CopterX CX 600E Pro User manual

CX 600E Pro
Flybarless Torque Tube
Version Helicopter Kit
www.copterx.com
Copyright © 2013 KY MODEL Company Limited.
INSTRUCTION MANUAL
INSTRUCTION MANUAL

01
MENU
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Table of content
Introduction
Safety Guidelines
Radio Equipment and Electronics
Assembly Tools Requirement
Main Rotor Assembly
Frame Assembly
Tail Rotor Assembly
Tail Section Assembly
Frame and Gear Assembly
Complete Kit Assembly
1
2
2
3
3
4
6
12
14
16
19
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit

02
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
1. Introduction
Thank you very much for purchasing a CopterX CX 600E Pro flybarless helicopter. In order to be able
to use this product safely, please read this manual before flying the helicopter. Please fly the
helicopter safely observing all rules and manners after having fully understood the flight
precautions, the unit’s capabilities, and the best way to fly it. Be sure to retain the manual for future
reference, routine maintenance, and tuning.
IMPORTANT NOTES
•This helicopter is recommended for skilled intermediates and advanced RC helicopter flyers.
•Make sure to read and follow all the instructions in this manual, including all accessories.
•Should any problems arise, please confirm with an experienced RC helicopter personnel /
instructor before introductory flight.
•Always find an experienced and / or qualified personnel / instructor for per flight inspection.
•Make sure flight vicinity is in an open space; free of crowds, obstacles, and buildings. Failure to
abide may cause accidental and potentially hazardous encounters.
•Introductory flight should incorporate only the basic maneuvers (hovering, linear movements),
until stick feel is mastered.
2. Safety Guidelines
Locate an appropriate location: R/C helicopters fly at very high speeds, thus posing a certain
degree of danger. Choose an appropriate location. A clear large room such as a Gymnasium,
basketball court, warehouse. Do not fly the model on residential or commercial places such as near
houses or buildings. Do not fly near electrical poles or high voltage cables that may cause radio
interference. Do not fly model on inclement weather such as rain, wind if snow.
Acquire the assistance of an experience pilot: Before starting up the model it is best that it is
checked by someone that is experienced with this models, Parts checking prior flight is mandatory.
On the flying field before actual power up of model and transmitter make sure the no other pilots
have the same frequency. Frequency interference can cause your model and other model of same
frequency to crash.
For first time pilots its highly recommended that you use a simulator (Computer based flight
simulator) for enhancement of flight skills
Aware of moving parts: During actual operation of the helicopter, the main rotor blades will be
spinning at a very high rate of speed. The blades are capable of imposing serious bodily injury and
damage to the environment. Be careful on body parts such as hand, eyes, arms. Also be cautious of
loose clothing, can be sucked up by the rotating blades. Do not turn your away you eyes when the
model is turned on or in use. Never leave the model unattended. Immediately turn off the model
and transmitter after use.

03
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
Prevent Moisture: R/C models are composed of many precision electrical components that is
sensitive to moisture and water. Keep away from water sources or moisture related places.
The introduction of moisture in any form can seriously damage the electrical parts of the model
that can cause malfunction and premature flight patterns.
Keep Away From Heat: R/C models are made of some parts plastic.
Make sure to store the model away from head producing appliances such as heaters or stoves. It is
best to keep the model indoors in a controlled cool environment with ambient room temperature.
NOTE: The following marks will be seen on the pages of this instruction manual. This designates
location and contact points that needs application of adhesive. Liquid thread lock are usually used
on metal to metal contact screws normally with fine pitch threading. For Metal to plastic CA can be
applied screws designated as force threading or self tapping.
3. Radio Equipment and Electronics
Transmitter
(6-CH, helicopter system)
4. Assembly Tools Requirement
Reciever
(6-CH, or more)
Motor
Standard Servos Flybarless Gyro
Scissors CA GluePitch GuageBall Link Pliers Liquid Thread LockCuter Blade
Liquid Thread Lock Cyano Acrylate ( CA )
ESC (100A or more)

04
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
5. Main Rotor Assembly
No.
1
2
3
4
5
6
7
8
9
10
11
Parts No.
CX600BA-01-05
CX600BA-01-16
CX600BA-01-14
CX600BA-01-18
CX600BA-01-15
CX600BA-09-06
CX600BA-09-09
CX600BA-01-22
CX600BA-09-10
CX600BA-01-17
CX600BA-01-12
Name
Feathering Shaft
Metal Rotor Housing
Metal Head Stopper
Metal Blade Holder
Main Shaft Spacer
8X14X4mm Bearings
5X10X4mm Thrust Bearings
Blade Grip Arm
3X7X3mm Bearings
Metal Washout Contral Arm
Main Rotor Set
Spec.
Ø8xØ14x4mm
Ø5xØ10x4mm
Ø3xØ7x3mm
1
2
3
M3X8
M4x10
Ø4 Flat Washer
M3X6
4
6
8
6
5
5
7
M2.5X10
M2X12
M3X24
Ø3xØ5x1.5
Ø3XØ2X0.5
Ø2xØ3.5x2
9
10
11

05
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
No.
12
13
14
Parts No.
CX600BA-01-02
CX600BA-01-13
CX600BA-01-19
Name
210 Degree Reinforced Swashplate
Main Shaft
Linkage Rod (Swash to Blade Grip)
Spec.
Ø2X58X10mm
12
13
M3X25
M3 Locknut
14

06
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
15
M2.5X6
15
17
18
18
25
26
21
22
22
23
24
16
M3X8 M3X8
M3X6
M3X6
M3X6
M3X16
M3X6
Ø5xØ9x3mm
Bearing
M3X8
M3X6
NOTE:
Bearing holder with
larger diameter (14.95mm) faces
outward, smaller diameter
(14.5mm) faces inward
19
20
6. Frame Assembly
No.
15
16
17
18
18
19
20
21
22
23
24
25
26
Parts No.
CX600BA-03-17
CX600BA-03-06
CX600BA-03-11
CX600BA-03-07
CX600BA-03-19
CX600BA-09-02
CX600BA-03-14
CX600BA-03-04
CX600BA-03-05
CX600BA-03-15
CX600BA-03-08
CX600BA-03-03
CX600BA-03-02
Name
Carbon Fiber Gyro Mount
Metal Elevator Servo Mount
Metal Main Shaft Bearing Block
Metal Pitch / Aileron Servo Mount
Cyclic Servo Mount V2
6X12X4mm Bearings
Motor Pinion Gear Bearing Mount
Carbon Bottom Plate
Carbon Frame Brace Set
Canopy Mounting Bolt
Metal Rudder Servo Mount
Carbon Main Frame Right
Carbon Main Frame Left
Spec.
Upgrade Parts
Ø6xØ12x4mm
IMPORTANT !
Please see Page 07 rst
before assembling.

07
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
No.
27
28
29
30
31
Parts No.
CX600BA-07-02
CX600BA-03-10
CX600BA-03-12
CX600BA-03-13
CX600BA-03-09
Name
Tail Boom Brace
Frame Mounting Block
Elevator Arm Set
Motor Mount
Front Sub Frame
Spec.
25
26
21
18
22
27
22
23
28
28
28
23
16
15
15
29
24
18
17
20
30
M2.5X6
M3X25
31
NOTE:
Bearing holder with
larger diameter (14.95mm) faces
outward, smaller diameter
(14.5mm) faces inward

08
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
No.
32
33
Parts No.
CX600BA-04-02
CX600BA-04-03
Name
Landing Skid
Landing Skid Pipe
Spec.
M3X8
Ø3 washer
M3X12
M3X35
32
33

09
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
No.
34
Parts No.
CX600BA-03-01
Name
Carbon Fiber & Metal Main Frame
Spec.
Ø2.5 washer
M2.5X10
Ø2.5 washer
M2.5X10
34

10
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
No.
35
Parts No.
CX600BA-10-01
Name
13T Pinion Gear
Spec.
13T
30
M4X5
M3X10
M3X6
35

11
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
No.
36
37
38
39
Parts No.
CX600BA-09-05
CX600BA-09-04
CX600BA-05-07
CX600BA-02-03
Name
12X18X4mm Bearings
4X9X4mm Bearings
M0.8 Torque Tube Front Drive Gear Set/34T
Torque Tube
Spec.
Ø12xØ18x4mm
Ø4xØ9x4mm
M0.8 / 34T
Ø1.5x9 Pin
M2.5X6
M3X6
M3X16
36
37
38
Ø1.5X9 Pin
36
39
37
38

12
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
No.
40
41
42
43
Parts No.
CX600BA-02-01
CX600BA-05-06
CX600BA-09-07
CX600BA-02-04
Name
Metal Tail Torque Tube Unit
Tail Drive Gear
5X10X4mm Bearings
Tail Rotor Slider Set
Spec.
Ø5xØ10x4mm
7. Tail Rotor Assembly
NOTE: Adjust the spacing between two gears by
increasing or decreasing the number of spacer
40
41
39
36
Ø1.5x9 Pin
41
M3x6
M3x6
M3x6
M2x5
42
M3x16
Ø3xØ6x2.5 bearing
43

13
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
No.
44
Parts No.
CX600BA-02-02
Name
Metal Tail Rotor Holder
Spec.
M3x8
Ø6xØ10x3mm bearing
M3 Locknut
M3x16
M2x8
M2x8
40
42
44
7

14
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
No.
45
46
47
48
49
50
Parts No.
CX600BA-03-16
CX600BA-06-02
CX600BA-07-04
CX600BA-07-01
CX600BA-07-03
CX600BA-06-01
Name
Tail Boom Holder
Carbon Horizontal Stabilizer
Metal Stabilizer Mount
Tail Boom
Tail Control Rod Assembly
Carbon Vertical Stabilizer
Spec.
8. Tail Section Assembly
M2
M2x10
M3x20
M3x8
45
39
6
47
48
47 49
46
M3x20
27
50
M3x6
M3x6
NOTE: After inserting the tail boom into
the gear box, positioning drill a Ø2.5 hole
here and tighten with screw.
Two holes must be in
parallel position (180°)

15
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
M3X12 Ø3xØ7x0.5 Washer
M3X8
27
45

16
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
29
M2.5X10
M3X8
M3X6
51
No.
51
Parts No.
CX600BA-09-01
Name
3X7X3mm Flanged Bearings
Spec.
Ø3xØ7x3mm
M4X4
Please push the Elevator Arm to the left side
first in oder to tighten the M4X4 screw.
9. Frame and Gear Assembly

17
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
No.
52
53
54
55
Parts No.
CX600BA-05-05
CX600BA-05-01
CX600BA-05-04
CX600BA-05-03
Name
One-way Bearing Shaft
One Way Bearing Case
CNC Slant Thread Main Drive Gear
CNC Autorotation Tail Drive Gear
Spec.
52
53
54
55
55
Ø12xØ18x6 bearing
Ø8xØ12x4 bearing
M3X6
M3X10

18
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
No.
56
Parts No.
CX600BA-01-11
Name
Flybarless Main Rotor Set
Spec.
56
M3X25
M3 Locknut
M4 Locknut
M4X30

19
CX 600E Pro
Flybarless Torque Tube Version Helicopter Kit
10. Complete Kit Assembly
