Cooper Lighting Metrolite ML Series User manual

605
EMERGENCY LIGHTS Architectural
COOPER LIGHTING - SURE-LITES®
COOPER LIGHTING
ML SERIES
METROLITE
METROLITE
EMERGENCY LIGHT
DIMENSIONS
DESCRIPTION
The Metrolite ML Series is the right choice for installations where aesthetics are a priority. With its
white finish and sculptured compact design the product blends in with the surroundings. Matching
remotes are available to insure a consistent appearance. The pleasing look is accompanied by a feature
rich design that provides fully adjustable heads with high efficiency halogen lamps making it easy to
direct ample light to the required areas. Each unit employs a quick mount universal back with hinged
access for hassle free installation.
21.6"
[549mm]
5.30"
[135mm]
1.90"
[48mm]
4.80"
[1221mm]
4.40"
[112mm]
11"
[280mm]
4.30"
[109mm]
5.30"
[135mm]
Rated Wattage to 87 1/2 % of Rated D.C. Voltage Lamp Information
Model DC Voltage 1 1/2 Hours Remote Wattage Available Type Wattage Number
ML1 6 25 0 Bi-Pin Halogen 12W ea 029-66
ML2 6 50 26 Bi-Pin Halogen 12W ea 029-66
ML3 12 50 26 Bi-Pin Halogen 12W ea 029-45
ML4NC 6 14 0 Bi-Pin Halogen 6W ea 029-12
ML5NC 12 28 0 Bi-Pin Halogen 12W ea 029-45
ENERGY DATA
Input Current (Max.)
ML1, ML2, ML3
120V = .3A
277V = .1A
ML4NC, ML5NC
120V = .085A
277V = .035A
ORDERING INFORMATION
ELECTRICAL RATINGS
Model Number
ML1
ML2
ML3
ML4NC(1)
ML5NC(1)
Options (add as suffix)
V= Voltmeter
TDM= Time Delay Monitor
Alternate Lamps(2)
Accessories
(Order separately)
VS1 = Polycarbonate Vandal Shield
WG12 = Wire Guard
SAMPLE NUMBER: ML1
• Dual-voltage input
120/277VAC, 60Hz
• Injection-Molded, High-
Impact, Thermoplastic
Housing, Rated UL 94-5VA,
Designer-White Textured
Finish, Integral Mounting
Plate
• Glare Free Lens, Fully
Adjustable, Halogen Lamps
• Sealed Lead Calcium or
Nickel Cadmium Battery
Maintenance Free, Long
Life, Full Recharge time,
24 Hours (max.)
• Line-Latching,
Low-Voltage Disconnect,
Test Switch, AC Power
Indicator, Brownout Circuit
• Red LED High Charge
Indicator, Amber LED AC
Power Indicator
• UL 924, Life Safety NFPA
101, NEC/OSHA, Most
State and Local Codes
(1) NC = Nickel Cadmium Battery. (2) Consult your Cooper Lighting Representative.
