ED2XX Dual Mounting Kit Installation Manual
© 1998-2010, IMI Cornelius Inc. - 1 - Publication Number: 620914101
INSTALLATION INSTRUCTIONS
FOR ED2XX DUAL–MOUNTING KIT
DISPENSER MODEL KIT PART NUMBER
ED200/250 629085101
!
WARNING:
Disconnect power to the unit before servicing. Follow all lock out/tag out procedures established by the user. Verify all
power is off to the unit before performing any work.
Failure to comply could result in serious injury, death or damage to the equipment.
1. Remove lower panel assembly from both Units.
2. Relocate beverage valve key switch to right side of the beverage panel on one of the Units. This Unit will be
positioned on the right side of the counter.
A. Remove beverage panel access covers.
B. Locate black and red wires of the key switch. Cut these wires approximately 2 inches from the crimp
nut connection to the yellow wires.
C. Loosen the key switch mounting nut and remove the key switch.
Using a 7/8–inch deep socket will help
access the nut.
D. Remove plastic plug from right side of the beverage panel and insert into the left side key switch opening.
E. Install key switch into the right side of the beverage panel and tighten mounting nut.
F. Move black and red wires from left to right side of the beverage panel. Strip red/black wires and recon-
nect to the key switch using wire connectors (item 4) provided.
G. Install beverage panel access covers.
3. Install Adaptor Kits if applicable for the type of ice makers used.
4. Apply self–adhesive gasket material (item 7) to the side of one Unit as indicated in Figure 1. Ends of the
gasket should fit tight to each other.
5. Place Units into position on the counter. The Units must be at the same height and sitting level. The out-
side-outside dimension of the Units should be 60-3/8 inches (3/8-inch between the Units at the center).
6. Remove one screw from each base at the rear of the Unit and install rear mounting plate (item 2) to main-
tain the proper spacing between the Units (see Figure 2).
Table 1. Parts List
Item No. Part No. Name Qty.
1 629080214 Insulated Lower Panel, Dual 1
2 29677 Rear Mounting Plate 1
3 620023904 Front Mounting Plate (For 6 and 8 Beverage Valve Units) 1
4 32990 Wire Connectors 4
5 50904 RTV Sealant, 3-oz Tube 2
6 620013301 Drip Tray Cover, Black 1
7 620500201 Gasket 150–In
8 620914101 Installation Instructions 1
9 70555 Screw, No. 8–32 By 1 5/16–In. long 2
10 71010 Captivating Plastic Washer, No. 8 2
11 91486 Cornelius Logo 1
Release Date: September 28, 2010 www.cornelius.com Revision: B

ED2XX Dual Mounting Kit Installation Manual
Publication Number: 620914101 - 2 - © 1998-2010, IMI Cornelius Inc.
7. Install front mounting plate (item 3) using the four beverage panel mounting screws at the center of the
Units. The rectangular plate is for use with the six or eight valve Units.
8. Apply RTV (item 5) at the gasket–cabinet joint to seal any gaps between the Units, on all sides of the gasket.
9. Using one screw on each cabinet at the center of the Units (above the drip trays), install drip tray cover to match
color of the drip tray. The drip trays must be at the same height along the edges for cover to fit properly.
10. Assemble two long #8-32 screws (item 9) to lower panel (item 1) using plastic washers (item 10). Install
lower panel assembly on Units.
11. Install Cornelius logo (item 11).
12. Replace hopper covers on the Units, manual fill Units.
13. Connect power cords for Ice/Beverage Dispenser to electrical outlet. Check Dispensers for proper operation.
Figure 1.

ED2XX Dual Mounting Kit Installation Manual
© 1998-2010, IMI Cornelius Inc. - 3 - Publication Number: 620914101
Figure 2.
