CoolGear CG-7U3DS User manual

7-Port USB 3.0 Metal Hub
with Surge Protection
Product Manual
Coolgear, Inc.
Version 1.1
September 2017
Model Number: CG-7U3DS
www.coolgear.com

2 CG-7U3DS – Product Manual
www.coolgear.com
Revision History
Revision Date Author Comments
1.0 07/14/2015 Coolgear Original format
1.1 10/4/2017 Coolgear New Manual Format
About this document
This product manual outlines installation and features of the CG-7U3DS 7-Port USB 3.0
Metal Hub with Surge Protection.
Scope
The scope of this manual is to give the user of the product an understanding of its use
with detailed diagrams and verbiage. The manual allows the users to apply the product
to their application.
Intended Audience
This product is intended for use in numerous industries including but not limited to
applications such as; Automotive, Machine Equipment, Kiosk, Office, and others.
Product Support
[email protected]

CG-7U3DS – Product Manual 3
www.coolgear.com
Table of Contents
1. Introduction.........................................................................................................4
1.1 Features .................................................................................................................. 4
1.2 Connector Layout.................................................................................................... 5
1.3 Hardware Installation ............................................................................................. 5
1.4 Checking the Hub Installation................................................................................. 6
1.5 Environmental Specifications ................................................................................. 6
2. Notes, Tips, Warnings, and Safety.........................................................................7
3. Supporting References .........................................................................................8
Table of Figures
Figure 1 – Connector Layout…………………………………………………………………………………………..5
Figure 2 – Device Manager……………………………………………………………………………………………..6

4 CG-7U3DS – Product Manual
www.coolgear.com
1. Introduction
The CG-7U3DS is a 7-Port USB 3.0 Hub that complies with the Universal Serial Bus 3.0
(USB 3.0) Specifications Revision 1.0 and performs at up to 5Gbps Super-Speed. The Hub
is DIN-Rail mountable and supports DC-Jack for +12V DC power input.
WEIGHT .637 lbs
DIMENSIONS 6.83”(L) x 2.35”(W) x 0.92”(H) (17.35 x 5.96 x 2.34 cm)
UPC 736983900340
WARRANTY 1 year from date of purchase
COLOR Black
DOWNSTREAM PORTS 7 USB 3.0 Type-A Ports
UPSTREAM PORTS 1 USB 3.0 Type-B Port
1.1 Features
•Compliant with USB 3.0 Specification
Revision 1.0
•Windows XP, 7, 8, 10 Supported
•Built-in RISC-like USB 3.0 Hub
Controller Chips
•Metal Case, Ideal for Critical
Applications
•One Up-stream Port (Type-B) Support
Super-speed, High-speed and Full-
Speed
•7 Down-stream Ports (Type-A) Support
Super-Speed, High-Speed, Full-speed
and Low-speed Traffic
•Supports DC-Jack for +12V DC Power
Input
•
Supports 5Gbps (Super-speed),
480Mbps (High-Speed), 12Mbps (Full-
speed) and 1.5Mbps (Low-speed)
Speed
•Supports 7 Concurrent Non-periodic
Transactions
•Supports Self-powered and Bus-
powered Mode
•Supports 900mA USB Bus Power for
Each Port
•Support USB Battery Charging: CDP and
DCP mode
•Supports 7 Port 350-Watt Surge
Protection
•Optional DIN RAIL Mounting Kit

CG-7U3DS – Product Manual 5
www.coolgear.com
1.2 Connector Layout
Figure 1
USB 3.0 Upstream Port USB 3.0 Downstream Port Self Power Input
Type-B connector from
upstream USB 3.0 port. It is
connected from host or
another USB 3.0 hub.
Supports both normal and
screw-lock type USB cables
on Type-B port only.
There are 7 Type-A
connectors for USB 3.0,
USB 2.0 or USB 1.1 devices.
They support normal Type-
A USB cables (non screw
lock).
This 2-pin (one pin for
positive voltage and the
other pin is GND) terminal
block connector is used to
connect strong power to
self-power the hub.
1.3 Hardware Installation
1. Use static electricity discharge precautions. Remove possible static
discharge potential from any objects that the hub may come in contact with
before installation. This can be accomplished by touching a bare metal
chassis rail after you have turned off the power.
2. Apply +12V DC power to the DC Jack Connector. The hub is self-powered by
this connector.
3. Connecting USB Host cables: The host cable could be either a standard A-to-
B USB 3.0 cable or an optional A-to-B USB 3.0 screw-lock cable. Please
connect the type-A end connector of the cable to your PC’s host USB 3.0
port, then insert the type-B end connector to this hub. Since the USB hub is
plug-and-play, you don’t have to turn off your host computer when installing
the hub.

6 CG-7U3DS – Product Manual
www.coolgear.com
4. Connect the USB Devices to the downstream ports of this hub.
5. Mount your hub on the wall or DIN RAIL if required.
1.4 Checking the Hub Installation
To check the USB hub installation in Windows device manager, please follow the
following steps:
1. Click Start
2. Click Control Panel
3. Click System
4. Click Device Manager
button
5. Double Click Universal
Serial Bus Controller
6. Double click Generic
USB Hub, the
message will show
that this device is
working properly
Figure 2
1.5 Environmental Specifications
Specification Data
Operating Temperature: 0-55°C (32 to 131°F)
Operating Humidity: 5 to 95% RH

CG-7U3DS – Product Manual 7
www.coolgear.com
2. Notes, Tips, Warnings, and Safety
Note N/A
Tip N/A
Warning Please make sure the polarity of the input power should be correctly
matched with the terminal block pins to function properly.
Safety
•Read the entire Product Manual before implementing this product for
your application. This manual contains important information about
electrical connections that must be followed for safe and proper
operation.
•Inspect the product closely for visual defects before putting it to use.
•Keep away from areas where moisture builds, this product contains
electrical components that can be damaged by moisture build up, this
can adversely affect your equipment connected to it.
•Do not disassemble the product. Handling the product’s internal
components can expose it to ESD (Electro-Static Discharge) hazards
that can affect the function of the device.
•If this product is not functioning properly, email our support team at
[e-mail].

8 CG-7U3DS – Product Manual
www.coolgear.com
3. Supporting References
Document Link
Website Product Page https://www.coolgear.com/product/7-port-
usb-3-metal-hub-with-surge-protection
