Cornell CCC-E2000 User manual

1
Ceramic CCC-E2000
Cooker

2
1. Thank you for your purchase of this appliance. Read all
instructions carefully. Keep this User Manual for future reference.
2. Always unplug appliance from the power supply before cleaning
or when not in use.
3. Always attach the power cord to the appliance BEFORE you plug
into the power supply. To disconnect appliance, switch off first
before removing the power plug from the power supply.
4. This product must not be left unattended while it is connected to
the main supply.
5. Do not use this appliance for other than its intended use.
6. Do not operate appliance with a damaged power cord set, or plug.
Any repairs should always be undertaken by an authorized
service centre.
7. Always place appliance on a flat sturdy surface. When moving
appliance, always ensure not to touch hot surfaces to avoid
possible spillage of hot liquids it may contain.
8. Do not immerse appliance, or electrical parts into water or any
other liquids.
9. Use of accessories or equipment not supplied by the
manufacturer may result in damage or malfunctioning of your
appliance or result in injuries.
10. This appliance should not be used by people who are physically
or mentally impaired (including children) unless proper guidance
is provided during operation.
GENERAL SAFETY PRECAUTIONS

3
1. Ensure that the AC supply voltage corresponds with that of the
Rating Label of the induction cooker.
2. Do not place the appliance on or near to a hot gas or electric
burner, in a heated oven, or near to easily flammable materials.
3. Do not use the ceramic cooker on a metal panel surface.
4. Ensure the ceramic cooker is placed on a flat and sturdy surface
before cooking.
5. If the cook top is found to be cracked or broken, switch off and
disconnect it from power supply. Send the ceramic cooker to an
authorized service centre nearby for examination and repairs. Do
not attempt to repair by yourself.
6. WARNING: Do not touch the cook top immediately after cooking.
It is extremely hot!
7. The ceramic cooker will recommence heating should the cooking
pan be removed from the cook top but replaced after a short
period.
8. Do not insert any flammable materials like pieces of paper,
cardboard, cloth, etc. in-between the pan and cook top of the
ceramic cooker as this might cause a fire.
9. Do not place metallic objects such as knives, forks, spoons and
lids on the cooking surface whilst the induction cooker is on.
They will heat up very quickly and pose a danger to the user.
10. Although tested to be SAFE, persons using a heart pacemaker
should consult their doctor whether they should be near or be
using any ceramic cooker.
11. Do not place credit cards, phone cards, cassette tapes, or other
objects that are sensitive to magnetic field on the cooking surface
as all data will be erased.
INDUCTION COOKER SAFETY REGULATION

4
12. The ceramic cooker has an automatic shutdown protection, it will
automatically shut down after 2 hours if there is no operation
detected.
13. The ceramic cooker also has an electronic devices, itself will
detect the temperature and make auto temperature adjustment
when overheat.
14. Do not allow water or food to overflow from the pan to the cook
top. Wipe off immediately.
15. NEVER clean the ceramic cooker under running water.
16. Do not touch any parts inside the ceramic cooker with a sharp
object, i.e. stick or screwdriver etc.
17. Do not use the cooker without cookware.
18. If the power cord is damaged, have it replaced by the after-sales
service agent or similarly qualified personnel to ensure proper
installation.

5
Model
CCC-E2000
Rated Voltage
220-240V~
Rated Wattage
2000W
Frequency
50-60Hz
SPECIFICATION
PARTS IDENTIFICATION
Heating Area
Ceramic Glass
Control Panel

6
Cookware Selection: The ceramic cooker allow to uses all kind of
flat-bottom cookware.
Cookware must be placed in the middle of the cooking zone.
Power ON: Connect the power plug into the Mains power supply and
switch on. The buzzer will sound “BI”，all power level LED indicator
light will blink, press the On/Off button the cooker will start working at
1000W. 1000W LED indicator light will illuminate.
Press "+" button or “-”button to increase or decrease the heating
level from 200W to 2000W. A total of five heating levels can be
selected at 200W，500W，1000W, 1500W and 2000W.
Timer mode: Press “Timer” key to increase or decrease auto off time
at 15min,30min,60min,90min and120min .
Power OFF: Turn the ceramic cooker off by pressing the On/Off
button again. The temperature indicator light will not be off until the
temperature of the panel is lower than 600C.
OPERATING INSTRUCTIONS

7
Points for safety
1. Over-beat protection for the cooker surface: when the
temperature of the surface is over 650℃，the cooker will be
automatically cooled down.
2. Over-temperature protection for the cooker: when the
temperature inside the cooker reaches 100℃the heating will be
stopped.
3. Over-voltage protection: when the voltage is over 270V，the
heating will be stopped.
4. Low-voltage protection: when the voltage is lower than 100V, the
heating will be stopped.
5. Constant-power protection: when the voltage rises （within
270V），the output currency will decrease ，the maximum
power increase will not exceed 500W. When the voltage
decreases，the maximum output power will decrease according
to the voltage change.
6. Protection categories and codes
Serial number
Protection categories
Codes
1
Low-voltage protection
E1
2
Over-voltage protection
E2
3
Heat-sensitive resistance
short-circuit protection
E3
4
Heat-sensitive resistance
open-circuit protection
E4
5
High-temperature
protection
E5

8
Fault cases
Inspection point
No heating , Indicator light is off
Inspect the power supply ( cable
plugged in the wall socket)
Check fuse.
The cooker has stop heating in
the course of cooking.
1. Check whether the
surrounding temperature
is very high or the
inhaling port are blocked.
2. Whether the preset time
is finished.
If the power wire is damaged, it must send to the professional
maintenance department or the manufacturer for replacement, users
should not change it privately.
Protection categories
Codes
Treating methods
Low-voltage protection
E1
Check whether the
voltage is lower than
100V
Over-voltage
protection
E2
Check whether the
voltage is higher than
270V
Heat-sensitive
resistance open-circuit
protection
E3
Check and test the
resistance
Heat-sensitive
resistance short-circuit
protection
E4
Check and test the
resistance
Over-temperature
protection
E5
Whether the inhaling
port and the exhaust
port are blocked.
TROUBLESHOOTING GUIDE

9
Before cleaning, the ceramic cooker must be allowed to cool at room
temperature.
Cook Top: The cleaning of the cook top is identical to that for
other similar glass surfaces. Do not use corrosive or abrasive
cleaning agents such as grill and oven sprays, stain and rust
removers, scouring powder and rough sponges. Clean the
cooking plate with a wet towel. A little mild soap can be used
before wiping.
Use an old toothbrush to clean ventilation slots. DO NOT splash
WATER on and into the ventilation slots. Such water seepage will
cause damage.
Always keep the cook top surface clean of food and other liquids
by using a soft damp cloth. Allow to dry before storage. Regular
cleaning, care and servicing of your induction cooker will ensure
its performance at all times.
CARE AND CLEANING
