Cooper Lighting IRiS M32T User manual

CATALOG#: TYPE:
Specification grade wet listed 32 or 26 Watt triple
tube compact fluorescent fixture rated for use in
wet locations. Regressed frosted lens provides a
low brightness aperture and a smooth illumination
pattern. Triple tube lamps provide excellent color
and long life. Dimming and emergenc ballast
options are available. Lamp module and optical
element can be changed after installation to pro-
ide a ariety of lamp sources and
distributions. e.g. into a PAR36 Adjustable
A...Reflector
.040 thick aluminum specular clear upper and
spun parabolic lower reflector in Clear, Gold,
Haze, Warm Haze, Black Alzak®finish,
painted gloss
white or matte white . Special cone colors listed
below.
B...Flange
Self flange reflector or die cast flange with either
matte white or clear coat finish. Die cast flanges
are easil removed for field painting. Elements are
ke ed for proper insertion. Gasket is a closed cell
foam.
C...Lens
.125 thick frosted lens obscures lamp and is
retained during relamping.
D...Attachment
Positive torsion springs pull flange tight to
ceiling. Mechanical light trap eliminates spill light
at edge of flange or reflector.
E...Socket
4 pin G24q3 base for 32 or 26W PLT, TBX and TTT
lamps. Fatigue free stainless steel spring ensures
positive lamp retention. Fixed socket height
ensures consistent lamp position.
F...Electronic Ballast
Thermall protected, current controlled electronic
ballast produces full light output and rated lamp
life. Meets stringent FCC part 18 Class B
requirements.
G...Electrical
Ke ed quick connect provides eas lamp module
installation.
H...Frame/Housing
Hot dipped galvanized 20 gauge steel frame
with built in 1/2 inch plaster lip Aluminum .032
thick housing allows for heat dissipation and
reduces weight.
I...Junction Box
18 cubic inches, listed for 4#12 AWG or 6#14 AWG
90° C additional feed through conductors, has five
1/2 inch pr outs.
J...Bar Hangers
No Flex®bar hangers with positive locking, for use
with joists spaced up to 24" O.C. ship with plat-
form. For use in T-bar ceilings order accessor
MBCLP. Nailess barb and locator lip provide con-
sistent installation height.
K...Codes
Thermall protected, IP labeled. Unit is airtight
and exchanges less than 2.0 CFM with the plenum
at apressure of 75 pascals. Insulation must be
kept three inches awa from fixture sides and
none on top as to entrap heat.
L...Labels
UL and cUL listed, standard wet label, IBEW union
made.
ADI030825
SPECIFICATION FEATURES
I
B
A
E
G
F
J
H
D
C
M32T=
32/26W
Compact
Flourescent
Ballast
M32T
Lutron =
32W onl
Tu Wire
Dimming
Ballast
ORDERING INFORMATION
Complete unit consists of a platform, module and element
PN5
PN5 = 5"
Airtight
Non-IC
Rated
Housing
Lamp
Module
E5SR = 5"
Regressed Lens
Showerlight
Optical
Element
Platform
COOPER LIGHTING
PN5
M32T
E5SR
32W TRIPLE
Compact Fluorescent
5" REGRESSED LENS
SHOWERLIGHT
51/4"
ENERGY DATA
5" AirTight
Input Power:
120V = 36W
Input Current (Max.):
120V = .306
Power Factor:
120V = .98
T.H.D.:
120V = <10%
M32T LUTRON
Input Power:
120V = 36W
Input Current (Max.):
120V = .33A
Power Factor:
120V = >.95
T.H.D.:
120V = <20%
DESCRIPTION
5 1/4"
[134mm]
6 1/4"
[159mm]
6 3/4"
[172mm]
Accessories
MBCLP = 40 Push
On T Bar Clips
(for 10 Units)
PLE5 = Plaster Lip
Extension for
Max 2" Thick
Ceiling
Blank= Matte
White die-cast
SF= Self Flange
RAW= Natural
Die-cast
SFWF= Self
Flange Painted
White
Flange
Finish
Standard
C = Clear
H = Haze
G = Gold
WMH = Warm Haze
W = Gloss White
MW= Matte White
B= Black
Custom
K = Cognac
KH = Cognac Haze
Custom
CC = Chocolate
CCH = Chocolate Haze
BU = Blush
BUH = Blush Haze
GP = Graphite
GPH = Graphite Haze
PN = Pine
PNH = Pine Haze
SK = Sk
SKH = Sk Haze
8 1/2"
[216mm]
8 1/2"
[216mm]
4 15/16"
[126mm]
16 1/2"
[419mm]
Ceiling Cutout
6 1/4" [159mm]
For additional options please consult factor .
Matte white is recommended for self flanged reflectors

PHOTOMETRICS
P5-M32T-E5SRC
Test No. H36117
Lamp: 26W PLT
Lumens: 1800
Cutoff: 75°
Spacing: 1.1
Efficienc : 32.4%
Unit LPW: 22.43
Unit Number: PN5-M32T-E5SRC
Candelas
Vertical CD
Angle
90 0
85 0
75 5
65 37
55 82
45 142
35 202
25 256
15 294
5 309
0 311
Luminance
Degree cd/m2
85˚0
75˚1410
65˚6266
55˚10183
45˚14384
4'6"
5'6"
6'6"
8'0"
10'0"
12'0"
5'0"
6'6"
7'6"
9'6"
11'6"
14'0"
15
10
7
5
3
2
Cone of Light
Distance to Initial Nadir Beam
Illuminated Plane Footcandles Diameter
Notes and Formulas:
Luminance: To convert cd/m2to footlamberts, multipl b 0.2919
Cone of Light:
• Footcandle and CU multiplier: clear x 1.0, Haze x .95, Gold x .90, Black x .65, Warm Haze x .90
• Beam diameter is to 50% of maximum footcandles, rounded to the nearest half-foot.
• Footcandle values are initial. Appl appropriate light loss factors where necessar .
CU Notes/Formulas:
• maintained illuminance=lamp lumens x CU x light loss factors
room area
• total number of luminaires=total room area x maintained illuminance
lamp lumens x CU x light loss factors
• CU data based on 20% effective floor cavit reflectance.
80% 70% 50% 30% 0%
70 50 30 10 50 10 50 10 50 10 0
38 38 38 38 38 38 36 36 34 34 32
36 35 34 33 34 33 33 32 32 31 29
34 32 31 29 32 29 30 28 29 28 26
32 29 27 26 32 29 30 28 29 28 26
30 27 25 23 26 23 26 22 25 22 21
28 24 22 20 24 20 23 20 23 20 19
26 22 20 18 22 18 21 18 21 18 17
24 20 18 16 20 16 19 16 19 16 15
22 18 16 14 18 14 18 14 17 14 14
21 17 15 13 17 13 16 13 16 13 12
19 16 13 12 15 12 15 12 15 12 11
Ceiling Reflectance
Wall Reflectance
Room Ca ity Ratio
0
1
2
3
4
5
6
7
8
9
10
Coefficient of UtilizationZonal Lumen Summary
Zone Lumens %Lamp %Luminaire
0-30 230 12.8 39.5
0-40 356 19.8 61.1
0-60 539 30.0 92.6
0-90 582 32.4 100.0
90-180 0 0.0 0.0
0-180 582 32.4 100.0
Distribution
0°
Note: Specifications and Dimensions subject to change without notice.
Visit our web site at www.cooperlighting.com
Customer First Center 1121 Highwa 74 South Peachtree Cit , GA 30269 770.486.4800 FAX [phone] ADI030825
