APOGEE INTERFACE
The controls for the Apogee are based on Capacitive Touch technology.When
attempting to press the button place your finger on the glass over the symbol for the
feature you desire (i.e. to turn on the unit press the on/off symbol on the glass). \
Power Button:
Use this button to turn the unit on and off
Mode/Select Button:
This button is used to confirm a selection in the menu screens.
Lock Button:
This is button is used to prevent users from adjusting the settings. Press this button
three times and the only button that will work is the Power Button. Unlocking the
mode will require three button presses as well.
Timer Button:
Used to set a specific cook time.
Slider Control:
This button allows you to quickly set your Power Cook settings.
Precision Control Buttons:
These arrow keys allow you to adjust Power Cook and Temperature settings more
precisely.
LCD Information Center:
Displays all vital cooking information and alerts the user of any possible problems.
1
OWNER’S MANUAL INSTALLATION AND OPERATION
ON/OFF LOCK
MODE
(SELECT)
TIMER
LCD
INFORMATION
CENTER
Power Button
Mode/Select Button
Lock Button
Slider Control
Timer Button
Precision Control Buttons
2
OWNER’S MANUAL INSTALLATION AND OPERATION
PREPARING YOUR COOKTEK MAGNAWAVE COOKTOP FOR USE
Before operating your Buffet Wok, do the following:
1. Remove all packing material.
2. Place the unit on a dry, level, hard,stable,and non-flammable surface.
3. Keep unit away from other heat sources and allow at least 2 inches clearance for
air circulation at sides,front and rear of the unit. If either the air intake or exhaust
outlet is blocked,the internal temperature will rise, causing an error code to occur.
Grounding Instructions:
The Buffet Wok must be properly grounded. In the event of an electrical short circuit,
grounding reduces the risk of electric shock by providing a safe path for the electric
current.The Buffet Wok has a power cord with a 3-prong grounding plug, which must
be used in a compatible and properly grounded outlet.It is the owner’s responsibility to
replace any 2-prong wall outlet with a properly grounded 3-prong wall receptacle.
For your safety, never cut, remove,or disable the electrical (ground) connection from the
plug.Never use an adapter plug or an extension cord with the Buffet Wok.
WARNING: Electric shock can result from an improperly grounded plug.Please consult a
qualified electrician if you have any questions about these grounding instructions.
Before You Begin:
Please make sure that this power cord is firmly attached to your CookTek unit BEFORE
plugging the unit into the power receptacle and before attempting operation.
ELECTRICAL INSTALLATION REQUIREMENTS
Every installation site has different electrical wiring.Because many different local codes
exist, it is the Owner and Installer’s responsibility to comply with those codes. CookTek
is not responsible for any consequential damages as a result of failure to comply with
installation requirements.
• Read all installation instructions carefully before starting installation.
• Remove the Buffet Wok carefully from carton.
• Remove all loose packaging and accessories.
• It is the responsibility of the installer to comply with all federal, state and local codes.
• Any installation not matching the specifications discussed in this manual
automatically voids the product’s warranty.
• CookTek recommends that a dedicated electrical line be used for each Buffet
Wok installed.
Electrical circuits should not be shared with any other electrical equipment.
3
OWNER’S MANUAL INSTALLATION AND OPERATION
APPROVED FOR COMMERCIAL USE
CookTek’s MagnaWave Buffet Woks have been tested to be in conformance with UL
197 and CSA C22.2 standards and bear the commercially rated approvals. CookTek’s
Magna Wave Buffet Woks have been tested to be in conformance with the European
Economic Area standards and bear the CE marking signifying European Conformity.
COOKING BY POWER COOK (WATTAGE)
General Operation:
Plug the Buffet Wok into a grounded, single-phase receptacle. Models will run on 100-
120V drawing up to 1800W depending on model, or on 208-240V drawing a maximum
of 3500W depending on the model. Check rating plate on unit to verify correct voltage
and wattage.Voltages below 120V or 240V can result in less than rated power and
slower heating times.
LCD Information Center display when plugged in, but in the OFF position.
NOTE: For proper operation, an independent dedicated circuit should be used for
each unit installed. Each circuit should be protected with a 20 amp circuit breaker.
What to Do:
1. Turn the Buffet Wok “ON”by pressing the Power button on the glass.
2. Adjust your power settings using the slider from 0-100 (MAX), also use the
Precision Control buttons to adjust to more precise power settings.
3. Use your finger on the slider or Precision Control Buttons to adjust the power
levels.The left side will lower power and to the right will increase power.
LCD Information Center will display this when in Cook mode.The pan logo in the upper
right corner indicates a pan is on the unit, if there is an “X” across the pan the unit is
indicating there is a non-induction compatible pan on the unit or no pan at all.
4. To turn the Buffet Wok off, press the power button on the glass and the LCD
information center will display the CookTek logo as in the picture below.
M 3500G
M
PO ER
M
4
COOKING USING THE TIMER SETTINGS
This feature is designed to allow you to cook according to time.This will also give
you an audile alarm for cooking processes that require you to add items after certain
period of time.You will be able to set the timers anywhere from 1 minute to 11hrs and
59 minutes. In the upper left hand corner of the LCD Information Center the unit will
display a clock logo and the set time you have programmed.
NOTE: Any time you are in a menu and you want to get out of screen without
making a selection just press POWER and the unit will turn off and reset.
1. While the unit is powered on press the Timer button.
2. A menu will then be displayed to allow you to select a Cook Timer, Alarm Timer,
or to cancel the timer. Reference the picture below of what the LCD Information
Center will display.
3. Use the Precision Control Buttons to move the cursor up and down to get to
the setting you desire. For example to set the alarm press the Precision Control
button on the left two times.
4. Once you have moved the cursor to your choice, press the Mode/Select button
to move to the next screen which will allow you to set the time. Reference the
picture below of what the LCD Information Center will display.
OWNER’S MANUAL INSTALLATION AND OPERATION
LCD Information Center display when plugged in, but in the OFF position.
MB 3500G
M
TIMER MODE
>CANCEL TIMER
SET COOK TIME
SET ALARM
EXIT
SET COOK TIME
hr min
9OUWILLNOWSELECTYOURTIMEINHOURSMINUTESORBOTH5SETHE0RECISION#ONTROL
"UTTONSTOSELECTYOURDESIREDTIME9OUCANCHOOSEFROMMINUTEUPTOHRS
ANDMINUTES4HESLIDERALSOHASPRESETTIMESPREPROGRAMMEDINTOITTOSELECT
APREPROGRAMMEDTIMEPRESSYOURlNGERONTHESLIDER
!FTERYOUHAVEDETERMINEDYOURDESIREDTIMEPRESSTHE-ODE3ELECTBUTTON
)FYOUHAVESETTHEh#OOK4IMEvITWILLBEGINCOUNTINGDOWNREGARDLESSIFYOUHAVE
APANONTHEUNITORNOT/NCETHETIMEHASEXPIREDTHEUNITWILLBEEPANDTURNOFF
)FYOUHAVESELECTEDTHEh!LARMvTIMETHEUNITWILLCOUNTDOWNTHETIMEREGARDLESS
IFYOUARECOOKINGORNOT7HENTHEALARMGOESOFFTHEUNITWILLBEEPBUTIFTHERE
ISAPANONTHEUNITITWILLCONTINUETOCOOK0RESSTHE4IMERBUTTONTOTURNOFFTHE
TIMERAFTERITHASEXPIRED
4OCANCELTHETIMERYOUHAVESELECTED0RESSTHE4IMERBUTTONANDSELECTTHE
#ANCEL4IMEROPTION
/04)/.3!.$&%!452%33%,%#4)/.
4HISSECTIONWILLDESCRIBEHOWYOUCANCUSTOMIZEYOUR!POGEEUNIT4HEFEATURES
THATWILLBECOVEREDARETHELOCKOUTFEATUREWHICHWILLALLOWYOUTOSETTHEUNITTOA
SPECIlCTEMPERATUREORCOOKINGPOWERANDCANONLYBEADJUSTEDBYUSINGSPECIlCKEY
SEQUENCE4HEOTHERFEATUREWILLALLOWYOUTOCHANGEFROM&AHRENHEITAND#ELSIUS
4OENTERTHE/PTIONSMENUYOUWILLNEEDTODOTHEFOLLOWING
A 4URNTHEUNITOFFSOTHATTHE,#$)NFORMATION#ENTERISDISPLAYINGTHE
#OOK4EKLOGO
B 0LACEYOURlNGERONTHEDOWN0RECISION#ONTROLBUTTONANDCONTINUETO
HOLDYOURlNGERONTHEBUTTONUNTILTHEUNITBEGINSTOBEEP
C !FTERTHEUNITBEGINSBEEPINGREMOVEYOURlNGERFROMTHE0RECISION
#ONTROLBUTTONANDTHENPRESS0OWER.OTE9OUWILLONLYHAVEONETO
TWOSECONDSTOPRESSTHEPOWERBUTTONTOGETINTOTHEMENUSCREEN
D !FTERPRESSING0OWERTHEUNITWILLDISPLAYTHEFOLLOWINGSCREEN
5SETHE0RECISION#ONTROLBUTTONSTOMOVETHECURSORTOTHEDESIREDSETTINGAND
THENPRESSTHE-ODE3ELECTBUTTON
/7.%23-!.5!,).34!,,!4)/.!.$/0%2!4)/.
4HEh3HOW,OCK)NFOvWILLALLOWYOUTODECIDEIFYOUWANTTHEKEYSEQUENCETO
UNLOCKTHEUNITBEVISIBLEWHENTHEUSERPRESSESANYBUTTON
4HEUNITWILLTHENGIVEYOUTHEOPTIONTOHIDEORSHOWTHEKEYSEQUENCEAND
THENTHEUNITWILLCONlRMYOURCHOICE
)FYOUSELECTTHEh2ESETDEFAULTSvOPTIONTHEUNITWILLTHENSETTHESETTINGSTO
SHOWLOCKFEATURE
)NORDERTOLOCKTHEUNITYOUWILLWANTTOPRESSTHE,OCKBUTTONTHREETIMES
4HEUNITWILLBEEPTOINDICATETHATITHASBEENLOCKED
!NYTIMESOMEONETOUCHESAKEYAFTERTHEUNITHASBEENLOCKEDWILLSEEA
MESSAGEONTHE,#$)NFORMATION#ENTERREADINGh,OCKEDv4HEUNITWILLALSO
REMAININ,OCKEDMODEEVENIFTHEUNITISTURNEDOFF4HELOCKMODEMAYBE
RESETBYUNPLUGGINGTHEUNITHOWEVERTHEUNITMUSTBEONWHENDOINGTHISAND
SIMPLYUNPLUGGINGWHILETHEUNITISPOWEREDOFFWILLNOTRESETTHELOCKMODE
4HEUNLOCKSEQUENCEWILLBEDISPLAYEDASAFACTORYDEFAULTANDIFYOUCHANGETO
h(IDE5NLOCKvITWILLNOTBESHOWNWHENTHEh,OCKEDvAPPEARSONTHESCREEN
./4%&ACTORYSETTINGSHAVETHEUNITSTARTIN&AHRENHEITAND3HOW5NLOCKCODE
4HESTANDARDFACTORYUNLOCKCODEREQUIRESTHELOCKBUTTONBEPRESSEDTHREETIMES
TOUNLOCKTHEUNIT
/7.%23-!.5!,).34!,,!4)/.!.$/0%2!4)/.
3%4/04)/.3
3ETTEMPSCALE
2ESETDEFAULTS
3HOWLOCKINFO
%XIT
3HOWUNLOCK
(IDEUNLOCK
7
CARE & CLEANING
Your CookTek Induction Buffet Wok is easy to keep clean. Be sure to follow these easy
instructions:
1. Turn the unit OFF and remove the plug from any power outlets prior to cleaning.
2. When the unit is cool, wipe the surface and body with a damp cloth. Use a mild
scouring agent on the stainless steel housing such as Bon Ami or Barkeeper’s
Friend for greasy or resistant soiling. Do not use a lye-based cleaner, such as an
oven cleaner, as it may damage the Buffet Wok.
3. To clean the glass surface, use a mild detergent or glass Buffet Wok cleansing cream.
4. Never immerse the Buffet Wok in water or put it in the dishwasher.
IMPORTANT INFORMATION
• If a large amount of liquid is spilled onto the Apogee interface it may respond to the
liquid on the interface.Wipe the liquid clean and allow the unit to sit for approximately
2 seconds untouched and normal sensitivity to the buttons will come back.
• Never heat an empty pan, it may damage the Buffet Wok or cookware and overheat
the unit.When overheating occurs, an error code will flash on the LCD Information
Center and the Buffet Wok will shut itself off automatically.When the temperature
returns to normal, the Buffet Wok will start to cook again.
• Remember to turn the Buffet Wok off after each use.
• Keep the Buffet Wok away from gas and electric ranges or open flames. Do not place
in the oven. If the surrounding air temperature is too high, the Buffet Wok will cease
to function properly.
• Be sure to dry off the outside of the pan before use.Otherwise As If the pan temperature
rises,the water droplets on the outside of the pan may begin to boil and spatter.
• Do not touch the ceramic plate (or the top of the Buffet Wok) immediately after use.
The heat from the pan will be transferred to the ceramic plate causing it to be hot to
the touch.
• Do not place any articles on the Buffet Wok other than inductive cookware. For
example, do not place cans on top of the Buffet Wok as they may explode.
• Do not use aluminum foil on top of the Buffet Wok.
• Do not use the Buffet Wok near a faucet,swimming pool, sink, or other areas where
water can be found. Never store the Buffet Wok outside or upside down.
• Do not obstruct, block, or alter the air entrance or outlet. Do not stick foreign objects
into these openings.
• Do not strike or damage the Buffet Wok. Do not put the Buffet Wok in your luggage.
Throwing or dropping the Buffet Wok can damage the internal components or crack
the Buffet Wok, voiding your Warranty. If the Buffet Wok becomes cracked, unplug
immediately and do not use.
OWNER’S MANUAL INSTALLATION AND OPERATION
8
IMPORTANT SAFETY PRECAUTIONS
• To reduce the risk of fire, electric shock, or injury - please read, follow and save all
instructions.
• Never immerse cords, plugs or appliance in water.
• Supervise carefully when appliance is used near children. Keep children away from
appliance when in operation.
• Always unplug appliance immediately after use and allow for cooling time if handling,
transporting, or storing.
• Do not use any appliance that has a damaged cord or plug, or one that has malfunctioned
or been damaged.Consult the warranty and follow instructions for service.
• Do not use any accessories or attachments that are not recommended by the
manufacturer. Use of unapproved accessories may cause injuries and void the warranty.
• The pan on the appliance will heat continuously as long as the power is ON.The pan
will be hot and caution should be exercised when working on or near the appliance.
• Do not let the power cord touch hot surfaces or hang over the edge of the counter.
Do not move the appliance when electric power is connected.
• Do not move the appliance while a hot pan or pan containing hot liquids is on top of
the appliance.
• To disconnect appliance, press the Power button and wait for the CookTek logo to
appear.You may then remove the plug from the outlet.
• Do not use CookTek Induction Buffet Wok for anything other than its intended use
as described in this manual.This unit is designed to heat and cook food and is not
intended for laboratory or industrial use.
• Do not put food or unopened cans on the Buffet Woks surface.
• This product may only be serviced by an authorized service agent or by CookTek
personnel. Do not attempt to open the unit or perform service of any kind. For service
information contact CookTek at 1-312-563-9600.
• This appliance must be grounded.Connect only to a properly grounded outlet. Before
operating, read grounding instructions and Electrical Installation Requirements on Page
3 of this booklet. Do not use an extension cord.
• Do not overcook food or leave appliance unattended while in use.
• In the unlikely event of a grease fire, smother flame by covering pan with a tight-
fitting lid, cookie sheet, or flat tray. DO NOT USE WATER. When the fire is under control,
turn off appliance and unplug from wall.
• Use only with induction-compatible and efficient cookware.
• Place Buffet Wok on a level, hard, stable, non-flammable surface before use.
OWNER’S MANUAL INSTALLATION AND OPERATION
6
WARRANTY STATEMENT
All commercial cooking equipment manufactured by CookTek is warranted against defects
in materials and workmanship for a period of one year from the date of Sale, or 18 months
from the date of shipment from our factory, whichever comes first. IMPORTANT! Keep a
copy of your sales receipt to verify date of purchase. A valid proof of purchase, indicating
Serial Number (s) and date of purchase is required to obtain Warranty Service.This
warranty is for the benefit of the original purchaser and is non-transferable. Any defects
in materials or workmanship, which are brought to the attention of CookTek by written
notification within the aforesaid warranty period will be repaired or replaced, at CookTek’s
discretion, with new or recertified products or parts.THIS IS THE SOLE REMEDY FOR ANY
BREACH OF THIS WARRANTY. IN NO EVENT WILL COOKTEK BE LIABLE FOR DAMAGES OF
ANY KIND,WHETHER DIRECT OR INDIRECT, SPECIAL OR CONSEQUENTIAL.
THIS WARRANTY IS THE COMPLETE AND ONLY WARRANTY, EXPRESS OR IMPLIED IN
LAW OR FACT, INCLUDING BUT NOT LIMITED TO,WARRANTIES OF MERCHANTABILITY,
SUITABILITY, QUALITY, OR FITNESS FOR ANY PARTICULAR PURPOSE.
This warranty is void if it is determined that upon inspection by an authorized service
agent that the equipment has been modified, misused, misapplied, improperly installed,
or damaged in transit or by fire, flood or act of God.Warranty will be considered void if the
serial nameplate has been removed or if the unit has been opened or modified in any way,
or service has been attempted by unauthorized personnel. IMPORTANT! Keep a copy of
your sales receipt to verify date of purchase. A valid proof of purchase,indicating Serial
Number(s) and date of purchase is required to obtain Warranty Service. The prices
charged by CookTek for its products are based upon the limitations in this warranty. Seller’s
obligation under this warranty is limited to the repair of covered defects without charge by
a CookTek factory authorized service agent or one of its sub-service agencies.
To receive Warranty Service, Please call CookTek at 312-563-9600 to obtain an RA number.
This RA number must be printed on the outside of the return shipping container, or on the
address label when returning units for service. Units received without an RA number will
be refused at our shipping dock and may encounter a delay in service. Units must be taken
or shipped to the required authorized service agency with transportation charges prepaid
for service. CookTek will provide return freight.In addition to restrictions contained in this
warranty, specific limitations are shown in the Service Policy and Procedure Guide. Please
save all packaging materials for possible use in shipping. CookTek assumes no liabilities
whatsoever for any damages incurred in transit.This warranty is valid in the continental
United States only if purchased through an authorized Cooktek Representative or Dealer.
This warranty is valid outside of the United States only if purchased through an Authorized
Cooktek International Distributor.Warranty Service is provided only through the Authorized
Agent from which the unit was purchased.
For additional information and other details concerning warranty, please contact our
Service Department at:
In the United States:
CookTek
810 W. Washington Blvd.
Chicago, IL 60607
Tel: (888) 266-5835
Fax: (888) 266-5329
Rev. 03/06
Outside of the United States:
Tel: 1-312-563-9600
Fax: 1-312-432-6220
Worldwide Web:
http://www.CookTek.com 9
TROUBLESHOOTING
Symptom Probable Cause Possible Solution
No Power
(No Lights or
Fan Noise)
Unit Unplugged
No Power to Receptacle
No Power to Receptacle
No Power to Receptacle
No Power to Receptacle
Plug Unit into Appropriate
Receptacle
Make Sure that Receptacle is
Energized
Check Wall Switches
Check Circuit Breaker
Plug a different electronic device
into the receptacle to make sure
that power is present
Pan Does Not Heat Pan is Not Induction Efficient
Pan Diameter is less than 7 inches
Pan Not Centered Over Cooktop Logo
Use Induction Efficient Pan
Use a larger Induction Efficient Pan
Center Pan
Cooktop Suddenly
Stops Heating
Possible Power Brown Out
Circuit Shared with another Electrical
Device
Air Vente Blocked of Insufficient Air
Circulation
Safety Shut-Off Engaged
Assure proper voltage/power
levels
Make sure that the Cooktop is
not sharing a circuit with other
Electrical Devices
Check air vents to make sure that
they are not blocked. Make sure
that there is sufficient air flow
around the appliance.
The Safety Shut-Off will engage
if an empty pan is left on the
Cooktop surface while the unit is
working at full power. Make sure
that the Cooktop surface is clear.
Wait 15-20 minutes for the unit
to reset.
Pan Does Not Get
Hot Enough Even
Though Power Levels
Are Set To Maximum-
Induction Efficient Pan
In Use
Extension Cord In Use
Circuit Shared with Another Electrical
Device
Do Not use extension cords.
Extension cords may affect
the power levels reaching the
appliance
Make sure that the Cooktop is
not sharing a circuit with other
Electrical Devices
Pan Cooks Unevenly.
Does Not maintain
Heat Level, or
Overheats
Pan is Not Induction Efficient
Bottom May Not Be Flat Enough
Pan Not Centered Over Cooktop Logo
Pan Diameter is Less than 7 inches
Use Induction Efficient Pan
Use Flatter Pan
Center Pan
Use a larger Induction Efficient Pan
10
OWNER’S MANUAL INSTALLATION AND OPERATION
Error
Code
Error Cause Displayed Message Troubleshooting
1 Shorted RTD Temperature sensor failed.
Call dealer.
Service Required
2 Opened RTD Temperature sensor failed.
Call dealer
Remove any pans from Buffet
Wok surface and let unit cool.
Then turn unit off, then on.
If problem was temperature
related, the unit will return to
normal operation, otherwise
service is required.
3 Over current (peak) Incompatible Pan. Try different cookware.
Service may be required
4 Open TCO Overheating. Check Airflow.
Unplug, let cool.
Check airflow. Clear air vents.
Listen for fan operation.
5 Air flow blocked Airflow blocked.
Clean grease filter.
Check to ensure the grease filter
is clean and dry.Make certain
there are no foreign objects
blocking air flow.Check the air
filter to ensure that the arrow on
the filter is pointing up.
6 High line voltage Input voltage too high.
Check mains voltage.
To reset, unplug unit, wait 5
seconds, and plug in again.
If problem persists, have an
electrician monitor the line
voltage.
7 Hardware Failure Call dealer for service. Service required.
8 Zero cross failure Call dealer for service Turn unit off, then on. Plug unit
into outlet on different circuit
breaker. If problem persists,
service is required on device.
9 Clock corrupt Reset clock. Reset Clock
10 Pan RTD failure Pan temperature sensor
failed.
RFID Pan needs repair.
Service needed for Pan
11 Tag Communication
failure
Reposition pan & cycle power. Ensure the RFID tag on the pan
is properly located
12 RFID Reader Failure Call dealer for service. Service Required
14 User Interface Error Cycle power. Service Required
16 Critical Error Call dealer for service. Service Required
In the event of a Possible Malfunction, your CookTek MagnaWave Buffet Wok will display
an Error Code on the LCD Information Center and the unit will beep the number of
times indicated by the error. Please consult the following table when encountering an
Error Code.To reset the error conditions remove the pan from the unit and press the
Power button or unplug the unit.
11
OWNER’S MANUAL INSTALLATION AND OPERATION
12
OWNER’S MANUAL INSTALLATION AND OPERATION
20.67 in
52.50 cm
16.16 in
41.05 cm
6.00 in
15.24 cm
19.64 in
49.89 cm
15.13 in
38.43 cm
15.30 in
38.86 cm
19.81 in
50.32 cm
19.64 in
49.89 cm
POWER CORD
6.00 in
15.24 cm
5.89 in
14.96 cm
20.67 in
52.50 cm
FRONT
Manual Translation Addendum
Dutch
Page 3
Doe het volgende voordat u uw kooktop gaat gebruiken:
1. 1. Verwijder al het verpakkingsmateriaal
2. 2. Zet het toestel op een droge, vlakke, harde, stabiele en onbrandbare ondergrond
3. Houd het toestel uit de buurt van andere warmtebronnen en zorg dat er aan de voor- en achterkant
en de zijkanten minstens 5 cm vrij is voor luchtcirculatie.
Page 3
Voor uw veiligheid mag u nooit de elektrische (massa) aansluiting uit de stekker snijden, verwijderen
of uitschakelen. Gebruik nooit een aangepaste stekker of een verlengsnoer met de kooktop.
WAARSCHUWING: Een verkeerd geaarde stekker kan u een elektrische schok bezorgen.
Raadpleeg een erkende elektricien als u vragen heeft over deze aardingsinstructies.
Voordat u begint:
Controleer eerst of dit snoer stevig aan uw CookTek-apparaat is bevestigd VOORDAT u de stekker van het
toestel in het stopcontact steekt en u probeert het te gebruiken.
Page 7
. • Raak de keramische plaat (of de bovenkant van de kooktop) nooit onmiddellijk na
gebruik aan. De hitte van de pan wordt op de keramische plaat overgebracht zodat deze heet is bij
aanraking.
Page 9
. • Dit product mag uitsluitend worden gerepareerd door een geautoriseerd servicebedrijf of
door personeel van CookTek. Probeer niet om het toestel open te maken of op enige wijze te repareren.
Neem voor informatie over onderhoud en reparatie contact op met CookTek op 001-312-563-9600.
. • Dit toestel moet worden geaard. Alleen aansluiten op een goed geaard stopcontact. Lees
voor het gebruik de aardingsinstructies en de vereisten voor de elektrische aansluiting op pagina 3 van dit
boekje. Gebruik geen verlengsnoer.
Finnish
Page 3
Ennen keittotason käyttöä toimi seuraavasti:
4. 1. Poista kaikki pakkausmateriaalit.
5. 2. Laita laite kuivalle, tasaiselle, kovalle, tukevalle ja palamattomalle pinnalle.
6. Pidä laite erossa muista lämmönlähteistä ja jätä laitteen sivuille, eteen ja taakse vähintään 10 cm (
2 tuumaa) vapaa tilaa ilmalle kiertää.
Page 3
Turvallisuussyistä älä koskaan leikkaa, irrota tai pura sähköliitoksia (maadoitusjohtoa) pistokkeesta.
Älä koskaan käytä keittotason kanssa sovitinpistoketta tai jatkojohtoa.
VAROITUS: Väärin maadoitettu pistoke voi aiheuttaa sähköiskun. Neuvottele valtuutetun
sähköasentajan kanssa, jos sinulla on kysyttävää näistä maadoitusohjeista.
Ennen kuin aloitat:
Varmista, että tämä virtajohto on tiukasti kiinnitetty CookTek:iin ENNEN laitteen pistokkeen työntämistä
pistorasiaan ja ennen käyttökokeilua.
Page 7
.• Älä koske keraamista levyä (keittotason päällä) heti käytön jälkeen. Astian kuumuus
siirtyy keraamiseen levyyn kuumentaen sen liian kuumaksi koskettaa.
Page 9
.• Tätä tuotetta saa huoltaa ainoastaan valtuutettu huoltopiste tai CookTekin henkilökunta.
Älä yritä avata laitetta ja suorittaa sille minkäänlaisia huoltotoimia. Tietoja huollosta saat soittamalla
CookTekiin numeroon +1-312-563-9600.
.• Tämä laite täytyy suojamaadoittaa. Liitä ainoastaan oikein suojamaadoitettuun
pistorasiaan. Ennen käyttöä lue maadoitusohjeet ja sähköasennusvaatimukset tämän lehtisen sivulta 3. Älä
käytä jatkojohtoa.
French
Page 3
Avant d’utiliser l’appareil Cooktop, effectuer les opérations suivantes :
7. 1. Retirer tous les matériaux d’emballage.
8. 2. Placer l’appareil sur une surface sèche, plane, solide, stable et non inflammable.
9. Placer l’appareil à distance de toute autre sources de chaleur et laisser un espace libre d’au moins
5 cm (2 pouces) des deux côtés, à l’avant et à l’arrière de celui-ci pour permettre la circulation de l’air.
Page 3
Pour votre sécurité, ne jamais couper, déconnecter ou désactiver le raccordement électrique (terre) de la
prise de courant. Ne jamais utiliser un adaptateur ou une rallonge électrique avec l’appareil Cooktop.
MISE EN GARDE : Une prise de courant incorrectement raccordée à la terre engendre un
risque de choc électrique. Pour toute question concernant ces instructions de mise à la terre,
consulter un électricien qualifié.
Avant de commencer :
S’assurer que le câble d’alimentation est solidement fixé à l’appareil CookTek AVANT de raccorder
l’appareil à une prise de courant et d’essayer de le faire fonctionner.
Page 7
. • Ne pas toucher la plaque de céramique (ou la partie supérieure de l’appareil Cooktop)
immédiatement après utilisation. La chaleur de la casserole se transmet à la plaque de céramique, aussi
celle-ci est chaude au toucher.
Page 9
. • L’entretien de cet appareil ne peut être effectué que par un réparateur agréé ou par un
membre du personnel de CookTek. Ne jamais essayer d’ouvrir l’appareil ni de le réparer. Pour des
informations concernant l’entretien, contacter CookTek au +1-312-563-9600.
. • Cet appareil doit être raccordé à la terre. Le brancher exclusivement à une prise de
courant correctement raccordée à la terre. Avant utilisation, lire les instructions de raccordement à la terre,
ainsi que les exigences en matière d’installation électrique figurant à la page 3 du présent manuel. Ne pas
utiliser de câble de rallonge.
German
Page 3
Vor Inbetriebnahme des Cooktop verfahren Sie bitte wie folgt:
10. 1. Entfernen Sie das gesamte Verpackungsmaterial.
11. 2. Stellen Sie das Gerät auf eine trockene, ebene, harte, stabile und nicht brennbare Fläche.
12. Halten Sie das Gerät von anderen Wärmequellen fern und lassen Sie um das Gerät herum (vorne,
hinten und seitlich) mindestens 5 cm für die Luftzirkulation frei.
Page 3
Zu Ihrer eigenen Sicherheit darf das Erdungskabel keinesfalls vom Stecker abgetrennt, entfernt oder in
schadhaftem Zustand verwendet werden. Benutzen Sie für Ihren Cooktop niemals einen Steckeradapter
oder ein Verlängerungskabel..
WARNHINWEIS: Ein nicht fachgemäß geerdeter Stecker kann zu einem Stromschlag führen. Falls
Sie noch Fragen zu diesen Anweisungen in Zusammenhang mit Schutzkontakt und Erdung haben,
wenden Sie sich bitte an einen Elektrofachmann.
Bevor Sie beginnen:
Dieses Netzkabel muss fest mit dem CookTek verbunden sein, BEVOR Sie das Gerät an die Steckdose
anschließen und es in Betrieb nehmen.
Page 7
. • Berühren Sie die Keramikplatte (oder Oberfläche des Cooktop) nicht unmittelbar nach
Gebrauch. Die Hitze der Pfanne überträgt sich auf die Keramikplatte, die dann ebenfalls heiß wird.
Page 9
. • Dieses Produkt darf nur durch bevollmächtigte Wartungstechniker oder das Fachpersonal
von CookTek gewartet werden. Versuchen Sie nicht, das Gerät zu öffnen und selbst zu warten. Nähere
Informationen zur Wartung erhalten Sie bei CookTek unter der Rufnummer 1-312-563-9600.
. • Das Gerät muss geerdet werden. Der Stecker muss in eine ordnungsgemäß geerdete
Steckdose gesteckt werden. Vor dem Öffnen lesen Sie bitte die Anweisungen zu Schutzkontakt/Erdung und
die Anforderungen an die elektrische Installation auf Seite 3 dieses Handbuchs. Verwenden Sie kein
Verlängerungskabel.
Greek
Page 3
ȆȡȚȞ șȑıİIJİ IJȠ Cooktop ıĮȢ ıİ ȜİȚIJȠȣȡȖȓĮ,İțIJİȜȑıIJİ IJĮ ĮțȩȜȠȣșĮ:
13. ǹijĮȚȡȑıIJİ ȩȜĮ IJĮ ȣȜȚțȐ ıȣıțİȣĮıȓĮȢ.
14. ȉȠʌȠșİIJȒıIJİ IJȘ µȠȞȐįĮ ıİ µȚĮ ıIJİȖȞȒ,İʌȓʌİįȘ,ıțȜȘȡȒ,ıIJĮșİȡȒ țĮȚ µȘ İȪijȜİțIJȘ İʌȚijȐȞİȚĮ.
15. ǻȚĮIJȘȡȒıIJİ IJȘ µȠȞȐįĮ µĮțȡȚȐ Įʌȩ ȐȜȜİȢ ʌȘȖȑȢ șİȡµȩIJȘIJĮȢ țĮȚ ĮijȒıIJİ țİȞȩ IJȠȣȜȐȤȚıIJȠȞ 2
ȓȞIJıİȢ (5 İțĮIJȠıIJȐ)ȖȚĮ IJȘȞ țȣțȜȠijȠȡȓĮ IJȠȣ ĮȑȡĮ ıIJĮ ʌȜĮȧȞȐ,IJȠ µʌȡȠıIJȚȞȩ µȑȡȠȢ țĮȚ IJȠ ʌȓıȦ µȑȡȠȢ IJȘȢ
µȠȞȐįĮȢ.
Page 3
īȚĮ IJȘȞ ĮıijȐȜİȚȐ ıĮȢ,ʌȠIJȑ µȘȞ țȩȥİIJİ,ĮijĮȚȡȑıİIJİ Ȓ ĮʌİȞİȡȖȠʌȠȚȒıİIJİ IJȘȞ ȘȜİțIJȡȚțȒ (ȖİȓȦıȘ)
ıȪȞįİıȘ Įʌȩ IJȠ ijȚȢ.ȂȘ ȤȡȘıȚµȠʌȠȚȒıİIJİ ʌȠIJȑ ʌȡȠıĮȡµȠȖȑĮ ijȚȢ Ȓ țĮȜȫįȚȠ ʌȡȠȑțIJĮıȘȢ (µʌĮȜĮȞIJȑȗĮ)
µİIJȠCooktop.
ȆȇȅǼǿǻȅȆȅǿǾȈǾ:DzȞĮ İıijĮȜµȑȞĮ ȖİȚȦµȑȞȠ ijȚȢ µʌȠȡİȓ ȞĮ ȑȤİȚ ȦȢ ĮʌȠIJȑȜİıµĮIJȘȞ
ȘȜİțIJȡȠʌȜȘȟȓĮ.ȆĮȡĮțĮȜİȓıIJİ ȞĮ ıȣµȕȠȣȜİȣIJİȓIJİ ĮȡµȩįȚȠ ȘȜİțIJȡȠȜȩȖȠ İȐȞ ȑȤİIJİ IJȣȤȩȞ İȡȦIJȒıİȚȢ
ıȤİIJȚțȐ µİ ĮȣIJȑȢ IJȚȢ ȠįȘȖȓİȢ ȖİȓȦıȘȢ.
ȆȡȚȞ ȟİțȚȞȒıİIJİ:
ǺİȕĮȚȦșİȓIJİ ȩIJȚ ĮȣIJȩ IJȠ ȘȜİțIJȡȚțȩ țĮȜȫįȚȠ İȓȞĮȚ ıIJĮșİȡȐ ıȣȞįİįݵȑȞȠ ıIJȘ µȠȞȐįĮ CookTek ıĮȢ Ȇȇǿȃ
ıȣȞįȑıİIJİ IJȠ ijȚȢ IJȘȢ µȠȞȐįĮȢ ıİ ȘȜİțIJȡȚțȒ ʌȡȓȗĮ țĮȚ ʌȡȚȞ ʌȡȠıʌĮșȒıİIJİ ȞĮ șȑıİIJİ IJȘ µȠȞȐįĮ ıİ
ȜİȚIJȠȣȡȖȓĮ.
Page 7
.•ȂȘȞ ĮȖȖȓȟİIJİ IJȘȞ țİȡĮµȚțȒ ʌȜȐțĮ (ȒIJȠȐȞȦµȑȡȠȢ IJȠȣ Cooktop) ĮµȑıȦȢ µİIJȐ IJȘ
ȤȡȒıȘ.ǾșİȡµȩIJȘIJĮ Įʌȩ IJȘȞ țȠȚȜȩIJȘIJĮ șĮ µİIJĮijİȡșİȓ ıIJȘȞ țİȡĮµȚțȒ ʌȜȐțĮ.ȍȢ İț IJȠȪIJȠȣ,ĮȣIJȒ șĮ İȓȞĮȚ
ʌȠȜȪ ȗİıIJȒ ȖȚĮ ȞĮ IJȘȞ ĮȖȖȓȟİIJİ.
Page 9
.•ȅȚ İȡȖĮıȓİȢ İʌȚıțİȣȒȢ IJȠȣ ʌȡȠȧȩȞIJȠȢ ĮȣIJȠȪ ʌȡȑʌİȚ ȞĮ ʌȡĮȖµĮIJȠʌȠȚȠȪȞIJĮȚ µȩȞȠ Įʌȩ
İȟȠȣıȚȠįȠIJȘµȑȞȠ ĮȞIJȚʌȡȩıȦʌȠ İʌȚıțİȣȫȞ Ȓ Įʌȩ ʌȡȠıȦʌȚțȩ IJȘȢ CookTek. ȂȘȞ İʌȚȤİȚȡȒıİIJİ ȞĮ ĮȞȠȓȟİIJİ
IJȘ µȠȞȐįĮ Ȓ ȞĮ İțIJİȜȑıİIJİ ȠʌȠȚĮįȒʌȠIJİ İȡȖĮıȓĮ İʌȚıțİȣȒȢ ıİ ĮȣIJȒȞ.īȚĮ ʌȜȘȡȠijȠȡȓİȢ ıȤİIJȚțȐ µİIJȚȢ
İʌȚıțİȣȑȢ,İʌȚțȠȚȞȦȞȒıIJİ µİ IJȘȞ CookTek ıIJȠȞ IJȘȜİijȦȞȚțȩ ĮȡȚșµȩ1-312-563-9600.
•Ǿ ıȣıțİȣȒ ĮȣIJȒ ʌȡȑʌİȚ ȞĮ İȓȞĮȚ ȖİȚȦµȑȞȘ.ȈȣȞįȑıIJİ µȩȞȠ ıİ ıȦıIJȐ ȖİȚȦµȑȞȘ ʌȡȓȗĮ.ȆȡȚȞ IJȘ
ȜİȚIJȠȣȡȖȓĮ,įȚĮȕȐıIJİ IJȚȢ ȠįȘȖȓİȢ ȖİȓȦıȘȢ țĮȚ IJȚȢ ĮʌĮȚIJȒıİȚȢ ȘȜİțIJȡȚțȒȢ İȖțĮIJȐıIJĮıȘȢ ıIJȘ ıİȜȓįĮ 3 IJȠȣ
ʌĮȡȩȞIJȠȢ ijȣȜȜĮįȓȠȣ.ȂȘ ȤȡȘıȚµȠʌȠȚİȓIJİ țĮȜȫįȚȠ ʌȡȠȑțIJĮıȘȢ (µʌĮȜĮȞIJȑȗĮ).
Italian
Page 3
Prima di mettere in funzione il piano cottura, eseguire le seguenti operazioni:
16. Rimuovere tutto il materiale di imballaggio.
17. Collocare l'unità su una superficie asciutta, piana, rigida, stabile e non infiammabile.
18. Tenere l'unità lontana da altre fonti di calore e lasciare almeno 5 centimetri di spazio per consentire la
circolazione dell'aria tutto intorno all'unità.
Page 3
Per la propria sicurezza, non tagliare, rimuovere o disattivare mai il collegamento elettrico di terra dalla
spina. Non utilizzare mai una spina adattatore o un cavo elettrico di prolunga per collegare il piano
cottura.
AVVERTENZA: una spina elettrica non correttamente collegata all'impianto di terra può provocare
scosse elettriche. Rivolgersi a un elettricista qualificato in caso di domande su queste istruzioni di
messa a terra.
Prima di iniziare:
Assicurarsi che questo cavo di alimentazione sia collegato saldamente all'unità CookTek PRIMA di
collegare l'unità alla presa elettrica e prima di metterla in funzione.
Page 7
. Non toccare la piastra di ceramica (o la superficie del piano cottura) subito dopo l'uso. Il calore
della pentola si trasferisce alla piastra di ceramica, rendendola estremamente calda.
Page 9
. Questo prodotto può essere riparato esclusivamente da un tecnico autorizzato o dal centro di
assistenza CookTek. Non tentare di aprire l'unità o di eseguire interventi di manutenzione di alcun tipo. Per
informazioni sull'assistenza, contattare la CookTek al numero 1-312-563-9600.
. Questo apparecchio deve essere collegato a terra. Collegarlo esclusivamente a una presa elettrica
dotata di messa a terra. Prima di mettere in funzione l'unità, leggere le istruzioni di messa a terra e i
Requisiti di installazione elettrica a pagina 3 di questo opuscolo. Non utilizzare un cavo elettrico di
prolunga.
Norwegian
Page 3
Før du bruker komfyren, må du gjøre følgende:
19. 1. Fjern all emballasje.
20. 2. Plasser enheten på et tørt, jevnt, hardt, stabilt og brannsikkert underlag.
21. Hold enheten unna andre varmekilder, og la det være minst 5 cm klaring for luftventilasjon på
sidene, foran og på baksiden av enheten.
Page 3
For din egen sikkerhet må du ikke kutte, fjerne eller ødelegge den elektriske (jordede) koplingen fra
kontakten. Ikke bruk en adapterkontakt eller skjøteledning for komfyren.
ADVARSEL: Elektrisk støt kan oppstå fra kontakt som ikke er korrekt jordet. Ta kontakt med en
kvalifisert elektriker dersom du har spørsmål om disse jordingsinstruksene.
Før du begynner:
Kontroller at strømkabelen er satt helt inn i CookTek-enheten FØR du kopler enheten til stikkontakten og
før bruk.
Page 7
. • Den keramiske platen (eller overflaten på komfyren) må ikke berøres umiddelbart etter
bruk. Varme fra kjeler vil overføres til den keramiske platen og gjøre den varm.
Page 9
. • Dette produktet kan bare repareres av en autorisert serviceagent eller av CookTek-
ansatte. Ikke prøv å åpne enheten eller utføre reparasjoner av noe slag. For serviceinformasjon, kontakt
CookTek på tlf. 1-312-563-9600.
. • Dette produktet må jordes. Må kun koples til et korrekt jordet støpsel. Før bruk bør du
lese jordingsinstruksene og kravene til elektrisk installasjon på side 3 i denne veiledningen. Ikke bruk
skjøteledning.
Polish
Strona 3
Przed rozpoczĊciem uĪywania urządzenia Cooktop, naleĪy wykonaüponiĪsze czynnoĞci:
22. 1. Usunąü wszystkie elementy opakowania.
23. 2. Ustawiüurządzenie na suchej, poziomej, twardej, stabilnej i niepalnej powierzchni.
24. Ustawiüurządzenie z dala od innych Ĩródeáciepáa i zapewniüwokóáurządzenia wolnąprzestrzeĔ,
co najmniej 0,5 cm, aby umoĪliwiüobieg powietrza
Strona 3
Dla bezpieczeĔstwa uĪytkownika nie wolno nigdy przecinaü, wyjmowaüani wyáączaüpoáączenia
elektrycznego (uziemienia) z wtyczki. Stosując urządzenie Cooktop nie wolno uĪywaüzáącza
poĞredniego ani przedáuĪacza.
OSTRZEĩENIE: NiewáaĞciwe uziemienie wtyczki moĪe spowodowaüporaĪenie prądem
elektrycznym. W przypadku wątpliwoĞci dotyczących instrukcji uziemienia naleĪy skontaktowaüsiĊz
wykwalifikowanym elektrykiem.
Przed rozpoczĊciem uĪywania:
NaleĪy sprawdziü, czy przewód zasilania jest pewnie przymocowany do moduáu CookTek PRZED
podáączeniem urządzenia do gniazdka zasilania i przed rozpoczĊciem jego uĪywania.
Strona 7
. • Nie dotykaüpáyty ceramicznej (lub wierzchniej czĊĞci urządzenia Cooktop) bezpoĞrednio
po zakoĔczeniu jego uĪywania. Wysoka temperatura patelni moĪe przenosiüsiĊna páytĊceramiczną,
stwarzając moĪliwoĞü oparzenia w przypadku jej dotkniĊcia.
Strona 9
.•Obsáuga serwisowa tego produktu moĪe byüprowadzona jedynie przez upowaĪnionego
pracownika serwisu lub przez personel firmy CookTek. Nie podejmowaüsamodzielnej próby otwarcia
urządzenia ani nie wykonywaüĪadnych napraw. Aby uzyskaüinformacje dotyczące obsáugi serwisowej,
naleĪy skontaktowaüsiĊz firmąCookTek pod numerem 1-312-563-9600.
. • Niniejsze urządzenie wymaga uziemienia. Podáączaüjedynie do wáaĞciwie uziemionego
gniazda. Przed uĪyciem naleĪy przeczytaüinstrukcjĊdotyczącąuziemienia oraz czĊĞü „Wymogi instalacji
elektrycznej” na stronie 3 niniejszej ulotki. Nie uĪywaüprzedáuĪacza.
Portuguese
Page 3
Table of contents
Other CookTek Cooktop manuals
CookTek
CookTek MW1800G User manual
CookTek
CookTek MagnaWave MC1800 Operating instructions
CookTek
CookTek MC1800G User manual
CookTek
CookTek MagnaWave MC1800 User manual
CookTek
CookTek MagnaWave MC1500 Safety guide
CookTek
CookTek MCD1800G User manual
CookTek
CookTek MC14004-200 User manual
CookTek
CookTek MC14004-200 User manual
CookTek
CookTek PL362CR-200/240 User manual
CookTek
CookTek MagnaWave MC1800 Installation instructions
