Convergent Design Odyssey7Q ProRes 422 (HQ) User manual

Setup Guide Odyssey7Q + FS700
Updated 18-Aug-2014 | Firmware Release v2.11.110
4K RAW up to 60p
4K RAW burst up to 120p
2K RAW up to 240p
4K RAW to Apple ProRes 422(HQ) up to 60p
1080p video to Apple ProRes 422(HQ) up to 60p

2
© 2014 Convergent Design, Inc. - All Rights Reserved.
RECORDING TIMES
Maximum record time in minutes, recording to two 512G SSDs (1TB)
RECORD TIME
23.98fps 25fps 29.97fps 50fps 60fps 100fps 120fps 200fps 240fps
REC MODE
4K RAW 62 60 50 30* 25* 155 Takes 155 Takes
2K RAW 200 192 160 96 80 48 40 24* 20*
4K2HD 775 744 620 372 310
HD DPX 87 84 70 42 35*
HD ProRes 775 744 620 372 310
* Two SSDs are required to capture
FORMAT DETAILS
4K RAW 4096x2160, 12-bit linear data, recorded as Uncompressed .DNG
2K RAW 2048x1080, 12-bit linear data, recorded as Uncompressed .DNG
4K to HD 1920x1080, 10-bit log video, originated from 4K RAW camera signal, transformed and recorded as Apple
ProRes 422 (HQ) compressed HD video
HD DPX* 1920x1080, 12-bit log video, originated from HD 8-bit camera signal, recorded as Uncompressed .DPX
HD ProRes 422 1920x1080, 10-bit log video, originated from HD 8-bit camera signal, recorded as Apple ProRes 422
(HQ) compressed HD video
* HD DPX files at 60p are “packed” on SSDs due to high data rate. Use free CD Data Unpacker
utility software to unpack files after transfer.
TYPICAL DOWNLOAD TIME IN MINUTES
Media USB3.0 Thunderbolt
256G SSD 20 10
512G SSD 40 20
Actual transfer rates are dependent on computer system and capture media.
USB 3.0 or Thunderbolt connections are recommended by Convergent Design for ecient data
rates.
Odyssey7Q + FS700 Recording Capabilities
For the latest firmware, product manuals and other information visit Convergent-Design.com
i

3
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 7)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Odyssey7Q Support for FS700 RAW Recording
ODYSSEY7Q SUPPORT FOR FS700
FS700(R)
Mode
Resolution Bit-
Depth
Frame Rates Support Two SSD's
Required
RAW*
4K RAW 4K RAW 4096 x 2160 12-Bit 23.98p, 24p, 25p,
29.97p, 50p,
59.94p
CinemaDNG 50p / 59.94p
4K HFR 4K HFR 4096 x 2160 12-Bit 100p, 120p 3-4 sec Burst
(CinemaDNG)
YES
2K RAW 2K RAW 2048 x 1080 12-Bit 23.98p, 24p, 25p,
29.97p, 50p,
59.94p, 100p, 120p
CinemaDNG NO
2K HFR 2K HFR 2048 x 1080 12-Bit 200p, 240p 3.7 / 4.4 second
burst (CinemaDNG)
200p / 240p
* FS700 RECORDING OPTION REQUIRED (Activation key can be purchased through website)

4
© 2014 Convergent Design, Inc. - All Rights Reserved.
Configure FS700 4K/2K RAW Recording
MENU » REC/OUT SET » REC SET » RAW SET
PICTURE PROFILE » PP7 » SETTING » GAMMA » S-Log2
PP7 is the default profile for S-Log2, Note that only S-Log2 is supported when
recording RAW.
Once the camera is set to the desired frame rate, then connect to the Odyssey7Q
Select any of the following frames rates that you wish to record on Odyssey7Q:
NOTE: In 4K Super Slow the camera only outputs a maximum of 4K 60p, thus this
mode will use internal buering, and then will need to playback the footage to an
Odyssey7Q. In 4 Super Slow, the Odyssey7Q Trigger must be set to Camera.
MENU » RECORD » TRIGGER » CAMERA
NOTE: For 2K up to 240fps sustained, or 4K up to 60p sustained, but 4K 100/120 7-8
second burst.
Once the selection is made you will need to press EXEC on the camera, to
return to live / record.
2Set Gamma (required for RAW recording)
1Set up the FS700 for RAW Recording
MENU » OTHERS » RAW S&Q BUTTON SET » 4K/2K SUPER SLOW
(BACK) » REC Command » ON
3Set the S&Q button for RAW High Speed
( Continued on Next Page » )
NTSC 4096x2096/24p
4096x2096/30p
4096x2096/60p
2048x1080/24p
2048x1080/30p
2048x1080/60p
PAL 4096x2160/25p
4096x2160/50p
2048x1080/25p
2048x1080/50p

5
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 7)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
( Continued on Next Page » )
Configure FS700 RAW Recording (Continued)
MENU » CAMERA SET » SLOW AND QUICK » RAW 2K SUPER SLOW » EXECUTE
4Setup FS700 High Frame Rate
Select your desired frame rate*:
TIME SAVER TIP: A quicker way of doing this is once the S&Q is set to RAW
HIGH SPEED, you can press and hold the S&Q button, then once the RAW Super
Slow frame is highlighted, you can now switch from 120 to 240. (or 100 to 200 in
record.)
TO ACCESS HIGH FRAME RATES:
» Press the S&Q button » Select 120fps or 240fps
The Odyssey7Q also has the ability of recording the buered 4K 100/120 p from
the FS700. If you wish to record this set the camera to 4K RAW, and enable S&Q.
Then the Odyssey7Q will record 4K100/120, for up to a 4 second burst.
RAW 4K SUPER SLOW 120FPS AND 100 FPS
Start Trigger - > 440 Frames
End Trigger -> 440 Frames
End Half Trigger -> 220 Frames
Start Trigger Processes 440 frames from when RECord button is pressed.
End Trigger Sends a buer of the 440 frames prior to hitting the REC button.
End Half Trigger sends a buer of the 220 frames prior to hitting the REC button.
120fps is 3.7 seconds record time - (440 frames) - 60fps playback
100fps is 4.4 seconds - (440 frames) - 50fps playback
NTSC 120
240
PAL 100
200
i

6
© 2014 Convergent Design, Inc. - All Rights Reserved.
Configure FS700 RAW Recording (Continued)
MENU » OTHERS » 60i/50i SEL » YES
5PAL: 25p, 50p, 100p and 200p
MENU » REC/OUT SET » VIDEO OUT » SDI/HDMI CONTROL » ON
6Setup Record Trigger (FS700 Rec Button)
MENU » REC/OUT SET » RAW REC CONTROL » RAW+HD
(BACK) » REC/OUT SET » HD SIMULTANEOUS REC » ON
7Dual Record: FS700 Internal + Odyssey7Q
NOTE: The clip name from the FS700 is not sent over the SDI to the
Odyssey7Q, thus if you wish to use the internal media as an oine, you
will need to rename the internal media to match the RAW files.

7
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 7)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Configure Odyssey7Q RAW Recording
MENU » ODYSSEY » SET » TIME
MENU » ODYSSEY » SET » DATE
3Set Date & Time to match FS700
MENU » SETUP » MONITOR --> RECORD » FS700 RAW-->RAW (.DNG)
The unit will restart.
1Set Odyssey7Q to FS700 Mode
Connect FS700 3G-SDI output to Odyssey7Q SDIA input
2Connect Odyssey7Q to FS700
Note: Use only 3G-SDI rated cables from FS700 to Odyssey7Q. Using a 1.5G
SDI cable in not recommended and may cause issues.
Note: When selected for the first time (or after an update) it may take up to
3 minutes to load.
ODYSSEY SETUP
MONITOR --> RECORD 4:2:2 -> PRORES HD (.MOV)
FS700 RAW -> RAW (.DNG)
CANON RAW -> RAW (.RMF)
ARRIRAW -> RAW (.ARI)
4:2:2/4:4:4 -> 4:4:4 (.DPX)
FS700 4K RAW -> PRORES HD (.MOV)
RECORD INPUTS OUTPUTS
ODYSSEY
SET ACTIVATION
TIME 07:30:11
▲
▼
OK X
DATE
RESET
SSD’S
ABOUT
MFG
SETUP RECORD INPUTS OUTPUTS
ODYSSEY
SET ACTIVATION
TIME
2014 MAR 19
▲
▼
OK X
DATE
RESET
SSD’S
ABOUT
MFG
SETUP RECORD INPUTS OUTPUTS
( Continued on Next Page » )

8
© 2014 Convergent Design, Inc. - All Rights Reserved.
The status on your Odyssey7Q will display your camera’s output.
Example:
Note: The recorded file will be RAW (.DNG) 2K or 4K.
2K up to 240fps, 4K up to 60fps (sustained) and 4K 100/120 (3-4 second bursts).
Configure Odyssey7Q RAW Recording (Continued)
4K 29.97 FS700
RAW
MENU » INPUTS » TIMECODE » SOURCE » SDI
MENU » ODYSSEY » SSD’S » FORMAT BOTH (or FORMAT SSD1 if you do not have a
second SSD drive installed.)
5
6
Set Timecode Source
Format SSDs
MENU » RECORD » TRIGGER » CAMERA
4Make FS700 the Record Trigger
ODYSSEY SETUP RECORD
TRIGGER
CLIP REC BUTTON
CAMERA
PROJECT
INPUTS OUTPUTS
7Connect to Camera and Verify Status Input
Note: Use only 3G-SDI rated cables from FS700 to Odyssey7Q. Using a 1.5G
SDI cable in not recommended and may cause issues.
Connect FS700 3G-SDI output to Odyssey7Q SDIA input
ODYSSEY SETUP RECORD
AUDIO
TIMECODE
SDI
LTC
SEED/REC RUN
SOURCE
INPUTS OUTPUTS

9
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 7)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
i
4K 23.98 to 30p rates = Single Drive
4K 50/59p = RAID (two drives)
2K 200/240p = RAID (two drives)
RAID is set up automatically upon detecting the input signal - no setup is required.
Note: You can use any Convergent Design media; they need not be matching (ie, one
256GB card and one 512GB card).
Configure Odyssey SSD RAID Configuration
Recording Across Two SSDs
( Next Step: O-loading Data )
SSD1 SSD2
1, 3, 5, 7… 0, 2, 4, 6…
iNotes

10
© 2014 Convergent Design, Inc. - All Rights Reserved.
Configure FS700 4K RAW to HD Apple ProRes 422
MENU » REC/OUT SET » REC SET » RAW SET
Select any of the following frames rates that you wish to record on Odyssey7Q:
Once the selection is made you will need to press EXEC on the camera, to
return to live / record.
1Set up the FS700 for 4K RAW Recording
NTSC 4096x2096/24p
4096x2096/30p
4096x2096/60p
PAL 4096x2160/25p
4096x2160/50p
MENU » REC/OUT SET » VIDEO OUT » SDI/HDMI COMMAND » ON
Connect FS700 3G-SDI output to Odyssey7Q SDIA input
2
4
Setup Record Trigger (FS700 Rec Button)
Connect FS700 to Odyssey7Q
PICTURE PROFILE » PP7 » SETTING » GAMMA » S-Log2
NOTES:
• Picture Profiles S-Log2, Rec709, Rec709 800% are all supported in this mode.*
• Custom Profiles are not supported at this time.
• Be sure to set the white balance correctly before shooting. Also note that if you wish
to trigger the Odyssey via the camera’s record trigger please set the following on the
FS700
• With 4K to HD what you see on the monitor is what will be recorded.
• Adjusting settings within each picture profile will not be reflected in the recording
since the Odyssey7Q can only detect which profile is set, not the individual
attributes.
3Set Gamma (required for RAW recording)
Note: Use only 3G-SDI rated cables from FS700 to Odyssey7Q. Using a 1.5G
SDI cable in not recommended and may cause issues.
( Next Step: Configure Odyssey7Q 4K RAW to HD Recording)

11
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 7)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Configure Odyssey7Q 4K RAW to HD Recording
MENU » SETUP » MONITOR --> RECORD » FS700 4K RAW-->PRORES HD
MENU » INPUTS » TIMECODE » SOURCE » SDI
If recording S-Log2 use Sony FS700 S-Log setting.
1
3
Set Odyssey7Q to FS700 4K RAW to Apple ProRes 422 Mode
Set Timecode Source
MENU » RECORD » TRIGGER » CAMERA
2Make FS700 the Record Trigger
Note: When selected for the first time it may take up to 3 minutes to load.
ODYSSEY SETUP RECORD
TRIGGER
CLIP REC BUTTON
CAMERA
REMOTE
PROJECT
INPUTS OUTPUTS
ODYSSEY SETUP RECORD
AUDIO
TIMECODE
SDI
LTC
SEED/REC RUN
SOURCE
INPUTS OUTPUTS
ODYSSEY SETUP
MONITOR --> RECORD 4:2:2 -> PRORES HD (.MOV)
FS700 RAW -> RAW (.DNG)
CANON RAW -> RAW (.RMF)
ARRIRAW -> RAW (.ARI)
4:2:2/4:4:4 -> 4:4:4 (.DPX)
FS700 4K RAW -> PRORES HD (.MOV)
RECORD INPUTS OUTPUTS
( Continued on Next Page » )

12
© 2014 Convergent Design, Inc. - All Rights Reserved.
Configure Odyssey7Q 4K RAW to HD Recording
MENU » ODYSSEY » SSD’S » FORMAT BOTH (or FORMAT SSD1 if you do not have a
second SSD drive installed.)
4
5
Format SSDs
Connect to Camera and Verify Status Input
Note: Use only 3G-SDI rated cables from FS700 to Odyssey7Q. Using a 1.5G
SDI cable in not recommended and may cause issues.
Connect FS700 3G-SDI output to Odyssey7Q SDIA input
The status on your Odyssey7Q will display your camera’s output.
Example:
Note: The recorded file will be 1920x1080 @ 23.98/25/29.97 fps.
4K 29.97p
S-Log2
4K->HD
PRORES

13
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 7)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
Configure FS700 FS700 422 to Apple ProRes 422
( Next Step: Configure Odyssey7Q for Apple ProRes 422 recording )
MENU » REC/OUT SET » REC SET » HD
Select any of the following frames rates that you wish to record on Odyssey7Q:
Note: 1080/60p, 1090/50p, 1080/100p, 1080/120p are not supported at this time.
1Set up the FS700 for Recording
MENU » REC/OUT SET » VIDEO OUT » SDI/HDMI COMMAND » ON
MENU » REC/OUT SET » VIDEO OUT » SDI/HDMI/COMPONENT » 1080p/480p
MENU » REC/OUT SET » VIDEO OUT » 24/30p Output » 24p/30p
2
3
4
Set up Record Trigger (FS700 Rec Button)
Set up FS700 Output Resolution
Set up FS700 Output Frame Rate
NTSC 1080/24p
1080/30p
1080/60p
PAL 1080/25p
1080/50p

14
© 2014 Convergent Design, Inc. - All Rights Reserved.
Configure Odyssey7Q FS700 to Apple ProRes 422
MENU » SETUP » MONITOR --> RECORD » 4:2:2->PRORES HD (.MOV)
MENU » INPUTS » TIMECODE » SOURCE » SDI
1
2
4
Set Odyssey7Q to FS700 to Apple ProRes 422 Mode
Set up Odyssey7Q for your FS700
Set Timecode Source
MENU » RECORD » TRIGGER » CAMERA
3Make FS700 the Record Trigger
ODYSSEY SETUP RECORD
TRIGGER
CLIP REC BUTTON
CAMERA
REMOTE
PROJECT
INPUTS OUTPUTS
ODYSSEY SETUP RECORD
AUDIO
TIMECODE
SDI
LTC
SEED/REC RUN
SOURCE
INPUTS OUTPUTS
MENU » SETUP » 4:2:2/4:4:4 SOURCE » SONY FS700
ODYSSEY SETUP
MONITOR --> RECORD
4:2:2/4:4:4 SOURCE
RECORD
ARRI
CANON
PANASONIC
RED
SONY FS700
INPUTS OUTPUTS
ODYSSEY SETUP
MONITOR --> RECORD 4:2:2 -> PRORES HD (.MOV)
FS700 RAW -> RAW (.DNG)
CANON RAW -> RAW (.RMF)
ARRIRAW -> RAW (.ARI)
4:2:2/4:4:4 -> 4:4:4 (.DPX)
FS700 4K RAW -> PRORES HD (.MOV)
RECORD INPUTS OUTPUTS
Note: If recording S-Log2 use
Sony FS700 S-Log2 setting
SONY FS700 (S-Log2)

15
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 7)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
MENU » ODYSSEY » SSD’S » FORMAT BOTH (or FORMAT SSD1 if you do not have a
second SSD drive installed.)
5Format SSDs
6Connect to Camera and Verify Status Input
Note: Use only 3G-SDI rated cables from FS700 to Odyssey7Q. Using a 1.5G
SDI cable in not recommended and may cause issues.
Connect FS700 3G-SDI output to Odyssey7Q SDIA input
The status on your Odyssey7Q will display your camera’s output.
Example:
Note: The recorded file will be 1920x1080 @ 23.98/25/29.97 fps.
Note: Camera trigger will not work with the FS700R for ProRes or DPX recordings
because the camera does not output the SDI record trigger with firmware version 3.10.
1080p29.97 422
FS700
PRORES
HQ
Configure Odyssey7Q FS700 to Apple ProRes 422

16
© 2014 Convergent Design, Inc. - All Rights Reserved.
QUESTIONS or FEEDBACK? We’re always available to help! [e-mail]
?
Configure FS700 Recording to Uncompressed DPX
( Next Step: Configure Odyssey7Q for Uncompressed DPX Recording )
MENU » REC/OUT SET » REC SET » HD
Select any of the following frames rates that you wish to record on Odyssey7Q:
Note: 1080/100p, 1080/120p are not supported at this time.
1Set up the FS700 for Recording
MENU » REC/OUT SET » VIDEO OUT » SDI/HDMI COMMAND » ON
MENU » REC/OUT SET » VIDEO OUT » SDI/HDMI/COMPONENT » 1080p/480p
MENU » REC/OUT SET » VIDEO OUT » 24/30p Output » 24p/30p
2
3
4
Set up Record Trigger (FS700 Rec Button)
Set up FS700 Output Resolution
Set up FS700 Output Frame Rate
NTSC 1080/24p
1080/30p
1080/60p
PAL 1080/25p
1080/50p

17
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 7)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Configure Odyssey7Q Recording Uncompressed DPX
MENU » SETUP » MONITOR --> RECORD » 4:2:2/4:4:4 -> 4:4:4 (.DPX)
MENU » SETUP » 4:2:2/4:4:4 SOURCE » SONY FS700
MENU » INPUTS » TIMECODE » SOURCE » SDI
1
2
4
Set Odyssey7Q to FS700 to Uncompressed DPX Mode
Set up Odyssey7Q for your FS700
Set Timecode Source
MENU » RECORD » TRIGGER » CAMERA
3Make FS700 the Record Trigger
ODYSSEY SETUP RECORD
TRIGGER
CLIP REC BUTTON
CAMERA
REMOTE
PROJECT
INPUTS OUTPUTS
ODYSSEY SETUP RECORD
AUDIO
TIMECODE
SDI
LTC
SOURCE
INPUTS OUTPUTS
Click OK
The unit will restart.
ODYSSEY
ODYSSEY
SETUP
SETUP
MONITOR --> RECORD
MONITOR --> RECORD
MONITOR --> RECORD
4:2:2 -> PRORES HD (.MOV)
FS700 RAW -> RAW (.DNG)
CANON RAW -> RAW (.RMF)
ARRIRAW -> RAW (.ARI)
4:2:2/4:4:4 -> 4:4:4 (.DPX)
FS700 4K RAW -> PRORES HD (.MOV)
RECORD
RECORD
INPUTS
INPUTS
OUTPUTS
OUTPUTS
ARRI
PANASONIC
SONY FS700
CANON
RED
SONY OTHER
OTHER
Note: Camera trigger will not
work with the FS700R for
ProRes or DPX recordings
because the camera does not
output the SDI record trigger
with firmware version 3.10.
Note: If recording S-Log2 use
Sony FS700 S-Log2 setting
SONY FS700 (S-Log2)

18
© 2014 Convergent Design, Inc. - All Rights Reserved.
Configure Odyssey7Q Recording Uncompressed DPX
MENU » ODYSSEY » SSD’S » FORMAT BOTH (or FORMAT SSD1 if you do not have a
second SSD drive installed.)
5Format SSDs
6Connect to Camera and Verify Status Input
Note: Use only 3G-SDI rated cables from FS700 to Odyssey7Q. Using a 1.5G
SDI cable in not recommended and may cause issues.
Connect FS700 3G-SDI output to Odyssey7Q SDIA input
The status on your Odyssey7Q will display your camera’s output.
Example:
Note: The recorded file will be 1920x1080 @ 23.98/25/29.97 fps.
Note: Camera trigger will not work with the FS700R for ProRes or DPX recordings
because the camera does not output the SDI record trigger with firmware version 3.10.
1080p29.97 422
FS700
DPX
4:4:4

19
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ [phone] | FAX: ++ [phone] | Oce Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 7)]
EMAIL: [e-mail] | WEBSITE: www.Convergent-Design.com
Odyssey7Q O-Loading Data
Connect the Convergent Design 2.5” Premium SSD Media to any o-the-shelf 2.5” SATA
adaptor (example: Seagate GoFlex Thunderbolt Adaptor or USB 3.0 Adaptor)
1Connect SSD Drive to Adapter
The SSD will mount within 10-20 Seconds. (You will see this mount on the desktop or within
finder on MAC, or within My Computer on Windows machines).
2Connect Adapter to Computer
All Clips or Takes are located within the “Clips” directory, navigate to this and copy all of
your files to a local or external drive or RAID for playback and/or editing.
3Copy Files for Playback/Editing
i
CD Clip Merger (Free Download from Website)
Use the Clip Merger for any Raided Record (ie if your recorded clip required more than
one SSD). See the At A Glance Chart, “No. of SSD’s Req” column, on page 2.
CD Apple ProRess Transfer Tool (Free Download from Website)
Use to combine clips into a single file
Use to copy all files to a single directory without folder structure.
CD Data Unpacker (Free Download from Website)
Use CD Data Unpacker to convert “packed” files to “unpacked” data.
DOWNLOAD HERE: http://convergent-design.com/support/firmware-downloads.html
Free Software Utilities
ATTENTION MAC OSX USERS
Before installing Convergent
Design Software on Mac
OSX You must first change
the following settings.
!
1) Navigate to Applications » Utilities » System Preferences
2) Select Security and privacy
3) Under General » Allow applications downloaded from: Select
Anywhere.
4) Now you will be able to run the installer for installing any
Convergent Design Applications.

20
© 2014 Convergent Design, Inc. - All Rights Reserved.
FS700 Post Production
Apple ProRes 422 (HQ)
The Odyssey7Q records in Apple ProRes 422 (HQ) which is a 10 bit 4:2:2 220Mb compressed
codec. This will allow for high quality recording while avoiding high data rates of working with
uncompressed video. (DPX)
Native Apple ProRes 422 Support
Adobe CC 2014* Final Cut Pro 7 Autodesk Smoke
Apple FCP X, Aperture Black Magic DaVinci Resolve Sony Vegas
Cineform Studio The Foundry Nuke
To playback Apple ProRes 422 (HQ) files in QuickTime Player X, the files must be first run
through our Apple ProRes 422 (HQ) Utility to be optimized for the recently released Apple
ProRes 422 (HQ) Codec update. If files are not optimized, then they will play the first second of
audio only. This is not an issue when playing in FCPX.
SONY FS700 RAW SUPPORT (DNG SEQUENCES)
All FS700 RAW recording on the Odyssey7Q is recorded as a 12-bit linear CinemaDNG file. With
DNG files, timecode and clip metadata is stored in every frame, as well as in the XML file within
each clip. All audio is recorded 48Hz 16 bit Uncompressed WAV audio.
It is important to correctly set the white balance of the camera, as this is baked into the RAW
file.
Native CinemaDNG Support
Adobe CC 2014* Assimilate Scratch Lab (future update)
Apple FCP X, Aperture Black Magic DaVinci Resolve
*Pending next Adobe CC update.
( Continued on Next Page » )
