Convergent Design Odyssey7 User manual

User Manual Odyssey7
Updated 21 Jul 2014 | Firmware Release v2.10.141
2014

3
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
TABLE OF CONTENTS
READ THIS FIRST!4
PRODUCT FEATURES5
Monitoring5
Recording5
Other Features6
Mounting6
PRODUCT SPECIFICATIONS7
RECORDING CAPABILITIES8
Apple ProRes 422 HQ8
Record Time Capacities8
PACKAGE CONTENTS9
CONVERGENT DESIGN SSD MEDIA10
2.5” Premium SSD Media10
Odyssey Utility Drive10
ODYSSEY7 ANATOMY11
Odyssey7 - Bottom11
Odyssey7 - Top11
Odyssey7 - Left Side12
Odyssey7 - Right Side12
Mounting12
Odyssey7 Activation13
Initializing13
Setting Up & Using the Odyssey714
The Odyssey7 Menu14
Powering Down14
WORKING W/ MEDIA15
Loss of Power During a Record15
Downloading Media15
File Management Software16
File Storage16
POST PRODUCTION17
Apple ProRes 422 HQ17
Working with Files Recorded by the Odyssey717
ODYSSEY7 MENUS18
System Status Buttons18
Upper & LOWER Tool BarS - Play Mode21
LOWER Tool Bar - Play Mode22
Lower Tool Bar23
Odyssey27
SETUP28
RECORD29
CONVERGENT DESIGN
ACCESSORIES32
CONVERGENT DESIGN
ACCESSORIES33
CONVERGENT DESIGN
ACCESSORIES34
THIRD-PARTY ACCESSORIES35
RELEASE NOTES ODYSSEY7
FIRMWARE 2.10.14136
Odyssey7 Features36
RELEASE NOTES ODYSSEY7
FIRMWARE 2.10.14137
FIXES & IMPROVEMENTS38
KNOWN ISSUES38
RELEASE NOTES ODYSSEY7
FIRMWARE 2.10.14138
OTHER NOTES39
RELEASE NOTES ODYSSEY7
FIRMWARE 2.10.14139
LIMITED WARRANTY40

4
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
Read This First!
Before you begin using the Odyssey7, we strongly suggest you review the
included Quick Start Guide, as well as:
1. Always record to the internal Media OF the camera; this is critical for proper Timecode and
ideal for dual media / backup.
2. DO NOT REMOVE THE FOUR SCREWS FROM REAR OF CASE. This may result in damage
to the OLED panel. Such damage is not covered by warranty.
3. Power and cabling: Make sure you have PROPER POWER (6.5-34vdc), plugged in to the
proper power port (left side of recorder), and that 3G-rated SDI cables are used.
4. Power source must be able to provide up to 24 watts at all times to the Odyssey7.
5. When powering the Odyssey7 from an ARRI Alexa camera, we recommend using the
24V r/s Fischer-3 output from the Alexa using the optional Convergent Design cable.
6. Familiarize yourself with the equipment and test prior to shooting.
7. Before using the SSDs it is IMPERATIVE TO FORMAT them in the Odyssey7. Formatting
SSD media is a Destructive process; any existing data will be lost during format.
8. Ensure that the camera’s viewfinder data is not being recorded; IF YOU SEE VIEWFINDER
DATA ON THE ODYSSEY7 monitor, then it will be recorded!
9. NEVER DELETE ANY FILES OFF OF AN SSD FROM A COMPUTER, except when going
through a firmware update procedure.
10. While we recommend that you always maintain the latest firmware on your Odyssey7,
we DO not recommend updating if you are in the Middle of a shoot (uNLEss instructed by
technical support).
11. When ooading media, ALWAYS MAKE A BACKUP COPY, ideally to a RAID1 drive.
12. be sure to allow the Odyssey7 to finish closing a record file before taking any further
action.
!

5
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Product Features
MONITORING
• Professional Monitor: 7.7” 1280x800 OLED panel featuring true blacks, and accurate color
with a full range color gamut for REC709 or DCI-P3 viewing.
• Image analysis tools: Waveform, Vectorscope (in future update), Histogram, False color
exposure view, Zebra, three-mode Focus assist, pixel Zoom (1:1 & 2:1), LUTs, and Frame
Guides.
• Flexible I/O: One dedicated 3G-SDI input, one dedicated 3G-SDI output, one HDMi input,
one HDMi output. Active cross-conversion means that both outputs are always active no
matter which input is used.
RECORDING
• High-capacity recording. A high-speed solid state Drive (SSD), available in 256 GB or 512
GB, allows for extended recording.
• Apple ProRes 422(HQ) up to 1080/30p, 1080/60i and 720/60p. Additional frame rates and
popular compressed codecs will be available at a later date via free firmware update.
For the latest firmware, product manuals and other information visit Convergent-Design.com
i

6
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
OTHER FEATURES
• Versatile Power. Wide voltage range (6.5-34v) and low draw (8-15w, depending on mode)
for great flexibility of battery and other power options.
• Light Weight. A magnesium case and ecient board design means only 1.25lbs for the
basic unit.
• Small size. even with a 7.7” screen, the Odyssey7Q is approximately 8”x6”x1”, making it
easy to use on cameras, mounted in tight spots or held in one’s hand.
MOUNTING
The Odyssey7 features three ¼”x20 threaded sockets, one on the lower rear of the case and
one each on the left and right sides of the case. Do not exceed 11mm of depth when inserting
a bolt, otherwise damage may occur to the Odyssey7. Additionally, there are four M3 threaded
socketson the rear of the case and two M4 sockets on each of the sides of the case.
Product Features (Continued)

7
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Product Specifications
Display 7.7" OLED, 1280x800, RGB 8-bit panel, ~ 16 million colors, wide gamut, 3400:1
contrast, 176° Viewing, true blacks
SDI Video I/O HD/3G Support: Single Link, 1-Input, 1-Output, Full-size BNCs, Up to
1080p60 422 10-bit
HDMI Video I/O HDMI I/O Version 1.4a support, Up to 1080p30 422 8-bit
LUT Support ARRI, Canon, Sony LUTs (No Custom LUT Support)
Focus Assist Video + Edges, Edges Only, Enhanced Edges, user choice of color:
Red, Green, or Blue + Pulsing
Zebras Currently one programmable level, future two programmable levels
False Color False color with 5 programmable levels
Waveform Monitor Luma only, RGB Parade, Red only, Blue only, Green only
Histogram Luma only, RGB Parade, Red only, Blue only, Green only
Vectorscope (future) Color vectorscope with 2X zoom
1:1 Pixel Mode Image Zoom, Vertical Flip, Aspect Ratio Guides
Digital Audio I/O 2-Channel Embedded Audio (48KHz, 24-bit)
Analog Audio I/O 3.5mm stereo unbalanced input up to -10dB (future), 3.5mm stereo
headphone output
Remote and
Timecode
RS-232 I/O (future), programmable GPIO (future). Timecode: LTC I/O
(BNC) or embedded SDI / HDMI (HDMI future)
User Interface Capacitive Touchscreen, Two user-programmable context-sensitive
mechanical keys
DC Power Input 6.5 to 34 VDC with built-in reverse polarity protection; locking Neutrik
connector, built-in power switch
Power Draw 8 Watts (monitor only), 9-12 Watts (simultaneous monitor/record
mode)
Weight and Size 560 grams / 1.3 lbs., 7.9" x 6.1" x 1.0" (200 x 155 x 25 mm), -10 to +40°C
(Operating), -20 to +70°C (Storage)
Record Triggers Touchscreen, SDI record trigger (ARRI, Canon, Panasonic, Red, Sony),
Optional Remote Control Cable (future)
Recording SSD
Media
Convergent Design SSDs with power-loss protection, in 256 and 512
GB sizes, 420MB/sec write, 500MB/sec read speed, compatible with
USB 3.0 and Thunderbolt adapters. SSDs and adpaters sold separately.
Recording Formats Compressed formats: Apple ProRes 422(HQ) up to 1080/30p (60p in
future release), 1080/60i, 720/60p
All specifications subject to change without notice.

8
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
The Odyssey7 is a single channel HD video recorder that records onto Convergent Design
Premium SSD Media from HD-SDI or HDMI inputs.
HD VIDEO The Odyssey7 records HD video as uncompressed 12-bit or 10-bit.DPX stacks or
10-bit Apple ProRes 422(HQ)
All .DPX files are recorded 4:4:4. 4:2:2 video signals are up-converted to 4:4:4.
3G-SDI: accepted 1080p/psf frame rates: 23.98, 24, 25, 29.97, 30, 50, 59.97, 60
(adding More) NOTE: 50, 59.97 & 60 are only available in DPX
HDMI: accepted 1080p/psf frame rates: 23.98, 24, 25, 29.97, 30, 50i, 60i, 720p50, 60
Compressed Apple ProRes 422(HQ) 1080p/psf 23, 24, 25, 29; 1080i 50, 60; 720p 50,
60
2K/1080p 12-bit support 23.98, 24, 25, 29.97 & 10-bit in DPX
Future free firmware updates will include additional compressed video codecs
with expanded frame rate, resolution selections, interlaced support, and pull down
support.
NOTE: Convergent Design manufactures the Odyssey7Q that is designed for recording in 2K, 4K,
RAW, MultiStream and other formats. Please see our website or talk to your dealer for details.
Apple ProRes 422 HQ
The Odyssey 7 records in Apple ProRes HQ which is a 10 bit 4:2:2 220Mb compressed codec.
This will allow for high quality recording while avoiding high data rates of working with
uncompressed video.
RECORD TIME CAPACITIES
The Odyssey7 can record several video formats and frame rates. Record time varies based on
format and frame rate. The chart below indicates maximum record time in minutes based on the
use of one 512 GB SSD. For 256 GB, divide in half.
MAXIMUM RECORD TIME IN MINUTES TO A 512GB SSD
Recording Format 24fps 25fps 30fps 50fps 60fps
1080p Apple ProRes 422(HQ) (50fps & 60fps future firmware) 330 318 264 159 132
1080i Apple ProRes 422(HQ) 312 300 250
720p Apple ProRes 422(HQ) 290 264
Recording Capabilities

9
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Package Contents
Odyssey7 box contains one (1) Odyssey7 monitor/recorder and one (1) universal power supply.
MEDIA AND ACCESSORIES SOLD SEPARATELY!

10
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
Convergent Design SSD Media
2.5” PREMIUM SSD MEDIA
To enable recording on the Odyssey7, you must use specific SSD media: Only Convergent
Design premium SSDs will work in the Odyssey7. These SSDs, available in 256 GB and 512 GB,
must be purchased separately.
256GB SSD for Odyssey7 and 7Q CD-SSD-256GB
512GB SSD for Odyssey7 and 7Q CD-SSD-512GB
ODYSSEY UTILITY DRIVE
The Odyssey Utility Drive is designed as a lower cost alternative to the Odyssey Premium SSD
media for secondary tasks. The Odyssey Utility Drive can be used for Odyssey7 & 7Q firmware
updates, Odyssey7Q 3D-LUT files and other future functionality. The Odyssey Utility Drive
will not record video files. It is intended for Odyssey7 & 7Q owners who do not wish to tie up
an Odyssey SSD with utility features, or for Odyssey7 & 7Q owners who use their devices as
monitors and do not need to purchase the more expensive recording media.
Utility Drive for Odyssey7 and 7Q CD-SSD-UTILITY

11
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
ODYSSEY7 - BOTTOM
There are seven connector ports on the bottom side of the Odyssey7 (left to right)
PWR on Power input socket to Odyssey7 (see Getting started – power). Just in front of the pwr On port is a
button, which is a Force power On/O control. Hold button five seconds to force power o. This is only
to be used if standard power on or o procedures fail (see Getting started – initializing).
SDI in BNC connector for 3G-SDI input
LTC io BNC connector for linear Timecode input/output
HDMi in HDMi 1.4 input from HDMi video source.
HDMI Out HDMi 1.4 output to external monitor or other device
SDI Out BNC connector for 3G-SDI output
AUDIO in 3.5mm mini-phone stereo socket for analog audio in.
This input will be enabled in a free future firmware update.
AUDIO Out 3.5mm mini-phone stereo headphone socket.
ODYSSEY7 - TOP
There is a single SSD slot on the top of the Odyssey7.
Only Convergent Design 256 GB and 512 GB SSDs can be used to capture video on the
Odyssey7. The Odyssey Utility Drive can be used for firmware updates and other future
functions, but not to record video files.
To mount SSD, insert connector-end first with the label facing forward and the handle near
Odyssey7 Anatomy
Power
Button
SDI
IN
HDMI
IN
AUDIO
IN
SDI
OUT
AUDIO
OUT
LTC
I/O
DC In

12
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
flush with the back of the Odyssey7. Push gently but firmly until the handle flange is flush with
the top of the Odyssey7. It is a snug fit, but the SSD should insert smoothly.
ODYSSEY7 - LEFT SIDE
There are two Function buttons, F1 LOCK and F2 SHUT DOWN.
F1 LOCK Lockout control for the Odyssey7 touchscreen. Push to engage and screen lock will appear in the center
of the touchscreen’s upper tool bar. Push F1 again to disengage.
F2 SHUT
DOWN
Preferred method to power down the Odyssey7. Properly closes files on the SSDs and performs other
maintenance functions (see Getting started -- powering Down). Push to activate prompt asking safely
power Down unit? In a future free firmware update it will be possible to program these buttons for
additional functions.
ODYSSEY7 - RIGHT SIDE
There are three connector ports, (top to bottom) USB, HDMI OUT and RMT.
USB An access point for servicing by Convergent Design.
HDMi out Output to an HDMi compatible device
RMT A remote control connection to the Odyssey7.
In a future free firmware update the rMt port will allow control interface
with functions of the Odyssey7.
Kensington A rectangular hole above the RMT port is for accepting a Kensington
Security Lock.
Lock Port A rectangular hole above the rMt port is for accepting a Kensington
security lock.
MOUNTING
TThe Odyssey7 features three ¼”x20 threaded sockets, one on the lower rear of the case and one
each on the left and right sides of the case. Do not exceed 11mm of depth when inserting a bolt,
otherwise damage may occur to the Odyssey7. Additionally, there are four M3 threaded sockets
on the rear of the case and two M4 sockets on each of the sides of the case.
Odyssey7 Anatomy (Continued)

13
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Getting Started
ODYSSEY7 ACTIVATION
Convergent Design requires each Odyssey7 to be registered via our website. This is so that we
can provide notices of free firmware updates and issue alerts for critical issues.
Upon first initializing of the Odyssey7, a prompt will appear asking if the device is to be
activated at this time or if it is to be used in Demo mode. In Demo mode the Odyssey7 is
fully functional, however a blue or pink bar “watermark” will appear in any recorded video.
The activation prompt will appear upon every initialization of the Odyssey7 until the device is
activated. When activate is selected, follow the prompts to activate the Odyssey7.
In order to activate the Odyssey7 after initial purchase, go to http://www.Convergent-design.
com to register the unit.
Also, make sure your Odyssey7 has the latest firmware, posted here:
https://www.convergent-design.com/odyssey7-firmware
See Firmware Updates under the Appendix below for more information on how to put new
firmware on your Odyssey7..
INITIALIZING
Plug in power to the Odyssey7. It should take about 5-10 seconds to initialize, depending on the
mode it is set to. If the Odyssey7 does not self-initialize, push the pwr on button next to the
power socket on the lower left corner of the Odyssey7.
As part of the initializing process, sMpte color bars may appear briefly on the screen. If there
is a signal input that matches the record format the Odyssey7 is
set to, then the image should appear on the screen. If there is an
SSD mounted in the Odyssey7 then a Detecting SSD message
will appear on the lower left of the screen. If the SSD needs to be
re-initialized or formatted, a second message may appear.
If the trigger button in the upper tool bar appears as a red Box
surrounding a white circle, then the Odyssey7 is ready to record.

14
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
SETTING UP & USING THE ODYSSEY7
The touch screen of the Odyssey7 features all of the device’s controls in a straightforward, easy
to navigate structure. Each box is a “virtual button.” Tap it briefly to activate/deactivate it, or
hold it for a few seconds to open up the menu defining its function. The controls at the top of
the display (upper tool bar) are the recording, playback and formatting administration. The
controls at the bottom of the display (lower tool bar) are the image analysis adjustments.
Upper tool bar – Record Mode
THE ODYSSEY7 MENU
Starting on the left, tapping the [ ☼ ] button brings up the initial setup menus for the Odyssey7.
Don’t be intimidated by the number of selections in the [
☼ ] section. This is by far the most in-
depth section of the Odyssey7 touchscreen menus:
(Please see the Odyssey7 Menus section of this manual for a full explanation of all menu
functions.)
POWERING DOWN
While it may seem an odd time to NOTE this, it is important to know that there is a preferred
method to shutting down the Odyssey7. On the left side of the case, the F2 shut down button
should be pressed. This prompts a confirmation to “safely power Down unit?” powering down
in this fashion properly closes the files and directory system on the SSD, preventing corruption.
If the Odyssey7 should ever suer a failure and the F2 shut down sequence does not function
properly, the unit can be Force power o by holding the pwr on button by the power socket on
the lower left corner of the Odyssey7, or simply by pulling the power connector out of the pow-
er socket. If the Odyssey7 is ever powered down in this fashion, it is important to run a recovery
on the SSD in the Odyssey7 menu at Menu » Odyssey » SSD’s » Recover SSD1.
Getting Started (Continued)
ODYSSEY SETUP RECORD INPUTS OUTPUTS

15
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Working w/ Media
LOSS OF POWER DURING A RECORD
You should never power o the camera while recording, many camera’s including the
Alexa, disable the user from doing so while recording. Included in the Odyssey 7’s recovery
mechanism, is in case of power loss, you will lose the last couple frames of the record, but not
the last take. You will receive several error messages due to the loss of source. If the unit fails
to close the last clip and return to normal operation once the source has returned, you will
need to remove the power from the unit, then re-power the unit.
After any failure of this type, the Odyssey will automatically mark the SSD as full once power
is restored to the unit. You will need to ooad the footage before you will be able to continue
recording, in order to help ensure proper recovery of the previous recordings.
DOWNLOADING MEDIA
Always make sure to properly safe eject to dismount the SSD before removing from Odyssey7.
While the Odyssey7 SSDs are exclusive Convergent Design products, they utilize a standard
2.5” SATA interface. No expensive proprietary download stations are required. Consumer card
adapters such as Seagate GoFlex adapters are available with thunderbolt or USB 3.0 interface.
Thunderbolt is fastest and USB 3.0 is most common and self-powering. Firewire 800 is not
recommended as it will take a very long time to download files. Convergent Design sells an
adapter to USB 3.0 (CD-SSD-USB3).
Convergent Design oers a USB 3.0 SSD Adapter (CD-SSD-USB3) through authorized dealers and
distributors. This device allows you to access files on the Convergent Design SSDs on any computer
with a USB 3.0 or USB 2.0 port. (Please note that USB 2.0 ports have much slower data transfer
rates.)

16
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
FILE MANAGEMENT SOFTWARE
Convergent Design has a free file utility program, CD ProRes Transfer Tool, available for
download for both Mac & PC on our website.
https://convergent-design.com/support/firmware-downloads/software-utilities.html
CD Apple ProRes TRANSFER 1.2
Copies Apple ProRes files recorded on the Odyssey7 and merges files within each clip. Also
optimizes Apple ProRes clips for playback and editing. Note: While not required, ooading
files from SSDs using this tool is a more ecient workflow than other methods.
FILE STORAGE
The Odyssey SSDs support read rates of 500 Mbytes/sec. Keep in mind you will be limited by
the slowest median in the transfer process. For example: eSATA 3GBps interface cards have
a max performance of ~270Mbps, and eSATA 1.5GBps have a max performance of ~130Mbps.
typical Hard Drives (non-RAID) generally perform anywhere in the range of 80-130MbpsFor
maximum performance, make sure you are using eSATA 6 GBps, USB 3.0 or thunderbolt to a
RAID configuration.
Video Format Video Data Rate Suggested RAID
Configuration
Real Time Playback/Edit
ARRI/2K/1080p24 4:4:4 10-Bit DPX 186.6 MB/Sec. 300
1080p25 4:4:4 10-Bit 194.4 MB/Sec. 300
1080p30 4:4:4 10-Bit 233.3 MB/Sec. 400
1080p50 10-Bit 400 MB/Sec. 600
1080p60 10-Bit 500 MB/Sec. 600
HD Compressed Apple ProRes 422 30MB/Sec. 100
2K RAW 23.98-120 500 MB/Sec. 600
4K RAW 23.98-29.97 500 MB/Sec. 600
4K RAW 50/60p 2K 200/240p 850 MB/Sec. 1000
Working w/ Media (Continued)

17
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Post Production
Apple ProRes 422 HQ
The Odyssey 7 records in Apple ProRes HQ which is a 10 bit 4:2:2 220Mb compressed codec.
This will allow for high quality recording while avoiding high data rates of working with
uncompressed video.
WORKING WITH FILES RECORDED BY THE ODYSSEY7
There are numerous post systems and NLEs that can read natively the various file formats
recorded by the Odyssey7. Some NLEs may require plug-ins in order to read certain file
formats. Blackmagic Design Resolve software is available for free and can read all formats
recorded by the Odyssey7.
FILE STRUCTURE

18
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
SYSTEM STATUS BUTTONS
Displays critical specs of Odyssey7. Input voltage, current
wattage draw of Odyssey7 (varies with mode), current
temperature of main processor. Tapping button brings up
more detailed information including the about menu of the
Odyssey7.
SYSTEM STATUS
VOLTS: 12.1V (6.5~34V)
POWER: 10.0W
TEMP: +31° (<60°C)
2014 JUL 21 08:42:58
ODYSSEY7 ABOUT
FIRMWARE: 2.10.136
SERIAL: 20-00000
WARRANTY: VOID
KEYS ACTIVATED:
BASIC FS700RAW CANONRAW
POWERED: 41 DAYS 19 HRS
RECORD: 9 DAYS 4 HRS
The Odyssey7 has a wide internal operating temperature
window, up to 65° Celsius (149° Fahrenheit). The Odyssey7
uses its magnesium case to passively shed excess heat. There
are no vents or fans. Even under most harsh conditions, the
Odyssey7 should not suer any operational issues due to heat.
However, if the internal temperature of the Odyssey7 rises high
enough there are a series of warnings and safeguards in place
to protect the device and the recorded files.
TEMPERATURE WARNINGS AND SAFEGUARDS
System Status Text & Warning Operational Protection
59° C Yellow text No change to operation
61° C Red text & flashing warning New recordings prevented
65° C Red text & flashing warning Current recording stopped
The Odyssey7 has a wide range of acceptable voltage for incoming power, from 6.5 volts to
34 volts. The total wattage draw from the Odyssey7 varies depending on the operational
mode it is set to, but is always within a very modest range from less than 8 watts to no more
than 15 watts. This allows a variety of battery options to be used with the device. While there
are file recovery parameters in place, it is never a good idea to lose power while in the midst
of recording. If the incoming voltage to the Odyssey7 drops low enough there are a series of
warnings and safeguards in place to protect the device and the recorded files.
LOW POWER WARNINGS & SAFEGUARDS
Voltage Level System Status Text & Warning Operational Protection
6.7v Yellow text No change to operation
6.5v Red text & flashing warning New recordings prevented
6.0v Red text & flashing warning Current recording stopped
Odyssey7 Menus
12.2V
8.1W
+40°C

19
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 6)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
INPUT STATUS BUTTTON
1080PSF29 422
SONY
Displays current video input signal type. Tapping button
brings up detailed information on Input and Output signals,
record mode and frame rates.
RECORD STATUS BUTTON
PRORES
HQ Displays current recording format. Tapping button brings up
detailed information on recording type and frame rates.
If a rented Record Option is in use, the remaining time is
noted here.
TRIGGER BUTTON
Displays status of recording mode. When button is Red with a
white circle it is ready to record. When Gray there is no signal
available to record. While recording, the button is Blue with
a white square and the background of the entire top menu
is Red. If REC Button is selected as the trigger then tapping
button triggers record start/stop ([*] [RECORD] [TRIGGER]
[REC BUTTON]). In PLAY mode the button becomes the
Playback Trigger.
SSD1 STATUS BUTTON
02:12
Displays record time available given current settings (HH:MM).
Tapping button brings up detailed information on SSD1 status.
SSD SAFE EJECT BUTTON
Prompts a confirmation to Safely Eject SSD? This is the proper
method for dismounting and ejecting SSDs so that the files
and directories can be closed properly.
SSD2 STATUS BUTTON
02:12
Displays record time available given current settings (HH:MM).
Tapping button brings up detailed information on SSD1 status.
Odyssey7 Menus (Continued)

20
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
REC/PLAY BUTTON
Displays current status as to whether Odyssey7 is in record
or playback mode. Tapping button toggles between modes.
NOTE: playback Mode changes the upper and lower tool bars.
See playback Mode, below.
CLIP METADATA BUTTON
CLIP0000
005_000
.MOV A
Displays detailed information on clip metadata. Clip name,
Reel name/number, Scene name/number, Take #, Day #,
Camera designation and Project name are indicated. Tapping
on button opens menu to adjust clip metadata.
LAST TAKE BUTTON
LAST TAKE
00:00:05
650 FRAMES
Displays timecode start and elapsed time of last recorded take.
Tapping button brings up detailed information of the last take
recorded.
AUDIO METERS
Displays left and right audio levels. Press and hold Level Meter
to access Audio Meters menu.
Odyssey7 Menus (Continued)
