Cooper Lighting COMBOLIGHT Recessed Single-Lamp Fixture User manual

DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
SPECIFICATION FEATURES
www.cooperlighting.com
18” flexible conduit
13.38”
14.20”
19.70”
9.48”
9.95”
11.31”
13.01”
1.70”
9.45”
Required
above
ceiling
45º x 45º
Adjust
Double
Gimbal
6.69”
Thermal
Protector
Perforated
Meshplate
Separate Wiring
Compartment
9.25”
4.10”
Integral Electronic
Metal Halide Ballasts
A ... Housing
Housing and junction box are aluminum,
trimless meshplate is steel with powder
coated finish. Perforated meshplate
allows for trimless installation in drywall/
plaster ceilings by allowing the ceiling’s
mudding compound to be applied right
up to the edge of the fixture opening.
Includes a beveled “knife-edge” lips to
ensure a clean edge. Can accommodate
various ceiling thickness.
B ... System Protection:
Thermal protection provided to guard
against overheating and misuse of
insulation over and around fixture. Vent
holes in housing provide cooler operation.
C... Junction Box
Junction Box is UL listed for through branch
wiring, 6 #12 90º C supply conductors or
60º C for end of run. The fixture is also UL
listed as ‘access above ceiling not required’.
D... Electrical
Integral electronic metal halide ballasts are
mounted in a separate metal enclosure
box attached to the junction box with
18” of flexible conduit. Ballast enclosure
includes a separated wiring compartment
and two knockouts for conduit entry and
features a perforated metal door for easy
maintenance access and cooler operation.
Entire electrical assembly (jbox and ballast
enclosure) is removable from the housing
for easy maintenance.
E ... Lamps
One (1) T6 G12 Metal Halide lamp with
reflector mounted in adjustable double
gimbal. Lamp holder is removable and
may be regressed 1” for additional cut-
off. Lamp can accept up to three optical
accessories (i.e. lens + hex louver +
snoot). 45º x 45º locking lamp adjust-
ment. Beveled-edge lamp ring is secured
with threadless, bayonet action. Optional
retractable arm is available for lamp
pulldown and extreme aiming. Includes
G12 socket.
F ... Mounting
Mounting clips are provided which
mount the housing edge flush with the
finished ceiling line. Mounting clips are
secured to the housing through the
meshplate with screws.
G... Labels
cULus listed for non-type IC
applications, suitable for use in damp
locations.
Ceiling Cut-Out: 7.80” x 7.80”
COMBOLIGHT®
Next Generation
Recessed
Single-Lamp Fixture
One (1) Light
T6 G12 Metal Halide
Remodel Housing
Trimless
ORDERING INFORMATION
An adjustable Single-lamp Recessed fixture for trimless installation suitable for
downlighting and accent applications. Utilizes ONE (1) T6 G12 Metal Halide
lamp.
For remodel applications. Insulation must be kept 3” from all sides and at least
1” above the housing.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
rev 050108
T6 G12 Lamp with Reflectors
This fixture utilizes T6 Metal Halide lamp and includes high-
performance clear aluminum reflectors in narrow, medium,
or wide distributions. Non-standard color reflectors are
available upon request.
Configuration
C1 =COMBOLIGHT
Recessed One (1) Light
Square
Housing
R =Remodel
C1 R E N N
Lamp Type / Wattage Label / Reflector Type
070T6N =70 Watt T6 G12 Metal Halide / Narrow
070T6M =70 Watt T6 G12 Metal Halide / Medium
070T6W =70 Watt T6 G12 Metal Halide / Wide
Power Supply
E =Electronic Metal Halide
Ballast
Power Supply
Voltage
1 =120V
2 =277V
Lamp Mechanism
G =Double Gimbal
R =Retractable Double Gimbal
Trim Finish
N =Trimless
Trim Insert
N =Trimless
Housing Interior/Electrical Door
/Sleeve Finish
W =White
B =Black
S =Industrial Silver
