ControlByWeb X-404C User manual

See users manual for setup instructions:
www.ControlByWeb.com/support/
| Quick-Start Guide
X-404C
Rev 1.0
(For faster setup, we recommend doing this step first)
1. Register or login to your account at: www.ControlByWeb.cloud
2. Choose ‘Devices’ from the left navigation bar and click ‘New Device’.
3. On the New Device page, select the ‘Cell Device’ tab.
4. Enter a device name, the last 6 digits of serial number, and the Cell ID
(located on the side of the device) and click ‘Submit’.
5. You’ll be redirected to the Device Edit page. *Click ‘Activate SIM Card’.
6. Once activated, power up the X-404C.
May take up to 5 minutes to connect.
Cloud Setup & Cell Activation
Power
Supply
Vin+
Gnd
Power
Gnd
Data
1-Wire Bus
5Vo Connect to
Temp/Humidity
sensors (optional)
D(A) D(A)
D(B) D(B)
Gnd Ground
Gnd Ground
+Vo
Modbus
Modbus
Slave
Gnd
D(A)
D(B)
RS-485
+5V Power Input
(9-28 VDC)
Vout to sensors = Vin
Antenna SMA Connector
Cell
Power
Indicator Light: Blinking = Connecting, Solid = Connected
*Note: If data plan was
purchased separately, first
enter Data Plan Code
(sent via email) & click
‘Apply Data Plan’.
Activation may take 15
minutes. Click ‘Check SIM
Status’ to verify activation.

1681 West 2960 South, Nibley, UT 84321, USA
| Quick-Start Guide
X-404C
1. Power the module and connect to network.
2. Set IP address on computer to be on the same network as the
module. (Example: Set computer to 192.168.1.50)
3. To configure the module, open a web browser and enter:
http://192.168.1.2/setup.html
4. Assign permanent IP address to module, then restart module.
5. Restore computer’s IP address, if necessary, and access the module
at its new IP address to finish setup.
LAN Setup Steps (Optional)
IP Address: 192.168.1.2
Subnet Mask: 255.255.255.0
Control Page Web Address: http://192.168.1.2
Control Password: (no password set)
Setup Page Web Address: http://192.168.1.2/setup.html
Setup Username: admin
Setup Password: webrelay (all lower case)
Factory Default Settings
