Copernicus Tech Tub2 User manual

FTT-AC1 - Version B - Released July 19th, 2016 - Copernicus Educational Products Inc.
®
2
Tech Tub Accessory Kit
Tub Rail Left
x1
Tub Rail Right
x1
M5 Barrel Nut
x4
D
M6 Lock Washer
x4
C
M6 Washer
x4
B
M5x5mm Screw
x4
A
Remove Cable Pocket Wall
At the back of the Cable Pocket Wall, there are two tabs. Press in on tabs and pull wall out.
1
Bottom Tab
Top Tab
4mm Driver
Allen Key
(43281)
Not to Scale
x2
Contents
For assistance, please contact us:
1-800-267-8494
Email [email protected]
Have your packing slip ready for reference
Assembly Guide
FTT-AC1_2016_B
Check out our other products online at
www.copernicused.com
FTT-AC1
WARNING
This product is meant to be assembled by an adult.
In its unassembled state, small parts present a choking hazard.
To be used under direct supervision of an adult.

FTT-AC1 - Version B - Released July 19th, 2016 - Copernicus Educational Products Inc.
Snap Tub Rails onto
®
2
Tech Tub Body
Note orientation of Tub Rails when installing them onto tub body. Ensure they are SNAPPED!
Tub Rail - Left
x1
2
You will need: (Not to Scale)
Tub Rail - Left Tub Rail - Right
Tub Rail - Right
x1
Push rails in until
you hear a SNAP
Use Hardware to Permanently Attach Tub Rails, Slide Cable Pocket Wall Back In
3
You will need: (Not to Scale)
Actual Size:
2
Same hardware on right side
1
Cable Pocket
Wall
1x
M5 Barrel Nut
x4
D
M6 Lock Washer
x4
C
M6 Washer
x4
B
M5x5mm Screw
x4
A
B
A
D
C
Install Left and Right Tub Rails Re-install Cable Pocket Wall
Push wall in until you hear a SNAP
4mm Driver
Allen Key
(43281)
x2
Once you have completed the steps in this guide refer to the
FTT600 or FTT1000 AI to complete the setup of your ®
2
Tech Tub .
