ControlByWeb X-320 User manual

H
L
L
H
1008
1012
1012
1016
1020
1016
1024
1016
1033
1028
1024
daqseries
data acquisition TM
3
X-320m™
User’s Manual
Revision 1.0
a division of....
Xytronix Research & Design, Inc.
North Logan, Utah, USA
Covers Models: X-320M-I
© 2012 Xytronix Research and Design, Inc.
Web Enabled
Meteorological
Station Controller

X-320M™ User's Manual
Table of Contents
Trademark and Copyright Information................................................................................................................ 4
Warranty................................................................................................................................................................ 5
FCC Statement...................................................................................................................................................... 6
Installation Guidelines Read Before Installing)................................................................................................ 7
Section 1: Introduction......................................................................................................................................... 8
1.1 X-320M™ Features................................................................................................................................ 10
1.2 X-320M™ Models Available................................................................................................................... 11
1.2.1 Optional Accessories........................................................................................................................ 11
1.3 Connectors & Indicators....................................................................................................................... 12
1.4 Accessing X-320M™............................................................................................................................. 13
Section 2: Installation and Setup ..................................................................................................................... 14
2.1 Mounting................................................................................................................................................ 14
2.1.1 Wall Mounting................................................................................................................................... 14
2.1.2 DI -Rail Mounting............................................................................................................................ 14
2.2 Connection............................................................................................................................................. 15
2.2.1 Power Supply Connection................................................................................................................ 16
2.2.2 Digital Input/Output Connections...................................................................................................... 17
2.2.3 Analog Input...................................................................................................................................... 19
2.2.4 Frequency Input................................................................................................................................ 22
2.2.5 Digital Temperature/Humidity Sensor Connection ........................................................................... 23
2.2.6 etwork Connection......................................................................................................................... 25
2.3 Establishing Communications for Setup............................................................................................ 26
2.3.1 Method 1: Assign a Temporary IP address to X-320M™ ................................................................. 26
2.3.2 Method 2: Assign a Temporary IP Address to Configuration Computer ...........................................28
2.4 X-320M™ Setup Pages ......................................................................................................................... 31
2.4.1 Main Tab........................................................................................................................................... 31
2.4.2 etwork Tab...................................................................................................................................... 33
2.4.3 Advanced etwork Tab..................................................................................................................... 37
2.4.4 Password Tab................................................................................................................................... 39
2.4.5 Date/Time Tab .................................................................................................................................. 41
2.4.6 Logging Tab...................................................................................................................................... 45
2.4.7 Remote Devices Tab......................................................................................................................... 47
2.4.8 I/O Tab.............................................................................................................................................. 49
2.4.9 Status Setup Tab.............................................................................................................................. 52
2.4.10 Wind Speed Tab............................................................................................................................. 54
2.4.11 Wind Direction Tab.......................................................................................................................... 59
2.4.12 Rain Tab.......................................................................................................................................... 61
2.4.13 Temperature Tab............................................................................................................................. 64
2.4.14 Humidity Tab................................................................................................................................... 69
2.4.15 Solar Radiation Tab........................................................................................................................ 73
2.4.16 Barometric Pressure Tab................................................................................................................ 77
2.4.17 AUX1 and AUX2 Tab....................................................................................................................... 81
Page 2 Xytronix Research & esign, Inc.

X-320M™ User's Manual
Section 3: Operation........................................................................................................................................... 85
3.1 Browser Operation................................................................................................................................ 85
3.2 XML Operation....................................................................................................................................... 88
3.2.1 State.XML......................................................................................................................................... 88
3.2.2 Diagnostics.XML............................................................................................................................... 93
3.3 GET Requests........................................................................................................................................ 94
3.3.1 Using GET for Control and Monitoring.............................................................................................. 94
3.4 Email Notification.................................................................................................................................. 95
3.4.1 Email otification Description........................................................................................................... 95
3.4.2 Email otification Setup ................................................................................................................... 95
Appendix A: Restoring Factory Default Settings............................................................................................. 97
Appendix B: Installing New Firmware............................................................................................................... 98
Appendix C: Accessing X-320TM Over the Internet....................................................................................... 100
Appendix D: External Server and Remote Services...................................................................................... 104
Appendix E: Log Files ..................................................................................................................................... 106
Appendix F: Methods and Calculation Details............................................................................................... 109
Appendix G: Common Sensor Setup Parameters.......................................................................................... 113
Appendix H: Specifications.............................................................................................................................. 117
Appendix I: Mechanical Information............................................................................................................... 120
Xytronix Research & esign, Inc. Page 3

Trademark and Copyright Information X-320M™ User's Manual
Trademark and Copyright Information
This document is Copyright ©2012 by Xytronix Research & Design, Inc. All rights reserved.
X-320M™, WebRelay™, ControlByWeb™, and Xytronix Research & Design™ are trademarks of
Xytronix Research & Design™, Inc. 2012.
All other trademarks are the property of their respective owners.
All parts of this product and design including but not limited to firmware, hardware design, schematics,
PCB layout, concept, graphics, users manual, etc., are property of Xytronix Research & Design, Inc.
©2012. X-320M™ may not be opened, disassembled, copied, or reverse-engineered.
o part of this manual may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying or scanning, for any purpose other than the personal use by the
purchaser of this product. Xytronix Research & Design, Inc. assumes no responsibility for any errors that
may appear in this document.
Whereas reasonable effort has been made to make the information in this document as useful and
accurate as possible, Xytronix Research & Design, Inc. assumes no responsibility for the application,
usefulness, or completeness of the information contained herein. Under no circumstance will Xytronix
Research & Design, Inc. be responsible or liable for any damages or losses including direct, indirect,
special, incidental, or consequential damages or losses arising from either the use of any information
contained within this manual or the use of any products or services referenced in this manual.
Xytronix Research & Design, Inc. reserves the right to change any product’s features, specifications,
documentation, warranties, fee schedules, and conditions at any time and without notice.
Page 4 Xytronix Research & esign, Inc.

X-320M™ User's Manual Warranty
Warranty
This Xytronix Research & Design, Inc. product has a warranty against defects in material and
workmanship for a period of one year from the date of shipment. During the warranty period, Xytronix
Research & Design, Inc. will, at its option, either repair or replace products that prove to be defective.
This warranty is extended to the original purchaser of the equipment only.
For warranty service or repair, the product must be properly packaged and returned to Xytronix
Research & Design, Inc. The purchaser shall prepay all charges for shipping to Xytronix Research &
Design, Inc., and Xytronix Research & Design, Inc. will pay the shipping charges to return the product to
the purchaser as long as the product is shipped within the United States. If the product is shipped
outside of the United States, the purchaser shall pay all shipping charges, duties, and taxes.
Limitation
The foregoing warranty shall not apply to defects or damage resulting from improper use or misuse,
unauthorized repair, tampering, modification, improper connection, or operation outside the
electrical/environmental specifications for the product. Further, the warranty does not cover Acts of God,
such as fire, flood, hurricanes, and tornadoes. This warranty does not cover damage to property,
equipment, direct, indirect, consequential, or incidental damage (including damage for loss of business
profit, business interruption, loss of data, and the like) arising out of the use or misuse of this product.
U DER O CIRCUMSTA CES WILL THE LIABILITY OF XYTRO IX RESEARCH & DESIG , I C. TO
THE PURCHASER OR A Y OTHER PARTY EXCEED THE ORIGI AL PURCHASE PRICE OF THE
PRODUCT, REGARDLESS OF THE FORM OF THE CLAIM. o other warranty is expressed or implied.
Xytronix Research & Design, Inc. specifically disclaims the implied warranties or merchantability and
fitness for a particular purpose. Some jurisdictions may not allow the exclusion of limitation of liability for
consequential or incidental damage.
Xytronix Research & esign, Inc. Page 5

FCC Statement X-320M™ User's Manual
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
- This device may not cause harmful interference.
- This device must accept any interference received, including interference that may cause undesired
operation.
Warning
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause interference to radio communications. There is no
guarantee, however, that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into a relay on a circuit different from where the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Notice
Changes or modification not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Page 6 Xytronix Research & esign, Inc.

X-320M™ User's Manual Installation Guidelines (Read Before Installing)
Installation Guidelines Read Before Installing)
- This unit must be installed by qualified personnel.
- This unit must not be installed directly outdoors.
- This unit must not be used for medical, life saving purposes, or for any purpose where its failure
could cause serious injury or the loss of life.
- This unit must not be used in any way where its function or failure could cause significant loss or
property damage.
Security Notes
X-320M™ does not employ a general purpose computer operating system and does not have features
such as telnet, FTP, SSH, nor uncontrolled open ports. This means it is not possible for someone to
‘break in’ to X-320M™ and access other devices on your local network. The simplicity of X-320M™
makes it an inherently secure device. evertheless, as with any device installed on a network,
appropriate security precautions should be observed.
If X-320M™ is installed on the Internet, it is recommended that passwords be enabled for the Control
Page. Passwords should be at least 8 characters in length and use a combination of upper and lower
case letters and numbers. For additional security, a firewall may be used to limit access to selected IP
addresses. Another option may be to set up a Virtual Private etwork (VP ) between the network where
X-320M™ resides and the client machine (web browser, another, ControlByWeb™ product, etc.).
Final Installation Notes
This ControlByWeb™ product supports connection to 10 Mbps and 100 Mbps networks. Although 100
Mbps networks are faster, the amount of data transferred to and from this device is very minimal and
little, if any, performance increase will be gained by setting it to 100 Mbps. There are advantages,
however, to operate this device at 10 Mbps. At 10 Mbps, less power is required, the unit runs cooler, and
the lifetime of the product will be extended.
Any changes to the Ethernet settings will require a removing and re-applying power to X-320M™.
Xytronix Research & esign, Inc. Page 7

Introduction X-320M™ User's Manual
Section 1: Introduction
X-320M™ contains a unique combination of dedicated meteorological instrument functions as well as
general purpose control capability in a compact, cost-effective package. Like all ControlbyWeb products,
X-320MTM is designed to operate through a web browser; no driver required, no subscription, no remote
server, no script programming.
A variety of weather sensors can be leveraged by X-320MTM for casual or scientific purposes. A list of
compatible sensors is available from Xytronix Research and Design, Inc.
For those using X-320MTM with the Davis Instruments Integrated Sensor Suite (ISS), an adapter kit is
available which facilitates connections to the Davis sensors and enables the Davis temperature and
humidity sensors so they can be used by X-320TM.
X-320MTM comes pre-installed with a weather station interface. Once the desired instruments are
connected and basic network parameters are configured, the users can immediately see a user-friendly
weather station on any HTML 5 browser.
Page 8 Xytronix Research & esign, Inc.
Figure 1.1a - Example Meteorological Station Setup

X-320M™ User's Manual Introduction
With proper configuration of Ethernet gateways, X-320MTM can be viewed through an Internet connection
at remote locations.
In addition to standard weather information, users can leverage the sophistication of X-320MTM for some
of the following functions:
- Data logging.
- Email or SMS text alerts on exception conditions, such as
freezing temperature.
- Trigger alarms using remote relays on other
ControlByWeb products based on weather conditions,
such as high wind.
- Disable irrigation system with high wind or rain.
- Expand X-320M with remote analog input capability
allowing instruments to be located elsewhere on the
network.
- Password-protected interface.
- Automatic time synchronization through TP service.
- Using the Remote Services interface, data from multiple
X-320s and other ControlByWeb products can be
aggregated under a common server.
Xytronix Research & esign, Inc. Page 9
Figure 1.1b - Product Image

Introduction X-320M™ User's Manual
1.1 X-320M™ Features
Frequency Input 1)
130 kHz maximum input, 0-5 V.
Wind sensors such as the RM Young 5103 use a frequency signal that is proportional to the wind
speed.
Analog Input 4)
24-bit analog measurements from 0-5 VDC.
Common analog sensors include wind vane, pyranometer, barometric pressure, humidity, and
temperature.
Also configurable as “digital” inputs with programmable switching thresholds for use with such things
as lightning detectors.
Digital I/O 2)
Programmable as outputs or inputs with selectable pull-up and pull-down resistors on inputs.
Pulse counter and pulse rate, 250 Hz max.
Inputs are compatible with switch-type wind speed sensors, and tipping bucket rain sensors.
Outputs can be used for irrigation and pump control.
Remote Relays 2)
Control relays on other ControlByWeb products based on input conditions. Useful for remote control
of alarms, irrigation systems, or equipment protection applications, such as cutting power during
lightning activity or turning on heating equipment in freezing conditions.
Remote Analog 4)
Expand sensor capability with up to 4 analog inputs from another device such as an X-320™ or
Analog Module.
Temperature or Humidity Digital Sensor Inputs 6)
Monitor any combination of temperature or humidity sensors up to 600 ft away. Wall mount and
sealed sensor probes are available for use with indoor and soil temperature applications.
Real-time Clock
Manual or TP capability.
Logging
Configurable logging for attached meteorological sensors.
System logging of device operating parameters and events, such as power reset and TP requests.
Email Notification
Send email alerts based on any sensor conditions, such as high wind, low temperature, or lightning.
Send text messages to cell phone through your wireless carriers email bridge.
Web Server and Protocols
All configurable through the built-in, password protected web server. Additional interface options
include XML and S MP. Static or DHCP IP address configuration.
Page 10 Xytronix Research & esign, Inc.

X-320M™ User's Manual Introduction
1.2 X-320M™ Models Available
X-320M™ is currently available in one model.
X-320M-I Web-enabled Meteorological Station Controller
1.2.1 Optional Accessories
Accessory Description Part Number
Temperature Sensor Digital temperature sensor with 12 inch wire leads.
ote: Leads may be extended.
X-DTS-U
Temperature Sensor
(Wall Mount)
Digital temperature sensor housed in vented plastic
enclosure.
X-DTS-WM
Temperature/Humidity
Sensor (Wall Mount)
Digital temperature and humidity sensor housed in
vented plastic enclosure.
X-DTHS-WM
Davis Adapter Kit Used with the Davis Instruments ISS to connect the
Davis sensors to X-320MTM.
X-MDA-1
Note: For a list of compatible sensors, please contact customer support.
Xytronix Research & esign, Inc. Page 11

Introduction X-320M™ User's Manual
1.3 Connectors & Indicators
I/O Connector
X-320M™ has a 14-position removable terminal connector. Which is used to provide power to the
module and connect Digital I/O, Analog Inputs, Frequency Input, and Temperature/Humidity Sensor
Inputs.
Network Connector
The Ethernet connector is a standard 8-position modular receptacle.
Module Power Indicator
The green Power LED indicator is illuminated whenever the module is powered.
I/O Indicators
Two amber LEDs illuminate when the corresponding Input or Output is active.
Page 12 Xytronix Research & esign, Inc.
Figure 1.4a - Connections & Indicators

X-320M™ User's Manual Introduction
Ethernet Indicators
The LI K LED is illuminated green when the module is properly connected to an Ethernet network
and is ready to communicate. etwork communications will only occur if this LED is illuminated. The
ACT LED flashes amber when activity is detected on the network.
1.4 Accessing X-320M™
Standard Access Using a Web Browser
X-320M™ has a built-in web server that provides simple web pages that can be accessed directly using
a standard web browser. This allows users to access the unit with O SPECIAL SOFTWARE installed
on their computer. This is ideal for applications that require a quick, simple solution that does not need to
be accessible to more than a few people. This configuration is simple to setup, simple to use, and can
be accessed from any computer.
Note: Network routers may need to be configured to allow access from computers outside of the local
network (see Appendix C: Accessing X- 20MTM Over The Internet .
Xytronix Research & esign, Inc. Page 13

Installation and Setup X-320M™ User's Manual
Section 2: Installation and Setup
Installation consists of mounting X-320M™, connecting it to an Ethernet network, providing power,
configuring via a web browser, and wiring the Digital I/O's, Analog Inputs, Frequency Inputs, and
Temperature and/or Humidity Sensors.
2.1 Mounting
X-320M™ can be wall mounted or mounted to a standard (35mm by 7.55mm) DI -Rail. It should be
mounted in a clean, dry location where it is protected from the elements. Ventilation is recommend for
installations where ambient air temperatures are expected to be high.
See Appendix H: Mechanical Information for additional mechanical details.
2.1.1 Wall Mounting
Mount X-320M™ to a wall using two #8 screws. Attach the screws to the wall vertically spaced exactly
2.5 inches apart. The head of the screw should be about 1/10 inch away from the wall.
2.1.2 DIN-Rail Mounting
Attach X-320M™ to the DI -Rail by hooking the top hook on the back of the enclosure to the DI -Rail
and then snap the bottom hook into place. To remove X-320M™ from the DI -Rail, use a flat-head
screwdriver. Insert a flathead screwdriver into the notch in the release tab and pry against the enclosure
to release the bottom hook.
Page 14 Xytronix Research & esign, Inc.

X-320M™ User's Manual Installation and Setup
2.2 Connection
CAUTION: MAKE SURE POWER IS SHUT OFF BEFORE WIRING!
CAUTION: THIS UNIT SHOULD BE INSTALLED BY A QUALIFIED TECHNICIAN.
MIS-WIRING OR MIS-CONFIGURATION COULD CAUSE PERMANENT DAMAGE TO X-320M™,
THE EQUIPMENT TO WHICH IT IS CONNECTED, OR BOTH.
A removable terminal connector is provided for simple wiring. The correct wiring procedure is as follows:
1. Make sure power is turned off.
2. Remove the terminal connector from X-320M™ and make wiring connections to the terminals.
3. Reconnect the terminal connector.
4. Apply power.
It is recommended that the load (device to be controlled) not be connected to X-320M™ until after X-
320M™ has been configured and tested. By doing this, wiring and configuration mistakes will not cause
the load device to turn on unexpectedly.
IMPORTANT: MAKE SURE WIRES ARE PROPERLY ATTACHED TO THE TERMINALS AND THAT
THE TERMINALS ARE TIGHT!
Xytronix Research & esign, Inc. Page 15

Installation and Setup X-320M™ User's Manual
14-pin Connector Pinout
Pin Description
Vin+
Power Supply VDC+.
9-28 VDC for model X-320M-I.
DO OT EXCEED MAXIMUM POWER SUPPLY VOLTAGE.
Vin- VDC- (Ground) power supply input.
Ain1 Analog Input 1 used with 0-5 V analog sensors, such as
temp, solar, humidity, and barometric pressure.
Ain2 Analog Input 2.
Ain3 Analog Input 3.
Ain4 Analog Input 4.
5V Rf +5 VDC reference output for analog sensors.
AGnd Analog Ground for Analog inputs.
Gnd Digital Ground for 5V Out return used with Outputs, Inputs,
Frequency inputs, and digital Temperature/ Humidity sensors.
5V Out +5 VDC Output. Voltage output for digital inputs and for the
digital temperature and humidity sensors.
D I/O 1 Digital I/O 1 can be configured as logic input, output, rate, or
counter. Programmable pull-up resistor for input mode.
D I/O 2 Digital I/O 2, same as above.
FreqIn AC frequency counter.
Data Temperature/Humidity Data Input for “1-wire” digital
temperature and humidity sensors.
2.2.1 Power Supply Connection
X-320M™ requires power for its internal logic circuits. Connect a 9-28 VDC power supply to the Vin+
and Vin- terminals. ote that a regulated power supply is recommended, such as a wall-mount AC-DC
adapter, or POE Injector and Splitter. Verify that the adapter is rated for the operating current of X-
320M™ (See Appendix G: Specifications for current requirements.)
Note: Vin- should be tied to Earth ground.
Multiple X-320M™ units may be connected to a single power supply by connecting the power supply
input terminals in parallel. The power supply must have a high enough current rating to power all units
connected. (See Appendix G: Specifications for current requirements.)
Page 16 Xytronix Research & esign, Inc.

X-320M™ User's Manual Installation and Setup
2.2.2 Digital Input/Output Connections
The Digital I/O's can be individually programmed to function as either inputs or outputs. When
configured as inputs, pull-up or pull-down resistors can be programmed. For unconnected inputs, the
pull resistors will be read as O when pulled up, or OFF when pulled down.
Input Connection
The inputs can be configured to count the tips of the bucket in a rain collector, the rate of spin on a wind
speed sensor, or detect switch closures on other connected devices, such as a lightning detector.
Pull-Up/Pull-Down Resistors
Weak pull resistors are used to control the state of the inputs when they are unconnected, such as when
connected to an open switch. Devices that use a switch contact, such as rain buckets, require the input
to be configured with a pull-up resistor. One side of the contact is connected to I/O 1 or I/O 2, and the
other side is connected to Gnd. When the bucket in a rain collector tips, the contact is momentarily
closed, causing the input to pulse OFF. This pulse increments the rain bucket counter.
Pull-down resistors are similar, but this configuration is typically not applicable for common weather
sensors.
Xytronix Research & esign, Inc. Page 17
Figure 2.2a - igital Input Connections

Installation and Setup X-320M™ User's Manual
Output Connection
The digital outputs can be used for controlling external devices. The digital outputs have limited drive
capability, but can be used with solid state relays to control larger loads.
Relays on other ControlByWeb devices can be controlled with X-320M through the Remote Relay
feature. Up to two remote relays can be configured, each of which may be on a separate device.
Applications for the digital outputs and remote relays include:
Activate external audible alarm or lights in cases of high wind, temperature, lightning detection, or other
sensor levels.
Deactivate pumps or irrigation system during high wind, rain, or freezing temperatures.
Disconnect sensitive equipment when lightning is detected.
Page 18 Xytronix Research & esign, Inc.
Figure 2.2b - igital Output Connections

X-320M™ User's Manual Installation and Setup
2.2.3 Analog Input
Voltage and current output sensors can be connected to X-320M analog inputs. Typical weather station
analog sensors can measure temperature, humidity, solar radiation, barometric pressure, and soil
moisture.
Additionally, the analog inputs can function in a digital mode, activating alarms based on voltage
thresholds. Many stations may use both digital inputs for wind or rain sensors. An analog input may be
available for such things as water (flood) or lightning detection.
*Switch state signals can be used with analog inputs to trigger actions using voltage level alarms.
Xytronix Research & esign, Inc. Page 19
Figure 2.2c - Analog Input Connections

Installation and Setup X-320M™ User's Manual
Wiring Considerations
The analog inputs on X-320M™ are very sensitive (10 uV) and can be affected by low level noise. The
Vin- on X-320M™ should be connected to earth ground. Additionally, all cable shields should be
connected to earth ground. Users should observe single-point ground strategies, typical of
instrumentation systems.
Proper grounding may be accomplished by connecting the grounding cables to either the AC mains
ground or to the station ground.
High Output Sensors, > 5 VDC
In the case of a sensor whose output levels are higher than 5 volts, a simple voltage divider can be used
to scale down the output. The following diagram shows a simple voltage divider circuit. In the example,
Vin can range from 0 to 10 volts and resistor values for R1 and R2 will be chosen so that Vout will have
a range that falls within the 0 to 5 volt range of the Analog Input.
Generally, you can choose a 1 kΩ resistor for R2 and then calculate the value of R1 using the following
formula.
Vout=Vin∗( R2
(R1+R2))
To determine the proper resistor value to use in the example above, use the maximum output of the
sensor (10 VDC) as Vin in the equation, the maximum input value of the the Analog Inputs (5 VDC) as
Vout, and R2 = 1 kΩ. Solving for R1 gives 1 kΩ.
R1 = 1 kΩ
R2 = 1 kΩ
As another example, if the maximum output voltage of the sensors is 15 VDC, choose R2 = 1 kΩ and by
solving the equation, R1 = 2 kΩ.
Page 20 Xytronix Research & esign, Inc.
Figure 2.2d - Voltage ivider Circuit
