CONVEY-ALL 1685-SP User manual

SELF-PROPELLED CONVEYOR
Models:
1685-SP, 1690-SP, 1695-SP
OPERATOR’S MANUAL

LIMITED WARRANTY
Convey-All™ warrants to the buyer that the new machinery is free from defects in material and
workmanship.
This warranty is only effective as to any new machinery which has not been altered, changed,
repaired or treated since its delivery to the buyer, other than by Convey-All™ or its authorized
dealers or employees, and does not apply to accessories, attachments, tools or parts, sold or
operated with new machinery, if they have not been manufactured by Convey-All™.
Convey-All™ shall only be liable for defects in the materials or workmanship attributable to
faulty material or bad workmanship that can be proved by the buyer, and specifically excludes
liability for repairs arising as a result of normal wear and tear of the new machinery or in any other
manner whatsoever, and without limiting the generality of the foregoing, excludes application
or installation of parts not completed in accordance with Convey-All™ operator’s manual,
specifications, or printed instructions.
Written notice shall be given by registered mail, to Convey-All™ within seven (7) days
after the defect shall have become apparent or the repairs shall have become necessary,
addressed as follows:
Convey-All Industries Inc.
130 Canada Street
Winkler, Manitoba R6W 0J3
Canada
This warranty shall expire one (1) year after the date of delivery of the new machinery.
If these conditions are fulfilled, Convey-All™ shall at its own cost and at its own option either
repair or replace any defective parts provided that the buyer shall be responsible for all expenses
incurred as a result of repairs, labor, parts, transportation or any other work, unless Convey-All™
has authorized such expenses in advance.
The warranty shall not extend to any repairs, changes, alterations, or replacements made to the
new equipment other than by Convey-All™ or its authorized dealers or employees.
This warranty extents only to the original owner of the new equipment.
This warranty is limited to the terms stated herein and is in lieu of any other warranties whether
expressed or implied, and without limiting the generality of the foregoing, excluded all warranties,
expressed or implied or conditions whether statutory or otherwise as to quality and fitness for any
purpose of the new equipment. Convey-All™ disclaims all liability for incidental or consequential
damages.
This machine is subject to design changes and Convey-All™ shall not be required to retrofit or
exchange items on previously sold units except at its own option.
WARRANTY VOID IF NOT REGISTERED

WARRANTY REGISTRATION FORM
and INSPECTION REPORT
UNIT INSPECTION SAFETY INSPECTION
£All Fasteners Tight £All Guards/Shields Installed and Secured
£Engine/Hydraulic Fluid Levels Checked £All Safety Decals Clear and Legible
£Hydraulic Hoses Good, Fittings Tight £
Reflectors, Slow Moving Vehicle (SMV) Sign Clean
£Machine and All Bearings Lubricated £
All Lights Clean and Working
£Conveyor Belt Aligned and Tensioned £
Safety Chain on Hitch
£Conveyor Belt Moves Freely £
Reviewed Operating and Safety Instructions
£Conveyor Tube Raises and Lowers Smoothly
£Unit Steers and Drives Smoothly
£Tire Pressure Checked
I have thoroughly instructed the buyer on the above described equipment. The review included the content
of the Operator’s Manual, equipment care, adjustments, safe operation and the applicable warranty policy.
Date _______________________ Dealer’s Signature ______________________________________________
The above equipment and Operator’s Manual have been received by me. I have been thoroughly instructed as
to care, adjustments, safe operation and applicable warranty policy.
Date _______________________ Buyer’s Signature _______________________________________________
The Dealer must fill out this form. It is to be signed by both the Dealer and Buyer at the time of delivery.
Scan or photograph the completed form (be sure it is legible). Email it to: r[email protected]
A copy of this form may also be mailed to Convey-All Industries Inc, at the above address.
Buyer’s Name ________________________________ Dealer’s Name ________________________________
Address ______________________________________ Address _____________________________________
City __________________________________________ City _________________________________________
Province/State ________________________________ Province/State _______________________________
Postal Code/Zip Code _________________________ Postal Code/Zip Code _________________________
Country ______________________________________ Country _____________________________________
Phone Number ________________________________ Phone Number________________________________
Unit’s Model Number __________________________ Unit’s Serial Number __________________________
Delivery Date _________________________________ General Purpose: £Private £Commercial
CONVEY-ALL INDUSTRIES INC.
130 CANADA STREET, WINKLER, MANITOBA R6W 0J3
T: [phone] P: [phone] F: [phone]
www.convey-all.com [email protected]

This page intentionally left blank

Operator’s Manual: 1600-SP Series Conveyor
Revised 06.2019 i
TABLE OF CONTENTS
DESCRIPTION PAGE
Section 1: INTRODUCTION ............................1-1
1.1 Operator Orientation.............................1-1
1.2 Serial Number Location ..........................1-1
Section 2: SAFETY ...................................2-1
2.1 Safety Orientation...............................2-2
2.2 General Safety .................................2-2
2.3 Equipment Safety Guidelines ......................2-3
2.4 Safety Decals ..................................2-3
2.4.1 How to Install Safety Decals ...................2-3
2.5 Work Preparation ...............................2-4
2.6 Placement Safety ...............................2-4
2.7 Lock-Out Tag-Out Safety .........................2-4
2.8 Maintenance Safety .............................2-5
2.9 Tire Safety.....................................2-5
2.10 Battery Safety .................................2-5
2.11 Engine Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2.12 Operating Safety...............................2-7
2.13 Hydraulic Safety ...............................2-7
2.14 Workplace Hazard Area .........................2-8
2.15 Transport Safety ...............................2-9
2.16 Storage Safety ................................2-9
2.17 Safety Decal Location ......................... 2-10
Section 3: OPERATION................................3-1
3.1 Machine Components ...........................3-2
3.2 Components and Controls ........................3-4
3.3 - 10 inch Swing-Out Conveyor (Optional) ........... 3-10
3.4 Swing-Out Remote Control (Optional) .............. 3-13
3.5 Machine Break-In .............................. 3-15
3.6 Pre-Operation Checklist ......................... 3-15
3.7 Attaching to Tow Vehicle ........................ 3-16
3.8 Conveyor Placement ........................... 3-17
3.9 Operating on Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
3.9.1 Starting Conveyor .......................... 3-19
3.9.2 Stopping Conveyor ......................... 3-19
3.9.3 Emergency Stopping ........................ 3-19
3.9.4 Restarting after Emergency Stop ............... 3-19
3.9.5 Unplugging................................ 3-19
3.10 Operating Hints .............................. 3-20
3.11 Transportation................................ 3-21
3.12 Storage ..................................... 3-22
continued on next page

Operator’s Manual: 1600-SP Series Conveyor
ii Revised 06.2019
TABLE OF CONTENTS
DESCRIPTION PAGE
Section 4: SERVICE AND MAINTENANCE .................4-1
4.1 Fluids and Lubricants ............................4-1
4.1.1 Greasing ...................................4-2
4.2 Servicing Intervals ..............................4-3
4.2.1 Every 10 Hours or Daily .......................4-3
4.2.2 Every 50 Hours or Weekly .....................4-5
4.2.3 Every 200 Hours or Annually ...................4-6
4.3 Maintenance Procedures .........................4-8
4.3.1 Main Conveyor Belt Tension....................4-8
4.3.2 Swing-Out Conveyor Belt Tension ...............4-9
4.3.3 Main Conveyor Belt Alignment................. 4-10
4.3.4 Swing-Out Conveyor Belt Alignment ............ 4-12
4.3.5 Conveyor Belt Replacement .................. 4-13
4.3.6 Changing Hydraulic Oil and Filter .............. 4-14
4.4 Service Record ................................ 4-15
4.5 Ordering Parts ................................ 4-16
Section 5: TROUBLESHOOTING ........................5-1
Section 6: SIGN-OFF FORM............................6-1
Section 7: REFERENCE ...............................7-1
7.1 Specifications ..................................7-1
7.2 Working Measurements ..........................7-2
7.3 Bolt Torque ....................................7-3

Operator’s Manual: 1600-SP Series Conveyor
Revised 06.2019 1-1
Section 1: INTRODUCTION
Congratulations on your choice of a Convey-All™ Self-Propelled Conveyor. It is designed to efficiently move grain,
pulse crops or granular material between a truck, trailer, and storage facility.
This equipment has been designed and manufactured to exceed the exacting standards for such equipment in the
agricultural industry. It will keep your seed delivery operation working at optimum efficiency.
Keep this manual handy for frequent reference. Pass it on to new operators or owners. Call your dealer, distributor
or Convey-All Industries Inc, if you need assistance, information, additional/replacement copies, or a digital copy
of this document.
Information provided herein is of a descriptive nature. Convey-All Industries Inc. reserves the right to modify the
machinery design and specifications provided herein without any preliminary notice.
Performance quality may depend on the material being handled, weather conditions and other factors.
1.1 OPERATOR ORIENTATION
The directions left, right, front and rear, as mentioned throughout this manual, are as seen from the tow vehicle
drivers’ seat and facing the direction of travel. The hopper is the front of the conveyor.
1.2 SERIAL NUMBER LOCATION
Always give your dealer the serial number of your conveyor when ordering parts or requesting service or other
information. The conveyor’s serial number is located at the hopper of the main conveyor.
Please mark the identifying numbers in the space
provided for easy reference.
Conveyor Model No: __________________________
Conveyor Serial No: __________________________
Engine Model No: __________________________
Engine Serial No: __________________________ Fig 1 - Serial number location

Operator’s Manual: 1600-SP Series Conveyor
1-2 08.2016
This page intentionally left blank

Operator’s Manual: 1600-SP Series Conveyor
Revised 06.2019 2-1
The following signal words are used in this manual to express
the degree of hazard for areas of personal safety.
When you see the above symbol, and/or the signal words described below,
obey the accompanying message to avoid possible injury or death.
DANGER - Indicates an imminently hazardous situation. If not avoided, it will
result in death or serious injury. This signal word is to be limited
to the most extreme situations typically for machine components
which, for functional purposes, cannot be guarded.
WARNING - Indicates a potentially hazardous situation. If not avoided, it could
result in death or serious injury. This word identifies hazards that
are exposed when guards are removed. It may be used to alert
against unsafe practices.
CAUTION - Indicates a potentially hazardous situation. If not avoided, it may
result in minor or moderate injury. It may be used to alert against
unsafe practices.
NOTICE - Indicates practices or situations which may result in the
malfunction of, or damage to, the equipment.
Section 2: SAFETY
The Safety Alert Symbol means:
ATTENTION!
BECOME ALERT!
YOUR SAFETY IS INVOLVED!
The Safety Alert Symbol identifies
important safety messages on
the Self-Propelled Conveyor
and in this manual.
3 Big Reasons why safety
is important to you:
• Accidents Disable and Kill
• Accidents Cost
• Accidents Can Be Avoided

Operator’s Manual: 1600-SP Series Conveyor
2-2 08.2016
2.1 SAFETY ORIENTATION
YOU are responsible for the SAFE operation and
maintenance of your Convey-All™ Self-Propelled
Conveyor. Be sure that everyone who will operate,
maintain or work around it, is familiar with the safety,
operating and maintenance procedures.
This manual will take you step-by-step through your
working day. It will alert you to all the safe practices
that should be adhered to while operating the
conveyor.
Remember, you are the key to safety. Good safety
practices not only protect you but also the people
around you. Make these practices a working part of
your workday. Be certain that all operators of this
equipment follows these procedures.
Most accidents can be prevented. Do not risk injury
or death by ignoring good safety practices.
•Conveyor owners must give operating instructions
to operators or employees before allowing them to
operate the machine.
Procedures must be reviewed annually thereafter,
as per OSHA (Occupational Safety and Health
Administration) regulation 1928.57.
•The most important safety device on this equipment
is a SAFE operator. It is the operator’s responsibility
to understand all safety and operating instructions
in this document, and to follow them.
•An untrained operator exposes himself and
bystanders to possible serious injury or death.
• Think SAFETY! Work SAFELY!
2.2 GENERAL SAFETY
•Read and understand the Operator’s
Manual and all safety decals before
operating, maintaining, adjusting or
unplugging the conveyor.
•Only trained, competent persons shall operate the
conveyor. An untrained person is not qualified to
operate the machine.
•Have a first-aid kit available for use
should the need arise and know how to
use it.
•Provide a fire extinguisher for use in
case of an accident. Store in a highly
visible place.
• Do not allow riders.
•Do not allow children, spectators or bystanders
within hazard area around the machine.
•Wear appropriate protective gear. This list may
include but is not limited to:
- Hard hat
- Protective shoes with
slip resistant soles
- Eye protection
- Work gloves
- Hearing protection
- Respirator or
filter mask
- Hi-Visibility safety
vest
•Never use alcoholic beverages or drugs which can
hinder alertness or coordination while operating
this equipment.
Consult your doctor about operating this machine
while taking prescription medications.
•If the elderly are assisting with farm work, their
physical limitations need to be recognized and
accommodated.
•Review safety related items annually with all
personnel who will be operating or maintaining the
conveyor.

Operator’s Manual: 1600-SP Series Conveyor
Revised 06.2019 2-3
2.3 EQUIPMENT SAFETY GUIDELINES
•Safety of the operator and bystanders is one of the
main concerns in designing and developing this
conveyor. However, every year many accidents
occur which could have been avoided by a few
seconds of thought and a more careful approach
to handling equipment.
•Do not allow personnel to operate this unit until
they have read this manual. They should have a
thorough understanding of the safety precautions.
Review the safety instructions with all personnel
annually.
•In order to provide a better view, some
images in this manual may show an
assembly with a safety guards removed.
Equipment should never be operated in
this condition. Keep all guards in place.
If removal becomes necessary for
repairs, replace the guard prior to use.
•This equipment is dangerous to children and
people unfamiliar with its operation.
You, the operator must be responsible, properly
trained and physically able. You should be familiar
with farm machinery in general.
•Never exceed the limits of a piece of machinery.
If its ability to do a job, or to do so safely, is in
question - DON’T TRY IT.
•Do not modify the equipment in any way.
Unauthorized modification result in serious injury
or death and may impair the function and life of the
equipment.
•The design and configuration of this conveyor
includes safety decals and equipment. They need
to be clean, readable or in good, working condition.
2.4 SAFETY DECALS
• Keep safety decals clean and legible at all times.
•Replace safety decals that are missing or have
become illegible.
•Replaced parts that displayed a safety decal
should also display the current decal.
•All safety decals have a part number in the lower
right hand corner. Use this part number when
ordering replacements.
•Safety decals are available from your
authorized distributor, dealer or directly from
Convey-All Industries Inc.
2.4.1 How to Install Safety Decals:
1. Be sure that the area is clean and dry. Preferably,
apply the decals inside.
2. Ensure temperature is above 10°C (50°F).
3. Remove all dirt, grease, wax from the surface.
4. Clean with a non-ammonia based cleaner.
5. Wipe the clean surface with isopropyl alcohol on
paper towel, and allow to dry.
6. Determine exact position before you remove the
backing paper.
7. Peel the smallest portion of the split backing
paper.
8. Align the decal over the specified area. Use a
squeegee to carefully press the small portion,
with the exposed adhesive backing, into place.
9. Slowly peel back the remaining paper and
carefully smooth the remaining portion of the
decal into place.
10. Small air pockets can be pierced with a pin and
smoothed out using the squeegee, or a piece of
sign backing paper.

Operator’s Manual: 1600-SP Series Conveyor
2-4 Revised 06.2019
•Clear the working area of stones, branches or
hidden obstacles that might be hooked, snagged
or tripped over, causing injury or damage.
• Operate only in daylight or good artificial light.
•Be sure machine is in a stable position, is adjusted
and in good operating condition.
•Ensure that all safety guards and safety decals are
properly installed and in good condition.
•Before starting, inspect the unit for any loose bolts,
worn parts, cracks, leaks or frayed belt.
Make the necessary repairs.
Always follow the maintenance instructions.
2.6 PLACEMENT SAFETY
•Stay away from overhead power lines when
operating or moving the conveyor. Electrocution
can occur without direct contact.
• Keep conveyor as low as possible.
• Chock conveyor wheels before operating.
•Position conveyor providing enough space for
trucks to unload.
•Operate the conveyor on level ground free of
debris.
2.7 LOCK-OUT TAG-OUT SAFETY
•Establish a formal Lock-Out Tag-Out program for
your operation.
•Train all operators and service personnel before
allowing them to work around the area.
•Provide tags on the machine and a sign-up sheet
to record tag out details.
2.5 WORK PREPARATION
•Never operate the conveyor until you have read
this manual, and comprehend the information.
Also, read the engine operator’s manual.
Be familiar with the safety messages found on the
decals around this unit.
• Personal protection equipment including:
- Hard hat
- Eye protection
- Protective shoes
- Work gloves
are recommended during placement,
operation, maintaining and repairing,
transportation and storage of the
equipment.
•Do not allow long hair, loose fitting clothing or
jewelry to be around equipment.
•PROLONGED EXPOSURE TO LOUD NOISE MAY
CAUSE PERMANENT HEARING LOSS!
Agricultural equipment can often be
noisy enough to cause permanent,
partial hearing loss. We recommend
that you wear hearing protection on
a full-time basis, if the noise exceeds
80db.
Noise over 85db on a long-term basis can cause
severe hearing loss.
Noise over 90db adjacent to the operator over
a long-term basis may cause permanent, total
hearing loss.
Note:
Hearing loss from loud noise
(tractors, chain saws, radios, etc.)
is cumulative over a lifetime
without hope of natural recovery.

Operator’s Manual: 1600-SP Series Conveyor
Revised 06.2019 2-5
2.8 MAINTENANCE SAFETY
•Review Section 4: Service and Maintenance, of
this Manual before maintaining or operating the
conveyor.
• Follow good shop practices:
- Keep service area clean and dry.
- Be sure electrical outlets and tools
are properly grounded.
- Use adequate light for the job.
•Place all controls in neutral or off. Stop the engine
and remove ignition key. Wait for all moving parts
to stop before servicing, adjusting or repairing.
•Relieve pressure from hydraulic circuit
before servicing.
•Before applying pressure to a hydraulic
system, make sure all components are
tight. The hoses and couplings must be
in good condition.
•Keep hands, feet, hair and clothing
away from all moving and/or rotating
parts.
•Replace parts with genuine factory replacements
parts to restore your equipment to original
specifications.
Convey-All Industries Inc. will not be responsible
for injuries or damages caused by the use of
unapproved parts and/or accessories.
•Make sure there is plenty of ventilation. Never
operate the engine in a closed building. The
exhaust fumes may cause asphyxiation.
•Clear the area of bystanders, especially children,
when carrying out any maintenance and repairs or
making any adjustments.
•Place stands or blocks under the frame before
working beneath the machine.
•Before resuming operation, install and secure all
guards when maintenance work is completed.
•Keep safety decals clean. Replace any decal that
is damaged or not clearly visible.
2.9 TIRE SAFETY
•Failure to follow procedure when
mounting a tire on a wheel or rim can
produce an explosion and may result in
serious injury or death.
•Do not attempt to mount a tire unless you have the
proper equipment and experience to do the job.
•Have a qualified tire dealer or repair service perform
required tire maintenance.
•When replacing worn tires, make sure they meet
the original tire specifications.
Never undersize.
•Reference the tire side wall for information on the
maximum cold tire pressure (PSI). Keep the tires
inflated to this setting.
2.10 BATTERY SAFETY
•Keep all sparks and flames away from batteries, as
gas given off by electrolyte is explosive.
•Avoid contact with battery electrolyte. Wash off
any spilled electrolyte immediately.
• Wear safety glasses when working near
batteries.
•Do not tip batteries more than 45 degrees, to avoid
electrolyte loss.
•To avoid injury from spark or short circuit,
disconnect battery ground cable before servicing
any part of electrical system.
•When storing the conveyor for an extended period:
- Remove the battery
- Be sure it is fully charged
- Store it inside
- Do not sit the battery on a cold, concrete floor
•Before using the battery, after it has been in
storage, be sure it is fully charged.

Operator’s Manual: 1600-SP Series Conveyor
2-6 Revised 06.2019
2.11 ENGINE SAFETY
•Read and understand the operating
manual provided with the engine.
• Use proper tools to service engine.
•Do not run engine in an enclosed area. Exhaust
gases contain carbon monoxide, an odorless and
deadly poison.
• Store fuel in approved safety containers.
• Do not store fuel near an open flame.
Appliances such as a stove, furnace, or
water heater use a pilot light which can
create a spark.
• No smoking when filling the fuel tank.
• Do not remove fuel cap while engine is running.
•Do not refuel indoors where area is not well
ventilated. Outdoor refueling is preferred.
•Do not refuel while engine is running. Allow engine
to cool for 5 minutes before proceeding.
• Use fresh fuel. Stale fuel can gum carburetor and
cause leakage.
•Check fuel lines and fittings frequently for cracks or
leaks. Replace if necessary.
•Do not operate engine if fuel has spilled. Move
machine away. Avoid creating any ignition until the
fuel has evaporated.
•Do not run engine above rated speeds. This may
result in damage and injury.
•Do not tamper with the engine speed selected by
the original equipment manufacturer.
•Do not tamper with governor springs, governor
links or other parts which may increase the
governed engine speed.
•Do not strike flywheel with a hard object or metal
tool. This may cause it to shatter in operation.
• Keep cylinder fins and governor parts free of grass
and other debris which can affect engine speed.
•Do not operate engine with grass, leaves, dirt or
other combustible materials in muffler area.
• Do not operate engine without muffler.
WARNING: Hot Equipment
Do not touch muffler, cylinder or fins while
engine is running. Contact will cause
burns.
•Do not use this engine on any forest
covered, brush covered, or grass
covered, unimproved land, unless a
spark arrester is installed on the muffler.
The arrester must be maintained in
effective working order by the operator.
In the State of California the above is required
by law (Section 4442 of the California Public
Resources Code). Other states may have similar
laws. Federal laws apply on federal lands.
• Inspect muffler periodically. Replace if necessary.
If engine is equipped with a muffler deflector,
inspect periodically. Replace with correct part.
•Do not check for spark, or crank the engine while
the spark plug or spark plug wire is removed.
•Do not run the engine with air filter or it’s cover
removed.
NOTICE: Possible Engine Damage
Decelerate engine slowly to stop. Avoid
choking the carburetor to stop engine. Choke
only for an emergency stop.

Operator’s Manual: 1600-SP Series Conveyor
Revised 06.2019 2-7
• Chock wheels of conveyor before starting.
•Be sure that conveyor tube is empty before raising
or lowering.
•Close valves in hydraulic line when machine is in
position or before transporting.
•High winds may overturn conveyor. To avoid
damage to structures and equipment, do not raise
conveyor fully in windy conditions.
Also, do not leave the conveyor raised, when it is
not in use.
2.13 HYDRAULIC SAFETY
•Always place all hydraulic controls in neutral before
disconnecting and working on hydraulic systems.
•Make sure that all components in the hydraulic
system are kept in good condition and are clean.
•Replace any worn, cut, abraded, flattened or
crimped hoses.
•Do not attempt any makeshift repairs to the
hydraulic fittings or hoses by using tape, clamps
or cements. The hydraulic system operates under
extremely high-pressure. Such repairs will fail
suddenly and create a hazardous and unsafe
condition.
•Wear proper hand and eye protection
when searching for a high-pressure
hydraulic leak. Use a piece of wood
or cardboard as a backstop instead of
hands to isolate and identify a leak.
•If injured by a concentrated high-
pressure stream of hydraulic fluid, seek
medical attention immediately. Serious
infection or toxic reaction can develop
from hydraulic fluid piercing the skin
surface.
•Relieve pressure in hydraulic system before
maintaining or working on machine.
2.12 OPERATING SAFETY
•Be sure that anyone who will be
operating the conveyor, or working
around the unit, reads the manual. They
must know the operating, maintenance
and safety information.
Review the manual annually.
•Clean or replace all safety decals if they cannot be
clearly read and understood.
•Place all controls in neutral, and stop the engine.
Remove the ignition key. Wait for all moving parts
to stop before adjusting, repairing or unplugging.
•Keep all bystanders, especially children, away from
the machine when running.
Also, keep away when authorized personnel are
carrying out maintenance work.
•Establish a Lock-Out, Tag-Out policy for the work
site. Be sure all personnel are trained in and follow
all procedures.
Lock-out and tag-out all power sources before
servicing the unit or working around equipment.
•Be familiar with machine hazard area. If anyone
enters hazard areas, shut down machine
immediately. Clear the area before restarting.
•Keep hands, feet, hair and clothing away
from all moving and/or rotating parts.
•Do not allow riders on the conveyor when moving
or transporting.
•Keep working area clean and free of
debris to prevent slipping or tripping.
•Stay away from overhead obstructions
and power lines during operation and
transporting. Electrocution can occur
without direct contact.
•Do not operate machine when any guards are
removed.

Operator’s Manual: 1600-SP Series Conveyor
2-8 Revised 06.2019
2.14 WORKPLACE HAZARD AREA
OVERHEAD WIRES
KEEP AWAY
KEEP OUT OF
SHADED HAZARD AREA
UNDER CONVEYOR AND
UNDERCARRIAGE
AREA HAZARD
KEEP AWAY
CONVEYOR INTAKE
AREA HAZARD
KEEP AWAY
DO NOT RAISE CONVEYOR
IN HIGH WIND
CONVEYOR DRIVE
AREA HAZARD
KEEP AWAY
WORK AREA
AUTHORIZED PERSONNEL
ONLY
Fig 2 - Workplace hazard area
WHEEL CHOCKS
WHEEL CHOCKS

Operator’s Manual: 1600-SP Series Conveyor
Revised 06.2019 2-9
2.15 TRANSPORT SAFETY
•The conveyor belt must be empty before raising or
lowering it.
• Always transport conveyor in collapsed position.
•Check that all the lights, reflectors and
other lighting requirements are installed
and in good working condition.
• Never allow riders on the conveyor.
•Comply with all local laws governing safety and
transporting of equipment on public roads.
•Do not exceed a safe travel speed. Slow down for
rough terrain and when cornering.
•Stay away from overhead power lines.
Electrocution can occur without direct
contact.
• Plan your route to avoid heavy traffic.
• Do not drink and drive.
•Be a safe and courteous driver. Always yield to
oncoming traffic in all situations, including narrow
bridges, intersections, etc. Watch for traffic when
operating near or crossing roadways.
2.16 STORAGE SAFETY
• Store the conveyor on a firm, level surface.
• Store in an area away from human activity.
•If required, make sure the unit is solidly blocked up.
•Remove the battery and store in dry location. Do
not sit on cold concrete floor.
•Make certain all mechanical locks are safely and
positively connected before storing.
•Do not permit children to play on or around the
stored machine.
OVERHEAD WIRES
KEEP AWAY
KEEP OUT OF
SHADED HAZARD AREA
Fig 3 - Transporting hazard area

Operator’s Manual: 1600-SP Series Conveyor
2-10 Revised 06.2019
REMEMBER - If safety decals have been damaged, removed, become illegible, or parts were replaced without
signage, new ones must be applied. New decals are available from your authorized dealer.
2.17 SAFETY DECAL LOCATION
The following illustrations show the general location of decals on this conveyor. The position of decals may vary
depending on the machine’s options. Decals are not shown at actual size.
Fig 4 - 1690-SP with optional swingout

Operator’s Manual: 1600-SP Series Conveyor
Revised 06.2019 3-1
The Convey-All™ Self-Propelled Conveyor is designed to efficiently move granular material between a truck and
trailer and storage facility. Power is provided by a diesel engine. Be familiar with the conveyor and engine before
starting.
It is the responsibility of the owner, and operators to become familiar with the operating procedures in this section.
Follow the instructions safely. It is everyone’s business to provide a safe working environment for their co-workers.
The design and configuration of this conveyor includes safety decals and equipment. Hazard controls and accident
prevention depend on the personnel operating and maintaining the equipment. Their concern, attentiveness and
proper training are crucial.
Many features incorporated into this machine are the result of suggestions made by customers like you. Read this
manual carefully for instructions on how to set it, to provide maximum efficiency.
By following these procedures, in conjunction with a good maintenance program, your Self-Propelled Conveyor
will provide many years of trouble free service.
Section 3: OPERATION
• Read and understand the Operator’s Manual.
Be familiar with all safety decals, before using.
•Place all controls in neutral. Stop the engine and
remove ignition key. Wait for all moving parts
to stop before servicing, adjusting, repairing or
unplugging.
•Clear the area of bystanders, especially children,
before starting.
•Be familiar with machine hazard area. If anyone
enters hazard areas, shut down machine
immediately. Clear the area before restarting.
• Keep hands, feet, hair and clothing away from all
moving and/or rotating parts.
•Do not allow riders on the conveyor when
transporting.
Operating Safety
•Stay away from overhead obstructions and
power lines during operation. Electrocution can
occur without direct contact.
•Do not operate machine when any guards are
removed.
• Chock wheels of conveyor before starting.
•Keep working area clean and free of debris to
prevent slipping or tripping.
•Establish Lock-Out Tag-Out policy for the work
site. Be sure all personnel are trained in and
follow all procedures.
•Lower conveyor to collapsed position for
transporting.

Operator’s Manual: 1600-SP Series Conveyor
3-2 08.2016
a
jl
f
b
Fig 5 - Hopper end of conveyor
3.1 MACHINE COMPONENTS
A diesel engine supplies power to the hydraulics
making this conveyor a self-contained, self-propelled
unit.
A hydraulic motor runs the conveyor belt.
Hydraulic cylinders are used to raise or lower the
hopper and frame.
Components may vary, and their positions may
change depending on the options contained in the
present unit.
The main components, and their general location are
listed below:
a. Conveyor Tube
b. Standard Hopper
c. Discharge Spout
d. Engine
e. Engine, Electrical and Hydraulic Controls
f. Drive Box
g. Hydraulic Motor
h. Hydraulic Reservoir and Fuel Tank
i. Axle and Drive Wheels
j. Mover Kit Steering Wheel
k. Working Lights
l. Hitch
m. Jack Mount
n. Hitch and Jack Storage Plate
o. Document Holder
p. Swing-Out (Optional)
q. Swing-Out Hopper Winch
