Cornelius 1522 User manual

DROP-IN AND FREE-STANDING
INSTALLATION INSTRUCTIONS
Alta 1522 Drop-In Dispenser
Release Date: June 12, 2013
Publication Number: 741200028INS
Revision Date: May 9, 2014
Revision: B
Visit the Cornelius web site at www.cornelius.com for all your Literature needs.

The products, technical information, and instructions contained in this manual are subject to change without
notice. These instructions are not intended to cover all details or variations of the equipment, nor to provide for
every possible contingency in the installation, operation or maintenance of this equipment. This manual assumes
that the person(s) working on the equipment have been trained and are skilled in working with electrical, plumb-
ing, pneumatic, and mechanical equipment. It is assumed that appropriate safety precautions are taken and that
all local safety and construction requirements are being met, in addition to the information contained in this man-
ual.
This Product is warranted only as provided in Cornelius’ Commercial Warrant applicable to this Product and is
subject to all of the restrictions and limitations contained in the Commercial Warranty.
Cornelius will not be responsible for any repair, replacement or other service required by or loss or damage
resulting from any of the following occurrences, including but not limited to, (1) other than normal and proper use
and normal service conditions with respect to the Product, (2) improper voltage, (3) inadequate wiring, (4) abuse,
(5) accident, (6) alteration, (7) misuse, (8) neglect, (9) unauthorized repair or the failure to utilize suitably qualified
and trained persons to perform service and/or repair of the Product, (10) improper cleaning, (11) failure to follow
installation, operating, cleaning or maintenance instructions, (12) use of “non-authorized” parts (i.e., parts that are
not 100% compatible with the Product) which use voids the entire warranty, (13) Product parts in contact with
water or the product dispensed which are adversely impacted by changes in liquid scale or chemical composition.
Contact Information:
To inquire about current revisions of this and other documentation or for assistance with any Cornelius product
contact:
www.cornelius.com
800-238-3600
Trademarks and Copyrights:
This document contains proprietary information and it may not be reproduced in any way without permission from
Cornelius.
This document contains the original instructions for the unit described.
CORNELIUS INC
101 Regency Drive
Glendale Heights, IL
Tel: + 1 800-238-3600
Printed in U.S.A.

TABLE OF CONTENTS
Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Read and Follow ALL Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Different Types of Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Qualified Service Personnel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Shipping And Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CO2 (Carbon Dioxide) Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Mounting in or on a Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unpacking and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Selecting a Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing the Dispenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Drop-In Dispenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Free-Standing Dispenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Preparing for Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Dispenser Valve Operating Pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting Product to the Dispenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Programming the Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Placing the Valve in Programming Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cleaning and Maintenance Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Daily Cleaning:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Daily Maintenance: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Monthly Cleaning: (In addition to daily and weekly procedures) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Annual Maintenance: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Sanitizing Product Cold Plate Tubing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Wash Product/Syrup Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Flush Cooling System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Sanitize Cooling System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Water Flush the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Purge Water (Restore Operation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cold Plate Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cleaning the Ice Bin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cleaning the Product Tubing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Sanitize syrup lines, BIB System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Replenishing CO2 Supply (As Required). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Adjust Water-To-Syrup Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Wiring and Plumbing diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Alta 1522 Drop-in Dispenser Installation Instructions
© 2013-2014, Cornelius Inc. - 1 - Publication Number: 741200028INS
SAFETY INSTRUCTIONS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
Safety Overview
• Read and follow ALL SAFETY INSTRUCTIONS in this manual and any warning/caution labels on the unit
(decals, labels or laminated cards).
• Read and understand ALL applicable OSHA (Occupational Safety and Health Administration) safety regula-
tions before operating this unit.
Recognition
DIFFERENT TYPES OF ALERTS
!
DANGER:
Indicates an immediate hazardous situation which if not avoided WILL result in serious injury, death or equipment
damage.
!
WARNING:
Indicates a potentially hazardous situation which, if not avoided, COULD result in serious injury, death, or equipment
damage.
CAUTION:
!
Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury or equipment
damage.
SAFETY TIPS
• Carefully read and follow all safety messages in this manual and safety signs on the unit.
• Keep safety signs in good condition and replace missing or damaged items.
• Learn how to operate the unit and how to use the controls properly.
• Do not let anyone operate the unit without proper training. This appliance is not intended for use by very
young children or infirm persons without supervision. Young children should be supervised to ensure that
they do not play with the appliance.
• Keep your unit in proper working condition and do not allow unauthorized modifications to the unit.
QUALIFIED SERVICE PERSONNEL
!
WARNING:
Only trained and certified electrical, plumbing and refrigeration technicians should service this unit. ALL WIRING
AND PLUMBING MUST CONFORM TO NATIONAL AND LOCAL CODES. FAILURE TO COMPLY COULD
RESULT IN SERIOUS INJURY, DEATH OR EQUIPMENT DAMAGE.
Recognize Safety Alerts
This is the safety alert symbol. When you see it in this manual or on the unit,
be alert to the potential of personal injury or damage to the unit.
!

Alta 1522 Drop-in Dispenser Installation Instructions
Publication Number: 741200028INS - 2 - © 2013-2014, Cornelius Inc.
SAFETY PRECAUTIONS
This unit has been specifically designed to provide protection against personal injury. To ensure continued
protection observe the following:
!
WARNING:
Disconnect power to the unit before servicing following all lock out/tag out procedures established by the user. Verify
all of the power is off to the unit before any work is performed.
Failure to disconnect the power could result in serious injury, death or equipment damage.
CAUTION:
!
Always be sure to keep area around the unit clean and free of clutter. Failure to keep this area clean may result in
injury or equipment damage.
SHIPPING AND STORAGE
CAUTION:
!
Before shipping, storing, or relocating the unit, the unit must be sanitized and all sanitizing solution must be drained
from the system. A freezing ambient environment will cause residual sanitizing solution or water remaining inside the
unit to freeze resulting in damage to internal components.
CO2(CARBON DIOXIDE) WARNING
!
DANGER:
CO2displaces oxygen. Strict attention MUST be observed in the prevention of CO2gas leaks in the entire CO2and
soft drink system. If a CO2gas leak is suspected, particularly in a small area, IMMEDIATELY ventilate the
contaminated area before attempting to repair the leak. Personnel exposed to high concentrations of CO2gas
experience tremors which are followed rapidly by loss of consciousness and DEATH.
MOUNTING IN OR ON ACOUNTER
!
WARNING:
When installing the unit in or on a counter top, the counter must be able to support a weight of 200 lbs. to insure
adequate support for the unit. FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY, DEATH OR
EQUIPMENT DAMAGE.
NOTE: Many units incorporate the use of additional equipment such as icemakers. When any addition
equipment is used you must check with the equipment manufacturer to determine the
additional weight the counter will need to support to ensure a safe installation.

Alta 1522 Drop-in Dispenser Installation Instructions
© 2013-2014, Cornelius Inc. - 3 - Publication Number: 741200028INS
UNPACKING AND INSPECTION
The unit was thoroughly inspected before leaving the factory and the carrier has accepted and signed for it. Any
damage or irregularities should be noted at the time of delivery and immediately reported to the delivery carrier.
Request a written inspection report from Claims Inspector to substantiate any necessary claim.
NOTE: IMI Cornelius is not responsible for damaged freight. If damage is found, you must save all packag-
ing material and contact the freight carrier. Failure to contact the carrier within 48 hours of receipt
may void your claim.
1. Inspect the carton and note any damage, regardless if it appears minor. If the carton is damaged, note on the
consignee copy of the freight invoice “exterior carton damage – concealed damage possible” and contact the
freight company immediately.
2. Remove any staples along the bottom edge of the carton and lift the carton off the pallet.
3. Remove the exterior carton sleeve, internal fillers and plastic bag around the unit. Carefully inspect the unit
for damage.
4. Remove the bolts holding the dispenser to the pallet.
5. Remove the packing fillers from the top of the unit.
6. Inspect the dispenser cabinet and make sure it has no scratches, dents or any other cosmetic defects.
7. Make sure that the glass or plastic merchandiser panels are not scratched or cracked.
8. Open the packages of loose parts and inspect all of the parts for damage or missing parts. Check the parts
received against the packing list to insure receipt of all parts.

Alta 1522 Drop-in Dispenser Installation Instructions
Publication Number: 741200028INS - 4 - © 2013-2014, Cornelius Inc.
SELECTING A LOCATION
The dispenser must be located near a permanent drain to route and connect the unit ice bin and drip tray drain
hoses. All drains and connections to such drains must meet local plumbing codes.
The unit must be located near a properly grounded electrical outlet. Circuit should be fused and no other electrical
appliance should be connected to the circuit. ALL ELECTRICAL WIRING MUST CONFORM TO NATIONAL AND
LOCAL ELECTRICAL CODES.
INSTALLING THE DISPENSER
!
WARNING:
It is the responsibility of the installer to ensure that the water supply to the dispensing equipment is provided with
protection back flow by an air gap as defined in ANSI A 112.1.2-1979; or an approved vacuum breaker or other such
method as proved effective by test and must comply with all federal, state and local codes.
Failure to comply could result in serious injury, death or damage to the equipment.
Water pipe connections and fixtures directly connected to a potable water supply shall be sized, installed and
maintained according to Federal, State and Local laws.
Drop-In Dispenser
1. Use the Template supplied to mark the location of the hole to be cut into the counter top. Cut the hole as marked
and remove the material.
2. Apply the double stick tape (if supplied with the loose shipped parts).
NOTE: To comply with the National Sanitation Foundation (NSF) requirements, the unit must be sealed to
the counter top.
3. Liberally apply a sealant, such as Dow Corning RTV 731 or equivalent, to the unit flange bottom surface.
4. Lower the unit into position to complete the seal of the rim to the counter top. Apply additional sealant
around the rim to ensure a complete seal.
CAUTION:
!
Do not move the unit after positioning or the seal may be broken.
5. Remove any excess sealant.
6. Mount the Transformer power supply under the counter, in a position to allow access to the electrical outlet
and to allow the 24V power cord to reach the dispenser.
7. Install the drain hose to the ice bin drain fitting and route the drain hose to a permanent drain.
Free-Standing Dispenser
1. Install the 6” legs to the dispenser cabinet if they are to be used.
2. Place the dispenser in the location selected. Be sure the dispenser is level. This is important to ensure that
the bin drains properly.
3. Mount the Transformer power supply in a convenient location to allow access to the electrical outlet and to
allow the 24V power cord to reach the dispenser.
4. Install the drain hose to the ice bin drain fitting and route the drain hose to a permanent drain.

Alta 1522 Drop-in Dispenser Installation Instructions
© 2013-2014, Cornelius Inc. - 5 - Publication Number: 741200028INS
PREPARING FOR OPERATION
1. Fill the bin with 32° F (0.0° C) ice. DO NOT use ice taken directly from a freezer.
2. Make sure that the cold plate has been chilled for at least 1/2 hour prior to setting the ratio (BRIX), per
Pepsi specifications.
3. Start the water booster system according to the suppliers instructions.
4. Turn on the water supply to the unit and pull the relief valve on the carbonator tank, located in bottom of the
unit, to assure that the system is flooded with water and all air is removed.
5. Turn off the water supply.
6. Turn on the CO2supply. Supply pressure of 110 PSIG from the bulk or high pressure tank to the secondary
CO2guage.
7. Plug the transformer into the electrical outlet. The 24V supply must be connected in the dispensing tower.
The ice-bin lid must be closed to allow the valve to operate.
8. Depress and hold any of the brand buttons that dispense carbonated water until CO2only dispenses to
purge the system. Now all air is evacuated and the tank is charged with CO2.
9. Turn on the water supply to the unit.
10. Plug in the pump deck and the motor will run to fill the carb tank with carbonated water.
11. Start up the BIB pumps according to supplier’s instructions.
12. Press each brand button individually and hold them open to prime the water and syrup lines. It may take
several dispenses until spitting stops and all air has been removed from the water and syrup lines.
13. Set the flow rate for the valve [2-3.75 oz/sec. (59.1-111 cc/sec.)].
DISPENSER VALVE OPERATING PRESSURE
Maximum operating pressure for the valve is 120 PSI (8.27 bar).
CONNECTING PRODUCT TO THE DISPENSER
NOTE: All inlet connections are clearly marked with a label adjacent to the inlet connections. Always leak
check all connections.
Valve must have a supply connected to each inlet. Refer to the plumbing diagram for details of the hook-up.
NOTE: A plumbing diagram, when supplied with the unit, can be found in the dispensing tower.
PROGRAMMING THE VALVES
The valves in the Alta 1522 drop-in dispenser may be programmed for dispensing either carbonated water or plain
water. Before operating the unit, the installer must enter programming mode to select any plain water valve settings
required.
Placing the Valve in Programming Mode
To place the valve in programming mode, press and hold both water buttons and hold them for 5 seconds. This
placed the valve in programming mode and allows the setting of the water type for each brand. When the valve
enters programming mode, the programming LED illuminates. All valves default to carbonated water on entering
programming mode.
To select plain water for a praticular product, the user must press and release the product button. The program LED
flashes twice to indicate acceptance.
After 5 seconds without a button press, the valve exits programming mode and saves the water types in memory.

Alta 1522 Drop-in Dispenser Installation Instructions
Publication Number: 741200028INS - 6 - © 2013-2014, Cornelius Inc.
CLEANING AND MAINTENANCE INSTRUCTIONS
!
WARNING:
Disconnect power to the unit before servicing. Follow all lock out/tag out procedures established by the user. Verify all
power is off to the unit before performing any work.
Failure to comply could result in serious injury, death or damage to the equipment.
CAUTION:
!
Do not use metal scrapers, sharp objects or abrasives on the ice storage hopper, top cover or exterior surfaces as
damage to the unit may result. Do not use solvents or other cleaning agents as they may attack the material resulting
in damage to the unit.
• Soap solution – Use a mixture of mild detergent and warm (100° F) potable water.
• Sanitizing Solution – Dissolve 2 packets (4 oz) of Stera Sheen Green Label into 2 gallons of warm [80-
100° F (26.7-37.8° C)] potable water to ensure 200 ppm of chlorine.
DAILY CLEANING:
1. Remove cup rest from drip tray and clean with warm soapy water, rinse with clean water and allow to air dry.
2. Wipe down the exterior of the unit with warm, soapy water and rinse with clean, warm water and allow to air
dry.
3. Remove valve nozzle and diffuser and wash in warm soapy water, rinse in clean, warm water and allow to air
dry.
4. Spray the nozzle and diffuser inside and outside with approved sanitizing solution, reinstall them on the valve
and allow to air dry.
5. Pour warm, soapy water down the drains to keep them clean and flowing smoothly.
6. Reinstall the cup rest into the drip tray.
7. Pour all remaining sanitizer solution down the drain to help keep the drain clear.
DAILY MAINTENANCE:
1. Check the temperature, smell and taste of the product.
2. Check the water pressure coming to the unit using the pressure gauges on the back room package.
3. Check carbonation of the drink.
4. Check level of CO2supply to the system.
5. Check the date on all of the BIB’s (bags in boxes).
MONTHLY CLEANING: (INADDITION TO DAILY AND WEEKLY PROCEDURES)
1. Flush and sanitize all syrup lines as well as all of the syrup connectors. (See the sanitize syrup lines section
shown later in this manual).
2. Remove the ice from ice bin and clean and sanitize the ice bin. (See the Cleaning the interior surfaces
section shown later in this manual).
3. While cleaning the ice bin, use the brush provided with the unit to clean the cold plate surface.
ANNUAL MAINTENANCE:
1. Have the water pump and check valve inspected and cleaned by a qualified service technician.
2. Have the CO2gas check valve inspected and cleaned by a qualified service technician.

Alta 1522 Drop-in Dispenser Installation Instructions
© 2013-2014, Cornelius Inc. - 7 - Publication Number: 741200028INS
SANITIZING PRODUCT COLD PLATE TUBING
Preparing the Cleaning Solution: Using a clean tank (tank system) or a five-gallon container (bag-in-box
system), prepare a full tank or container of liquid dishwasher detergent by using 70° F (21° C) to 100° F (38° C)
potable water and 0.5 oz. (15 ml) of liquid dishwasher detergent (such as Joy, Ivory, etc.) to one gallon of potable
water. Shake detergent solution to thoroughly mix the solution.
Preparing the Sanitizing Solution: Using a clean tank (tanks system) or a five-gallon container (bag-in-box
system), prepare sanitizing solution using 70° F (21° C) to100° F (38° C) potable water and 0.5 oz. (15 ml) of
household liquid bleach such as non-scented Hi-Lex or Chlorox that contains a 5.25 % sodium hypochlorite
concentration to one gallon of potable water.This mixture must not exceed 200 PPM of chlorine. Shake sanitizing
solution to thoroughly mix.
Wash Product/Syrup Systems
1. Using a five-gallon container, prepare a container of liquid dishwasher detergent by using 70° F (21° C) to 100°
F (38° C) potable water and 0.5 oz. (15 ml) of liquid dishwasher detergent (such as Joy, Ivory, etc.) to one gallon
of potable water. Thoroughly mix the solution.
2. Install bag valves (cut from empty bag-in-box syrup containers) on ends of syrup containers syrup outlet
tubes connectors.
3. Place all BIB syrup outlet tubes, with bag valves on their ends, in container containing detergent solution.
4. Place waste container under the dispensing valve.
5. Activate the dispensing valve for one minute for each product flavor to purge all syrup and flush out the
syrup system.
6. Continue to activate the dispensing valve in cycles (“ON” for 15 seconds, “OFF”, then “ON” for 15
seconds). Repeat “ON” and “OFF” cycles for 15 cycles.
7. Connect detergent solution to remaining syrup systems and flush syrup out of syrup systems as instructed
in Step 2.
8. Remove detergent solution source from the syrup system.
Flush Cooling System
1. Fill a five-gallon container with potable water, then place all bag-in-box syrup outlet tubes in the container.
2. Place a waste container under the dispensing valve.
3. Activate the valve for one minute for each product flavor to purge all detergent solution and flush out of the
syrup system.
4. Continue to activate the valve in cycles (“ON” for 15 seconds, “OFF”, then “ON” for 15 seconds). Repeat
“ON” and “OFF” cycles for 15 cycles.
5. Remove potable water source from the syrup system.
Sanitize Cooling System
1. Using a five-gallon container, prepare sanitizing solution using 70° F (21° C) to 100° F (38° C) potable water and
0.5 oz. (15 ml) of household liquid bleach such as non-scented Hi-Lex or Chlorox that contains a 5.25 % sodium
hypochlorite concentration to one gallon of potable water.This mixture must not exceed 200 PPM of chlorine.
Thoroughly mix the solution.
2. Place all BIB outlet tubes in the sanitizing solution container.
3. Place a waste container under the dispensing valve.
4. Activate the dispensing valve for one minute for each product flavor to purge all water and install sanitizing
solution in the syrup system and dispensing valve.
5. Continue activating the dispensing valve in cycles (“ON” for 15-seconds, “OFF”, then “ON” for 15-
seconds). Repeat “ON” and “OFF” cycles for 15-cycles.
6. Remove the sanitizing solution source from the syrup system.

Alta 1522 Drop-in Dispenser Installation Instructions
Publication Number: 741200028INS - 8 - © 2013-2014, Cornelius Inc.
7. Allow sanitizing solution to remain in the syrup systems for not less than 10 or no more than 15 minutes
(max.).
Water Flush the System
1. Fill a five-gallon container with potable water.
2. Place all BIB outlet tubes into the potable water container.
3. Place a waste container under the dispensing valve.
4. Activate the dispensing valve for one minute for each product flavor to purge all sanitizing solution out of
the syrup system and the dispensing valve.
5. Continue to activate the dispensing valve in cycles (“ON” for 15 seconds, “OFF”, then “ON” for 15
seconds). Repeat “ON” and “OFF” cycles for 15 cycles.
6. Remove the potable water source from the syrup system.
Purge Water (Restore Operation)
1. Remove all bag valves from BIB syrup container outlet tube connectors.
2. Reconnect the BIB containers to the syrup system.
3. Place a waste container under the valve. Dispense from the valve to permit syrup to purge all potable water
from the syrup systems and the dispensing valve. Continue to dispense from the valve until only syrup is
dispensed from the syrup systems and valve.
4. Repeat Step 3 for all product flavors.
!
WARNING:
To avoid possible personal injury or property damage, do not attempt to remove the syrup tank cover until CO2
pressure has been released from the tank.
5. Dispose of waste sanitizing solution in sanitary sewer, not in a storm drain, then thoroughly rinse the inside
and outside of the container that was used for sanitizing solution to remove all sanitizing solution residue.
COLD PLATE CLEANING
1. Locate and remove any debris from the drain trough. Check that the drain holes are not clogged.
2. Pour small amount of soap solution on cold plate.
3. Using a cloth, wash down the surfaces of the cold plate with soap solution.
4. Rinse cold plate surface by pouring potable water.
CLEANING THE ICE BIN
1. Prepare a mild detergent soap solution in 100° F (38° C) potable water.
2. Using a nylon (not wire) bristle brush, clean the cold plate and the interior of the ice bin with the soap
solution.
3. Rinse the cold plate and interior bin surfaces with clean potable water.
4. Using a mechanical spray bottle, prepare a sanitizing solution according to the manufacturer’s directions
and spray all of the interior bin surfaces. Allow to air dry.
CLEANING THE PRODUCT TUBING
!
WARNING:
Only trained and certified electrical, plumbing and refrigeration technicians should service this unit.
All wiring and plumbing must conform to national and local codes. Failure to comply could result in serious injury,
death or equipment damage.

Alta 1522 Drop-in Dispenser Installation Instructions
© 2013-2014, Cornelius Inc. - 9 - Publication Number: 741200028INS
Sanitize syrup lines, BIB System
1. Remove all the quick disconnects from all the BIB containers.
2. Fill a suitable pail or bucket with soap solution.
3. Submerge all disconnects (gas and liquid) in the soap solution and then clean them using a nylon bristle
brush. (Do not use a wire brush). Rinse with clean water.
4. Using a plastic pail, prepare approximately five gallons of sanitizing solution.
5. Rinse the BIB disconnects in the sanitizing solution.
6. Sanitizing fittings must be attached to each BIB disconnect. If these fittings are not available, the fittings
from empty BIB bags can be cut from the bags and used. These fittings open the disconnect so the
sanitizing solution can be drawn through the disconnect.
7. Place all the BIB disconnects into the pail of sanitizing solution. Operate the valve until the sanitizing
solution is flowing from the valve. Allow sanitizer to remain in lines for 15 minutes.
8. Remove the nozzle and syrup diffuser from the valve and clean them in a soap solution. Rinse with clean
water and reassemble the nozzle and syrup diffuser to the valve.
9. Remove the sanitizing fittings from the BIB disconnects and connect the disconnects to the appropriate
BIB container. Operate the valve until all sanitizer has been flushed from the system and syrup is flowing
freely.
REPLENISHING CO2SUPPLY (ASREQUIRED)
NOTE: When indicator on the 1800-psi gage is in the shaded (“change CO2cylinder”) portion of the dial,
CO2cylinder is almost empty and should be changed.
!
DANGER:
CO2displaces oxygen. Strict attention MUST be observed in the prevention of CO2gas leaks in the entire CO2and
soft drink system. If a CO2gas leak is suspected, particularly in a small area, IMMEDIATELY ventilate the
contaminated area before attempting to repair the leak. Personnel exposed to high concentrations of CO2gas
experience tremors which are followed rapidly by loss of consciousness and DEATH.
1. Fully close (clockwise) the CO2cylinder valve.
2. Slowly loosen the CO2regulator assembly coupling nut allowing CO2pressure to escape, then remove the
regulator assembly from the empty CO2cylinder.
3. Unfasten safety chain and remove the empty CO2cylinder.
!
WARNING:
To avoid personnel injury and/or property damage, always secure the CO2cylinder with a safety chain to prevent it
from falling over. Should the valve become accidently damaged or broken off, a CO2regulator can cause serious
personnel injury or death.
4. Position the full CO2cylinder and secure with a safety chain.
5. Make sure gasket is in place inside the CO2regulator assembly coupling nut, then install the regulator
assembly on the CO2cylinder.
6. Open (counterclockwise) the CO2cylinder valve slightly to allow the lines to slowly fill with gas, then open
the valve fully to back-seat the valve (back-seating the valve prevents gas leakage around the valve shaft).
7. Check CO2connections for leaks. Tighten any loose connections.

Alta 1522 Drop-in Dispenser Installation Instructions
Publication Number: 741200028INS - 10 - © 2013-2014, Cornelius Inc.
ADJUST WATER-TO-SYRUP RATIO
Figure 1. Water to Syrup Ratio Adjustment
1. Remove valve cover and install syrup separator over the diffuser and through the nozzle.
2. Hold cup under valve and dispense beverage for a specific time (i.e. 2 seconds).
NOTE: Water and syrup must be cold before checking ratios.
3. Adjust carbonated water flow to the desired rate [such as 2 to 3 oz. (59 to 88.5 ml) per second].
4. Turn the flow adjuster 1/4 of a turn at a time and recheck the flow. To increase reading turn clockwise.
5. Set syrup flow adjuster to get the desired ratio.
6. Test the valve and adjust until a consistent ratio is delivered three consecutive times.
Separator
Water-To-Syrup
Ratio Cup

Alta 1522 Drop-in Dispenser Installation Instructions
© 2013-2014, Cornelius Inc. - 11 - Publication Number: 741200028INS
TROUBLESHOOTING
!
WARNING:
Only trained and certified electrical, plumbing and refrigeration technicians should service this unit.
All wiring and plumbing must conform to national and local codes. Failure to comply
could result in serious injury, death or equipment damage.
NOTE: Crushed ice in the glass also causes dispensing problems. When finished drink hits sharp edges of
ice, carbonation is released from dispensed drink.
Trouble Probable Cause Remedy
ADJUSTMENT OF
DISPENSING VALVE SYRUP
FLOW REGULATOR DOES
NOT INCREASE TO DESIRED
WATER-TO-SYRUP “RATIO”
A. Dispensing valve syrup flow regu-
lator, BIB quick disconnect, or
syrup line restricted.
B. BIB quick disconnects not secure.
C. Secondary CO2 regulator out of
adjustment.
D. No syrup supply.
E. Improper syrup BRIX.
F. Dirty or inoperative piston or
spring in dispensing valve syrup
flow regulator.
A. Sanitize syrup system as
instructed.
B. Secure quick disconnects.
C. Adjust syrup tanks secondary
CO2 regulator as instructed.
D. Replenish syrup supply.
E. Replace syrup supply.
F. Disassemble and clean dispens-
ing valve syrup flow regulator.
ADJUSTMENT OF
DISPENSING VALVE SYRUP
FLOW REGULATOR DOES
NOT DECREASE TO
DESIRED WATER-TO-SYRUP
“RATIO”
A. Dirty or inoperative piston or
spring in dispensing valve syrup
flow regulator.
A. Disassemble and clean dispens-
ing valve syrup flow regulator.
DISPENSED PRODUCT
CARBONATION TOO LOW
A. Carbonator primary CO2regula-
tor out of adjustment for existing
water conditions or temperature.
B. Air in carbonator tank.
C. Water, oil, or dirt, in CO2supply.
A. Adjust carbonator primary CO2
regulator (Reference manual pro-
vided with carbonator).
B. Vent air out of carbonator tank
through relief valve. Actuate dis-
pensing valve carbonated water
lever to make carbonator pump
cycle on.
C. Remove contaminated CO2.
Clean CO2system (lines, regula-
tors, etc.) using a mild detergent.
Install a clean CO2supply.
CARBONATED PRODUCT
DISPENSED WITH PLAIN
WATER
A. Tower not programmed correctly
for product.
A. Verify valve programming and cor-
rect.
DISPENSED PRODUCT
COMES OUT OF
DISPENSING VALVE CLEAR
BUT FOAMS IN CUP OR
GLASS (Continued)
A. Oil film or soap scum in cup or
glass.
B. Ice used for finished drink is sub-
cooled.
A. Use clean cup or glass.
B. Do not use ice directly from
freezer. Allow ice to become “wet”
before using. (Refer to following
NOTE).

Alta 1522 Drop-in Dispenser Installation Instructions
Publication Number: 741200028INS - 12 - © 2013-2014, Cornelius Inc.
NOTE: If water supply is dirty, be sure to flush lines and carbonator completely. It may be necessary to
remove lines to carbonator tank. Invert and flush tank and all inlet lines to remove any foreign parti-
cles or dirt.
DISPENSED PRODUCT COMES
OUT OF DISPENSING VALVE
CLEAR BUT FOAMS IN CUP OR
GLASS
C. Carbonator CO2regulator pres-
sure too high for existing water
conditions or temperature.
D. Syrup over-carbonated with CO2
as indicated by bubbles in inlet
syrup lines leading to unit.
E. Warm Product - No ice in bin,
bridged ice on cold plate or
plugged drain.
C. Reduce carbonator CO2regulator
pressure setting. Reference man-
ual provided with carbonator.
D. Remove BIB quick disconnects.
Relieve CO2pressure, then
relieve CO2pressure as many
times as necessary to remove
over-carbonation.
E. Replenish ice, break ice up to
eliminate bridging, unplug the
drain.
NO PRODUCT DISPENSED
FROM ONE DISPENSING
VALVE
A. Broken or disconnected wiring.
B. Inoperative dispensing valve
solenoid coil.
C. Inoperative dispensing valve
micro switch.
A. Repair or connect wiring.
B. Replace solenoid coil as
instructed.
C. Replace micro switch as
instructed.
ONLY CARBONATED WATER
DISPENSED
A. Quick disconnects not secure
on syrup tanks.
B. Out of syrup.
C. BIB connectors not properly
connected.
D. Syrup secondary CO2regulator
not properly adjusted.
E. Inoperable dispensing valve.
F. Dispensing valve syrup flow reg-
ulator not properly adjusted.
G. Dispensing valve syrup flow reg-
ulator, BIB quick disconnect, or
syrup lines restricted.
A. Secure quick disconnects on
syrup tanks.
B. Replenish syrup supply as
instructed.
C. Properly attach the connectors.
D. Adjust syrup tanks secondary
CO2regulator as instructed.
E. Repair dispensing valve.
F. Adjust dispensing valve syrup
flow regulator (Water-to-Syrup
“Ratio”) as instructed.
G. Repair regulator, disconnect or lines
and sanitize syrup system as
instructed.
ONLY SYRUP DISPENSED
A. Plain water inlet supply line
shutoff valve closed.
B. Carbonator power cord
unplugged from electrical outlet.
C. Carbonator primary CO2regula-
tor not properly adjusted.
A. Open plain water inlet supply line
shutoff valve.
B. Plug carbonator power cord into
electrical outlet.
C. Adjust carbonator primary CO2
regulator (Reference manual
provided with carbonator).

Alta 1522 Drop-in Dispenser Installation Instructions
© 2013-2014, Cornelius Inc. - 13 - Publication Number: 741200028INS
WIRING AND PLUMBING DIAGRAMS
Figure 2. Alta 1522 Drop-in Dispenser Wiring Diagram

Alta 1522 Drop-in Dispenser Installation Instructions
Publication Number: 741200028INS - 14 - © 2013-2014, Cornelius Inc.
Figure 3. Alta 1522 Drop-in Dispenser Plumbing Diagram

IMI Cornelius Inc.
www.cornelius.com
