Cookology FOM55SS User manual

45cm Built-in Electric Oven
Instruction Manual
FOM55SS

1）The appliance is not to be used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction. children being supervised not to
play with the appliance.
2）During use the appliances becomes hot. Care should be taken to avoid touching
heating elements inside the oven, for cooking ranges and ovens.
3）WARNING: Accessible parts may become hot during use. Young children should
be kept away.
4）Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven
door glass since they can scratch the surface, which may result in shattering of the
glass.
5）If during the test of Clause 11, the temperature rise at the centre of the internal
bottom surface of a storage drawer exceeds that specified for handles held for short
periods in normal use, the instruction shall state that these surfaces can get hot.
6）The oven must be switched off before removing the guard and that, after
cleaning, the guard must be replaced in accordance with the instructions.
7）Details indicating the correct installation of the shelves.
8）A steam cleaner is not be used.
9）Ensure that the appliance is switched off before replacing the lamp to avoid the
possibility of electric shock.
10）The appliance must not be installed behind a decorative door in order to avoid
overheating.
11）Disconnection of the appliance after installation, by accessible plug or a switch
in the fixed wiring.
12）If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
13）This appliance should be connected to a circuit which incorporates an isolating
switch which can accessible by the user after installation providing full disconnection
from the power supply. The disconnection may be achieved by incorporating a
Warning

switch in the fixed wiring in accordance with the wiring rules.
14）This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. children shall not
play with the appliance. cleaning and user maintenance shall not be made by
children without supervision.
15）WARNING: The appliance and its accessible parts become hot during use.
16）Care should be taken to avoid touching heating elements.
17）Children less than 8 years of age shall be kept away unless continuously
supervised.
18) This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
Warning
19）If using alcohol in your recipes, please be aware that high temperatures can
cause the alcohol to vaporize and even to ignite on the hot heating elements.
20）When residual heat is used to keep food warm, the high level of humidity and
condensation can cause corrosion in the oven. The control panel, worktop or
furniture unit may also be damaged. Do not switch the oven off completely while
food is inside it , but select the lowest possible temperature for the oven function
you are using. This will ensure the fan will automatically continue to run.
21）Cover any food which is left in the oven to be kept hot, as moisture in the food
could lead to corrosion damage in the oven. This also prevents the food from drying
out.
22）Never cover the floor of the oven with aluminium foil, or place oven dishes, pans,
saucepans or trays directly onto the floor of the oven.
This would cause concentrations of heat which could cause damage to the floor of
the oven.

The oven is exceptionally easy to use and extremely efficient.After reading the instruction
manual,operating the oven will be easy.
Before being packaged and leaving the manufacturer,the oven was thoroughly checked
with regard to safety and functionality.
Before using the appliance,please read the instruction manual carefully.
By following these instructions carefully you will be able to avoid any problems in using
the appliance.
It is important to keep the instruction manual and store it in a safe place so that it can be
consulted at any time.
It is necessary to follow the instructions in the manual carefully in order to avoid possible
accidents.
Caution!
Do not use the oven until you have read this instruction manual.
The oven is intended for household use only.
The manufacturer reserves the right to introduce changes which do not
affect the operation of the appliance.

............................
Safety instructions........................................................................3
How to save energy..................................................................................5
Description of the appliance...............................................................7
Specifications of the applance...........................................................................................
Operation................................................................................................
Cleaning and maintenance............................................................................
Operation in case of emergency.......................................................................
Technical data........................................................................
1
Installation...................................................................................... .........
8
9
1
15
19
20

The appliance becomes hot during operation.Take care not to touch the hot parts
inside the oven.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they do
not play with the appliance.While in operation direct contact with the cooker may cause
burns!
Ensure that small items of household equipment,including connection leads,do not
touch the hot oven or the hob as the insulation material of this equipment is
usually not resistant to high temperatures.
Do not leave the cooker unattended when frying.Oils and fats may catch fire due to
overheating or boiling over.
Do not put pans weighing over 15 Kg on the opened door of the oven and pans
over 25 kg on the hob.
Do not use harsh cleaning agents or sharp metal objects to clean the door as they
can scratch the surface,which could then result in the glass cracking.
Do not use the cooker in the event of a technical fault.Any faults must be fixed by an
appropriately qualified and authorised person.
In the event of any incident caused by a technical fault,disconnect the power and
report the fault to the service centre to be repaired.
NOTE:
Ensure there is a grounded socket nearby(behind the unit)
A dedicated power circuit is recommended for the unit but not required.Additional electrical
appliances on the same circuit may exceed the current(amperage)rating for that
circuit.If after the installation of your unit.the circuit breaker trips or the fuse fails on
a repeated basis,then a dedicated circuit will likely be required.
!The appliance must be installed only by a qualified person in compliance with the
instructions provided.Incorrect installation may cause harm to persons,animals or
may damage property.
The manufacturer declines all responsibility for improper
installation which may harm persons and animals and damage property.
Important:The power supply to the appliance must be cut off before any adjustments or
maintenance work is done on it.
WARNING:
When using this product,basic precautions should always be taken,including the following:
Your built-in oven is a classified electrical appliance.As with any electrical appliance and
particularly with electric heaters,basic precautions must be followed in order to reduce
the risk of fire,burns,electrical shocks and/or other serious injuries or death.

The rules and provisions contained in this instruction manual should be
strictly observed. Do not allow anybody who is not familiar with the contents
of this instruction manual to operate the cooker.
The cooker should not be cleaned using steam cleaning equipment.
The panels adjacent to the oven must be made of heat-resistant material.
Cabinets with a veneer exterior must be assembled with glues which can
withstand temp- erature of up to 100℃.
Keep combustible materials,such
as:curtains,drapes,furniture,pillows,clothing,linens,bedding, paper,etc.,at
least 3 feet(0.9 meters)from the front sides and rear of the heater.Do not
use this unit in areas where gasoline,paint or other flammable liquids or
their associated vapors may be present.
To reduce the risk of fire,do not place or install this unit in areas where the
ventilation or circulation ducts may become blocked.
The unit's power cord must be connected to a properly grounded and
protected,220-240V electrical outlet.Always use ground fault protection where
required by the electrical code.To reduce the risk of fire,avoid running the
power cord under rugs,carpets,etc.Keep the power cord away from high
traffic areas where it may pose as a tripping hazard.
Avoid the use of an extension cord,which may overheat and cause a fire.
When transporting or storing the unit,keep it in a dry location,free from
dust,excessive vibration or other factors,which may damage the unit.
Do not operate any oven with a damaged cord or plug or after the heater
malfunctions,has been dropped or damaged in any manner.Return the oven to
an authorised service centre to be checked.
If the supply cord is damaged, it must be replaced by a special cord or assembly
available from the manufacturer or its service agent.
Use this oven only as described in this manual.Any other use not recommended
by the manufacturer may cause fire,electric shock,or injury to persons.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
Never add cold water to food on a hot universal tray or baking tray or directly
onto food in a hot oven.The steam created could cause serious burns or
scalding and the sudden change in temperature can damage the enamel.
Do not lift the oven by the handle.

Using energy in a respon-
sible way not only saves
money but also helps the
environment.So let's save
energy!And this is how you
can do it:
! Do not uncover the pan too often
(a watched pot never boils!)
Do not open the oven door unnecessarily
often.
! Switch off the oven in good time and
make use of residual heat.
For long cooking times,switch off heating
zones 5 to 10 minutes before finishing
cooking,This saves up to 20% on energy.
Only use the oven when cooking larger
dishes.
Meat of up to 1 kg can be prepared more
economically in a pan on the cooker hob.
! Make use of residual heat from the
oven.
If the cooking time is greater than 40
minutes switch off the oven 10 minutes
before the end time.
Important!When using the timer,set
appropriately shorter cooking times
according to the dish being
prepared.
! Make sure the oven door is properly
closed.
Heat can leak through spillages on the door
seals.Clean up any spillages immediately.
! Do not install the cooker in the direct
vicinity of refrigerators/freezers.
Otherwise energy consumption increases
unnecessarily.

During transportation,protec-
tive packaging was used to
protect the appliance against
any damage.After unpack-
ing,please dispose of all
elements of packaging in a
way that will not cause dam-
age to the environment.
All materials used for packaging the appli-
ance are environmentally friendly;they are
100% recyclable and are marked with the
appropriate symbol.
Caution! During unpacking,the packag-
ing materials(polythene bags,polystyrene
pieces,etc.)should be kept out of reach of
children.
Old appliances should not sim-
ply be disposed of with normal
household waste,but should
be delivered to a collection and
recycling centre for electric and
electronic equipment.A symbol
shown on the product,the
instruction manual or the packaging shows
that it is suitable for recycling.
Materials used inside the appliance are
recyclable and are labelled with information
concerning this.By recycling materials or
other parts from used devices you are making
a significant contribution to the protection of
our environment.
Information on appropriate disposal centres
for used devices can be provided by your
local authority.
UNPACKING DISPOSAL OF THE APPLIANCE
▲
▲

1) Oven function selection knob
2) Temperature control knob
3) Timer
4) Red temperature regulator signal light
5) Yellow function operation signal light
6) Oven door handle
FOM55SS

Deep t a
ry
8

595
580
600
560
415
Min 600
600
Min 38
450
595
23
580
415
450 415
560
9

The oven is manufactured to work with single-
Warning!
All electrical work should be carried out by a
suitably qualified and authorised
eletrician.No alterations or wilful changes in
the electricity supply should be carried out.
Fitting guidelines
phase alternating current(220V-240V/
50Hz).The connection diagram is also found on
the cover of the connection box. Remem-ber
that the connection wire should match the
connection type and the power rating of the
oven.
The connection cable must be secured in a
strain-relief clamp.
Warning!
Remember to connect the safety circuit to the
connection box terminal marked with
.The connection box terminal marked with
.The electricity supply for the oven must have a
safety switch which enables the power to be cut
off in case of emergency.The distance between
the working contacts of the safety switch must
be at least 3 mm.
Before connecting the oven to the power supply
it is important to read the information on the data
plate and the connection diagram.
PE N
N L
L
220V-240V~
10

Before first use
! Remove packaging,clean the interior
of the oven.
! Take out and wash the oven fittings
with warm water and a little washing-
up liquid.
! Switch on the ventilation in the room
or open a window.
! Heat the oven (to a temperature of
250℃, for approx,30 min.),remove any
stains and wash carefully.
Important!
The inside of the oven should only be
washed with warm water and a small
amount of wash-ing-up liquid.
11

Oven functions and operation.
The oven can be warmed up using the bottom
and top heaters. Operation of the oven is
controlled by the oven function knob-to set a
required function you should turn the knob to
the selected position.
as well as the temperature regulator knob
-to set a required function you should turn
the knob to the selected position.
The oven can be switched off by setting both
of these knobs to the position “●”/”○”.
Oven on and off
To set the timer, turn the knob clockwise to the
required time.
12
FOM55SS

13

heating mode.
bottom heater,
e r
i
Fast oven heat-up
Mode of operation:
set the oven function to the position of
set the temperatur egulator knob to the
position of 150℃,
the oven warms up to the temperature of
150℃(or lower if set);the oven reaching
the temperature is s gnalled by the red
light of the temperature regulator going
off,
now put the tray with dough into the oven,
set the oven function knob to the selected
Important!
1.When the fast oven heat-up
function has been selected, the
chamber should not contain a
baking tray with dough or other
elements that do not constitute
the oven fittings.
2.The fast heat-up function is not
recommended for use with the
programmer set.
3.The oven door shut.
14

S
By ensuring proper cleaning and mainte-
nance of your cooker you can have a sig-
nificant influence on the continuing fault-free
operation of your appliance.
Before you start cleaning ,the cooker must
be switched off and you should ensure that
all knobs are set to the “● ”/”0”posi- tion. Do
not start cleaning until the cooker has
completely cooled.
Caution ! The sharp blade should always
be protected by adjusting the cover (just
push it with your thumb).Injuries are pos-
sible so be careful when using this instru-
ment-keep out of reach of reach of children.
! Ap p ropriate l i g h t cl e a n i n g o r w a s h i n g
products are recommended, such as e.g. any
kind of liquids or emulsions for fat removal. In
particular, special cleaning products such as
COLLO Luneta, Sidol Stahlglanz , tahl-Fix for
wa s hi n g an d cl e ani n g an d Ce r a F i x fo r
m a i n t e n a n c a r e r e c o m m e n d e d . I f t h e
recommended products are not available, it is
advisable to use a solution of warm water with
a little washing-up liquid or cleaning products
for stainless steel sinks.
15

Oven
! The oven should be cleaned after every use.
When cleaning the oven the lighting should
be switched on to enable you to see the
surfaces better.
! The oven chamber should only be washed
With warm water and small amount of
washing-up liquid.
! After cleaning the oven chamber wipe it dry.
Caution!
Do not use cleaning products contain-
ing abrasive materials for the cleaning
and maintenance of the glass front
panel.
!steam cleaning:
-pour 250ml of water(1 glass)into a bowl
placed in the oven on the first level from
the bottom,
-close the oven door,
-set the temperature knob to 50℃ ,and
the function knob to the bottom heater
position,
-heat the oven chamber for approximately
30 minutes,
-open the oven door, wipe the chamber
inside with a cloth or sponge and wash us-
ing warm water with washing-up liquid.
Ca u t i on! P o s s ibl e m o istu r e or wa t e r
residues under the cooker can result from
steam cleaning.
! After cleaning the oven chamber wipe it
dry.
Replacing of the oven bulb
IMPORTANT: The oven must be
disconnected from your mains supply
before you attempt to either remove or
replace the oven bulb.
!Remove all oven shelves, the drip tray
and the side rack that is on the same side
as the oven light.
!Remove the light cover by turning itanti-
clockwise.
!Unscrew the bulb anti-clockwise and remove
it
from its holder.
!Replace the bulb with a
25 W/300°C,
plugged in type.
!Do not use any other type of bulb.
Place the lamp cover back into position.
16

Removing the doors
a. The oven door is fully open。
b. The latch hinges completely lifted。
c. Gently close the oven door until you
hear the sound of engagement, once
they reach a clamping position, with
both hands holding the door and
continue to push, pull up at the same
time so that the hinge bolt removed from
the oven
a.After cleaning, the hinge is aligned
with the oven door latch push until bite
each other
b.The oven door is fully open and fully
push the latch down to its original
position. Oven door installation
Remove the inner glass panel
b.Remove the fixed block and the top
ends of the plastic ventilation grid.
c. The inner glass pulled out from
beneath plastic fixed block. After
cleaning, the inner glass insert the following
plastic fixed block.
a.Glass door has two plastic fixed
blocks.Use a slotted screwdriver to insert
into the hole of the plastic fixed block and
gently pry it.
17
