CONTROL DATJ);.
·MUL TIPLE DISK DRIVE
CONTROL DATA
BM1A5
GENERAL DESCRIPTION
OPERATION
INSTALLATION"
CHECKOUT
MAINTENANCE
CUSTOMER ENGINEERING MANUAL

•

CONTROL DAT~
MULTIPLE DISK DRIVE
CONTROL DATA
:::ORPORAT10N
BM1A5
GENERAL DESCRIPTION
OPERATION
INSTALLATION &
CHECKOUT
MAINTENANCE
CUSTOMER ENGINEERING MANUAL

REVISION
A
(9-27- 69)
B
(12-1- 69)
C
(4-24-70)
D
(12 -7 -70)
RECORD
of
REVISIONS
NOTES
Manual released.
Engineering Change Order PE1l269 incorporating the following:
Editorial changes affecting cover
title page,
pages iii, v, 1-1, 1-2, 1-3, 1-4,2-1, 2-2, 2-3,
2-4,2-5,
2-6, 2-8
2-14, 3-2
3-5
3-6
3-16,
Section 4 and 5 filler, 6-2, 6-47,
6-8!, Section 7,
8,
9 filler,
comment sheet.
Technical
changes affecting pages v, 3-14, 3-15,
6-3,
6-12.
Engineering Change Order PE21147 incorporatin~ the following:
Engineering Change Orders PEll090,
PE11345, PE11475, PE11291, PE21058 affecting pages
vi,
1-3, 6-23, 6-25.1. thru 6-25.3, 6-34,
6-76, 6-77,
6-78.
Field Change Orders PE11204,
PE11294, PE21058, affecting pages vi, 6-25.1 thru 6-25.3, 6-34, 6-76, 6-77, 6-78. Technical
and editorial changes affecting pages 2 -10,
2-11, 2 -12, 3-1, 3 -3, 3 -15,
3-16, 6-1, 6-2, 6-4 thru
6-7, 6-16, 6-17,
6-18, 6-44, 6-54, 6-59, 6-61 thru 6-64, 6-66, 6-67, 6-68, 6-69, 6-70, 6-72
thru 6 -75,
6-79, 6 -81, 6 -85.
Engineering Change Order PE21852 incorporating the following:
Engineering Change Orders PE21197, PE21421,
PE21462.
Field Change Order P-E21512.
Technical and editorial changes.
This edition obsoletes all previous editions.
Address comments concerning this
manual to:
Pub No. 70602400
© 1969, 1970
Control Data Corporation
Technical Publications Department
4201 North Lexington Avenue
St. Paul. Minnesota 55112
by Control Data Corporation
Printed in United States of America
or use Comment Sheet in the back of
this manual.
...
CD
I
->
....
0:

PREFACE
