Cosmo COS-FDR225 Series User manual

REFRIGERATOR
COS-FDR225 SERIES
OWNER’S MANUAL
IMPORTANT:
INSTALLER:
OWNER:
READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
PLEASE LEAVE THESE INSTRUCTIONS WITH THIS UNIT FOR
THE OWNER.
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
FRENCH DOOR REFRIGERATOR
Rev.23.02

2
THANK YOU FOR YOUR PURCHASE
Thank you for your purchase. We know that you have many brands and
products to choose from and we are honored to know that you have decided
to take one of our products into your home and hope that you enjoy it.
COSMO Appliances are designed according to the strictest safety and
performance standard for the North American market. We follow the most
advanced manufacturing philosophy. Each appliance leaves the factory after
thorough quality inspection and testing. Our distributors and our service
partners are ready to answer any questions you may have regarding how to
install, use and case for your products. We hope that this manual will help you
learn to use the product in the safest and most effective manner.
Before using this product, please read through this manual carefully. Keep
this user manual in a safe place for future reference. Please ensure that other
persons using this product are familiar with these instructions as well.
If you have any questions or concerns, please contact the dealer from whom you
purchased the product, or contact our Customer Support at:
1-888-784-3108
Reach us online at:
www.cosmoappliances.com

3
TABLE OF CONTENTS
REFRIGERATOR SAFETY...................................................................................... 4
Important Safety Instructions ................................................................................. 5
PRODUCT DIMENSIONS ....................................................................................10
INSTALLATION INSTRUCTIONS..........................................................................11
Before Installing ........................................................................................................11
Preparation ................................................................................................................11
Attaching Refrigerator Door Handles ..................................................................14
Connecting to the House Water Line ...................................................................16
Completing Installation .........................................................................................20
Level the Refrigerator ........................................................................................20
Level the Refrigerator Doors.............................................................................. 21
OPERATION....................................................................................................... 22
Before Use ................................................................................................................ 22
Energy Saving Tips.................................................................................................. 23
Placement / Relocation.......................................................................................... 24
Interior Overview..................................................................................................... 25
Control Panel ........................................................................................................... 27
Control Buttons................................................................................................... 27
Display .................................................................................................................. 29
Error Codes.................................................................................................... 29
MAINTENANCE & CARE ....................................................................................30
General Cleaning....................................................................................................30
TROUBLESHOOTING......................................................................................... 34
PRODUCT SPECIFICATIONS ..............................................................................44
LIMITED WARRANTY ........................................................................................ 45

Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on
your appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards
that can kill or hurt you and others.
All safety messages will follow the safety alert
symbol and either the word "WARNING" or
"CAUTION." These words mean:
You can be killed or seriously injured if you
don't follow instructions.
A potentially hazardous situation which, if not
avoided, could result in minor or moderate
injury.
All safety messages will tell you what the potential hazard is, tell you how
to reduce the chance of injury, and tell you what can happen if the
instructions are not followed.
WARNING
CAUTION
California Proposition 65 Warning
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
4
REFRIGERATOR SAFETY
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

5
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, explosion, electric shock, or
injury when using your refrigerator, follow these basic
safety precautions:
•This refrigerator must be
properly installed and located in
accordance with the installation
instructions before it is used.
•Unplug the refrigerator before
making repairs or cleaning.
NOTE: Power to the refrigerator
cannot be disconnected by any
setting on the control panel.
NOTE: Repairs must be
performed by a qualified service
professional.
•Replace all parts and panels
before operating.
•Do not use an extension cord.
•Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
•Do not store explosive
substances such as aerosol cans
with a flammable propellant in
this appliance.
•To prevent suffocation and
entrapment hazards to children,
remove the fresh food and
freezer doors from any
refrigerator before disposing of
it or discontinuing its use.
•To avoid serious injury or death,
children should not stand on, or
play in or with the appliance.
•Children and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge can
use this appliance only if they
are supervised or have been
given instructions on safe use
and understand the hazards
involved.
•This appliance is intended to be
used in household and similar
applications such as: staff
kitchen areas in shops, offices
and other working
environments; farm houses; by
clients in hotels, motels, bed &
breakfast and other residential
environments; catering and
similar non-retail applications.
•Do not apply harsh cleaners to
the refrigerator. Certain cleaners
will damage plastic which may
cause parts such as the door or
door handles to detach
unexpectedly.
•Connect to potable water supply
only. A cold water supply is
required for automatic icemaker
operation. The water pressure
must be between 21 and 121 psi
(147-834 kilo-Pascals).
READ AND SAVE THESE INSTRUCTIONS
WARNING

6
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of injury when using your
refrigerator, follow these basic safety precautions:
•Do not clean glass shelves or
covers with warm water when
they are cold. Glass shelves and
covers may break if exposed to
sudden temperature changes or
impact, such as bumping or
dropping. Tempered glass is
designed to shatter into many
small pieces if it breaks.
•Keep fingers out of the "pinch
point" areas; clearances
between the doors and between
the doors and cabinet are
necessarily small. Be careful
closing doors when children are
in the area.
•Do not touch the cold surfaces in
the freezer compartment when
hands are damp or wet, skin
may stick to these extremely
cold surfaces.
•Do not refreeze frozen foods
which have thawed completely.
•In refrigerators with automatic
icemakers, avoid contact with
the moving parts of the ejector
mechanism, or with the heating
element that releases the cubes.
Do not place fingers or hands on
the automatic ice making
mechanism while the
refrigerator is plugged in.
INSTALLATION
FIRE AND EXPLOSION HAZARD
Keep flammable materials and vapors, such as gasoline, away from
refrigerator. Failure to do so can result in fire, explosion, or death.
READ AND SAVE THESE INSTRUCTIONS
CAUTION
WARNING

7
IMPORTANT SAFETY INSTRUCTIONS
CONNECTING ELECTRICITY
ELECTRICAL SHOCK HAZARD
Plug into a grounded 3-prong outlet.
Do not remove the ground prong.
Do not use an adapter or an extension cord.
Failure to do so can result in death, fire, or electrical shock.
Do not, under any circumstances, cut or remove the third (ground) prong
from the power cord. For personal safety, this appliance must be
properly grounded.
•The power cord of this appliance
is equipped with a 3-prong
(grounding) plug which mates
with a standard 3-prong
(grounding) wall outlet to
minimize the possibility of
electric shock hazard from this
appliance.
•Have the wall outlet and circuit
checked by a qualified
electrician to make sure the
outlet is properly grounded.
•Where a standard 2-prong wall
outlet is encountered, it is your
personal responsibility and
obligation to have it replaced
with a properly grounded 3-
prong wall outlet.
•The refrigerator should always
be plugged into its own
individual electrical outlet which
has a voltage rating that
matches the rating plate.
•A 115 Volt AC, 60 Hz, 15- or 20-
Amp fused, grounded electrical
supply is required. This provides
the best performance and also
prevents overloading house
wiring circuits which could cause
a fire hazard from overheated
wires.
•Never unplug your refrigerator
by pulling on the power cord.
Always grip plug firmly and pull
straight out from the outlet.
•Immediately discontinue use of
a damaged supply cord. If the
supply cord is damaged, it must
be replaced by a qualified
service professional with an
authorized service part from the
manufacturer.
•When moving the refrigerator
away from the wall, be careful
not to roll over or damage the
power cord.
READ AND SAVE THESE INSTRUCTIONS
WARNING

8
IMPORTANT SAFETY INSTRUCTIONS
PROPER DISPOSAL OF YOUR OLD REFRIGERATOR
SUFFOCATION AND ENTRAPMENT HAZARD
Failure to follow these disposal instructions can result in death or serious
injury.
IMPORTANT: Child entrapment and suffocation are not problems of the
past. Junked or abandoned refrigerators are still dangerous even if they
will sit for "just a few days." If you are getting rid of your old refrigerator,
please follow the instructions below to help prevent accidents.
Before You Throw Away Your Old Appliance
•Take off the fresh food and freezer doors.
•Leave the shelves in place so that children may not easily climb inside.
REFRIGERANT AND FOAM DISPOSAL
Dispose of appliance in accordance with Federal and Local Regulations.
Flammable insulation material used requires special disposal of your
appliance. Contact your local authorities for the environmentally safe
disposal of your appliance.
READ AND SAVE THESE INSTRUCTIONS
WARNING
WARNING

9
IMPORTANT SAFETY INSTRUCTIONS
FLAMMABLE REFRIGERANT
Check the rating label for refrigerant type. If R600a, follow the warning
instructions below.
FIRE OR EXPLOSION HAZARD
This appliance contains isobutane refrigerant, also known as R600a, a
natural gas with high environmental compatibility. However, it is also
combustible. Adhere to the warnings below to reduce the risk of injury or
property damage.
•When handling, installing and
operating the appliance, care
should be taken to avoid
damage to the refrigerant
tubing.
•Service shall only be performed
by authorized service personnel.
Use only manufacturer-
authorized service parts.
•Dispose of refrigerator in
accordance with the Federal
and Local Regulations. The
flammable refrigerant and
insulation material used in this
product require special disposal
procedures. Contact your local
authorities for the
environmentally safe disposal of
your refrigerator.
•Keep ventilation openings in the
appliance enclosures or in the
built-in structure clear of
obstruction.
•To remove frost, scrape with a
plastic or wood spatula or
scraper. Do not use an ice pick or
a metal or sharp-edged
instrument as it may puncture
the freezer liner and then the
flammable refrigerant tubing
behind it.
•Do not use electrical appliances
inside the food storage
compartment of the appliance.
•Do not use any electrical device
to defrost your freezer.
READ AND SAVE THESE INSTRUCTIONS
WARNING

10
PRODUCT DIMENSIONS
FRONT VIEW
35.8"
70"
TOP VIEW (DOORS CLOSED)
35.8"
29"
TOP VIEW (DOORS OPENED)
62.7"
39.1"
135°

11
INSTALLATION INSTRUCTIONS
BEFORE INSTALLING
Read these instructions completely and carefully.
•IMPORTANT: Observe all governing codes and ordinances. Save these
instructions for local inspector’s use.
•Note to Installer – Be sure to leave these instructions with the Consumer.
•Note to Consumer – Keep these instructions for future reference.
•Skill level – Installation of this appliance requires basic mechanical skills.
•Completion time – Refrigerator Installation: 20 minutes
•Completion time – Water Line Installation: 30 minutes
•Proper installation is the responsibility of the installer.
•Product failure due to improper installation is not covered under the
Warranty.
PREPARATION
UNPACK THE REFRIGERATOR
•Use two or more people to move and install the refrigerator. Failure to
do so can result in back injury or other injury.
•The refrigerator is heavy. Protect the floor when moving the
refrigerator for cleaning or service. Always pull the refrigerator straight
out when moving it. Do not wiggle or walk the refrigerator when trying
to move it, as floor damage could occur.
•Keep flammable materials and vapors, such as gasoline, away from
the refrigerator. Failure to do so can result in fire, explosion, or death.
WARNING EXCESSIVE WEIGHT HAZARD

12
NOTE:
•Remove tape and any temporary labels from your refrigerator before
using. Do not remove any warning labels, the model and serial number
label, or the rating label.
•To remove any remaining tape or glue, rub the area briskly with your
thumb. Tape or glue residue can also be easily removed by rubbing a
small amount of liquid dish soap over the adhesive with your fingers.
Wipe with warm water and dry.
•Do not use sharp instruments, rubbing alcohol, flammable fluids, or
abrasive cleaners to remove tape or glue. These products can damage
the surface of your refrigerator.
•Reinstall or adjust shelves as needed. Refrigerator shelves are installed
in the shipping position. Reinstall shelves according to your individual
storage needs.
WATER SUPPLY TO THE ICEMAKER AND DISPENSER
If the refrigerator has an icemaker, it will have to be connected to a cold
water line.
REFRIGERATOR LOCATION
•Do not install the refrigerator where the temperature will go below 60°F
(16°C) because it will not run often enough to maintain proper
temperatures.
•Do not install the refrigerator where the temperature will go above 100°F
(37°C) because it will not perform properly.
•Do not install the refrigerator in a location exposed to water (rain, etc.) or
direct sunlight.
•Install it on a floor strong enough to support it fully loaded.

13
TOOLS YOU MAY NEED
•Adjustable wrench
•Phillips-head screwdriver
•Socket ratchet/driver
•Nut drive
•Tape measure
•Pencil
•Level
•Wire Cutters
PARTS SUPPLIED
Parts Quantity Usage
Mounting fasteners
(COS-FDR225RHSS-G only) 4 To mount the door handles
Screw caps
(COS-FDR225RHSS-G only) 4 To cover the screws on the
door handles
Snap rings 4 To level the refrigerator
doors
Water line union
connector 1 To connect the refrigerator water lines

ATTACHING REFRIGERATOR DOOR
HANDLES
(FOR COS-FDR225RHSS-G ONLY)
14
1. Assemble the mounting fasteners
on each refrigerator door with a
Phillips-head screwdriver.

2. Loosen/Remove the set screws in
the handle end caps.
3. Place the handle over the
mounting fasteners on the door
until it is flush against the surface
of the door.
4. Hold the handle firmly against
the door, make sure there are no
gaps between the handle end
caps and the door, and tighten
both set screws in the handle end
caps.
5. Place the screw caps over the set
screws on the handles.
Set screw
(pre-installed)
Fitting for
mounting
fastener
15

CONNECTING TO THE HOUSE WATER LINE
ELECTRIC SHOCK HAZARD
Attach tubing clamp using existing hole only. DO NOT drill into the
refrigerator.
WHAT YOU WILL NEED
Connect to potable water supply only. A cold water supply is required for
automatic ice maker operation. The water pressure must be between 21
and 121 psi (147-834 kilo-Pascals).
•A copper or approved flexible universal refrigerator tubing kit or ice-
maker install kit with 1/4" outer diameter to connect the refrigerator to
the water supply. If using copper, be sure both ends of the tubing are cut
square.
•A cold water supply. The water pressure must be between 21 and 121 psi
(147-834 kPa).
•Power drill.
•1/2" or adjustable wrench.
•Straight and Phillips blade screwdriver.
•Two 1/4" outer diameter compression nuts and two ferrules
(sleeves) to connect the copper tubing to the shutoff valve
and the refrigerator water valve, OR you can find kits that
come with all parts included such as Stop Tee and
compressing fittings.
•If your existing copper water line has a flared fitting at the end, you will
need an adapter (available at plumbing supply stores) to connect the
water line to the refrigerator, OR you can cut off the flared fitting with a
tube cutter and then use a compression fitting.
•Shutoff valve to connect to the cold water line. The shutoff
valve should have a water inlet with a minimum inner
diameter of 5/32" at the point of connection to the cold
water line. Saddle-type shutoff valves are included in many
water supply kits. Before purchasing, make sure a saddle-
type valve complies with your local plumbing codes.
16
WARNING
WARNING

17
NOTE:
•Before making the connection to the refrigerator, be sure
the refrigerator power cord is not plugged into the wall
outlet.
•Before connecting the water line to the house, purge the
house line for at least 2 minutes.
•Only use approved plastic universal tubing if not using
copper tubing. Cross linked High Density Polyethylene
(PEX) hose is extremely durable and is becoming
increasingly preferred.
•Install a shutoff valve on the nearest frequently used
drinker water line.
1. SHUT OFF THE MAIN WATER SUPPLY
Then turn on the nearest faucet long
enough to clear the line of water.
2. CHOOSE THE VALVE LOCATION
Choose an easily accessible location on the
cold water pipe for the shutoff valve. It is
best to connect into the side of a vertical
water pipe. When it is necessary to connect
into a horizontal water pipe, make the
connection to the top or side, rather than
at the bottom, to avoid drawing off any
sediment from the water pipe.
3. DRILL THE HOLE FOR THE VALVE
Drill a 1/4" hole in the water pipe (even if
using a self-piercing valve) using a sharp
bit. Be cautious not to allow water to drain
into the drill. Remove any burrs resulting
from drilling the hole in the pipe. Failure to
drill a 1/4" hole may result in reduced ice
production or smaller cubes.

18
4. FASTEN THE SHUTOFF VALVE
Fasten the shutoff valve to the cold water
pipe with the pipe clamp.
NOTE:
•Commonwealth of
Massachusetts Plumbing Codes
248CMR shall be adhered to.
Saddle valves are illegal and use
is not permitted in
Massachusetts. Consult with
your licensed plumber.
5. TIGHTEN THE PIPE CLAMP
Tighten the clamp screws until the sealing
washer begins to swell.
NOTE:
•Do not over tighten or you may
crush the tubing.
6. ROUTE THE TUBING
Route the tubing between the cold water
line and the refrigerator. Route the tubing
through a hole drilled in the wall or floor
(behind the refrigerator or adjacent the
base cabinet) as close to the wall as
possible.
Pipe Clamp
Inlet
End
Washer
Clamp
Screw
Pipe Clamp
Saddle-Type
Shutoff Valve
Vertical
Cold
Water
Pipe

19
7. FASTEN THE SHUTOFF VALVE
Place the compression nut and ferrule
(sleeve) for copper tubing onto the end of
the tubing and connect it to the shutoff
valve. Make sure the tubing is fully inserted
into the valve. Tighten the compression nut
securely. For plastic tubing with the water
line union connector (included), insert the
molded end of the tubing into the shutoff
valve and tighten the compression nut until
it is hand tight, then tighten one additional
turn with a wrench.
NOTE:
•Over tightening may cause leaks.
Water Line Union Connector (Included)
Saddle-Type
Shutoff Valve
Packing
Nut Outlet
Valve
Ferrule
(sleeve)
Compression
Nut Union
Connector
Tubing
OR
•Connector grips before it seals. Ensure
tube is pushed into the tube stop.
•Pull on the tube to check it is secure.
Turn on water and check for leaks. (If
you have leaks, just cut a small
portion of hose further down to give a
smooth edge.)
•To disconnect, ensure the system is
depressurized before removing the
tube. Push in the connector end piece
squarely against face of fitting. With it
held in this position, the tube can be
removed.

20
8. FLUSH THE TUBING
Turn on the main water supply and flush
out the tubing until the water is clear. Shut
off the water at the water valve after
about 1 quart (1 Liter), or 2 minutes, of
water has been flushed through the tubing.
COMPLETING INSTALLATION
TURN ON THE POWER
Plug the refrigerator’s power cord into a 3-prong grounded outlet, and
carefully push the refrigerator into the final position.
LEVEL THE REFRIGERATOR
Adjustable legs at the front corners of the refrigerator should be set so the
refrigerator is firmly positioned on the floor, and the front is raised just
enough that the door closes easily when opened about halfway.
•To adjust the leveling legs, turn the legs clockwise to raise the refrigerator,
counterclockwise to lower it.
