Cornell CGS-P125SSD User manual

1
CGS-P125SSD
CGS-P1102SSD
GAS COOKER
CGS-P125SSD
CGS-P1102SSD

2
Contents
Important safety information 3 - 6
Specifications 7 - 8
CGS-P125SSD 7
CGS-P1102SSD 8
Using the gas table top hob 9 - 11
Before first use 9
The gas table top hob 9
Automatic ignition with flame failure safety device 10
Energy saving tips 11
Cleaning 12 - 13
Cleaning the hob top 12
After each use 12
Cleaning the hob burners 13
Maintaining the cast iron pan stands 13
Installation 14 - 18
My appliance isn’t working correctly 19
Attention
Please read these instructions carefully before using.
Please keep themin a safe place for future
reference.

3
Important safety information
Your safety is of the utmost importance. Please ensure
that you read this instruction booklet before
attempting to install or use the appliance. If you are
unsure of any of the information contained in this
booklet, please contact AMTEK MARKETING SERVICES
PTE LTD.
General Information
oThis appliance is designed for domestic household use and for
the cooking and frying of domestic foodstuffs.
oIMPORTANT: The adjacent furniture and all materials used in
the installation must be able to withstand a minimum
temperature of 85°C above the ambient temperature of the
room it is located in, whilst in use.
oCertain types of vinyl or laminate kitchen furniture are
particularly prone to heat damage or discolouration at
temperatures below the guidelines given above.
oAny damage caused by the appliance being installed in
contravention of this temperature limit, will be the liability of
the owner.
oYour new appliance is guaranteed against electrical or
mechanical defects, subject to certain exclusions that are noted
in AMTEK MARKETING SERVICES PTE LTD Conditions Of
Guarantee.
oThe use of this appliance for any other purpose or in any other
environment without the express agreement of AMTEK
MARKETING SERVICES PTE LTD will invalidate any warranty or
liability claim.
oYou should not use this appliance to store items on or as a work
surface.
oNo modifications to the appliance are permitted as this will
invalidate any warranty or liability claim.

4
oYou should not store or place flammable or highly flammable
liquids/materials on top of or near the appliance. Items made
from aluminium, plastic or plastic film should also be kept away
from the appliance, as they may fuse to the surface.
oRepairs may only be carried out by AMTEK MARKETING
SERVICES PTE LTD service engineers or their authorised
service agent.
Child Safety
oIt is strongly recommend that babies and young children are
prevented from being near to the appliance and not allowed to
touch the appliance at any time. During and after use, all
surfaces will be hot.
oCAUTION: Accessible parts may be hot when the grill is in use.
Young children should be kept away.
oIf it is necessary for younger family members to be in the
kitchen, please ensure that they are kept under close supervision
at all times.
oOlder children should only be allowed to utilise the appliance
when supervised.
oChildren should be supervised to ensure that they do not play
with the appliance.
General Safety
oThe appliance should only be installed and connected by a
registered installer.
oCare should be taken to ensure that the units and work surfaces
that you build the appliance into, meet with the relevant
standards.
oThis appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.

5
During use
oAny film or stickers that are present on the hob surface when it
is delivered should be removed before use.
oPrior to installation, ensure that the local distribution conditions
(nature of the gas and gas pressure) and the adjustment of the
appliance are compatible.
oThe adjustment conditions for this appliance are stated on the
label (or data plate)
oThis appliance is not connected to a combustion product
evacuation device. It shall be installed and connected in
accordance with current installation regulations. Particular
attention shall be given to the relevant requirements regarding
ventilation.
oCAUTION: The use of a gas cooking appliance results in the
production of heat and moisture in the room in which it is
installed. Ensure the kitchen is well ventilated. Keep natural
ventilation holes open or install a mechanical ventilation device
(mechanical extractor hood).
oCAUTION: This appliance is for cooking purposes only. It must
not be used for other purposes, for example room heating.
oProlonged intensive use of the appliance may call for additional
ventilation, for example opening of a window or more effective
ventilation, for example increasing the level of mechanical
ventilation where present.
oCare should be used when utilising the appliance, otherwise
there is a risk of burns being caused.
oYou should not allow the electrical connection cables to come
into contact with the hob surface when it is hot or any hot
cookware.
oIf oil overheats, then it can ignite extremely quickly. For this
reason, when cooking with oil the appliance should not be left
unattended.

6
oMake sure that all of the cooking zones are switched off after
use.
Cleaning
oCleaning of the hob should be carried out on a regular basis.
oIMPORTANT: Before attempting to clean the appliance, it
should be disconnected from the mains and cool.
oGreat care should be taken whilst using this appliance and when
following the cleaning procedure.
oYou should not use a steam jet or any other high pressure
cleaning equipment to clean the appliance.
Installation
This appliance must be correctly installed by a
registered installer, strictly in accordance with the
manufacturer’s instructions. Please see the
specific section of this booklet that refers to
installation.
oAMTEK MARKETING SERVICES PTE LTD. declines any
responsibility for injury or damage, to person or property,
as a result of improper use or installation of this
appliance.
oThis appliance is NOT recommend to installed on any type
of marine vessel.

7
Specifications
Gas Cooker surface layout
CGS-P125SSD
A = 4.50 kW outer ring Φ125mm and inner ring Φ70 burner
Min heat input 0.9KW
F = Control knob
Product dimensions:
Depth: 415 mm
Width: 300 mm
Height: 97 mm
Product specifications:
o1 x 4.50 kW outer ring Φ125mm and inner ring Φ70 burner
oFront control operation
oBlack enameled pan stands
oAutomatic ignition
oFlame failure safety device on each burner

8
CGS-P1102SSD
B= 4.20 kW outer ring Φ110mm and inner ring Φ40 burner
Min heat input 0.6KW
F = Control knob
Product dimensions:
Depth: 300 mm
Width: 690 mm
Height: 115 mm
Product specifications:
o2x 4.20 kW outer ring Φ110mm and inner ring Φ40 burner
oFront control operation
oBlack enameled pan stands
oAutomatic ignition
oFlame failure safety device on each burner
Gas details
Connection Type: Alternative LPG G30 (28-30mbar)

9
Using the gas table top hob
Before first use
IMPORTANT: You should clean the hob surface (see
“Cleaning and maintenance” section).
The following symbols will appear on the control panel, next to each
control knob:
Black circle: gas off
Large flame: maximum setting
Small flame: minimum setting
oThe minimum setting is at the end of the anti-clockwise rotation
of the control knob.
oAll operation positions must be selected between the maximum
and minimum position.
oNever select a knob position between the maximum and off
position.
oThe symbol on the control panel, next to the control knob will
indicate which gas burner it operates.

10
Automatic ignition with flame failure safety device
The appliance is fitted with a flame failure safety device on each
burner, which is designed to stop the flow of gas to the burner head in
the event of the flame going out.
To ignite a burner:
oPress in the control knob of the burner that you wish to light and
turn it anti-clockwise to the maximum position.
oIf you keep the control knob depressed, the automatic ignition
for the burner will operate.
oYou should hold down the control knob for 15 seconds after the
flame on the burner has lit. If after 15s the burner has not lit,
stop operating the device and open the compartment door
and/or wait at least 1 min before attempting a further ignition of
the burner.
oAfter this 15-second interval, to regulate the flame you should
continue turning the control knob anti-clockwise until the flame
is at a suitable level. The operating position MUST be at a
position between the maximum and minimum position.
oTo switch the burner off, turn the control knob fully clockwise to
the gas off position.
oIn case of power failure, the burners can be lit by carefully using
a match.

11
Energy saving tips
oThe diameter of the bottom of the pan should correspond to that
of the burner.
oThe burner flame must never extend beyond the diameter of the
pan.
oUse flat bottomed pans only
oWhen possible, keep a lid on the pan whilst cooking.
oCook vegetables with as little water as possible, to reduce cooking
times.
IMPORTANT: Always place pans centrally over the hob burners and
position them so that the handles cannot get accidentally caught or
knocked off. You should also make sure that the handle is not over one
of the other hob burner flames.
Please note Φ90mm burner is only suited to 220mm-300mm pot and
Φ50 burner is suited to 80mm-120mm pot.

12
Cleaning
Cleaning operations must only be carried out when
the hob is cool.
The appliance should be disconnected from your
mains supply before commencing any cleaning
process.
Cleaning the hob top
Any residues that are left on the hob top surface from cleaning
agents will damage it. You should remove any residues with
warm soapy water.
Abrasive cleaners or sharp objects will damage the hob surface;
you should clean it using warm soapy water.
Although it is easier to clean some deposits whilst the
hob surface is still warm. Make sure that the hob surface,
pan supports and hob burners have all cooled sufficiently
before you attempt to touch them.
After each use
oRemove the pan stands and wipe the appliance over with a soft,
damp cloth that has been put into warm soapy water. The cloth
should be wrung out after being taken out of the soapy water.
oDry the appliance by rubbing the surface with a soft, clean cloth.
oWe would recommend that an appropriate stainless steel cleaner
and polish is regularly used on the stainless steel surfaces of this
appliance.

13
Cleaning the hob burners
The hob burners should be cleaned once a week or more frequently if
they get soiled.
oIMPORTANT: Make sure that the hob surface, pan stands and
hob burners have cooled before you attempt to touch them.
oRemove the hob burners by pulling them upwards and away
from the hob top.
oSoak them for about ten minutes in hot water and a little
detergent.
oAfter cleaning and washing them, wipe and dry them carefully.
oBefore placing the burners back on the hob top, make sure that
the gas jet is not blocked.
oIMPORTANT: Make sure that you reassemble the burners in the
original way.
Maintaining the cast iron pan stands
oIMPORTANT: Make sure that the hob surface and pan stands
have cooled before you attempt to touch them.
oWipe the pan stands over with a soft, damp cloth that has been
put into warm soapy water. The cloth should be wrung out after
being taken out of the soapy water.
oUsing a paper towel, thoroughly dry the pan stands.
oTo maintain the appearance of the cast iron pan stands, we
would recommend that you rub a small amount of olive oil into
the pan stands, after you have finished cleaning them.

14
Installation
The installation must be carried out by a registered
installer, in accordance with the current version of
the following.
Gas connection
This appliance must be installed by a competent
person
Important information
oThe appliance must not be installed in a bathroom or shower
room.
oThe edges of the hob must be a minimum distance of 150 mm
from a side or rear wall.
oThis hob is supplied to run on Liquefied Petroleum Gas only
and cannot be used on any other type of gas.
oThe hob must be installed by a qualified person.
oFailure to install the appliance correctly could invalidate AMTEK
MARKETING SERVICES PTE LTD’s guarantee and lead to
prosecution under the regulations quoted above.

15
Ventilation requirements
oThe room containing the hob should have an air supply in
accordance with the current edition of BS 5440: Part 2:
oThe room must have opening windows or equivalent; some
rooms may also require a permanent vent.
oIf the room has a volume between 5 and 10m³, it will require an
air vent of 50cm² (effective area). Unless it has a door which
opens directly to the outside.
oIf the room has a volume of less than 5m³, it will require an air
vent of 100cm² (effective area).
oIf it is installed in a room with a volume that exceeds 11m³, then
no air vent is required.
oIf there are any other fuel burning appliances in the same room
the current edition of BS 5440: Part 2: should be consulted to
determine air vent requirements.
oEnsure that the room containing the hob is well ventilated, keep
natural ventilation holes or install a mechanical ventilation device
(mechanical cooker hood).
oProlonged intensive use of the appliance may call for additional
ventilation, either by the opening of a window, or by increasing
the level of the mechanical ventilation device (where present).
oThis hob is not fitted with a device for discharging the products
of combustion. Ensure that the ventilation rules and regulations
are followed.
oThe walls behind and near the hob should be resistant to heat,
steam and condensation.
oRemember that the quantity of air necessary for combustion
must never be less than 2m³/h for each kW of power (see total
power in kW on the appliance rating plate).

16
My appliance isn’t working correctly
IMPORTANT: If your appliance appears not to be
operating correctly, then you should disconnect it
from your mains supply and contact AMTEK
MARKETING SERVICES PTE LTD.
DO NOT ATTEMPT TO REPAIR THE APPLIANCE
YOURSELF.
Please note that if an engineer is asked to attend whilst the product is
under guarantee and finds that the problem is not the result of an
appliance fault, then you may be liable for the cost of the call out
charge.
The appliance must be accessible for the engineer to perform
any necessary repair. If your appliance is installed in such a
way that an engineer is concerned that damage will be caused
to the appliance or your kitchen, then he will not complete a
repair.
This includes situations where appliances have been tiled in,
sealed in with sealant, have wooden obstructions placed in
front of the appliance, like plinths.
Please refer to the conditions of guarantee that appear on the
warranty card that you receive with the appliance.
IMPORTANT: AMTEK MARKETING SERVICES PTE LTD operates a
policy of continuous improvement and reserves the right to
adjust and modify its products without prior notification.
