CORBERO CC510GB90W User manual

90X60 gas & electrical oven with
bottle compartment
90X60 gas y horno eléctrico con
compartimiento de botella
90X60 forno elétrico gás botija
com o compartimento
CC510GB90W/CC510GB90X
CCSF5GB922W/ /CCSF5GB922X
USER MANUAL
MANUAL DEL USUARIO
MANUAL DO UTILIZADOR

G
B
2
Dear user,
Our objective is to make this product provide you with the best output
which is manufactured in our modern facilities in a careful working
environment, in compliance with total quality concept.
Therefore, we suggest you to read the user manual carefully before using
the product and, keep it permanently at your disposal.
Note: This user manual is prepared for more than one model. Some of the
features specified in the manual may not be available in yourappliance.
All our appliances are only for domestic use, not for commercial use.
Products marked with (*) are optional.
“THIS APPLIANCE SHALL BE INSTALLED IN ACCORDANCE WITH THE
REGULATIONS FORCE AND ONLY USED IN A WELL VENTILATED SPACE. READ
THE INSTRUCTIONS BEFORE INSTALLING OR USING THIS APPLIANCE”
“Conforms with the WEEE Regulations."

3
Contents
Important warnings 4
Electrical connection 16
Gas connection 17
Introduction of the appliance 22
Accessories 23
Technical features of your oven 24
Installation of your oven 27
Installation of the oven feet 29
Chain lashing illustration 29
Control panel 30
Using oven section 31
Using the grill 32
Using the chicken roasting 32
Using cooker section 33
Program types 35
Cooking time table 36
Maintenance and cleaning 37
Installation of the oven door 38
Cleaning and maintenance of the
oven’s front door glass 39
Catalytic walls 39
Rack positions 39
Changing the oven lamp 40
Using the grill deflector sheet 41
Troubleshooting 42
Handling rules 44
Recommendations for energy saving 44
Environmentally-friendly disposal 45
Package information 45

4
G
B
IMPORTANT WARNINGS
1. Installation and repair should always be performedby
“AUTHORIZED SERVICE”. Manufacturer shall not be held
responsible for operations performed by unauthorized
persons.
2. Please read this operating instructions carefully. Only
by this way you can use the appliance safely and in a
correct manner.
3. The oven should be used according to operating
instructions.
4. Keep children below the age of 8 and pets away
when operating.
5. WARNING: The accessible parts may be hot while using
the grill. Keep away from children.
6. WARNING: Fire hazard; do not store the materials
onthe cooking surface.
7. WARNING: The appliance and its accessible parts are
hot during operation.
8. Setting conditions of this device are specified on
the label. (Or on the data plate)
9. The accessible parts may be hot when the grill is
used. Small children should be kept away.
10. WARNING: This appliance is intended for cooking. It
should not be used for other purposes like heating a
room.
11. To clean the appliance, do not use steam cleaners.

5
12. Ensure that the oven door is completely closed
after putting food inside the oven.

6
G
B
13. NEVER try to put out the fire with water. Only shut
down the device circuit and then cover the flame with a
cover or a fire blanket.
14. Children under 8 years of age should be kept away,if
they cannot be monitored continuously.
15. Touching the heating elements should be avoided.
16. CAUTION: Cooking process shall be supervised.
Cooking process shall always be supervised.
17. This device can be used by children over 8 years of
age, people with physical, hearing or mental challenges or
people with lack of experience or knowledge; as long as
control is ensured or information is provided regarding the
dangers.
18. This device has been designed for household use
only.
19. Children must not play with the appliance. Cleaningor
user maintenance of the appliance shall not be performed
by children unless they are older than 8 years and
supervised by adults.
20. Keep the appliance and its power cord away from
children less than 8 years old.
21. Put curtains, tulles, paper or any flammable (ignitable)
material away from the appliance before starting to use the
appliance. Do not put ignitable or flammable materials on or in
the appliance.

7
22. Keep the ventilation channels open.

8
G
B
23. The appliance is not suitable for use with an external
timer or a separate remote control system.
24. Do not heat closed cans and glass jars. The pressuremay
lead jars to explode.
25. Ovenhandleis notatoweldrier. Do nothangtowels,etc.
on the oven handle.
26. Do not place the oven trays, plates or aluminium
foils directly on the oven base. The accumulated heat may
damage the base of the oven.
27. While placing food to or removing food from the
oven, etc., always use heat resistant oven gloves.
28. Do not use the product in states like medicated
and/or under influence of alcohol which may affect your
ability of judgement.
29. Be careful when using alcohol in your foods. Alcoholwill
evaporate at high temperatures and may catch fire tocause a
fireif it comes in contact withhot surfaces.
30. After each use, check if the unit is turned off.
31. If the appliance is faulty or has a visible damage,do
not operate the appliance.
32. Do not touch the plug with wet hands. Do not pullthe
cord to plug off, always hold the plug.
33. Do not use the appliance with its front door glass
removed or broken.
34. Place the baking paper together with the food intoa
pre-heated oven by putting it inside a cooker or on anoven

9
accessory (tray, wire grill etc.).

10
G
B
35. Do not put objects that children may reach on the
appliance.
36. It is important to place the wire grill and tray properlyon
the wire racks and/or correctly place the tray on therack.
Place the grill or tray between two rails and makesure it is
balanced before putting food on it.
37. Against the risk of touching the oven heater elements,
remove excess parts of the baking paper that hang over
from the accessory or container.
38. Never use it at higher oven temperatures than the
maximum usage temperature indicated on your baking
paper. Do not place the baking paper on the base of the
oven.
39. When the door is open, do not place any heavy
object on the door or allow children to sit on it. You may
cause the oven to overturn or the door hinges to be
damaged.
40. The packaging materials are dangerous for children.
Keeppackagingmaterialsawayfromthereachof children.
41. Do not use abrasive cleaners or sharp metal scrapersto
clean the glass as the scratches that may occur on the
surface of the door glass may cause the glass to break.
42. Do not place the appliance on a surface covered
with carpets. Electric parts gets overheated since therewill
be no ventilation from below. This will cause failureof the
appliance.

11
43. Do not hit glass surfaces of vitro-ceramic cookers
with a hard metal, resistance can get damaged. It may
cause an electric shock.
44. User should not handle the oven by himself.
45. Use shall be careful when cleaning gas burners. It
may cause personal injuries.
46. Food can spill when foot of oven is dismantled or
gets broken, be careful. It may cause personal injuries.
47. During usage, the internal and external surfaces of
the oven get hot. As you open the oven door, step back to
avoid the hot vapour coming out from the interior.There is
risk of burning.
48. Upper cover of the oven can be closed for a reason,
than cookware can trip over. Step back to avoid the hot
food coming on you. There is risk of burning.
49. Do not place heavy objects when oven door is open,risk
of toppling.
50. User should not dislocate the resistance during
cleaning. It may cause an electric shock.
51. Do not remove ignition switches from the appliance.
Otherwise, live electric cables can be accessed. It may
cause an electric shock.
52. Oven supply can be disconnected during any
construction work at home. After completing the work,re-
connecting theovenshallbedonebyauthorizedservice.
53. Do not place metal utensils such as knife, fork, spoonon

12
G
B
the surface of the appliance, since they will get hot.

13
54. To prevent overheating, the appliance should notbe
installed behind of a decorative cover.
55. Turn off the appliance before removing the
safeguards. After cleaning, install the safeguards
according to instructions.
56. Cable fixing point shall be protected.
57. WARNING: Don’t use oven and grill burners at
same time.
58. Please don’t cook the food directly on the tray / grid.
Please put the food into or on appropriate tools before
putting them in the oven.
59. Hot surface, leave for cooling before closing the
cover.

14
G
B
Electrical Safety
1. Plug the appliance in a grounded socket protected by a
fuse conforming to the values specified in the technical
specifications chart.
2. Haveanauthorizedelectriciansetgroundingequipment.Our
company shall not be responsible for the damages that
shall be incurred due to using the product without
grounding according to local regulations.
3. The circuit breaker switches of the oven shall be
placed so that end user can reach them when the ovenis
installed.
4. The power supply cord (the cord with plug) shall not
contact the hot parts of the appliance.
5. If the power supply cord (the cord with plug) is
damaged, this cord shall be replaced by the manufactureror
its service agent or an equally qualified personnel to
prevent a hazardous situation.
6. Never wash the product by spraying or pouring wateron
it! There is a risk of electrocution.
7. WARNING: To avoid electric shock, ensure that
thedevice circuit is open before changing the lamp.
8. WARNING: Cut off all supply circuit connections
beforeaccessing the terminals.
9. WARNING:If thesurfaceis cracked,turn off theappliance
to avoid risk of electric shock.
10. Do not use cut or damaged cords or extension

15
cords other than the original cord.

16
G
B
11. Make sure that there is no liquid or humidity in the
outlet where the product plug is installed.
12. The rear surface of the oven also heats up when the
oven is operated. Electrical connections shall not touch
the rear surface, otherwise the connections may be
damaged.
13. Do not tighten the connecting cables to the oven
door and do not run them over hot surfaces. If the cord
melts, this may cause the oven to short circuit and even a
fire.
14. Unplug the unit during installation, maintenance,
cleaning and repair.
15. If the power supply cable is damaged, it must be
replaced by its manufacturer or authorized technical
service or any other personnel qualified at the same level,
in order to avoid any dangerous situation.
16. Make sure the plug is inserted firmly into wall
socket to avoid sparks.
17. Do not use steam cleaners for cleaning the appliance,
otherwise electric shock may occur.
18. An omnipolar switch capable to disconnect power
supply is required for installation. Disconnection from
power supply shall be provided with a switch or an
integrated fuse installed on fixed power supply
according to building code.

17
19. Appliance is equipped with a type ‘’Y’’ cord cable.

18
G
B
20. Fixed connections shall be connected to a power
supply enabling omnipolar disconnection. For applianceswith
over voltage category below III, disconnection deviceshall be
connected to fixed power supply according to wiring code.
Gas Safety
1. This appliance is not connected to burning products
evacuation apparatus.This appliance must be connectedand
installed according to the installation regulations in force.
Conditionsregardingventilationmustbeconsidered.
2. When a gas cooking appliance is used; humidity, heat
and burning products are generated in the room. First of
all, make sure the kitchen is well ventilated when
operating the appliance and maintain natural ventilation
openings or install a mechanical ventilationequipment.
3. After using the appliance heavily for en extended
period of time, additional ventilation may be required.For
example open a window or adjust a higher speed for
mechanical ventilation, if any.
4. This appliance must be used only in well ventilated
locations in accordance with the regulations in force.
Please read the manual before installing or using this
product.
5. Before positioning the appliance, make sure local
network conditions (gas type and gas pressure) meets
appliance requirements.

19
6. The mechanism cannot be run for longer than 15
seconds. If the burner is not on after 15 seconds, stopthe
mechanism and wait for at least one minute beforetrying
to ignite the burner again.
7. All kinds of operations to be performed on gas
installation must be performed by authorized and
competent people.
8. This appliance is adjusted for natural gas (NG). If you
have to use your product with a different gas type, you
havetoapplytoauthorizedservicefortheconversion.
9. For proper operation, hood, gas pipe and clamp
should be replaced periodically accordint to manufacturer
recommendations and when required.
10. Gas should burn well in gas products. Well burning
gas can be understood from blue flame and continuous
burning. If gas does not burn sufficiently, carbonmonoxide
(CO) can be generated. Carbon monoxide is a colourless,
odourless and very toxic gas; even small amounts have
lethal effect.
11. Ask your local gas supplies about the phone numbersfor
emergencies related to gas and the measures to betaken
upon gas odour is detected.

20
G
B
What To Do When Gas Odour Is Detected
1. Do not use naked flame, and do not smoke.
2. Do not operate any electrical switch.
(For example: lamp switch or doorbell)
3. Do not use telephone or mobile phone.
4. Open the doors and windows.
5. Close all valves on the appliances that utilize gasand
the gas counters.
6. Call fire brigade from a telephone outside the home.
7. Check all hoses and their connections against leaks. If
you still smell gas, leave the house and warn your
neighbours.
8. Do not enter into the house until authorities clarifyit is
safe.
