM ADJUST SCREW
Used to set mid point of door trav-
el during limits set up.
DOOR CODE button (blue) is
used for storing or erasing the
transmitter button you wish to use
to command the door to open, stop
or close.
CODING LED (red) light
indicates whether a code is being
stored or when a transmitter button
is pressed.
SET button (orange) is used
during the installation phase
together with the Plus and Minus
buttons to set the door limit
positions. The Set button is also
used to re-initialise the Opener.
1.
2.
3.
4.
5.
6.
OPERATE button (blue) is used
during installation to test the open,
stop and close cycles for the
opener. The opener has to be
initialised by the Set button before
the OPERATE button becomes
operable.
FORCE MARGIN SET The
obstruction force pressure is set
automatically by the opener during
installation. The pressure can be
adjusted manually using the Force
Margin Set button (White).
Pressing the force margin set
button and open or close button
will increase or decrease the
amount of force. The Force Margin
Set is only ever used if other
environmental factors (wind, etc.)
affect the operations of the
door/opener.
PLUS button (green) can be used
during installation to set the open
limit position. Pressing this button
will move the door in the open
direction. Movement stops when
the button is released.
NOTE: The open safety
obstruction detection is
inoperable whenever the Open
Drive button is used to move
door. This button is disabled
after initialisation.
This button is also used to increase
the force margin sensitivity.
7.
8.
9.
OPEN LIMIT LED (green) the
led is very helpful during
installation. It illuminates and
flashes when the door is opening
and remains steady on when the
open limit position has been
reached.
MINUS button (red) can be used
during installation to set the close
limit position. Pressing this button
will move the door in the close
direction. Movement stops when
the button is released.
NOTE: The close safety
obstruction detection is
inoperable whenever the Close
Drive button is used to move
door. This button is disabled
after initialisation.
This button is also used to decrease
the force margin sensitivity.
CLOSE LIMIT LED (red) the led
is very helpful during installation.
It illuminates and flashes when the
door is closing and remains steady
on when the close limit position
has been reached.
ENGAGE/DISENGAGEMENT
CORD is used to switch the door
into manual mode especially in
case of a power failure. The length
of the string is also adjustable.
SECURITY LOCK FOR
MANUAL RELEASE (where
fitted) prevents the manual release
handle being pulled to disengage
the opener into manual mode.
10.
11.
12.
13.
14.
©Copyright 2006 B&D Doors

OPERATING CONTROLS
6
24VAC
SUPPLY
PROG
P.E
MOTOR
1) P.E. BEAM INPUT
2) DOOR STATUS LED (YELLOW)
3) DATUM ADJUST SCREW
4) DOOR CODE BUTTON (BLACK)
5) CODING LED (RED)
6) SET BUTTON (ORANGE)
7) OPERATE BUTTON (BLUE)
8) FORCE MARGIN SET BUTTON
9) PLUS BUTTON (FOR LIMITS SETTING & FORCE MARGIN)
10) OPEN LIMIT LED (GREEN)
11) MINUS BUTTON (FOR LIMITS SETTING & FORCE MARGIN)
12) CLOSE LIMIT LED (RED)
13) MANUAL RELEASE HANDLE
1
2345678
10 11 12
13
9
©Copyright 2006 B&D Doors

PACKAGE CONTENTS
7
ITEM QUANTITY
1
2RS WITH VISOR CLIPSETTIMSNARTDLEHDNAH
1RABTHGIEW
PAN HEAD SCREW M4x50mm 2
24MTUNXEHKCOLIN
FLAT WASHER I.D 3/16 x 1/2 2
2SREVOCRABGNIKCOL
1LAUNAMNOITALLATSNI
©Copyright 2006 B&D Doors
TRANSMITTER
B&D CONTROLL-A-DOOR®SHEDMASTER DRIVE UNIT
COLLAR KIT 1
SELF TAPPING SCREWS 10X32 AND WASHERS (TO PIN DOOR CURTAIN) 2 EA
TRANSMITTER WALL BRACKET KIT 1
SCREWS &
WASHERS TO
PIN DOOR
CURTAIN
TRANSMITTER
WALL BRACKET
KIT
COLLAR KIT

BEFORE INSTALLATION
8
IMPORTANT SAFETY INSTRUCTIONS FOR
INSTALLATION
Warning: Incorrect installation can lead to severe injury.
Follow ALL installation instructions.
SIDE ROOM REQUIREMENTS
Fig. 1 shows the minimum and recommended side room that is
required to mount the opener. The distance between the edge of
the door curtain and the inside of the bracket must be at least
40mm. However, for easier access it is recommended that at
least 95mm is allowed .
1. CHECK OPERATION OF DOOR
BEFORE BEGINNING THE INSTALLATION OF THE
SHED MASTER AUTOMATIC OPENER CHECK THE
OPERATION OF THE DOOR.
The door must be well balanced and be in a reasonable
operating condition. You should be able to lift the door
smoothly and with little resistance. It should stay open around
900mm to 1200mm above the floor. The door should not stick
or bind in the guide tracks. The ideal operational effort in
raising or lowering the door should not exceed a force of 10kg
(22 lbs.). Make sure that all door locks, ropes, chains etc. are
either released, or disabled and remove unnecessary
accessories.
2. FIXING OF DOOR WEIGHT BAR
Move the door manually to the mid open position. Place the
weight bar on the bottom rail, in the middle of the door and
secure with the fasteners provided (Fig. 2). Check the operation
of the door again. If the door feels heavy it may require extra
tension to be added to the door springs. Refer to the door
Installation manual from the manufacturer on how to tension
the door.
3. INSTALLING LOCKING BAR COVERS
To protect against entrapment of fingers etc. inserted into door
guides – remove the protective backing of the double sided tape
and install the locking bar covers over the holes in each door
guide.
FIG. 2
FIG. 1
MINIMUM
SIDE ROOM RECOMMENDED SIDE ROOM
FIG. 3
Double Sided Tape
Locking Bar Hole
Door Side Guide
©Copyright 2006 B&D Doors

MOUNTING THE OPENER
9
4. FIXING DRIVE UNIT TO THE DOOR
The Drive Assembly can be fixed to the rolling garage
door in a variety of ways. Described below is one method of
fixing. Make sure there is enough side room to slide the drive
assembly onto shaft.
PLEASE NOTE: THE INSTRUCTIONS FOR FIXING THE
DRIVE ASSEMBLY TO THE DOOR IS FOR RIGHT HAND
INSTALLATION.
FITTING DRIVE UNIT TO DOOR
(Fig. 4, Fig. 5, and Fig. 6).
1. Check that the door shaft U bolt is securely tightened on the
left hand side of the door. Fit the Collar Kit to the lefthand
2. Raise the door and tie a rope around the centre to secure the
roll.
3. Support the right hand end of the door with a suitable prop,
e.g. step ladder and soft padding to protect door surface.
WARNING: DO NOT ALLOW CHILDREN/PERSONS
AROUND THE DOOR AND PROP. SERIOUS PERSONAL
INJURY AND/OR PROPERTY DAMAGE CAN RESULT
FROM FAILURE TO FOLLOW THIS WARNING.
4. Carefully loosen and remove the right hand door shaft U
bolt.
5. Make sure that the door supporting prop is secure. While the
door is supported remove the right hand door mounting
bracket from wall.
6. Remove the drive assembly from the packaging. Try to
rotate the drive gear by pushing on the fork. If the gear
does not rotate the manual mode has to be selected. To
select pull downward on the string handle, then release
slowly. The drive gear should now rotate freely.
7. Slide the drive assembly over the door axle making sure that
the fork extends into and over one of the spokes of the door
drum wheel.
8. Refit the door mounting bracket to the wall. In some cases
the bracket may have to be re-positioned. Re-fit and tighten
the door shaft U bolt. Remove door supporting prop and
untie the rope from the curtain.
9. Straighten the drive assembly and position as per Fig. 6.
Tighten the two locking bolts firmly to secure the Drive
Unit.
10. Check the manual operation of the door by raising and
lowering the door. The door should run smoothly and not
catch on any part of the drive assembly.
11. Adjust the length of the manual release cord so that it can
be easily reached by an adult of average height (ie. less than
1.8m tall).
NOTE: After installation, ensure that parts do not extend over
public footpaths or roads.
FIG. 4
FIG. 5
FIG. 6
©Copyright 2006 B&D Doors
axle, ensuring it is in contact with the door drum

MOUNTING THE OPENER
10
5. FIXING OF DOOR CURTAIN TO DRUM
WHEEL
The door curtain has to be secured to the drum wheel with
suitable fasteners.
1. With the door in the fully closed position, mark the curtain
(Fig. 7) on both ends of the door.
2. Open door slightly to have access to the marked positions.
Secure the curtain to drum wheel using self drilling screws
(two on each end). The screws should be at least 90 degrees
apart.
FIG. 7
©Copyright 2006 B&D Doors
DRUM WHEEL
5.1 MOUNTING THE TRANSMITTER
BRACKET (Fig. 7.1)
1. Locatewallmountbracketatleast1.5mabovethe floor,so that
young hands cannot reach.
2. Attach to the wall with 2 x 3.5 max flat head screws
3. Slide remote control onto wall mount bracket
NOTE - Tightening the wall mount screws will reduce
clearance between bracket and wall.
FIG. 7.1

SETTING LIMITS
11
6.2 SETTING TRAVEL LIMITS
NOTE: The opener is factory preset for installation on the
RIGHT HAND SIDE. When the opener is mounted on the
left side of the door the opener will travel in reverse.
1. Press Minus (-) button, the door will start closing. If the
door starts to open - press the Operate button (Fig. 10
within two seconds. Press Minus (-) button again - the door
should now close. Release the button once you have reached
your desired closed limit position.
2. Press Set button to store the closed limit position into
memory.
3. Press Plus (+) button, the door will start opening. Release
the button once you have reached your desired open limit
position.
IMPORTANTWARNING: Please be aware that the garage
door will start closing automatically once step 4 is
performed. The door will also automatically re-open after
fully closing with a short pause between the cycles.
4. Press Set button to store the open limit position into
memory.
The door will now automatically close to its limit position then
fully open to calculate the safety obstruction forces. Please be
aware of the above warning.
7. RESETTING DOOR LIMITS POSITIONS
The door limit positions can be deleted for new positions by
following the steps below:
1. Press and hold the Minus button (Fig. 10) for six (6) seconds
until you hear three beeps and the red Close Limit LED
starts to flash. Release the button.
2. Follow STEP 6.2 above to set new travel limit positions.
Important: Their is no need to re-code the transmitter used
for setting the limit positions. After the limits are set the
transmitter will automatically reset to normal operation.
Go to STEP 8 and test the Safety Obstruction Force.
FIG. 10
©Copyright 2006 B&D Doors
6. SETTING DOOR TRAVEL LIMITS
IMPORTANT NOTE: The OPERATE button will not
function until the open and close limits positions are set.
6.1 SETTING DATUM POSITION
1. Switch the opener into manual mode (
2. Move the door by hand to an approximately mid open
position.
3. Re-engage the opener.
4. Using a small blade screw driver turn the datum adjust
screw slowly until the yellow status LED just illuminates.
Note: If the status LED is already illuminated when power is
connected then turn the datum adjust screw until the LED goes
off then turn back one notch to illuminate again.
FIG. 8
FIG. 9
WARNING! DO NOT adjust datum screw after setting
limits, as this will affect the opener’s operation, and
potentially damage both door and opener. .

SETTING SAFETY OBSTRUCTION FORCE
12
8. SAFETY OBSTRUCTION TEST
Please take care when testing the Safety Obstruction Force.
Due to Excessive forces failure to follow this warning may
cause SERIOUS PERSONAL INJURY and/or property
damage. The test below should be repeated at regular
intervals (approximately every two months).
8.1 TESTING CLOSE CYCLE
1. Open the door by pressing the OPERATE button (Fig. 11).
2. Place a length of timber approximately 50mm high on the
floor directly under the door (Fig. 12).
3. Press the OPERATE button to close door. The door should
strike the object and start to re-open.
NOTE: If the door stops and fails to reopen, it is possible that
the motor direction is set incorrectly. Change the motor
direction and retest.
IMPORTANT WARNING: If the test fails, there may be a
problem with the door, discontinue use, put the door into
manual operation and call for service.
8.2 TESTING OPEN CYCLE
1. With the door closed - press the OPERATE button to open
the door. When the door is approximately one metre above
the timber hold the bottom rail of the door firmly, the door
should stop.
ADJUSTING SAFETY OBSTRUCTION FORCE
The Safety Obstruction Force is calculated automatically and
set in memory on the Shed Master. It is usually not necessary to
adjust the Safety Obstruction Force. The only time the force
may need to be increased is due to environmental conditions,
for example, windy or dusty areas, and areas with extreme
temperature changes. If adjustments are made you must retest
the obstruction force margin as per above.
8.3 TO INCREASE FORCE PRESSURE
1. Press and hold the Force Margin Set button (Fig. 11)
2. While holding down the Force Margin button, press the
Plus button. Each press increases the force margin in both
directions. The Open Limit LED will illuminate each time
the Plus button is pressed. Each press increases the force
margin. Test the force as per step 8.1 and 8.2. If the Open
Limit LED flashes continuously when the Plus button is
being pressed, this indicates that the maximum force
pressure setting has being reached.
8.4 TO DECREASE FORCE PRESSURE
1. Press and hold the Force Margin Set button (Fig. 11).
2. While holding down the Force Margin button, press the
Minus button. Each press decreases the force margin. The
Close Limit LED will illuminate each time the Minus button
is pressed. Test the force as per step 8.1 and 8.2. If the Close
Limit LED flashes continuously when the Minus button is
being pressed, this indicates that the minimum force
pressure setting has been reached.
FIG. 12
8.5 TO RECALL FACTORY SET FORCE
1. While holding down the Force Margin Set button (Fig. 11)
press the SET button for two (2) seconds.
2. Release both buttons. The default setting should now be
recalled.
8.6. TO RE-CALCULATE FORCE MARGIN
Press and hold the Set Button for two (2) seconds, the beeper will
sound once. The door will start to move and re-calculate force
margins. The door can move between the open and close limit
positions up to four (4) times (depending on the position of the
door and the power up condition). A single beep will be heard once
the process is complete. The door is now ready for use.
IMPORTANT NOTE:
After installation ensure that the opener stops or is
prevented from opening when the door is loaded
with a mass of 20kg fixed centrally at the bottom
edge of the door.
FIG. 11
©Copyright 2006 B&D Doors

CODING TRANSMITTERS
13
9. SETTING TRANSMITTER CODES
Make sure to insert the battery into the transmitter. The
memory in the openers receiver can store up to six unique
remote control transmitters, one dipswitch transmitter and one
entry keypad.
9.1 CODE SETTING THE RECEIVER WITH SMART
CODE OR DIP SWITCH TRANSMITTERS
1. Make sure that the battery is inserted in the Transmitter
2. Press the Door Code button on the opener. The Code Set LED
will illuminate to indicate the opener is in Code Learn mode.
This mode is exited If a valid code is not stored in 15 seconds.
3.
.
SMART CODE TRANSMITTER - Press and hold the
remote control transmitter button to be programmed until the
Code Set LED flashes. This indicates successful programming
of the transmitter. (Fig. 13)
DIP SWITCH TRANSMITTER - Select your dipswitch
combination of switches by sliding them on or off. Now
press and hold the remote control transmitter button to be
programmed until the Code Set LED flashes, indicating
successful programming. (Fig.14)
4. Release the button in the remote control transmitter - the code
is now set.
10.1- SETTING ENTRY KEYPAD TRANSMITTER
CODE.
1. Make sure that the battery is set in the Keypad
Transmitter.
2. Press the Code Set button on the opener, the Code Set LED
will illuminate to indicate the opener is in Code Learn
mode. (if a valid code is not stored within 15 seconds, the
opener will exit Code Learn).
3. For an entry keypad the desired code should be typed (a
minimum of four numbers or letters) and the ENTER
button held down until the Code Set LED flashes to
indicate that it has been learnt.
4. Release the button on the keypad transmitter.
The code is now set.
FIG. 13
Press and hold
Door Code
Button
©Copyright 2006 B&D Doors
10.2DELETINGPROGRAMMED CODES
1. If the Door Codebutton ontheopener ispressedand heldfor
6seconds, theLEDwillblink rapidlyforonesecond toindicate
thatallprogrammed codes havebeenerased.
11. LOCKING THE CONTROL PANEL
To lock or disable the control panel a transmitter button must be
coded for the operate function.
1. Press and hold a coded button on a transmitter and the Plus (+)
button for 4 seconds until you hear a beep.
2. Release both buttons.
3. To test press the Operate button to confirm that the door
does not move.
To unlock the control panel repeat the above procedure.
FIG. 14

PE BEAM AND FINAL SET UP
14
13. FITTING THE SAFETY PHOTO
ELECTRIC BEAM SENSOR (OPTIONAL)
Locate the Photo Electric Beam (P.E.) normally closed contact
type in a strategic location within doorway. We recommend
150mm above the floor level and as close as possible to the
door opening, inside the garage. Remove shunt from P.E
connector (Fig. 14) and connect the wires from the P.E. wiring
harness as per Fig. 15.
Note: The wiring diagram is for a Transmitter/Receiver type
photo electric beam: model: PE-2 (Order Code 90214) with
Wiring Harness (Order Code 01900).
Make sure to align the beams correctly. Follow the manual
supplied with the Photo Electric Beam.
WARNING; The location of the beam and manner in which
it is installed might not give safety protection at all times.
Check to make sure that the height of the beam and type
used give maximum protection possible.
14. MANUAL RELEASE
To switch the opener to manual mode simply pull the red
manual release handle down and release. To re-engage the
opener repeat the above action (Fig. 16).
Note: The door may move uncontrollably if the spring tension
is weak or not set properly or the door is unbalanced. If this
occurs do not use the door and contact your installer for
service.
The manual release handle can be locked to prevent unwanted
disengagement (where fitted). This is useful if the opener is
mounted on an exposed carport or perimeter door. To disable
the manual release turn the key clockwise to the locked position
as indicated on the label. To enable turn the key anti-clockwise.
15. RESET ALL FACTORY DEFAULTS
1. Turn power off.
2. Press and hold Set button.
3. Turn power on and continue holding Set until all LEDs are
off.
Note: This does not erase transmitter codes stored in memory.
16. RE-INITIALISING THE OPENER
To re-initialise the opener press and hold the Set Button for two
(2) seconds, the beeper will sound once. The door will start to
move and re-calculate force margins. The door can move
between the open and close limit positions up to four (4) times
(depending on the position of the door and the power up
condition). A single beep will be heard once the initialisation is
complete. The door is now ready for use.
FIG. 14
FIG. 15
Model: PE-2
FIG. 16
REMOVE
PE SHUNT
1 2 3 4 5
0V
PE
24V
©Copyright 2006 B&D Doors

PARAMETERS
15
DOOR STATUS INDICATORS
DOOR OPENER STATE OPEN LED
GREEN CLOSE LED RED DOOR STATUS LED YELLOW BEEPER
OPEN ON
CLOSE ON
OPENING FLASHING
CLOSING FLASHING
DOOR TRAVEL STOPPED FLASHING FLASHING
DOOR OBSTRUCTED WHEN OPENING FLASHING
DOOR OBSTRUCTED WHEN CLOSING FLASHING BEEPS WHILE
DOOR IS MOVING
OPENER OVERLOADED ALTERNATING
FLASHES ALTERNATING FLASHES
MAINS POWER INTERRUPTED RAPID
FLASHES
BUTTONS FUNCTION
OPERATE Opens/Stops/Closes the door
Door Code Codes a transmitter button for OPERATE function
Force Margin Set + Plus (+) Increases the obstruction force margin setting
Force Margin Set + Minus (-) Decreases the obstruction force margin setting
Force Margin Set (then) Set Reloads the factory set default obstruction force margin setting
Close for 6 Secs Clears the door limits set positions. Limits then need to be reset.
Set (then power on) & hold until all LEDs are off Deletes control parameters excluding transmitter storage memory.
Door Code (then power on) & hold until all LEDs are off Deletes all transmitter stored in memory.
Set for 2 sec. Re-initialises the Opener to re-calculate force margins
©Copyright 2006 B&D Doors

TECHNICAL SPECIFICATIONS
INPUT VOLTAGE: 230V - 240V AC 50Hz
CONTROLLER VOLTAGE: 24V DC
STANDBY POWER: 2.8 Watts
MOTOR POWER: 100 Watts
MOTOR TYPE: 24V DC Permanent Magnet
OPERATING TEMPERATURE: +5° to +40°C
MAXIMUM DOOR OPENING:1,2 WIDTH: 5500mm
HEIGHT: 2700mm
WEIGHT: 100Kg
RATED LOAD: 450N (45Kg)
RECOMMENDED LOAD: 200N (20Kg)
OPENER LIMITS TRAVEL: 3.0 Turns of Door Drum Wheel
OPERATING TIME - INTERMITTENT: 4 Minutes
RECEIVER TYPE: UHF 433.92 MHz. AM Receiver
RECEIVER CODE STORAGE CAPACITY: 6 Smart Code Transmitters
1 Dipswitch Transmitter
1 Entry Keypad
TRANSMITTER FREQUENCY: 433.92 MHz
CODING TYPE: Fixed
No. of CODE COMBINATIONS: Over 3.86 Billion Codes
TRANSMITTER BATTERY: 2 x 3V Type 2032 Button Cell
DEFAULT SETTINGS AND SPECIFICATIONS
16
Note:
1. The maximum continuous curtain residential roll up door opening that the Shed Master can be installed on is 5500mm wide by
2700mm high. The door must be well balanced. A person of average strength should be able to lift up the door manually with very
little effort in case of an emergency.
2. Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra pressure on the door
and tracks which may in turn trigger the safety obstruction detection system intermittently.
DEFAULT STEP MAXIMUM
MAXIMUM MOTOR RUN TIME 30 Secs. — —
OBSTRUCTION FORCE MARGIN 8 1 20
FACTORY DEFAULT SETTINGS
©Copyright 2006 B&D Doors

TROUBLE SHOOTING
17
*Please Note: Some areas may be prone to excessive radio interference brought on by devices such as cordless telephones, wireless
stereo headphones and baby monitors. It is possible that these devices could cause a degree of interference such as to greatly reduce
the range of the transmitter. In such an instance please contact your B&D dealer for an alternative frequency replacement kit. As this
is not a warrantable situation but an environmental issue charges may apply for the changeover.
SYMPTOM POSSIBLE CAUSE REMEDY
Door will not operate. Mains power not switched on.
Door is obstructed.
Door is locked or motor jammed.
Door tracks/hardware damaged.
Switch on mains power.
Remove obstruction.
Unlock door or remove jam.
Door requires service/repair by qualified
technician.
Door starts to close but automatically
reverses to open position. Adverse weather conditions (wind or cold)
causing door to stiffen and become tight in
the tracks.
Possible obstruction in the doorway.
Increase force margin setting See Step 8.3
on page 13. Or re-calculate force margin.
See Step 8.6 on page 13.
Remove obstruction.
Door operates from drive unit (OPERATE)
button but not from transmitter.*
See note.
Transmitter code not stored in memory.
Flat Battery.
Code transmitter in to openers memory.
Refer Step 9.1 on page 14.
Replace battery.
Door will not open or close fully. Door limits position need to be reset. Reset limits position. See Page 12.
Door is overshooting or not reaching limits. Datum position not set correctly. Reset datum position. See Step 6.1 Page 11.
Door not working with PE installed. PE Beam or wiring faulty
PE Beam not aligned correctly.
PE Beam is obstructed.
Door obstructed when closing.
Repair PE Beam or replace wiring.
Re-align optics. See PE Instructions.
Remove obstruction from the path of PE.
Remove obstruction.
DATE MAINTENANCE PERFORMED BY SIGNATURE AMOUNT INV. No.
Please Note: Failure to maintain your garage door may void the warranty for your garage door opener.
Cannot set limits. Datum position not set correctly. Set datum position. See Step 6.1 Page 11.
©Copyright 2006 B&D Doors

SPARE PARTS LIST
18
©Copyright 2006 B&D Doors
ITEM
No.
1 2 3
4 5 6 7 8 9
10
11
12 13 14 15 16 17 18 19 20 21
22
23a 23b
24
25
26
27
28
29
DESCRIPTION DRIVE CHASSIS SUB-ASSY
INTERNAL GEAR AXLE
HEX SERRATION HEAD SCREW M6X20
INTERNAL GEAR 62080
CLAMP WASHER 62071
RETAINING RING STW 45 62073
CLAMPING SADDLE BRACKET
CLUTCH GEARED MOTOR ASSY 12-01 WS 62065
TRANSFORMER TDB-72-01 KIT (72VA) 62079
RATCHET TIMING ASSY 62078
POWER CORD A.S 1.5M 2P1R 62081
FELT 21 X 29 TERMINAL BLOCK 500/02DS 2 POS CAP POLYFILM 0.1UF K X2 275 VAC HEX SERRATION HEAD SCREW M8X16 TAPTITE SCREW ‘P’ M4X10 PAN HEAD SCREW W/WASHER M4X8 TAPTITE SCREW ‘P’ BLACK ZNC M3X14 INTERNAL TOOTH LOCK WASHER I.D 3 CABLE TIE 4” GT-100M STRING HANDLE ASSY 62076
CONTROL BOARD CB-17 62055 CHASSIS ENCLOSURE ASSY WARNING INFO LABEL_SM CONTROL COVER ASSY INDUSTRIAL SADDLE U-BOLT M8 HEX SERRATION FLANGE NUT M8 (BLACK)
FLAT WASHER 8.4X18X1.6
WEIGHT BAR 59693
ORDER CODE

WARRANTYAND EXCLUSION OF LIABILITY
1. Definitions
‘B&D’ means
(a) in Australia – B&D Doors of 17 Oasis Court, Clontarf Qld 4019, a division of B&D Australia Pty Ltd
(ABN 25 010 473 971), or
(b) in New Zealand – B&D Doors NZ Ltd of 70 Allens Road East Tamaki Auckland, which is a subsidiary
of B&D Australia Pty Ltd (an Australian company).
‘Purchaser’ means the purchaser of the Opener.
‘Opener’ means the ‘B&D Controll-A-Door® Shed Master Automatic Garage Door Opener’
‘Manufacturer’s Written Instruction Manual’ means the instruction manual provided with the Opener.
2. This warranty applies to every sale of an Opener to a Purchaser and is the only warranty given on behalf of B&D.
3. B&D warrants that it will, at its option, either repair or replace any defects for a period of twenty-four (24) months,
provided that all costs of disconnection and reinstallation shall be borne by the Purchaser.
4. The warranty provided in clause 3 shall only apply to an Opener which is being used under normal use and service in
accordance with the Manufacturer’s Written Instruction Manual and are limited to the repair or replacement, at B&D’s option,
of any defective Opener or parts thereof.
5. The warranty provided in clause 3 shall apply from the date of purchase of the Opener by the Purchaser.
6. For service under warranty within Australia, the faulty item should be suitably packaged with the details of the problem and
the customer details and sent via Australia post to the following address:
B&D Doors & Openers
34-36 Marigold Street, Reply Paid 76926
REVESBY 2212
For all enquiries phone [phone].
For service under warranty within New Zealand, contact B&D Doors New Zealand on 0800 427 236.
7. The Purchaser will pay for any service call made by B&D or an Authorised Distributor where such a call is made for the
purpose of adjustment (as described in the Manufacturers Written Instruction Manual) and not for rectification of a defect
pursuant to the warranty hereunder.
8. (i) The Purchaser shall be responsible for any expense incurred by B&D or anAuthorised Distributor in ensuring that
the Opener is readily accessible for any repair work carried out under this warranty.
(ii) Where an Opener is installed outside a capital city metropolitan area and a warranty claim is made pursuant to this
warranty, any travelling expenses and costs of transporting the Opener, incurred by B&D or its Authorised
Distributor, shall be borne by the Purchaser.
9. Subject to paragraph 12 hereof;
(i) the obligations of B&D under this warranty are limited to those contained herein and such warranties are
expressly in lieu of all other warranties, express or implied, including any implied warranty of merchantability
or fitness for a particular purpose and notwithstanding any course of dealing between the parties or custom and usage
in the trade to the contrary.
(ii) B&D shall not be subject to nor incur and the Purchaser releases B&D from any claim or liability (including
consequential loss or damage and loss or use or profit) by reason of delay, defective or faulty materials or
workmanship, negligence or any act, matter or thing done, admitted or omitted by B&D.
The Purchaser shall complete this certificate and keep it together with a copy of the receipt of purchase in a safe
place – production of such information will assist the handling of a claim made under this warranty.
19
Purchased From ___________________________________ Phone ______________________
Installed By _______________________________________ Date _______________________
Serial No. ________________________________________
©Copyright 2006 B&D Doors

For Product support within Australia contact 1800 636 407
For Product support within New Zealand contact 0800 427 236
QLD Office: 17 Oasis Court, Clontarf 4019 Ph: [phone]
NSW Office: 34-36 Marigold Street, Revesby 2212 Ph: [phone]
VIC/TAS Office: 147-153 Canterbury Road, Kilsyth 3137 Ph: [phone]
SA Office: 23 Frederick Road, Royal Park 5014 Ph: [phone]
WA Office: 96 Mulgul Drive, Malaga 6090 Ph: [phone]
NZ Office: 70 Allens Road, East Tamaki, Auckland Ph: [phone]
www.bnd.co.nz
B&D Doors is a Division of B&D Australia Pty Ltd
A.B.N. 25 010 473 971
www.bnd.com.au
©Copyright 2006 B&D Doors. All Rights Reserved.
In an ongoing commitment to product quality B&D reserve the right to change specifications without notice. E&OE. Printed For Export.
10. Subject to Clause 12 hereof, this warranty does not extend to and B&D will be relieved of all obligations, responsibilities
and liabilities (direct or consequential) in the event that defects in manufacture of the Opener are directly or indirectly in the
opinion of B&D due to or result from:
(i) being fitted to any door or other closing device which is not of the type or condition defined in the Manufacturers
Written Instruction Manual as suitable for installation of the Opener.
(ii) Lack of proper maintenance or care of the Opener or door. Failure to have the door serviced annually may void this
warranty.
(iii) Incorrect and unreasonable use.
(iv) Faulty installation or adjustment of the Opener or door to which the Opener is connected where such installation
or adjustment is not carried out by B&D or one of its Authorised B&D Distributors.
(v) Failure to observe any instructions or directions provided with the Opener or given to the Purchaser by B&D or an
Authorised Distributor.
(vi) Modifications or repairs made or attempted to be made by any unauthorised person.
(vii) Faulty electrical wiring of structures to which the Opener is affixed.
(viii) Radio or other electronic interference (including citizen band transmissions).
(ix) Water damage.
11. The warranty contained in Clause 3 does not cover batteries or globes and B&D shall not be liable for any defect,
malfunction or failure of such items.
12. It is expressly provided that the warranties or any terms and conditions of them or other statement contained in this
document or other literature given to the Purchaser shall not be read or applied so as to purport to exclude, restrict or modify
or have the effect of excluding, restricting or modifying the application in relation to the supply of the Opener of all or any of
the provisions of Divisions 2 and 2A of Part V of the Trade Practices Act, 1974, or the Consumer Guarantees Act 1993 if the
purchase is a ‘consumer’and purchased the opener in New Zealand, (“The Act”) as amended or the exercise of a right conferred
by such a provision or any other condition or warranty implied by any relevant State Act or Territorial Ordinance or by the
general law and which by law cannot be excluded, restricted or modified provided that to the extent that the Act permits B&D
to limit its liability for a breach of condition or warranty implied by the Act, B&D’s liability for such breach shall be limited to
the payment of the cost of replacing the Opener or acquiring an equivalent Opener or repairing the Opener.
13. This warranty shall be governed by and construed in accordance with Australian law if the opener was purchased in
Australia, or New Zealand law if the opener was purchased in New Zealand.
14. Upon making a claim under this warranty the purchaser must produce proof of the date of purchase, together with the details
of the installer, the date of installation and the serial number of the unit.
WARRANTYAND EXCLUSION OF LIABILITY
