CoolGear CG-7PU313C User manual

USB Type-C 7 Port Hub
with 3 Type-C & 5 Type-A
Ports w/DIN Rail – Surge
Protection
Product Manual
Coolgear, Inc.
Version 1.1
September 2017
Model Number: CG-7PU313C
www.coolgear.com

2 CG-7PU313C – Product Manual
www.coolgear.com
Revision History
Revision Date Author Comments
1.0 3/20/2017 Coolgear Original format
1.1 10/9/2017 Coolgear New Manual Format
About this document
This product manual outlines installation and features of the CG-7PU313C USB Type-C 7
Port Hub with 3 Type-C & 5 Type-A Ports w/DIN Rail – Surge Protection.
Scope
The scope of this manual is to give the user of the product an understanding of its use
with detailed diagrams and verbiage. The manual allows the users to apply the product
to their application.
Intended Audience
This product is intended for use in numerous industries including but not limited to
applications such as; Automotive, Machine Equipment, Kiosk, Office, and others.
Product Support
[email protected]

CG-7PU313C – Product Manual 3
www.coolgear.com
Table of Contents
1. Introduction.........................................................................................................4
1.1 Features .................................................................................................................. 4
1.2 Connector Layout.................................................................................................... 5
1.3 Hardware Installation ............................................................................................. 5
1.4 Checking the Hub Installation................................................................................. 6
1.5 Environmental Specifications ................................................................................. 6
2. Notes, Tips, Warnings, and Safety.........................................................................7
3. Supporting References .........................................................................................8
Table of Figures
Figure 1 – Connector Layout…………………………………………………………………………………………..5
Figure 2 – Device Manager……............................................................................................6
Figure 3 – 2-Pin Power Connector Diagram…………………………………………………………………….8

4 CG-7PU313C – Product Manual
www.coolgear.com
1. Introduction
USB 3.1 USB-C hub incorporates 5 USB Type-A and 2 USB-C reversible ports downstream
and 1 USB-C Upstream port. This is a great hub choice for applications that need USB 3.1
5Gbps data speeds and multiple mounting options. It is backward compatible with USB
2.0/1.1 compliant host using its RISC-like USB controller.
WEIGHT .7 lbs
DIMENSIONS 5.23”(L) x 2.42”(W) x 1.43”(H) (13.30 x 6.15 x 3.63 cm)
UPC 045079158771
WARRANTY 1 year from date of purchase
COLOR Black
DOWNSTREAM PORTS 7 USB 3.1 (2 Type-C and 5 Type-A)
UPSTREAM PORTS 1 USB 3.1 Type-C Port
1.1 Features
•Compliant with USB 3.1 Gen 1
Specifications
•Provides 1 USB3.1 Gen 1 Upstream
Port with USB-C connector
•Provides 7 USB3.1 Gen 1 Downstream
Facing Ports (with 2 USB-C and 5 USB-A
Connectors) which manage up to
5Gbps
•Full-Featured USB-C Port Enables
Reversible Plug Orientation and Cable
Direction
•Supports 5Gbps, 480Mbps, 12Mbps
and 1.5Mbps Speed
•Includes a Mounting bracket for flat
surface mounting i.e. under desk, on
walls or tech bench
•Supports Multi Transaction Translators
per Hub
•Supports Wide Range Input (+7~48V
DC) Self-power Mode from the
Terminal Blocks (power adapter sold
separately)
•Supports 15KV ESD Surge Protection
for Each Port.
•Supports a 2-pin Terminal Block
Connector for external power input
from AC adapter

CG-7PU313C – Product Manual 5
www.coolgear.com
1.2 Connector Layout
Figure 1
USB C Upstream Port USB C Downstream Port Self Power Input
Type-C connector from
upstream USB 3.1 port. It is
connected from host or
another USB 3.1 hub’s
downstream facing ports.
The two small 24-pin USB-C
connectors are fully
reversible-plug connectors
for USB devices and USB
cabling.
This 2-pin (one pin for
positive voltage and the
other pin is GND) terminal
block connector is used to
connect strong power to
self-power the hub; the
voltage can be in the range
from +7V to 24VDC.
1.3 Hardware Installation
1. Use static electricity discharge precautions. Remove possible static
discharge potential from any objects that the hub may come in contact with
before installation. This can be accomplished by touching a bare metal
chassis rail after you have turned off the power.
2. Apply DC power (range from +7V to 48V) to the 2-pin Terminal Block
Connector. The hub is bus powered by the upstream USB port (USB-C
connector), This terminal block connector is to add power to ensure enough
power for the 7 downstream ports..
3. Connecting USB Host cables: The host cable could be either a standard A-to-
B USB 3.0 cable or an optional A-to-B USB 3.0 screw-lock cable. Please

6 CG-7PU313C – Product Manual
www.coolgear.com
connect the Type-A end connector of the cable to your PC’s host USB 3.0
port, then insert the type-B end connector to this hub. Since the USB hub is
plug-and-play, you don’t have to turn off your host computer when installing
the hub.
4. Connect the USB Devices to the downstream ports of this hub.
5. Mount your hub on the wall or DIN RAIL if required. Mounting options are
pictured in figure 2 above.
1.4 Checking the Hub Installation
To check the USB hub installation in Windows device manager, please follow the
following steps:
1. Click Start
2. Click Control Panel
3. Click System
4. Click Device Manager
button
5. Double Click Universal
Serial Bus Controller
6. Double click Generic
USB Hub, the
message will show
that this device is
working properly
Figure 2
1.5 Environmental Specifications
Specification Data
Operating Temperature: 0-55°C (32 to 131°F)
Operating Humidity: 5 to 95% RH

CG-7PU313C – Product Manual 7
www.coolgear.com
2. Notes, Tips, Warnings, and Safety
Note
In some cases, during hardware installation, you will see an error message
said that the USB Hub caused the USB bus power over the current limit,
please ignore this message since the hub is hot plug and its power capacitor
will cause a very short period of current. It will NOT affect your USB function.
Reference Section 1.2 Hardware Installation.
Tip N/A
Warning
Please make sure the polarity of the input power should be correctly
matched with the terminal block pins to function properly.
Figure 4
Safety
•Read the entire Product Manual before implementing this product for
your application. This manual contains important information about
electrical connections that must be followed for safe and proper
operation.
•Inspect the product closely for visual defects before putting it to use.
•Keep away from areas where moisture builds, this product contains
electrical components that can be damaged by moisture build up, this
can adversely affect your equipment connected to it.
•Do not disassemble the product. Handling the product’s internal
components can expose it to ESD (Electro-Static Discharge) hazards
that can affect the function of the device.
•If this product is not functioning properly, email our support team at
[email protected].

8 CG-7PU313C – Product Manual
www.coolgear.com
3. Supporting References
Document Link
Website Product Page https://www.coolgear.com/product/usb-c-7-
port-hub-3x-type-c-5x-type-a-din-rail-surge-
protection
