CS-3060 / CS-2560
WORKGROUP MFP

1. Introduction
II. Product Positioning
III. Product Overview
IV. Yields
V. Product Configuration
VI. Technology
VII. Features
VIII. Connectivity
IX. Print
X. Scan / Send
XI. Copy
XII. Fax / Send
XIII. Product Options
XIV. Solutions
XV. Reliability
XVI. Summary
XVII. Trademarks
TABLE OF CONTENTS
KM-3060 / KM-2560 PRODUCT GUIDE 2

INTRODUCTION
CS-3060 / CS-2560 PRODUCT GUIDE 3
Copystar is pleased to introduce the New CS-3060 / CS-2560
The New CS-3060 / CS-2560 are the latest addition to Copystar’s line of Monochrome
Multifunctional Devices. The new CS-3060 / CS-2560 come standard with Network Print
and Color Scan and Send capabilities, which will accommodate the needs of most small
to mid-size business workgroups.
With the Copystar CS-3060 / CS-2560, customers can choose whether they require a
30PPM devices or a 25PPM device, based on their print, scan and copying needs.With
the Copystar CS-3060 / CS-2560 and it’s abilities to Network Print and Network Color
Scan, customers’ can also reduce equipment redundancy, such as locally attached
flatbed scanners and printers by consolidating all of these requirements using a centrally
located CS-3060 / CS-2560 MFP. .
The CS-3060 / CS-2560 will provide customers with a wider range of choices when
deciding on which product will best fit their business structure, and are a welcome addition
to Copystar’s Monochrome Multifunctional Product Line.

PRODUCT POSITIONING
CS-3060 / CS-2560 PRODUCT GUIDE 4
The new CS-3060 and the new CS-2560 are products intended for the workgroup,
where printing, scanning and faxing are part of the daily workflow process and require
an MFP that is highly reliable and easy to use.
The CS-3060 and the CS-2560 standard features and functionality, when combined
with Copystar’s advanced user-friendly software solutions, allow users to easily network
print, network scan or network fax from the desktop or the MFP. For the IT administrator,
the advance software monitoring tools will allow administrators to control all of the
business processes across their network from a central location, easily and effectively.
Copystar gives businesses the choice, on whether they need a 30 page per minute
device or a 25 page per minute device, without losing any of the features and
functionality that are normally found on more expensive high-end MFPs. Copystar also
designed the CS-3060 and the CS-2560 around Kyocera’s Long Life components,
making the CS-3060 and CS-2560 cost effective to operate and the ideal choice for the
any workgroup.

CS-3060 / CS-2560 PRODUCT GUIDE 5
PRODUCT OVERVIEW
The CS-3060 and the CS-2560 are Workgroup Multifunctionals with standard
Network Print, Network Color Scan, Optional Fax/Network Fax/Internet Fax,
Stackless Duplex, 500x2 Paper Drawers and 200 Sheet MPT. Standard/Maximum
512MB/1GB shared memory, Standard 80GB HDD Optional 75 Sheet Reversing
Automatic Document Processor (RADF), Optional Paper Handling and Finishing.
• Single Board Architecture
• Multi Task Operation
• Single Laser Writing
• Amorphous Silicon (ASi) Drum
• Monocomponent Toner
• 600 dpi, 256 Levels of gray
• Fast 1200 Mode Print Resolution
• Scan Once Print Many
• Multi Send Functions
• Network Authentication
• Standard Stackless Duplex
• Section 508 Compliant
• RoHS Compliant
• Energy Star Compliant
Productivity & Ease of Use
• Covers
• Booklet Mode (Copy)
• Page Numbering
• Continuous Scan/Job Build
• 1,000 Account Codes
• User/ Department Name
• Paper Size
• Integrates with KMnet Admin
• Integrates with KM-NET for Accounting
• Warmup of 15 seconds or less
• Fast FCOT- 4.7 Seconds
• 50 SPM/OPM Monochrome at 300 dpi
• 15 SPM/OPM Color
• APS/AMS/AE/AS
• Auto Start
• Job Interrupt
• Image Rotation
• 50 Job Programs (Copy/Send)
• Copy/Send Shortcuts
• Color Wide Touch Screen Interface
• Help/Animated Guidance
• Multiple Language Selection
• Memory Gauge
• Job Status
• 1-999 Copy Selection
• Job Finish Notice (Copy/Send)
Technology
Output Speeds
Memory Management
Publishing
Reports
Media Type 2560 3060
Letter 25 30
Letter R 17.5 22
Legal 12.5 15
Ledger 12.5 15
• Standard 512MB RAM
• Maximum 1GB RAM
• Standard 80GB Multipurpose HDD
• Maximum 1GB RAM
via 512MB x 2 100 Pin SDIMMs
• Standard Compact Flash Slot (Type 1)
Document Box
• Custom Box
• Job Box
• Removable Memory Box (USB Host Print)
• Fax Box (Requires Opt. Fax System)

PRODUCT OVERVIEW
CS-3060 / CS-2560 PRODUCT GUIDE 6
• Auto, Text, Photo, Mixed, ECO and Manual
• 5R/5E Fixed Ratios
• 25%-400% Zoom
• XY Zoom
• 110 lb. Index via MPT
• Positive/Negative Reverse
• Mirror Image
• Form Overlay
• Erase Modes
• Split Copy
• Mixed Size processing
• Cover Mode
• Repeat Copy
Paper Handling
Image Quality & Versatility
• Optional 75 Sheet RADF (DP-670)
• Standard 3-way 1,200 Sheet Paper Supply
• 500 x 2 Drawers
• 200 Sheet Multi-purpose Tray (MPT)
• Up to 28 lb. Bond via Paper Drawers/Decks
• Auto Tray Switching support
• Standard Stackless Duplex
• 1:2, 2:2, 2:1, Book:2
• Optional Paper Handling
• 500 x 2 Sheet Paper Drawers (PF-670)
Finishing
• Optional 1,000 Sheet Finisher (DF-730)
• 30 Sheet Single-position Edge Staple
• 20 Sheet Legal/Ledger
• Requires Attachment Kit (AK-670)
• Optional 500 Sheet Internal Finisher (DF-670)
• 30 Sheet Single position staple
• Offset shift
• Optional Job Separator (JS-670)
• 100 Sheet Tray capacity
• PowerPC750/ 400MHz Processor
• Shared Memory Resources
• Fast 1200 Print Mode
• PDL/Emulations: PRESCRIBE, PCL 6 (XL, 5e),
KPDL3 (PS3), KCGL (HP-GL/2), Diablo 630, IBM
ProPrinter X24, Epson LQ850, Line Printer
• Font Support:
• 80 Outline Fonts for PCL XL/5e
• 80 Outline Fonts for KPDL
• 1 Bitmap Font
• Driver Support
• KX Driver for Windows®
• PPD for MAC
• PPD for Linux/UNIX
• Certified Uni Driver
• Windows® 64-bit Drivers
• Operating System Support
• Windows® 95/98/Me/
NT4/2000/XP/2003/Vista
• Novell 3.x/4.x/5.x/6.x
• Mac OS 8.x/9.x/10.x
• UNIX
• Protocol: TCP/IP, IPX/SPX, AppleTalk, NetBEUI
• Standard Interfaces
• 10/100BaseTX
• High Speed USB 2.0
• USB Host Interface (2)
• Expansion Slot (2)
• Optional Fax System (M) x 2
• Web Interface: Kyocera Command Center
• Utilities: KMnet Admin, KM-NET for Accounting,
PDF Direct Print
Standard Network Print
Standard Network Scan
• Color and Monochrome Scanner
• Resolution: 200,300,400,600 dpi
• Scan Speed:
• 50 OPM Monochrome at 300 dpi or less
• 30 OPM - Monochrome
• 15 OPM - Color
• File Format
• Monochrome - PDF, TIFF
• Color - PDF, JPEG
• TWAIN
• Monochrome - PDF, TIFF
• Color - JPEG, TIFF, PDF

CS-3060 / CS-2560 PRODUCT GUIDE 7
Optional Fax System (M)
• Fax/Network Fax/Internet Fax
• Super G3 Fax
• Quick Scan Speed: Less than 2 sec. per page
• Transmission Speed:Less than 3 sec. per page
• Modem Speed: 33.6 kbps w / Auto Fallback
• Data Compression: MMR, MR, MH, JBIG
• Fax Memory: Shared System Memory
• Remote Switching
• 50 Program Dial settings
• 50 Group Dial Numbers
• Auto Reduction Reception
• Duplex Reception
• Network Fax Driver
• NW Fax Reception: SMB, FTP, e-Mail
• NW Fax Distribution: PDF, TIFF
• Internet Fax:Send and Receive Fax via the Internet
Resolution Gradation Resolution
Normal 2 8 dot/mm x 3.85 line/mm
Fine 2 8 dot/mm x 7.7 line/mm
Super Fine 2 8 dot/mm x 15.4 line/mm
Ultra-fine 2 16 dot/mm x 15.4 line/mm
Half-tone 128 8 dot/mm x 7.7 line/mm
Standard Network Scan
• Scanning Features
• Scan to e-Mail
• Standard LDAP
• Scan to Folder (via SMB)
• Scan to FTP
• TWAIN
• Protocol: TCP/IP
• Driver: TWAIN (PC)
• Consolidated Address Book
• Web Interface: Kyocera Command Center
PRODUCT OVERVIEW
Optional Data Security Kit (C)
• Provides Security Overwrite and Encryption
• Automatic and Manual Deletion processes
• Copy, Print and Send Data
Optional UG-30 PDF Enhancement Kit
• PDF Compression
• PDF Encryption
• Supports up to 128bit Encryption
Optional Workflow Solutions
• iTag
Document Management Solution
• KYOcapture Express
Simplified Document Workflow Solution
• KYOcapture
Document Capture Workflow Solution
Maintenance and Yields
• Monocomponent Technology
• 20K Toner Yield
• Amorphous Silicon Drum
• 300K Yield
• Preventive Maintenance Schedule
• 300K
• Maximum Monthly Volume
• KM-2560 - 80K
• KM-3060 - 100K
Additional Information
• 22.4” W x 24.4” D x 30.2” H
• 166 lbs.
• 120V, 60Hz, 11.5A

Yields
CS-3060 / CS-2560 PRODUCT GUIDE 8
Item Description Yield
TK-677 Toner 1,160g 20,000 @ 6%
MK-670 Maintenance Kit 300,000
Item Description CS-2560/3060 CS-3050/4050/5050
Fax System (M) Network Fax System √ √
DP-670 Document Processor √
DF-670 Internal Finisher √
DF-730 1,000 Sheet Finisher √ √
JS-670 Job Separator √
BU-10 Fax Data Backup Kit √ √
PF-670 Paper Deck √
Data Security Kit (C) HDD Overwrite √ √
UG-30 PDF Compression /
Encryption Kit
√ √
Accessory Compatability

PRODUCT CONFIGURATION
CS-3060 / CS-2560 PRODUCT GUIDE 9
Option Description Item Code
DP-670 Document Processor 1203K56KL0
PF-670 500x2 Paper Feeder 1203K62US0
DF-730 1,000 Sheet Finisher 1205H10U10
DF-670 Internal Finisher 1203LB0UN0
JS-670 Job Separator 1203LC0UN0
Fax System (M) Fax Unit 1503KH2US0
BU-10 Fax Data Backup Memory 1703KJ0UN0
HDD Overwrite Data Security Kit (C) 1503KP0UN0
PDF Compression /
Encryption Kit
UG-30 1503KR0UN0

PRODUCT CONFIGURATION
CS-3060 / CS-2560 PRODUCT GUIDE 10
Base Unit with Optional DP-670
Document Processor and PF-670
Dual Paper Drawers
Base Unit with Optional DP-670
Document Processor, PF-670 Dual
Paper Drawers and DF-730 Simple
Finisher
