Convoy Performance Series Quick start guide

Owner’s / Installaon Manual
Performance Series
M7302HD
LCD COLOR MONITOR
Convoy Technologies 6409 Highview Drive | Fort Wayne, IN 46818 | Ph [phone]
Please read this manual thoroughly before operang the unit, and keep it for further reference.

Owner’s / Installaon Manual
Performance Series
M7302HD
PRECAUTIONS
Convoy Technologies 6409 Highview Drive | Fort Wayne, IN 46818 | Ph [phone]
1. Precauons
Storage and keeping
Do not expose the monitor to excessive heat or cold. The storage temperature of this device is -30 ~+75 C, and the oper
ang temperature is -20 ~+60 C. The Humidity is Rh90%.
Never use this device near a bathtub, wash basin, kitchen, damp basement, swimming pool or similar place.
Never use this device in environments with excessive moisture, dust or smoke.
Avoid dropping or striking this device.
Never puncture, scratch or use abrasive cleaning materials on this device.
The monitor is not designed to be waterproof.
Operang Precauons
Make sure all cables are connected properly observe polarity. Improer cable connecons may damage the monitor. Re
move the power cable connecons when you do not intend to use the unit.

1. Precauons
Maintenance
1. Remove all the cable connecons from the monitor before cleaning the unit.
2. Use a mild household detergent and clean the unit with a slightly damp, so cloth. Never use strong solvents such as thin-
ner or benzene, as they might damage the nish of the device.
This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s en-
closure that may be of sucient magnitude to constute risk of electric shock to persons.
This symbol is intended to alert the user to the presence of important operang and maintenance (servcing) instruc-
ons in the literature accompanying the appliance.
This symbol is intended to alert the user not to waste electrical and electronic equipment.
CAUTION
You are cauoned that any changes or modicaons not expressly approved in this manual could void your warran-
tee and necessitate expensive repairs.
Declaraon of conformity
This device complies with Part 15 of the FCC Rules. Operaon is subject to the following two condi-
ons: This device may not cause harmful interference. This device must accept any interference
received, including interference that may cause under desired operaon.
Owner’s / Installaon Manual
Performance Series
M7302HD
PRECAUTIONS
Convoy Technologies 6409 Highview Drive | Fort Wayne, IN 46818 | Ph [phone]

Owner’s / Installaon Manual
Performance Series
M7302HD
Mounng the Monitor
Convoy Technologies 6409 Highview Drive | Fort Wayne, IN 46818 | Ph [phone]
1) Select a locaon allowing 2” space between monitor and walls, cabinets, or other objects to allow adequate air circulaon
around it. Avoid enclosed spaces, areas with excessive vibraon or subject it to severe impacts.
2) Never use this device in environments with excessive moisture, dust or smoke. Do not place cables where they may be
pinched or stepped on. Monitor is not designed to be waterproof.
3) The device may be powered by a 12 or 24 volt automove baery or vehicle electrical system.
4) Make sure all cables are connected properly, observe polarity. Improper cable connecons may damage the monitor. Remove
the power cable connecons when you do not intend to use the unit.
Aach bracket to monitor here
Installaon Notes: Trigger wire funcon
• Camera 1 and Camera 2 connecons are powered from the monitor
and both work whether or not the trigger wire is connected . When us-
ing the monitor, you may cycle between them to monitor either camera.
When the trigger wire is energized, the monitor automacally switches to view that Camera (Green for Camera 2, White for
Camera 1). When voltage is removed from the trigger wire, monitor returns to previous view.
• If the monitor is o, when the trigger wire is energized, the monitor will turn on to show Camera 2. This safety feature is par-
cularly useful for night driving, as the monitor light can be distracng to the operator. Mode will adjust monitor brightness
in dierent presets.
• Grid bars are available when triggered to assist in backing. They may be turned o in the menu. When there is no voltage on
the trigger wire, the on screen display will show “CAM1” or “CAM2” .
Connecng the Monitor
Cam2 Trigger
Supplied Accessories
Cam1 Trigger (White) +12V~24V DC
1) GND (Black)
2) Power (Red) +12V~24V DC
3) Cam2 Trigger (Green) +12V~24V DC
4) Cam1 Trigger (White) +12V ~24V DC

Owner’s / Installaon Manual
M7302HD Operaon
Convoy Technologies 6409 Highview Drive | Fort Wayne, IN 46818 | Ph [phone]
(1) CAM – Switches between all cameras Connected to Monitor.
(2) MENU – Access Brightness, Contrast, Language, Rotaon, etc., also selects choice
(3) √ - Select buon to conrm video presets (STANDARD, SOFT, VIVID, LIGHT)
(4) buon – For adjusng of Volume, Brightness, Contrast, Language, Rotaon, etc. increase
(5) buon – For adjusng of Volume, Brightness, Contrast, Language, Rotaon, etc. decrease
(6) POWER – Turns monitor On and O.
Pressing MENU opens one feature at a me (Picture, Volume, Language, Mirroring, Video, Opon, Imperial or Metric, Park Setup,
Interval Cong, Cam Delay) and use buons to highlight, MENU to select, and to adjust.
• buons adjust Volume. Aer pressing MENU, they adjust the feature shown.
• To adjust the Aspect Rao from 16:9 to 4:3, select “Opon” in the MENU and use to adjust
• If installing monitor upside down, select Mirroring in the menu and use to adjust Vercle “V”, and if you need to mirror the
image as well, adjust to Vercle and Horizontal “VH”.
123456

Owner’s / Installaon Manual
Troubleshoong
Warranty and Support Informaon
Convoy Technologies 6409 Highview Drive | Fort Wayne, IN 46818 | Ph [phone]
7” TFT-LCD Color Monitor
Input Support: 720P/25 fps;
720P/30 fps;
1080P/25 fps
AHD/NTSC/PAL
Power Supply: Automobile Storage
Baery (9~36V)
Power Consumpon: 4W Max, 0.33amps
Outer Dim (WxHxD): 195(W) x 125(H) x
32(D) mm
Resoluon: 800W x 480H
Contrast: 500:1
Brighness: 800cd/m²
Viewing Angle: 50°V x 70°H
Operang Temperature: -20°C—+70°C,
RH90%
Storage Temperature: -20°C—+65°C,
RH90%
Subject to the provisions described below, this CT product is protected for 1
year against defects in material and workmanship. Should a product fail to
perform as described above within the warranted period, it will be repaired or
replaced with the same or funconally equivalent product by CT. This warrant
does not apply if , in the judgement of CT, the product fails due to damage
from shipment, handling, storage, accident, abuse or misuse, or if it has been
used or maintained in a manner not conforming to product manual instruc-
ons, has been modied in any way. Repair by anyone other than CT or an ap-
proved agent will void this warranty. The maximum liability of CT under this
warranty is limited to the purchase price of the product covered by the warran-
ty. All defecve products should be returned to CT with shipping charges pre-
paid. CT will not accept collect shipments.
Symptom possible Causes/Soluons
No picture. No sound Improper connecon of automobile adapter. Use of un-authorized power supply. Power switch is on OFF posion (Blue light indi-
cates the monitor has power, you sll have to hit the power buon to turn it on).
No picture Check whether locking cable is properly connected.
No sound Check whether locking cable is properly connected, or the sound wolume is set too low
Dark picture Check whether brightness and contrast are adjusted correctly; Check whether the environments temperature is too low.
No color Adjust the color sengs.
Upside down or lateral
inverted picture Use the remote/ MENU-ROTATION buon to set proper orientaon
No reversing funcon
(i.e. Picture) Check the wires (black/ red/ Green) that may be loose
