COP Security 15-W116R User manual

Instructions
Tel: [phone] Fax: [phone]
For more instructions & support material, please visit our website at:
http://www.cop-eu.com

19"x1U Rack Mounting 16 Port Twisted Pair Hub Receive “Passive”
ITEM NO.: 15-W116R
1.FEATURE
16 Port Twisted Pair Hub Receiver +1U Rack Mounting Case
 16 port 19"x 1U rack mounting case.
 Use with 15-W100V, 15-W100VT.
 Use category-5 twist-pair wire, easy to install.
 Video only. Transmission distance up to 600M.
 Built-in impedance couple device + noise filter.
 Built-in video signal detection circuit.
2.OVERVIEW OF INSTALLATION
Condition A: 15-W116R link with 15-W100V
1 2 3 4 5 6 7 8
9
10 11 12 13 14 15 16
+ + + + + + + +
++++ + + + +
Condition B: 15-W116R link with 15-W100VT
#Please note “＋”, “－” of signal and cable, if confuse them, picture would be not clear or twist.
Gi-w-12-02

RJ-45 Jack Function
RJ-45 JACK
PIN Number Color
1 White-Orange (＋) PAIR1
2 Orange (－)
PAIR2 3 White-Green (＋)
4 Black (－) PAIR3
5 White-Black (＋)
PAIR2 6 Green (－)
7 White-Brown (＋) PAIR4
8 Brown (－)
121345678
3.SPECIFICATION
ITEM 15-W116R
VIDEO INPUT PORT 16 Port (Terminal Block)
VIDEO OUTPUT PORT 16 Port (BNC Connector)
AUDIO X
TRANSMISSION DISTANCE 600M
CABLE Twisted Pair CAT5
DIMENSIONS mm 482x170X44
4.TROUBLESHOOTING
1. No video signal, please check cable installation.
2. Video signal is not clear, please check “＋” and “－” of cable.
<OPTION>
15-AVC201 15-AVC202
CAT-5 UTP 4 Twisted Pair Cable
 CAT-5 UTP 4 twisted Pair Cable: AWG 24
solid anneal copper wire.
 1000Ft/ Box
CAT-5 UTP 2 Twisted Pair Cable
 CAT-5 UTP 2 twisted Pair Cable:
AWG 24 solid anneal copper wire.
 1000Ft/ Box
15-AVC203
CAT-5 UTP 4 twisted Pair Cable + Power Cord
 CAT-5 UTP 4 twisted Pair Cable: AWG 24 solid anneal copper wire.
 Power Cord: AWG 20 (7x0.32mm) anneal copper wire, 5Amp (Max.)
 100Metter/ Box
1
2
3
4
Red
While
AWG 24
10.8
5.4
AWG 20
Twisted Pair Power
G-w-22-02
