• Available with Biaxial, T8
and cutting-edge T5 and
T5HO lamps
• Lamps and all hardware
are completely shielded
from view
• Far more efficient than the
competition, the most
efficient Recessed
Direct/Indirect in the
industry
• Available in center-mount
and side mount lamp
shield configurations
• Available in 1, 2, 3 and 4
lamp modules
• High reflectance matte
white finish Painted-after-
Fabrication for optimum
uniformity, efficiency and
glare control
• UL/CUL Listed. Suitable for
damp locations.
• Can be used in drywall
applications in conjunction
with drywall frame kit as
necessary.
RDI SERIES
1' x 2', 1' x 4', 2' x 2'
or 2' x 4'
1, 2, 3 or 4 Lamp
T5, T5HO, T8 or Biaxial
CENTER-MOUNT, SIDE-
MOUNT OR ASYMMETRIC
RECESSED
DIRECT/INDIRECT
NOTES: (1) 2' x 2' and 2' x 4' Center Lamp Shield models only. (2)Products also available in non-US voltages and frequencies for international markets. (3)Not available
when specifying emergencies, voltage must be specific. (4)Not available with Emergency Battery Pack.
For complete product data, reference the Fluorescent Specification binder. Specifications & dimensions subject to change without notice. Consult your Cooper Lighting
Representative for availability and ordering information.
DIMENSIONS DESCRIPTION
The Ovation Series is a
complete family of recessed
direct/indirect luminaires
featuring pleasant modern
architectural styling,
computer-designed optics
and the latest energy efficient
lamp and ballast technology.
The luminaire combines
matte white components and
perforated direct lamp shields
to provide optimum
brightness control. All
components are located
above the ceiling plane for a
clean architectural
appearance in the finished
space. Carefully balanced
design elements combine to
provide an efficient and
exciting alternative to
traditional general lighting.
Ovation is a series of high
performance luminaires
designed for a variety of
architectural applications.
Ovation is an excellent choice
for private offices, conference
rooms, reception areas, retail
stores, libraries, open offices,
airports, classrooms, banks,
restaurants, corridors and
many other commercial
applications.
ORDERING INFORMATION
SAMPLE NUMBER: 2RDI-2BX40RP-120V-EB51-U
Number
of Lamps
(Not included)
1= 1 Lamp
2= 2 Lamp
3= 3 Lamp
4= 4 Lamp
T1=2'x4'
Fixture
with One
Biax Lamp
at Each
End
T2=2'x4'
Fixture
with Two
Biax
Lamps at
Each End
T3=2'x4'
Fixture
with Three
Biax
Lamps at
Each End
Wattage (Length)
17=17W T8 (24")
32=32W T8 (48")
BX40=40W Biax (24")
BX50=50W Biax (24")(1)
BX55=55W Biax (24")(1)
14T5=14W T5 (24")(1) (6)
24T5=24W T5HO (24")(1) (6)
28T5=28W T5 (48")(1) (6)
54T5=54W T5HO (48")(1) (6)
Voltage(2)
120V=120 Volt
277V=277 Volt
347V=347 Volt
UNV=Universal
Voltage 120-277
Lamp Shield
X=Solid Matte White
RP=Round Perforated
White Steel
RP/TBW=Round Perforated
White Steel w/Thin Blade
White Baffle (1)
RP/PLI=Round Perforated
White Steel w/Semi-
Specular Parabolic Baffle(1)
RP/PLMI=Round Perforated
White Steel w/Specular
Parabolic Baffle(1)
RPD=Round Perforated Steel
Below Ceiling Lamp Shield(4)
RPD/TBW=Round Perforated
Below Ceiling Lamp Shield
with Thin Blade White
Baffle(4)
FLS=Frosted Lamp Shield(1)
SLS=Split Lamp Shield(1)
Trim Type
Leave Blank=Grid/Lay-in
(Standard)
Leave
Blank= 1' Width(2)
2= 2' Width
Ovation Series
RDI=Recessed
Direct/Indirect
Leave Blank=Center mounted
Lamps (standard)
S=Side Mounted Lamps
ASY=Asymmetric
Options
GL=Single Element Fuse
GM=Double Element Fuse
Lamps - for lamps installed,
see lamp options table
Flex - for flex installed, see
flex ordering table
Emergency - for EM installed,
see EM options table
Ballast Type(2)
Blank=Standard Magnetic Ballast (40W Biax only)
EB8 = T8 Electronic Instant Start.
Total Harmonic Distortion < 10%
EB8 /PLUS= T8 Electronic Instant Start.
High Ballast Factor >1.13. Total
Harmonic Distortion < 20%
ER8 = T8 Electronic Program Rapid Start.
Total Harmonic Distortion < 10%
EB5 = T5 Biax Electronic Instant Start.
Total Harmonic Distortion < 20%
TEB5 =T5 Biax Electronic Instant Start.
Total Harmonic Distortion < 10%
EBT =T5 Linear Electronic Program Rapid
Start Total Harmonic Distortion < 10%
(For complete details on generic or to specify manufacturer’s
ballast see pg. 469)
No. of Ballast
1, 2 or 3
No. of
Ballast
1, 2 or 3
No. of Ballast
1, 2 or 3
No. of Ballast
1, 2 or 3
No. of Ballast
1, 2 or 3
No. of Ballast
1,2 or 3
Options
(See Options
Section)
Packaging
U=Unit Pack
PALC=Job
Pack, in carton
NOMINAL
SIZE A B
2' x 2' 23-3/4" (603mm) 6" (153mm)
2' x 4' 23-3/4" (603mm) 6" (153mm)
1' x 2' 11-5/8" (295mm) 6" (153mm)
1' x 4' 11-5/8" (295mm) 6" (153mm)
RECESSED STATIC
403
COOPER LIGHTING
COOPER LIGHTING - METALUX®
