COUGAR STE Series User manual

COUGAR
Facebook
Superior Reliability And Silent Operation
Trouble shooting
WARNING:
Never work on the PSU yourself. Even long time after its deactivation,
life-threatening voltages can still be present in the PSU. Repairs should only be
made by authorized specialists.
Working at power sources can lead to life-threatening injuries. If there is smoke,
cable damage or intrusion of liquids the PSU has to be immediately disconnected
from the power network and must not to be put into operation anymore afterwards.
Never open the PSU. It contains components, which can show high voltages even
after long periods of deactivation.
Again, repairs should only be done by authorized specialists!
Problem: After the installation of the new PSU the system does not start.
Possible solutions:
●Check the power code and the power supply of the wall socket and/or multiple
socket strip. Also check whether the multiple socket strip can supply the
necessary power.
●Check all connections within the PC; maybe not all cables are correctly connected.
●Check the internal cable of the I/O-switch of the PC case to the mainboard.
●Check the components for possible short-circuits or defects.
Please also check the other components for compatibility. Often mainboard chipsets
are not compatible with all memory and/or graphics card solutions. Contact the
manufacturer of the component to get more information.
If your PSU still does not function even though you have checked sources of errors
mentioned above, please get in touch with our customer service.
Advice
This product is not to be disposed in the regular household waste and
must be brought to a collection-point for electrical and electronic devices
for recycling. The symbol to the left refers to that and can be found on the
product, in the manual or on the packaging. Materials can be recycled
according to their description. With the reuse, the recycling or other forms
of reutilization of old devices you make an important contribution to the
protection of our environment. Please inquire the appropriate location of
disposal from your local administration.
Introduction
Dear customer:
Thank you for choosing a COUGAR®power supply unit. Before the installation
please read the manual below carefully. If you have any questions, please contact
our customer service:
Warnings and safety notes
Never open the PSU cover. There is potential danger of life due to high voltage inside.
The PSU should only be opened by an authorized technician. The manufacture
warranty will be void, if the PSU is opened by an unauthorized person.
Do not work on the PSU or the PC as long as the main voltage is still connected.
Switch the I/O button to position "0" and disconnect the power plug from the power
network.
Protect the PSU against moisture.
The PSU is suitable for operation at 200-240V/50Hz.
The ambient temperature should not exceed 50°. Please pay attention to the power
de-rating on all models with a decrease of 1%/°C starting at an ambient temperature
of 25°C. Please ensure that there is sufficient ventilation of the entire system.
The leakage current must not exceed 3.5 mA.
Make sure during the installation of the PSU that the ventilation slots are not covered.
Do not clog the ventilation slots of the PSU. Keep your PC away from direct heat
sources such as radiators.
When using an extension cord and/or multiple sockets pay attention to the maximum
through-connection ability in order to avoid short-circuits.
If you want to clean your PSU, disconnect the power plug from the power network
and remove it from the PC case. Before the removal make sure that you are not
statically charged, (e.g. through carpets or wool sweaters).Only clean the PSU on the
outside, always using dry cloth, never water or detergent.
Specifications
●Operating conditions
Working temperature:
+10°C ~ +40°C (Please note the de-rating condition in Warnings and safety notes)
Storage temperature:
-40°C~+70°C
Operating humidity (without condensation water):
20%~85% relative humidity
Storage humidity (without condensation water):
5%~95% relative humidity
● Connectors
● Output power
Main CPU
24(20+4)
Pin
8(4+4)
Pin
Peripheral S-ATA PCI-E
Pin
Connector
5 Pin 8(6+2)
Pin
4 Pin
1 2 4 11
STE400
1 2 5 21
STE500
1 2 6 21
STE600
+3.3V
15A
105W 360W
0.3A 2A 400W
15A 30A
+5V +12V Total
200-240V~
50Hz / 5A
-12V +5Vsb
AC inputModel Name
DC output
STE400
110W 408W
0.3A 2.5A 500W
15A 15A 34A
STE500
110W 552W
0.3A 2.5A 600W
15A 15A 46A
STE600

Where the product warranty according to local laws and regulations extends to less than 24
months after the date of purchase, Compucase will provide an extended limited warranty
starting the day in which the implied warranty (according to local laws and regulations) ends
and finishing 24 months after the date of purchase. If the local laws and regulations establish
a warranty period of 24 or more months, no extended limited warranty shall be provided.
During this period, defects in material or workmanship will be repaired or restored with
spare parts. In case of a guarantee service, the customer should claim the COUGAR PSU
at the retailer, where the PSU was bought, accompanied by a copy of the invoice and an
error description. Compucase will only support directly if the retailer is not reachable
repeatedly.
In case of direct support by Compucase , the end user has to assure that the goods are
packed properly and that he is in charge of all transportation costs.
Compucase’s warranty does not cover any of the following:
● Damages due to acts of nature (e.g. Lightning, Water, Fire and so on)
● Accessory or consequential damages that happened by using or not using the PSU
● Damages caused by misuse of the PSU or caused by negligence
● Loss of information or data, software or applications
● Damages caused by opening or modifying the PSU without previous accordance
● Damages caused by using or installing the PSU under conditions outside of the technical
specifications which are described in the attached manual
This warranty is valid only for the first end user or consumer and is restricted to the above
named period.
Guarantee Terms and conditions for
COUGAR Power Supply Units (PSU) of the STE Series
www.cougargaming.com
Warranty and information of the manufacturer
For further information of the warranty terms, please read the information of
“Guarantee Terms and conditions for COUGAR Power Supply Units (PSU) of the
STE-Series”.
Manufacturer contact:
Compucase Enterprise Co.,Ltd.
No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C
Tel:[phone]
Service E-Mail: [email protected]
More information you will find at cougargaming.com
Compucase Enterprise Co.,Ltd.
All rights reserved.
Legal notices
This manual was created by COMPUCASE ENTERPRISE CO., LTD. and may not be
completely or partially copied, passed on, distributed or stored without written
consent by COMPUCASE ENTERPRISE CO., LTD.
COUGAR is a registered brand of COMPUCASE ENTERPRISE CO., LTD. Other
product and company names mentioned in this documentation may be brands or
trademarks of their respective owners.
COMPUCASE ENTERPRISE CO., LTD. reserves the right to make changes concerning
the contents of the manual and the technical data of the product without previous
announcement.
The following parts are included within the delivery:
● Screws for the PSU assembly
● Power cord (Please only use the power cord which is included; low-quality cords can
damage your PSU and your PC-system.)
● Brief instruction incl. Information about the warranty
● Place the PSU into its designated place within the case and fix it with the supplied
screws.
● First insert the plugs for the mainboard supply (20/24 pin, 4 pin and possibly
8 pin – according to mainboard layout) into the respective slots.
● Connect the disk drives and if necessary the graphics cards to the PSU.
● Close the PC and ensure that the PSU power switch is set to the position "0".
● Connect the PSU to the power network using the supplied power cord. Using only
the power cord provided in the package. Low quality power cord may damage the
PSU and PC system!
● Turn on the PSU and then start your PC.
Safety functions
● UVP (Undervoltage protection)
If the voltages fall below a certain tolerance value on the single lines, the PSU
automatically switches off.
● OVP (Overvoltage protection)
If the voltages increase above a certain tolerance value on the single lines, the PSU
automatically switches off.
● SCP (Short-circuit protection)
In the case of a short-circuit this feature prevents damage to the core components
of the PSU and its system components.
● OPP (Overload protection)
If the system is oversized and requires more power from the PSU than it can
perform, this protection function is activated.
During the operation of the PSU pay attention to the maximum loads. The single
loads and the total loads must not exceed to cross the values shown in output power
table. Avoid the use of adapters, such as 4Pin Molex to 6+2Pin PCI-Express.
Technical details and special features
● EXTREMELY HIGH EFFICIENCY
Up to 83% of efficiency.
● COMPATIBLE WITH THE LATEST PC-TECHNOLOGY
Created for use with current and next-generation multi-core CPU platforms.
● SUPPORT MULTI-GPU TECHNOLOGY
Supports PCI Express 3.0 next-generation graphics cards with 8(6+2) pin
PCI-E connector.
● ULTRA-QUIET & TEMPERATURE-CONTROLLED 120mm FAN
Extremely Low Noise Level, fan speed automatically regulated according to the
temperature.
● INTEGRATED AIR INLET DESIGN
Optimal aerodynamic design that provides more silent operation.
● ACTIVE POWER FACTOR CORRECTION (ACTIVE PFC)
PF value up to 98%, provides clean and reliable power.
● FULL PROTECTIONS WITH SCP, OVP, UVP, OPP
Installation/accessories
Before you begin with the installation, please read the section
”Warnings and safety notes.”For the arrangement only use the supplied screws since
these have the correct thread. You need a screwdriver for the correct arrangement.
