PM634ob
60 Amp Busway
Catalog #
Type
Project
A machined aluminum track fixture for PAR38MH
lamps 70 or 100 watts. For use with RSA Profile Series
60 Amp Busway, 20 Amp 1 or 2 Circuit Track or 20
Amp 2 Circuit / 2 Neutral Track.
Integral electronic metal halide ballast in aluminum
housing. Ballast by Aromat®.
Front loading lamp with bayonet action lens /
accessory bezel. Optical accessories are captured
in the bezel with a threaded retainer ring preventing
accessory spill-out during relamping. Can accom-
modate up to three optical accessories.
Auto extending / retracting lamp holder. Lamps
extend for easy access and automatically retract
to optimum position. This is extremely helpful when
dealing with varying accessory combinations or dif-
fering manufacturer lamp dimensions.
Optical accessories include color filters, UV fil-
ters, screens, spread lenses, louvers, hex louvers,
snoots. Consult RSA for details.
Locking on both the horizontal and vertical
planes. 370º vertical rotation possible due to over-
center locking mechanism (60 amp busway only).
270º horizontal locking adjustment.
UL and CUL listed
Available in White, Black, Natural Aluminum or
custom finishes.
PAR38 Metal Halide
Open Back Machined Fixture w/ Integral Ballast
PM634ob | PM434ob | PM234ob | PM134ob
Ordering Example: PM634ob-39-AL-120
PM434ob
20 Amp Track
2 Cct. 2 Ntl.
PM134ob
PM234ob
20 Amp Track
1 or 2 Cct.
Open Back Machined Fixture w/ Integral Ballast Lamp Wattage Finish Voltage
❑ PM634ob - PAR38MH for 60 Amp Busway
❑ PM134ob - PAR38MH for 20 Amp 1 Circuit Track
❑ PM234ob - PAR38MH for 20 Amp 2 Circuit Track
❑ PM434ob - PAR38MH for 20 Amp 2 Circuit / 2 Neutral Track
❑ 70 70 Watt PAR38MH ❑ WH White ❑ 120 120 Volts primary
❑ 100 100 Watt PAR38MH ❑ BK Black ❑ 277 277 Volts primary
❑ AL Natural Alum.
❑ PT Custom Finish

PM103
®
0° Aiming Angle 30° Aiming Angle 30° Aiming Angle 45° Aiming Angle
Horizontal Footcandles Horizontal Footcandles Vertical Footcandles Vertical Footcandles
D FC L W D FC L W CB D FC L W CB D FC L W CB
FC FC
FC
CB
CB
L L
L
30° 30°
D
W
D
W
W
Lamp Performance Data
D = Distance to the horizontal or vertical surface.
FC = Initial footcandles at the center of the beam.
L = Length of the beam where candlepower is reduced to 50%
of center beam candlepower.
W = Width of the beam where candlepower is reduced to 50%
of center beam candlepower.
CB = Distance to the center of the beam.
Lamp data given is typical and is based on bare lamp performance.
Contact lamp manufacturers for availability and specific performance.
Distance, length and width given in decimal feet.
PAR38MH Ceramic Metal Halide
CDM70 /PAR38 /SP /3K PHI 15 207 3.7 3.7 15 134 4.7 4.2 8.7 5 244 4.2 2.4 8.7 8 257 3.7 2.7 8.0
Beam Spread = 15° x 15° 20 116 5.0 5.0 20 76 6.3 5.6 11.5 7 125 5.9 3.4 12.1 10 165 4.6 3.4 10.0
CBCP = 46572 25 75 6.2 6.2 25 48 7.8 7.0 14.4 9 75 7.6 4.3 15.6 12 114 5.5 4.0 12.0
Rated Life = 10,000 Hrs. 30 52 7.5 7.5 30 34 9.4 8.4 17.3 11 50 9.2 5.3 19.1 14 84 6.4 4.7 14.
CDM70 /PAR38 /FL /3K PHI 8 276 3.5 3.5 8 186 4.3 3.9 4.6 5 127 5.3 3.6 8.7 5 283 3.6 2.9 5.0
Beam Spread = 25° x 25° 10 177 4.4 4.4 10 119 5.4 4.9 5.8 7 65 7.4 5.0 12.1 7 145 5.0 4.0 7.0
CBCP = 17697 12 123 5.2 5.2 12 82 6.5 5.9 6.9 9 39 9.5 6.5 15.6 9 87 6.4 5.1 9.0
Rated Life = 10,000 Hrs. 14 90 6.1 6.1 14 61 7.5 6.8 8.1 11 26 11.6 7.9 19.1 11 59 7.9 6.3 11.0
CDM70 /PAR38 /WFL /3K PHI 4 301 3.2 3.2 4 211 3.8 4.0 2.3 3 178 3.3 3.4 5.2 3 266 3.2 3.3 3.0
Beam Spread = 60° x 60° 6 134 4.9 4.9 6 94 5.6 6.0 3.5 4 100 4.5 4.6 6.9 4 150 4.2 4.4 4.0
CBCP = 4822 8 75 6.5 6.5 8 53 7.5 8.0 4.6 5 64 5.6 5.7 8.7 5 96 5.3 5.5 5.0
Rated Life = 10,000 Hrs. 10 48 8.1 8.1 10 34 9.4 10.0 5.8 6 44 6.7 6.9 10.4 6 67 6.4 6.6 6.0
CDM100 /PAR38 /SP /3K PHI 15 284 3.8 3.8 15 185 4.8 4.3 8.7 6 234 5.1 2.9 10.4 10 226 4.7 3.4 10.
Beam Spread = 15° x 15° 20 160 5.1 5.1 20 104 6.4 5.7 11.5 8 132 6.8 3.9 13.9 12 157 5.6 4.1 12.0
CBCP = 639747 25 102 6.3 6.3 25 66 7.9 7.1 14.4 10 84 8.5 4.9 17.3 14 115 6.5 4.8 14.0
Rated Life = 10,000 Hrs. 30 71 7.6 7.6 30 46 9.5 8.5 17.3 12 58 10.3 5.8 20.8 16 88 7.5 5.5 16.
CDM100 /PAR38 /FL /3K PHI 9 279 4.1 4.1 9 187 5.0 4.6 5.2 4 259 4.2 2.9 6.9 6 253 4.4 4.8 6.0
Beam Spread = 25° x 25° 13 134 5.9 5.9 13 90 7.3 6.6 7.5 5 166 5.3 3.7 8.7 8 142 5.9 6.4 8.0
CBCP = 22614 17 78 7.7 7.7 17 52 9.5 8.6 9.8 7 85 7.4 5.1 12.1 10 91 7.3 8.0 10.0
Rated Life = 10,000 Hrs. 20 57 9.0 9.0 20 38 11.2 10.1 11.5 9 51 9.5 6.6 15.6 12 63 8.8 9.6 12.0
CDM100 /PAR38 /WFL /3K PHI 5 274 3.8 3.8 5 195 4.7 4.5 2.9 3 233 3.7 3.4 5.2 3 353 3.4 4.5 3.0
Beam Spread = 60° x 60° 7 140 5.3 5.3 7 100 6.5 6.3 4.0 4 131 5.0 4.6 6.9 4 198 4.5 6.0 4.0
CBCP = 6862 9 85 6.8 6.8 9 60 8.4 8.1 5.2 5 84 6.2 5.7 8.7 5 127 5.7 7.5 5.0
Rated Life = 10,000 Hrs. 11 57 8.3 8.3 11 40 10.2 9.9 6.4 6 58 7.4 6.9 10.4 6 88 6.8 9.0 6.0
