Cooper & Hunter CH-S09FTXC User manual

MODELS:
CH-S09FTXC
CH-S12FTXC
CH-S18FTXC
CH-S24FTXC
(Refrigerant R32)

CONTENT
1. Safety Precautions ...................................................................................... 1
2. Specifications .............................................................................................. 2
2.1 Unit Specifications ................................................................................ 2
2.2 Operation Characteristic Curve .......................................................... 6
2.3 Capacity Variation Ratio According to Temperature ......................... 6
2.4 Cooling and Heating Data Sheet in Rated Frequency ....................... 7
3. Construction Views ..................................................................................... 8
3.1 Indoor Unit ............................................................................................ 8
3.2 Outdoor Unit ......................................................................................... 9
4. Refrigerant System Diagram .................................................................... 10
5. Schematic Diagram ................................................................................... 10
5.1 Electrical Wiring .................................................................................. 10
6. Function and Control ................................................................................ 12
6.1 Remote Control Operations ............................................................... 12
6.2 Description of Each Control Operation ............................................. 16
7. Installation Manual .................................................................................... 18
7.1 Notices for Installation ....................................................................... 18
7.2 Installation Dimension Diagram ....................................................... 20
7.3 Installation Indoor Unit ...................................................................... 21
7.4 Installation Outdoor Unit ................................................................... 24
7.5 Check after installation ...................................................................... 27
7.6 Test operation ..................................................................................... 27
7.7 Configuration of connection pipe ..................................................... 28
7.8 Pipe expanding method ..................................................................... 29
8. Exploded Views and Parts List ................................................................ 30
8.1 Indoor Unit ........................................................................................... 30
8.2 Outdoor Unit ........................................................................................ 36
9. Troubleshooting ........................................................................................ 42
9.1 Error Code List .................................................................................... 42
9.2 PCB Printed Diagram .......................................................................... 48
9.3 Procedure of Troubleshooting ........................................................... 50
10. Removal Procedure ................................................................................ 68
10.1 Removal Procedure of Indoor Unit ................................................. 68
10.2 Removal Procedure of Outdoor Unit .............................................. 72
Summary and Features
Indoor Unit
Remote Controller Outdoor Unit

1
Safety Precautions
1. Safety Precautions
Installing, starting up, and servicing air conditioner can behazardous due to system pressure, electrical components, and
equipment location, etc.Only trained, qualified installers and service personnel areallowed to install, start-up, and service this
equipment.Untrained personnel can perform basic maintenance fun-ctions such as cleaning coils. All other operations should be
performed by trained service personnel.When handling the equipment, observe precautions in themanual and on tags, stickers,
and labels attached to theequipment. Follow all safety codes. Wear safety glasses andwork gloves. Keep quenching cloth
and fire extinguisher nearby when brazing.Read the instructions thoroughly and follow all warnings orcautions in literature and
attached to the unit. Consult localbuilding codes and current editions of national as well as local electrical codes.
Recognize the following safety information:
◆ Make sure the outdoor unit is installed on a stable, level surface with no accumulation of snow, leaves, or trash beside.
◆ Make sure the ceiling/wall is strong enough to bear the weight of the unit.
◆ Make sure the noise of the outdoor unit does not disturb neighbors.
◆ Follow all the installation instructions to minimize the risk of damage from earth quakes, typhoons or strong winds.
◆ Avoid contact between refrigerant and fire as it generate spoi onous gas.
◆ Apply specified refrigerant onl . Never have it mixed with any other refrigerant. Never have air remain in the refrigerant line as
it may lead to rupture and other hazards.
◆ Make sure no refrigerant gas is leaking out when installation is completed.
◆ Should there be refrigerant leakage, the density of refrigerant in the air shall in no way exceed its limited value, or it may lead
to explosion.
◆ Keep your fingers and clothing away from any moving parts
◆ Clear the site after installation. Make sure no foreign objects are left in the unit.
◆ Always ensure effective grounding for the unit.
Incorrect handling could result inpersonal injury or death. Incorrect handling may result inminor injury,or damage to product
or property.
Warning Caution
Warning Caution
All electric work must be performed by a licensed technician
according to local regulations and the instructions given in
this manual.
Before installing, modifying, or servicing system,
mainelectrical disconnect switch must be in the OFF position.
There may be more than 1 disconnect switch. Lock out and
tag switch with a suitable warning label.
Never supply power to the unit unless all wiring and tubing
are completed, reconnected and checked.
This system adopts highly dangerous electrical voltage.
Incorrect connection or inadequate grounding can cause
personal injury or death. Stick to the wiring diagram and all
the instructions when wiring.
Have the unit adequately grounded in accordance with local
electrical codes.
Have all wiring connected tightly. Loose connection may lead
to overheating and a possible fire hazard
All installation or repair work shall be performed by your
dealer or a specialized subcontractor as there is the risk of
fire, electric shock, explosion or injur .
Never install the unit in a place where a combustible gas
might leak, or it may lead to fire or explosion
Make a proper provision against noise when the unit is
installed at a telecommunication center or hospital.
Provide an electric leak breaker when it is installed in a
watery place.
Never wash the unit with water.
Handle unit transportation with care. The unit should not be
carried by only one person if it is more than 20kg.
Never touch the heat exchanger fins with bare hands
Never touch the compressor or refrigerant piping without
wearing glove.
Do not have the unit operate without air filte .
Should any emergency occur, stop the unit and disconnect
the power immediately.
Properly insulate any tubing running inside the room to
prevent the water from damaging the wall.

32
Specifications
Specifications
2. Specifications
2.1 Unit Specifications
Parameter Unit Value Value
Model -- CH-S09FTXC CH-S12FTXC
Product Code -- SCB001N0610_A0023 SCB001N0620_A0023
Power Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases -- 1 1
Power Supply Mode -- outdoor outdoor
Cross-sectional Area of Power Cable Conductor mm2 1.0 1.0
Recommended Power Cable(Core) N 3 3
Min/Max. Voltage V 198/264 198/264
Cooling Capacity Btu/h 8530 11601
Min. Cooling Capacity Btu/h 1638 2047
Max. Cooling Capacity Btu/h 9895 13307
Heating Capacity Btu/h 9554 12283
Min. Heating Capacity Btu/h 2491 2730
Max. Heating Capacity Btu/h 11260 14330
Cooling Power Input W 775 1055
Min. Cooling Power Input W 125 165
Max. Cooling Power Input W 1430 1560
Heating Power Input W 775 995
Min. Heating Power Input W 165 190
Max. Heating Power Input W 1550 1650
Cooling Current A 3.44.7
Heating Current A 3.4 4.4
Rated Input W 1550 1650
Rated Current A 6.9 7.3
EER W/W 3.23 3.22
COP W/W 3.61 3.62
Air Flow Volume m3/h 520/440/230/150 580/500/300/230
Dehumidifying Volume L/h 0.80 1.40
Dehumidifying Volume PINT/D 1.69 2.96
Application Area m2 12-18 16-24
Indoor Unit
Indoor Unit Model -- CH-S09FTXC CH-S12FTXC
Fan Type -- Cross-flo Cross-flo
Fan Diameter Length(D×L) mm Ф97.5×579 Ф97.5×579
Cooling Speed r/min 1300/1150/750/600 1350/1200/800/650
Heating Speed r/min 1300/1150/850/800 1350/1200/900/850
Fan Motor Power Output W 18 20
Fan Motor RLA A 0.2 0.24
Fan Motor Capacitor μF 1 1.5
Evaporator Form -- Alumium Tube Alumium Tube
Evaporator Pipe Diameter mm φ5 φ5
Evaporator Row-fin Ga mm 2-1.4 2-1.4
Evaporator Coil Length (L×D×W) mm 584.4×22.8×266.7 584.4×22.8×266.7
Swing Motor Model -- 24BJ-A224BJ-A2
Swing Motor Power Output W 1.5 1.5
Fuse Current A 3.15 3.15
Set Temperature Range ℃16~31 16~31
Set Temperature Range ℉61~88 61~88
Sound Pressure Level dB (A) 38/34/21/19 40/35/22/20
Sound Power Level dB (A) 51/47/34/32 53/48/35/33
Dimension (W×H×D) mm 792x279x195 792x279x195
Dimension of Carton Box (W×H×D) mm 868x280x349 868x280x349
Dimension of Package (W×H×D) mm 871x290x352 871x290x352
Stacked Layers - 7 7
Net Weight kg 9 9
Gross Weight kg 11 11
Parameter Unit Value Value
Outdoor Unit
Outdoor Unit Model -- CH-S09FTXC CH-S12FTXC
Compressor Trademark panasonic panasonic
Compressor Model -- 9RS092ZAB21 9RS102ZAA21
Compressor Oil -- FV50S FV50S
Compressor Type -- Rotary Rotary
Compressor LRA. A 20.2 16.5
Compressor RLA A 6.22 6.48
Compressor Power Input W 855 970
Fan Type -- Axial-flowAxial-flow
Fan Diameter mm 405 405
Fan Diameter inch 15.9 15.9
Fan Motor Speed rpm 880 880
Fan Motor Power Output W 30 30
Fan Motor RLA A 0.4 0.4
Outdoor Unit Air Flow Volume m3/h 1800 1800
Condenser Form -- Alumium Tube Alumium Tube
Condenser Pipe Diameter mm φ7 φ7
Condenser Rows-fin Ga mm 1-1.4 2-1.4
Condenser Coil Length (L×D×W) mm 742×19.05×506 719×38.1×506
Permissible Excessive Operating Pressure for the
Discharge Side MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side MPa 2.5 2.5
Maximum Allowable Pressure MPa 4.3 4.3
Cooling Operation Ambient Temperature Range ℃18~52 18~52
Cooling Operation Ambient Temperature Range ℉64~126 64~126
Heating Operation Ambient Temperature Range ℃ -15~24 -15~24
Heating Operation Ambient Temperature Range ℉5~75 5~75
Throttling Method -- Capillary Capillary
Defrosting Method -- Automatic Defrosting Automatic Defrosting
Climate Type -- T1 T1
Climate Zone -- Temperate Zone Temperate Zone
Isolation -- I I
Moisture Protection -- IP24 IP24
Sound Pressure Level dB (A) 52 53
Sound Power Level dB (A) 61 62
Dimension (W×H×D) mm 830X540X325 830X540X325
Dimension of Carton Box (W×H×D) mm 876x585x363 876x585x363
Dimension of Package (W×H×D) mm 879x605x366 879x605x366
Stacked Layers -- 5 5
Net Weight kg 29 30
Gross Weight kg 31.5 32.5
Refrigerant -- R32 R32
Refrigerant Charge kg 0.52 0.78
Connection Pipe
Length m 5 5
Length ft 16.4 16.4
Gas Additional Charge g/m 20 20
Gas Additional Charge oz/ft. 0.2 0.2
Outer Diameter of Liquid Pipe(GREE Allocation)
(Metric) mm φ6 φ6
Outer Diameter of Liquid Pipe(British System
Allocation) inch 1/4" 1/4"
Outer Diameter of Gas Pipe(GREE Allocation)
(Metric) mm φ9.52 φ9.52
Outer Diameter of Gas Pipe(British System
Allocation) inch 3/8" 3/8"
Max Distance Height m 10 10
Max Distance Height ft 32.8 32.8
Max Distance Length m 20 20
Max Distance Length ft 65.6 65.6

54
Specifications
Specifications
Parameter Unit Value Value
Model -- CH-S18FTXC CH-S24FTXC
Product Code -- SCB001N0630_A0023 SCB001N0640_A0023
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases -- 1 1
Power Supply Mode -- outdoor outdoor
Cross-sectional Area of Power Cable Conductor mm2 1.5 2.5
Recommended Power Cable(Core) N 3 3
Min/Max. Voltage V 198/264 198/264
Cooling Capacity W 5270 6450
Cooling Capacity Btu/h 17981 22007
Min. Cooling Capacity Btu/h 3412 4777
Max. Cooling Capacity Btu/h 22860 23884
Heating Capacity Btu/h 18766 22519
Min. Heating Capacity Btu/h 3753 5118
Max. Heating Capacity Btu/h 23202 26955
Cooling Power Input W 1540 1840
Min. Cooling Power Input W 320 380
Max. Cooling Power Input W 2460 2800
Heating Power Input W 1480 1750
Min. Heating Power Input W 350 400
Max. Heating Power Input W 2300 2500
Cooling Current A 7.0 8.9
Heating Current A 6.3 8.4
Rated Input W 2300 2500
Rated Current A 10.2 11.09
EER W/W 3.42 3.51
COP W/W 3.723.77
Air Flow Volume m3/h 850/760/570/480 1090/930/670/560
Dehumidifying Volume L/h 1.80 2.40
Dehumidifying Volume PINT/D 3.80 4.22
Application Area m2 25-36 37-54
Indoor Unit
Indoor Unit Model -- CH-S18FTXC CH-S24FTXC
Fan Type -- Cross-flo Cross-flo
Fan Diameter Length(D×L) mm Ф106×706 Φ108×830
Fan Diameter Length(D×L) inch Φ4 1/6×27 4/5 Φ4 1/4×32 7/10
Cooling Speed r/min 1230/1130/900/800 1250/1100/850/750
Heating Speed r/min 1350/1200/900/850 1250/1100/900/800
Fan Motor Power Output W 40 55
Fan Motor RLA A 0.36 0.47
Fan Motor Capacitor μF 2.5 2.5
Evaporator Form -- Alumium Tube Alumium Tube
Evaporator Pipe Diameter mm Ф7 φ7
Evaporator Pipe Diameter inch 0.276 0.276
Evaporator Row-fin Ga mm 2-1.4 2-1.4
Evaporator Coil Length (L×D×W) mm 715×25.4×304.8 850×25.4×342.9
Swing Motor Model -- 35BJ-A1 35BJ-A1
Swing Motor Power Output W 2.5 2.5
Fuse Current A 3.15 3.15
Set Temperature Range ℃16~31 16~31
Set Temperature Range ℉61~88 61~88
Sound Pressure Level dB (A) 47/44/31/29 48/44/35/33
Sound Power Level dB (A) 58/55/42/40 61/57/48/46
Dimension (W×H×D) mm 972x302x224 1081x327x248
Dimension of Carton Box (W×H×D) mm 1044x304x374 1155x342x410
Dimension of Package (W×H×D) mm 1047x314x377 1158x352x413
Stacked Layers - 7 7
Net Weight kg 13 16
Gross Weight kg 15.5 19
Parameter Unit Value Value
Outdoor
Unit
Outdoor Unit Model --
Compressor Trademark panasonic panasonic
Compressor Model -- 9RD132ZEA21 9RD160ZAA21
Compressor Oil -- FV50S FV50S
Compressor Type -- Rotary Rotary
Compressor LRA. A 2325
Compressor RLA A 6.76.9
Compressor Power Input W 1260 1645
Fan Type -- Axial-flowAxial-flow
Fan Diameter mm 455 522
Fan Diameter inch 17.9 20.6
Fan Motor Speed rpm 850 800
Fan Motor Power Output W 55 60
Fan Motor RLA A 0.67 0.79
Outdoor Unit Air Flow Volume m3/h 2800 3300
Condenser Form -- Alumium Tube Alumium Tube
Condenser Pipe Diameter mm Φ7 φ7
Condenser Rows-fin Ga mm 2-1.4 2-1.4
Condenser Coil Length (L×D×W) mm 869×38.1×572 878×38.1×660
Permissible Excessive Operating Pressure for
the Discharge Side MPa 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side MPa 2.5 2.5
Maximum Allowable Pressure MPa 4.3 4.3
Cooling Operation Ambient Temperature Range ℃18~52 18~52
Cooling Operation Ambient Temperature Range ℉64~126 64~126
Heating Operation Ambient Temperature Range ℃ -15~24 -15~24
Heating Operation Ambient Temperature Range ℉5~75 5~75
Throttling Method -- Capillary Capillary
Defrosting Method -- Automatic Defrosting Automatic Defrosting
Climate Type -- T1 T1
Climate Zone -- Temperate Zone Temperate Zone
Isolation -- I I
Moisture Protection -- IP24 IP24
Sound Pressure Level dB (A) 55 59
Sound Power Level dB (A) 63 68
Dimension (W×H×D) mm 890x598x372 960×700×396
Dimension of Carton Box (W×H×D) mm 938x647x409 1008x742x452
Dimension of Package (W×H×D) mm 941x663x412 1011x763x455
Stacked Layers -- 4 4
Net Weight kg 4043.5
Gross Weight kg 4347
Refrigerant -- R32 R32
Refrigerant Charge kg 0.93 1.05
Connection
Pipe
Length m 5 5
Length ft 16.4 16.4
Gas Additional Charge g/m 20 50
Gas Additional Charge oz/ft. 0.2 0.5
Outer Diameter of Liquid Pipe(GREE Allocation)
(Metric) mm φ6 φ6
Outer Diameter of Liquid Pipe(British System
Allocation) inch 1/4" 1/4"
Outer Diameter of Gas Pipe(GREE Allocation)
(Metric) mm φ12 φ16
Outer Diameter of Gas Pipe(British System
Allocation) inch 1/2" 5/8"
Max Distance Height m 10 10
Max Distance Height ft 32.8 32.8
Max Distance Length m 25 25
Max Distance Length ft 82.0 82.0
CH-S18FTXC CH-S24FTXC

76
Specifications
Specifications
2.2 Operation Characteristic Curve 2.4 Cooling and Heating Data Sheet in Rated Frequency
Model
Rated cooling
condition(°C) (DB/WB)
Pressure of gas pipe
connecting indoor and
outdoor unit
Inlet and outlet pipe
temperature of heat
exchanger
Fan speed of
indoor unit Outdoor fan
mode (rpm)
Indoor Outdoor P (MPa) T1 (°C) T2 (°C)
Super High
09K
27/19 35/24 0.9~1.1 12 to 14 75 to 37
880
12K 880
18k 800
24k 800
Compressor Speed(rps)
Compressor Speed(rps)
Cooling
Heating
Current(A)
Current(A)
0
1
2
3
4
5
6
7
8
9
10
020406080 100 120
WB19 °C
0
1
2
3
4
5
6
7
8
020406080100 12
0
Condition
Indoor:DB 27°C
Indoor air flow: Super High
Pipe length:5m
Voltage:230V
Condition
Indoor:DB 20°C
Indoor air flow: Super High
Pipe length:5m
Voltage:230V
2.3 Capacity Variation Ratio According to Temperature
50
60
70
80
90
100
110
120
130
32 33 34 35 36 37 38 39 40 41 42 43 44 45 46
Capacity ratio(%)
Outdoor temp. (°C)
Capacity ratio(%)
HeatingCooling
HeatingCooling
-20 -15-10 -5 0510
110
120
130
100
90
80
70
60
50
40
Outdoor temp.(°C)
50
60
70
80
90
100
110
120
130
32 33 34 35 36 37 38 39 40 41 42 43 44 45 46
Capacity ratio(%)
Outdoor temp. (°C)
Capacity ratio(
%)
–15–10 –5
110
100
90
80
70
60
50
40
05
710
Conditions
Indoor:DB20°C
Indoor air flow:Super High
Pipe length:5m
Outdoor temp.(°C)
Condition
Indoor:DB27°C WB19°C
Indoor air flow:
High
Pipe length:5m
Condition
Indoor:DB27°C WB19°C
Indoor air flow:
High
Pipe length:5m
Condition
Indoor:DB20°C
Indoor air flow:
High
Pipe length:5m
Heating operation ambient temperature range is -20ºC~24ºC
Heating operation ambient temperature range is -15ºC~24ºC
Model
Rated cooling
condition(°C) (DB/WB)
Pressure of gas pipe
connecting indoor and
outdoor unit
Inlet and outlet pipe
temperature of heat
exchanger
Fan speed of
indoor unit Outdoor fan
mode (rpm)
Indoor Outdoor P (MPa) T1 (°C) T2 (°C)
Super High
09K
20/- 7/6 2.2~2.4 70 to 35 2 to 4
880
12K 880
18k 800
24k 800
T1: Inlet and outlet pipe temperature of evaporator;
T2: Inlet and outlet pipe temperature of condenser;
P: Pressure of air pipe connecting indoor and outdoor units.
NOTES :
(1) Measure surface temperature of heat exchanger pipe around center of heat exchanger path U bent.(Thermistor themometer)
(2) Connecting piping condition : 5m

98
Construction ViewsConstruction Views
3. Construction Views
3.1 Indoor Unit Unit:mm
Model W(mm) H(mm) D(mm)
CH-S09FTXC 792 279 195
CH-S12FTXC 792 279 195
CH-S18FTXC 972 302 224
CH-S24FTXC 1081 327 248
CH-S09FTXC
CH-S12FTXC
CH-S18FTXC
3.2 Outdoor Unit Unit:mm
Model:CH-S09FTXC
CH-S12FTXC
890 310
598
344
550372
W
H
D
540
290
830
762
540
257
325
CH-S24FTXC
Model:CH-S18FTXC

11
Schematic Diagram
10
Construction Views
4. Refrigerant System Diagram
Indoor unit Outdoor unit
COOLING
HEATING
4-Way valve
Discharge
Suction
Heat
exchanger
(evaporator) Heat
exchanger
(condenser)
Valve
Valve
Liquid pipe
side
Gas pipe
side
Strainer Electron
expansion
valve
Strainer
Capillary
Accumlator
Compressor
Refrigerant pipe diameter
Liquid :1/4" (6 mm) Gas : 3/8" (9.52mm)(9、12K); 1/2"(12mm)(18K); 5/8"(16mm)(24K)
5. Schematic Diagram
5.1 Electrical Wiring
Symbol OG WH YE RD YEGN BN BU BK VT
Color symbol ORANGE WHITE YELLOW RED YELLOW GREEN BROWN BLUE BLACK VIOLET
Symbol COMP CT1,2 4V XT
Parts name COMPRESSOR OVERLOAD 4-WAY VALVE TERMINAL BLOCK PROTECTIVE EARTH
Meaning of marks
Model（outdoor):CH-S09FTXC
CH-S12FTXC
CH-S18FTXC
CH-S24FTXC
These circuit diagrams are subject to change without notice, please refer to the one supplied with the unit.
Model（indoor):CH-S09FTXC
CH-S12FTXC
CH-S18FTXC
CH-S24FTXC
960 340
700
368
560396
Model:CH-S24FTXC

1312
Function and Control
Function and Control
6. Function and Control
6.1 Remote Control Operations
Health button
Wi-fi button
I feel button
I feel
Wi-fi
There is no this function for some remote control.

1514
Function and Control
Function and Control
Note:
There is no this function for the units. If press this button, the main unit will sound, but it also runs under original status.
Note:
Note:
I feel button
Optional function, if the model without this function, no feedback from the aircon when press this button
Default WIFI open on remote control , WIFI button for air conditioner WIFI link.
Note:
Health button
Note:
Note:
Note:
Note:
Turn on the back cover of the remote control according to
the counter clockwise direction
Put one unit CR2032 button cell, and make sure the position
of“+”polar and“-”polar are correct.
Re-install the back cover into the remote control according to the back
ockwise direction. And make sure the 2 concave points coincide.

1716
Function and Control
Function and Control
6.2 Description of Each Control Operation
1. The mainboard design with below function
(1) Auto (2) Cooling (3) Dehumidifying (4) Air fan (5) Heating
2. Control
Indoor fan(Quiet、speed 1、speed 2、speed 3、speed 4、speed 5、Turbo), left and right louver, up and down louver, buzzer,
display, outdoor electric heater(option), outdoor power, healthy(option).
3. Basis control function
Cooling mode
(1) Setting Temp 16-31 degree,the indoor fan and louver run as the original mode.
(2) The indoor will run as original mode if the outdoor does not work,and the indoor will show error code.
Fan
(1) Setting Temp 16-31 degree,the indoor fan and louver run as the original mode.
(2) The indoor will run as original mode if the outdoor does not work,and the indoor will show error code.
Heating mode
(1) Setting temperature range 16-31 degree.
(2) It will in anti-cold air first when unit run in heating mode,and then heating.It will blow hot air after unit is o f.
(3) Indoor power light blink and then indoor fan stop after unit entering defrost mode.
(4) Indoor blow hot air one minute if outdoor is malfunction.
(5) Indoor blow hot air 10 minutes after turn off unit when indoor fan is running.
4. Auto mode
(1) When environment temperature is equal or above 26 degree,and setting the cooling mode,the setting temperature will reach
25 degree.
(2)When the environment temperature i is equal or below 19 degree plus additional temperature,it will run in heating mode,and
the setting temperature reach 20 degree at that time.
(3) When 1(9 degree +additional temperature,)<environment temperature<26 degree.It will run in airfan mode if it is the firs time
entering auto mode.It will run in original mode if it change from cooling and heating mode.If original mode is dehumidifying,it will
be in airfan after change into auto mode.
5. Protect
(1)Anti cold air
The louver will be in horizontal level when evaporator temperature is too low,and indoor fan does not work or run in low speed.
(2)Blow hot air
Indoor will run in few minutes before turn off when turn off in heating or indoor temperature above environment temperature.
(3)Sensor malfunction
If the environment sensor or pipe sensor AD is above or equal 250 5s continually or the environment sensor or pipe sensor AD
is below 5 when the unit is on ,it means sensor malfunction.
(4)Motor blockage
When mainboard can not find the indoor fan speed continually,or motor fan run in low speed continually ,compressor outdoor
fan,indoor fan and louver stop running.Indoor will show error code.
(5)Jumper malfunction
Un-install the jumper
(6)Communication malfunction
When the unit is running except for airfan mode,outdoor and indoor can not communicate 3 minutes.It will show error code.
(7)Defrost
When outdoor condensing defrost,it will start defrost mode.
(8)Manually Defrost
Press the "FAN" and "MODE" 3s at the same time in heating mode,it will enter or exit the manually defrost,and indoor will buzz.
6. Other Function
(1) Auto button
when you press this button,it will enter auto mode,indoor motor in auto fan speed,Indoor fan run and louver motor stop. Press
the auto button,unit will be off.
(2) Filter cleaning
Indoor motor fan run 600 hours ,unit will show b3 to notice filter cleaning.The b3 is o f after turn off unit
(3) Health
Indoor healthy function start when push healthy button.
(4) Dry
Unit will run in cooling 10 min after set up dry function.
(5) Saving energy
Indoor will show in ECO after unit run in energy saving mode.
(6) Low temperature heating
Press "MODE" and "+" button at the same time in heating mode,it will show LA.
(7) Environment temperature
push temperature button,it will show environment temperature 5s and the setting temperature.
(8) Outdoor power
Power on,outdoor power is off.
(9) When unit is on except for fan mode,outdoor power supply input high frequency.
(10) Entering off mode or fan mode,outdoor power is off after 4 minutes.
(11) 1W Standby.
7. Display
(1) Basis display,Power on,it maintain 2s-3s display,and then power light is on.
(2) The running light is on when remote controller turn on unit,and indoor show the running mode.
(3) If turn off the light button,and all display is off.
(4) It displays as original mode after setting sleeping function.
1. Press the back side of remote controller marked ①, as shown in the fig, and
then push out thecover of battery box along the arrow direction.
2. Installation two 7# (AAA 1.5V) dry batteries, and make sure the position of
"+" polar and "-" polar are correct.
3. Reinstall the cover of battery box.
Above 2 types remote controllers, each one is available
for choosing.

1918
Installation Manual Installation Manual
7. Installation Manual
7.1 Notices for Installation
Caution
1.The unit should be installed only by authorized service center according to local or government regulations and in compliance
with this manual.
2.Before installing, please contact with local authorized maintenance center. If the unit is not installed by the authorized service
center, the malfunction may not be solved due to incovenient contact between the user and the service personnel.
3.When removing the unit to the other place, please rstly contact with the local authorized service center.
4.Warning: Before obtaining access to terminals, all supply circuits must be disconnected.
5.For appliances with type Y attachment, the instructions shall contain the substance of the following. If the supply cord is
damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid a hazard.
6.The appliance must be positioned so that the plug is accessible.
7.The temperature of refrigerant line will be high; please keep the interconnection cable away from the copper tube.
8.The instructions shall state the substance of the following:This appliance is not intended for use by persons(including
children)with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
7.1.1 Installation Site Instructions
Installing the unit in the following places maycause malfunction. If it is unavoidable, please consult the local dealer:
1.The place with strong heat sources,vapors,flammable or explosive gas,or volatile objects spread in the ai .
2.The place with high-frequency devices (such as welding machine,medical equipment).
3.The place near coast area.
4.The place with oil or fumes in the air.
The place with sulfureted gas.5.
Other places with special circumstances.6.
7.The appliance shall not be installed in the laundry.
1. There should be noobstruction near air inlet and air outlet.
2. Select a location where the condensation water can be dispersed easily and won't affect other people.
3. Select a location which is convenient to connect the outdoor unit and near the power socket.
4. Select a location which is out of reach for children.
5. The location should be ableto withstand the weight of indoor unit and won't increase noise and vibration.
6. The appliance must be installed 2.5m above fioo .
7. Don't install the indoor unit right above the electric appliance.
8. Please try your best to keep way from fluorescent lamp
1.Select a location where the noise and out flow air emitted by the outdoor unit will not a fect neighborhood.
2.The location should be well ventilated and dry, in which the outdoor unit won't be exposed directly to sunlight or strong wind.
3.The location should be able to withstand the weight of outdoor unit.
4.Make sure that the installation follows the requirement of installation dimension diagram.
5.Select a location which is out of reach for children and far away from animals or plants.If it is unavoidable, please add the
fence for safety purpose.
7.1.2 Installation Site of Indoor Unit
7.1.3 Installation Site of Outdoor Unit
7.1.4 Safety Precautions for Electric Appliances
1. A dedicated power supply circuit should be used in accordance with local electrical safety regulations.
2. Don't drag the power cord with excessive force.
3. The unit should be reliably earthed and connected to an exclusive earth device by the professionals.
4. The air switch must have the functions of magnetic tripping and heat tripping to prevent short circuit and overload.
5. The minimum distance between the unit and combustive surface is 1.5m.
6. The appliance shall be installed in accordance with national wiring regulations.
7. An all-pole disconnection switch with a contact separation of at least 3mm in all poles should be connected in fixed wiring
7.1.5 Earthing Requirements
Note:
● Make sure the live wire, neutral wire and earth wire in the family power socket are properly connected.
There should be reliable circuit in the diagram.
● Inadequate or incorrect electrical connections may cause electric shock or fire.
1. Air conditioner is type I electric appliance. Please ensure that the unit is reliably earthed.
2. The yellow-green wire in air conditioner is the earthing wire which can not be used for other purposes. Improper earthing may
cause electric shock.
3. The earth resistance should accord to the national criterion.
4. The power must have reliable earthing terminal. Please do not connect the earthing wire with the following:
● Water pipe
● Gas pipe
● Contamination pipe
● Other place that professional personnel consider is unreliable
5. The model and rated values of fuses should accord with the silk print on fuse cover or related PCB.

2120
Installation Manual Installation Manual
7.3 Installation Indoor Unit
Step 1: Choosing installation location
Recommend the installation location to the client and then confirm it with the client
Step 2: Install wall-mounting frame
1. Hang the wall-mounting frame on the wall; adj ust it in horizontal position with the level meter and then point out the screw fixin
holes on the wall .
2. Drill the screw fixing holes on the wall with impact drill (the specification of drill head should be the same as the plastic
expansion particle) and then fill the plastic expansion particles in the holes.
3. Fix the wall-mounting frame on the wall with tapping screws (ST4.2X25TA) and then check if the frame is firmly inatalled by
pulling the frame.If the plastic expansion particle is loose, please drill another fixing hole nearb .
Step 3: Open piping hole
1. Choose the position of piping hole according to the direction of outlet pipe. The position of piping hole should be a little lower
than the wall-mounted frame, shown as below.
2. Open a piping hole with the diameter of Ф55 on the selected outlet pipeposition.
In order to drain smoothly, slant the piping hole on the wall slightly downward to the
outdoor side with the gradient of 5-10°.
indoor outdoor
5～10°Ф55
Note:
● Pay attention to dust prevention and take relevant safety measures
when opening the hole.
● The plastic expansion particles are not provided and should be
bought locally.
Step 4: Outlet pipe
1.The pipe can be led out in the direction of right, rear right or left. 2.When select leading out the pipe from left or right, please cut
off the corresponding hole on the bottom case.
7.2 Installation Dimension Diagram
09K/12K18K
24K

2322
Installation Manual Installation Manual
Step 5: Connect the pipe of indoor unit
1. Aim the pipe joint at the corresponding bellmouth.
2. Pretightening the union nut with hand.
3. Adjust the torque force by referring to the following sheet. Place the
open-end wrench on the pipe joint and place the torque wrench on the
union nut. Tighten the union nut with torque wrench.
union nutpipe joint pipe
insulating pipe
torque wrench
open-end
wrench
indoor pipe
pipe
union nut
Hex nut diameter Tightening torque (N·m)
Ф 6 15-20
Ф 9.52 30~40
Ф 12 45~55
Ф 16 60~65
Ф 19 70~75
4. Wrap the indoor pipe and joint of connection pipe with insulating pipe,
and then wrap it with tape.
Step 6: Install drain hose
1. Connect the drain hose to the outlet pipe of indoor unit.
2. Bind the joint with tape.
outlet
pipe
drain hose
drain hose
tape
outlet pipe
drain hose
insulating pipe
Note:
● Add insulating pipe in the indoor drain hose in order to prevent condensation.
● The plastic expansion particles are not provided.
Step 7: Connect wire of indoor unit
1. Open the panel, remove the screw on the wiring cover and then take down the cover.
2. Make the power connection wire go through the cable-cross hole at the back of indoor unit and then pull it out from the front
side.
3. Remove the wire clip,connect the power connection wire to the wiring terminal according to the color, tighten the screw and then
fix the power connection wirewith wire clip
4. Put wiring cover back and then tighten the screw.
5. Close the panel.
Note:
● All wires of indoor unit and outdoor unit should be connected by a professional.
● If the length of power connection wire is insufficient, please contact the supplier for a new one. Avoid extending the wire by
yourself.
● For the air conditioner with plug,the plug should be reachable after finishing installation
● For the air conditioner without plug, an air switch must be installed in the line. The air switch should be all-pole parting and
the contact parting distance should be more than 3mm.
Step 8: Bind up pipe
1. Bind up the connection pipe, power cord and drain hose with the band.
2. Reserve a certain length of drain hose and power cord for installation when binding them.
When binding to a certain degree, separate the indoor power and then separate the drain hose.
3. Bind them evenly.
4. The liquid pipe and gas pipe should be bound separately at the end.
Step 9: Hang the indoor unit
1. Put the bound pipes in the wall pipe and then make them pass through the wall hole.
2. Hang the indoor unit on the wall-mounting frame.
3. Stuff the gap between pipes and wall hole with sealing gum.
4. Fix the wall pipe.
5. Check if the indoor unit is installed firmly and closed to the wall
Note:
● Do not bend the drain hose too excessively in order to prevent blocking.
drain hose
band
connection pipe
indoor power cord
Note:
● The power cord and control wire can't be crossed or winding.
● The drain hose should be bound at the bottom.
indoor outdoor
wall pipe
sealing gum
Outdoor unit connection
N(1)
blue
yellow-
green
3
brown
Heat hump type:
black
2

2524
Installation Manual Installation Manual
Step 1: Fix the support of outdoor
Select it according to the actual installation situation
1. Select installation location according to the house structure.
2. Fix the support of outdoor unit on the selected location with expansion screws.
Note:
● Take sufficient protecttive measures when installing the outdoor unit
● Make sure the support can withstand at least four times of the unit weight.
● The outdoor unit should be installed at least 3cm above the the floor in orde
to install drain joint.
● For the unit with cooling capacity of 2300W~5000W, 6 expansion screws are
needed; for the unit with cooling capacity of 6000W~8000W, 8 expansion
screws are needed; for the unit with cooling capacity of 10000W~16000W,
10 expansion screws are needed.
Step 2: Install drain joint
(Only for cooling and heating unit)
1. Connect the outdoor drain joint into the hole on the chassis, as shown in the
picture below.
2. Connect the drain hose into the drain vent.
Step 3: Fix outdoor unit
1. Place the outdoor unit on the support.
2. Fix the foot holes of outdoor unit with bolts.
drain joint
Step 4: Connect indoor and outdoor pipe
union nut
pipe joint
1. Remove the screw on the right handle of outdoor unit and
then remove the handle.
2. Remove the screw cap of valve and aim the pipe joint
at the bell mouth of pipe.
3. Pretightening the union nut with hand. 4. Tighten the union nut with torque wrench by referring to
the sheet below.
liquid valve
gas valve
7.4 Installation Outdoor Unit
Step 5: Connect indoor and outdoor pipe
1. Remove the wire clip; connect the power connection wire and signal control wire (only for cooling and heating unit) to the
wiring terminal according to the color,fix them with screws
2. Fix the power connection wire and signal control wire with wire clip (only for cooling and heating unit).
Note:
● After tighten the screw,pull the power cord slightly to check if it is firm
● Never cut the power connection wire to prolong or shorten the distance.
Step 6: Neaten the pipes
1. The pipes should be placed along the wall,bent reasonably and hidden
possibly. Min.semidiameter of bending the pipe is 10cm.
2. If the outdoor unit is higher than the wall hole, you must set a U-shaped curve
in the pipe before pipe goes into the room, in order to prevent rain from getting
into the room.
Hex nut diameter Tightening torque (N.m)
Ф 6 15~20
Ф 9.52 30~40
Ф 12 45~55
Ф 16 60~65
Ф 19 70~75
Note:
The through-wal height of drain hose shouldn't be higher than the outlet pipe hole of indoor unit.
The water outlet can't be placed in water in order to drain smoothly.

2726
Installation Manual Installation Manual
Use vacuum pump
1. Remove the valve caps on the liquid valve and gas valve and
the nut of refrigerant charging vent.
2. Connect the charging hose of piezometer to the refrigerant
charging vent of gas valve and then connect the other charging
hose to the vacuum pump.
3. Open the piezometer completely and operate for 10-15min to
check if the pressure of piezometer remains in -0.1MPa.
4. Close the vacuum pump and maintain this status for 1-2min to
check if the pressure of piezometer remains in -0.1MPa. If the
pressure decreases, there may be leakage.
5. Remove the piezometer, open the valve core of liquid valve and
gas valve completely with inner hexagon spanner.
6. Tighten the screw caps of valve and refrigerant charging vent.
7. Reinstall the handle.
1. With leakage detector:
Check if there is leakage with leakage detector.
2. With soap water:
If leakage detector is not available, please use soap water for leakage detection.Apply soap water at the suspected position and
keep the soap water for more than 3min. If there are air bubbles coming out of this position, there's a leakage.
liquid valve
gas valve
refrigerant charging
vent
nut of refrigerant
charging vent
vacuum pump
piezometer
valve cap
Lo Hi
inner hexagon
spanner
open
close
Step 7: Vacuum pumping
Step 8：Leakage detection
7.5 Check after installation
Check according to the following requirement after finishing installation.
Items to be checked Possible malfunction
Has the unit been installed firmly The unit may drop, shake or emit noise
Have you done the refrigerant leakage test? It may cause in sufficient cooling(heating)
capacity.
Is heat insulation of pipeline sufficient It may cause condensation and water dripping.
Is water drained well? It may cause condensation and water dripping.
Is the voltage of power supply according to the voltage marked on the
nameplate? It may cause malfunction or damaging the parts.
Is electric wiring and pipeline installed correctly? It may cause malfunction or damaging the parts.
Is the unit grounded securely? It may cause electric leakage
Does the power cord follow the specification It may cause malfunction or damaging the parts.
Is there any obstruction in the air inlet and outlet? It may cause in sufficient cooling(heating)
capacity.
The dust and sundries caused during installation are removed? It may cause malfunction or damaging the parts.
The gas valve and liquid valve of connection pipe are open completely? It may cause in sufficient cooling(heating)
capacity.
7.6 Test operation
1. Preparation of test operation
● The client approves the air conditioner.
● Specify the important notes for air conditioner to the client.
2. Method of test operation
● Put through the power, press ON/OFF button on the remote controller to start operation.
● Press MODE button to select AUTO, COOL, DRY, FAN and HEATto check whether the operation is normal or not.
● If the ambient temperature is lower than 16℃, the air conditioner can’t start cooling.

2928
Installation Manual Installation Manual
7.7 Configuration of connection pipe
1. Standard length of connection pipe
● 5m, 7.5m, 8m.
2. Min. length of connection pipe is 3m.
3. Max. length of connection pipe and max. high difference.
Cooling capacity Max length
of connection pipe
Max height
difference Cooling capacity Max length
of connection pipe
Max height
difference
5000Btu/h(1465W) 15 5 24000Btu/h(7032W) 25 10
7000Btu/h(2051W) 15 5 28000Btu/h(8204W) 30 10
9000Btu/h(2637W) 15 5 36000Btu/h(10548W) 30 20
12000Btu/h(3516W) 20 10 42000Btu/h(12306W) 30 20
18000Btu/h(5274W) 25 10 48000Btu/h(14064W) 30 20
4. The additional refrigerant oil and refrigerant charging required after prolonging connection pipe
● After the length of connection pipe is prolonged for 10m at the basis of standard length, you should add 5ml of refrigerant oil
for each additional 5m of connection pipe.
● Thecalculation methodof additional refrigerant charging amount (onthe basis of liquid pipe):
Additional refrigerant charging amount = prolonged length of liquid pipe × additional refrigerant charging amount per meter
● Basing on the length of standard pipe, add refrigerant according to the requirement as shown in the table. The additional
refrigerant charging amount per meter is different according to the diameter of liquid pipe. See the following sheet.
Additional refrigerant charging amount for R22, R407C, R410A and R134a
Diameter of connection pipe Outdoor unit throttle
Liquid pipe(mm) Gas pipe(mm) Cooling only(g/m) Cooling and heating(g/m)
Ф6 Ф9.52 or Ф12 15 20
Ф6 or Ф9.52 Ф16 or Ф19 15 50
Ф12 Ф19 or Ф22.2 30 120
Ф16 Ф25.4 or Ф31.8 60 120
Ф19 - 250 250
Ф22.2 - 350 350
7.8 Pipe expanding method
Improper pipe expanding is the main cause of refrigerant leakage. Please expand the pipe according to the following steps:
A: Cut the pipe
Confirm the pipe length according to the distance of indoor unit and outdoor unit. Cut the required pipe with pipe cutte .
pipe
pipe cutter
unevenleaning burr
B: Remove the burrs
Remove the burrs with shaper and prevent the burrs from getting into the pipe.
pipe
shaper
downwards
C: Put on suitable insulating pipe
D: Put on the union nut
Remove the union nut on the indoor connection pipe and outdoor valve; install the union nut on the pipe.
union pipe
pipe
E: Expand the port
Expand the port with expander.
expander
hard
mold
pipe
Note:
"A" is different according to the diameter, please refer to the sheet below:
Outer diameter(mm) A(mm)
Max Min
Ф6 - 6.35(1/4") 1.3 0.7
Ф9.52(3/8") 1.6 1.0
Ф12-12.7(1/2") 1.8 1.0
Ф15.8-16(5/8") 2.4 2.2
F: Inspection
Check the quality of expanding port.
If there is any blemish, expand the port again according to the steps above.
smooth surface
the length is equal
improper expanding
leaning damaged
surface
crack uneven
thickness

3130
Schematic DiagramSchematic Diagram
8.1 Indoor Unit
Model: CH-S09FTXC CH-S12FTXC
8. Exploded Views and Parts List
36
NO. Description CH-S09FTXC CH-S12FTXC QTY
product code SCB001N0610 SCB001N0620
1 decorate strip S21200001 S21200001 1
2 panel S20000001 S20000001 1
3 filter subassembly S15420001 S15420001 2
4 panel S20000005 S20000005 1
5 left axile bush S15210003 S15210003 1
6 air louver S15200001 S15200001 1
7 swing louver S15200003 S15200003 1
8 chassis subassembly S21400001 S21400001 1
9 water pan rubber S62600001 S62600001 1
10 bearing rubber ring subassembly S62400001 S62400001 1
11 cross-flow fan S15020002 S15020002 1
12 evaporator angular carriage S21800002 S21800002 1
13 evaporator assembly S10200012 S20210001 1
14 wall frame S10620001 S10620001 1
15 fan motor clamp board S22020002 S22020002 1
16 fan motor S16800001 S16800001 1
17 fan motor clamp board S22020001 S22020001 1
18 drain pipe S1301000101 S1301000101 1
19 step motor S17000001 S17000001 1
20 crank S61200002 S61200002 1
21 swing louver S15200004 S15200004 1
22 axile bush S15210002 S15210002 1
23 electrical box cover 2 subassembly S21420003 S21420003 1
24 screw cap S21830001 S21830001 1
25 electrical box assembly S39901012 S39901013 1
26 Wifi module Y3500000101 Y3500000101 1
27 display board S304100002 S304100002 1
28 electrical box cover shielding cover S11020004 S11020004 1
29 electrical box cover S21420001 S21420001 1
30 tempreature sensor S3300000101 S3300000101 1
31 jumper wire cap S3361000112 S3361000110 1
32 main board S300500044 S300500044 1
33 electrical box S20410001 S20410001 1
34 electrical box shielding cover 2 S11020003 S11020003 1
35 electrical box shielding cover 1 S11020002 S11020002 1
36 remote controller S30400002K023 S30400002K023 1

3332
Schematic DiagramSchematic Diagram
Model:CH-S18FTXC
NO. Description CH-S18FTXC QTY
product code SCB001N0630
1 decorate strip S21200005 1
2 panel S20000008 1
3 screw cap S21830002 3
4 filter subassembly S15420003 2
5 panel S20000007 1
6 left axile bush S15210003 1
7 air louver S15200008 1
8 swing louver S15200007 3
9 chassis subassembly S21400007 1
10 water pan rubber S62600001 1
11 bearing rubber ring subassembly S62400003 1
12 cross-flow fan S15020003 1
13 evaporator angular carriage S21800005 1
14 evaporator assembly S10200004 1
15 wall frame S10620007 1
16 fan motor clamp board S22020004 1
17 fan motor S16800003 1
18 fan motor clamp board S22020007 1
19 connction pipe pressed plate S22020005 1
20 motor stand S22020006 1
21 drain pipe S1301000103 1
22 step motor S17000003 1
23 crank S61200002 1
24 axile bush S15210002 1
25 electrical box cover 2 subassembly S21420006 1
26 electrical box assembly S11800087 1
27 WiFi module Y3500000101 1
28 display board S304100002 1
29 electrical box cover shielding cover S11020007 1
30 electrical box cover S21420005 1
31 tempreature sensor S33000001 1
32 jumper wire cap S3361000122 1
33 main board S300500045 1
34 electrical box S20410004 1
35 electrical box shielding cover 2 S11020006 1
36 electrical box shielding cover 1 S11020005 1
37 remote controller S30400002K023 1

3534
Schematic DiagramSchematic Diagram
Model:CH-S24FTXC
NO. Description CH-S24FTXC QTY
product code SCB001N0640
1 panel S20000011 1
2 decorate strip S21200006 1
3 screw cap S21830002 3
4 filter subassembly S15420004 2
5 panel S20000010 1
6 left axile bush S15210003 1
7 air louver S15200010 1
8 swing louver S15200009 3
9 chassis subassembly S21400008 1
10 water pan rubber S62600001 1
11 bearing rubber ring subassembly S62400003 1
12 cross-flow fan S15020004 1
13 evaporator angular carriage S21800006 1
14 evaporator assembly S10200007 1
15 wall frame S10620017 1
16 fan motor clamp board S22020008 1
17 fan motor S16800008 1
18 connction pipe pressed plate S22020005 1
19 drain pipe S1301000104 1
20 step motor S17000003 1
21 crank S61200002 1
22 axile bush S15210002 2
23 display board S304100002 1
24 electrical box cover 2 subassembly S21420006 1
25 electrical box assembly S11800088 1
26 electrical box cover 1 shielding cover S11020007 1
27 electrical box cover 1 S21420005 1
28 tempreature sensor S33000001 1
29 jumper wire cap S3361000125 1
30 main board S300500046 1
31 WiFi module Y3500000101 1
32 electrical box S20410004 1
33 electrical box shielding cover 2 S11020006 1
34 electrical box shielding cover 1 S11020005 1
35 remote controller S30400002K023 1
