Elektro-Automatik PSB 9000 3U Series User manual

Elektro-Automatik
Doc ID: PSB9EN
Revision: 04
Date: 11/2018
Operating Guide
PSB 9000 3U
Bidirectional DC Power Supply
Attention! This document is only
valid for devices with rmwares
“KE: 2.25” (standard models)
resp. “KE: 2.09” (GPIB models),
“HMI: 2.04” and “DR: 1.6.5” or
higher.

Page 3
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
TABLE OF CONTENTS
1GENERAL
1.1 About this document......................................5
1.1.1 Retention and use..........................................5
1.1.2 Copyright........................................................5
1.1.3 Validity ............................................................5
1.1.4 Symbols and warnings ..................................5
1.2 Warranty.........................................................5
1.3 Limitation of liability ........................................5
1.4 Disposal of equipment ...................................6
1.5 Product key ....................................................6
1.6 Intended usage ..............................................6
1.7 Safety .............................................................7
1.7.1 Safety notices.................................................7
1.7.2 Responsibility of the user...............................8
1.7.3 Responsibility of the operator .......................8
1.7.4 User requirements .........................................8
1.7.5 Alarm signals..................................................9
1.8 Technical Data ...............................................9
1.8.1 Approved operating conditions......................9
1.8.2 General technical data...................................9
1.8.3 Specic technical data (400V / 480 V mod-
els)................................................................10
1.8.4 Specic technical data (208 V models).......20
1.8.5 Views............................................................21
1.8.6 Control elements..........................................24
1.9 Construction and function............................25
1.9.1 General description......................................25
1.9.2 Block diagram ..............................................25
1.9.3 Scope of delivery .........................................26
1.9.4 Accessories..................................................26
1.9.5 Options .........................................................26
1.9.6 The control panel (HMI)...............................27
1.9.7 USB port (rear side).....................................30
1.9.8 Interface module slot ...................................30
1.9.9 Analog interface ...........................................31
1.9.10 “Share” connector ........................................31
1.9.11 “Sense” connector (remote sensing)...........31
1.9.12 Master-Slave bus.........................................31
1.9.13 GPIB port (optional) .....................................32
2INSTALLATION &
COMMISSIONING
2.1 Transport and storage .................................33
2.1.1 Transport ......................................................33
2.1.2 Packaging ....................................................33
2.1.3 Storage.........................................................33
2.2 Unpacking and visual check........................33
2.3 Installation ....................................................33
2.3.1 Safety procedures before installation and
use................................................................33
2.3.2 Preparation...................................................34
2.3.3 Installing the device .....................................34
2.3.4 Connection to AC supply .............................35
2.3.5 Connection to DC loads or DC sources......38
2.3.6 Grounding of the DC terminal......................39
2.3.7 Connecting the analog interface .................39
2.3.8 Connection of remote sense .......................39
2.3.9 Installation of an interface module...............40
2.3.10 Connecting the “Share” bus ........................41
2.3.11 Connecting the USB port (rear side)...........41
2.3.12 Initial commission.........................................41
2.3.13 Commission after a rmware update or a
long period of non-use.................................41
3OPERATION AND APPLICATION
3.1 Terms............................................................42
3.2 Important notes ............................................42
3.2.1 Personal safety ............................................42
3.2.2 Genera .........................................................42
3.3 Operating modes .........................................42
3.3.1 Voltage regulation / Constant voltage .........42
3.3.2 Current regulation / constant current / current
limiting ..........................................................43
3.3.3 Power regulation / constant power / power
limiting ..........................................................43
3.3.4 Internal resistance regulation (source
mode) ...........................................................44
3.3.5 Resistance regulation / constant resistance
(sink mode) ..................................................44
3.3.6 Sink-source mode switching........................45
3.4 Alarm conditions ..........................................46
3.4.1 Power Fail ...................................................46
3.4.2 Overtemperature..........................................46
3.4.3 Overvoltage protection.................................46
3.4.4 Overcurrent protection.................................46
3.4.5 Overpower protection ..................................46
3.4.6 Safety OVP ..................................................47
3.5 Manual operation .........................................48
3.5.1 Switching on the device...............................48
3.5.2 Switching o󰀨 the device...............................48
3.5.3 Conguration via MENU..............................48
3.5.4 Adjustment limits..........................................58
3.5.5 Changing the operating mode.....................58
3.5.6 Manual adjustment of set values.................59
3.5.7 Switching the DC terminal on or o󰀨.............60
3.5.8 Recording to USB stick (logging) ................60
3.6 Remote control.............................................62
3.6.1 General.........................................................62
3.6.2 Control locations ..........................................62
3.6.3 Remote control via a digital interface ..........62
3.6.4 Remote control via the analog interface
(AI)................................................................63
3.7 Alarms and monitoring.................................68
3.7.1 Denition of terms ........................................68

Page 4
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
3.7.2 Device alarm and event handling................68
3.8 Control panel (HMI) lock..............................70
3.9 Limits lock.....................................................71
3.10 Loading and saving a user prole ...............71
3.11 The function generator.................................72
3.11.1 Introduction...................................................72
3.11.2 General.........................................................72
3.11.3 Method of operation.....................................73
3.11.4 Manual operation .........................................74
3.11.5 Sine wave function.......................................75
3.11.6 Triangular function .......................................75
3.11.7 Rectangular function....................................76
3.11.8 Trapezoidal function.....................................77
3.11.9 DIN 40839 function ......................................77
3.11.10 Arbitrary function..........................................78
3.11.11 Ramp function..............................................82
3.11.12 IU table function (XY table)..........................83
3.11.13 PV table function (photovoltaics).................84
3.11.14 FC table function (fuel cell)..........................86
3.11.15 Extended PV table function according to EN
50530 ...........................................................87
3.11.16 Battery test function .....................................92
3.11.17 MPP tracking function..................................96
3.11.18 Remote control of the function generator....98
3.12 Other applications........................................99
3.12.1 Parallel operation in master-slave (MS)......99
3.12.2 Series connection ......................................102
3.12.3 Operation as battery charger (source
mode) .........................................................102
4SERVICE AND MAINTENANCE
4.1 Maintenance / cleaning..............................103
4.2 Fault nding / diagnosis / repair.................103
4.2.1 Firmware updates ......................................103
5CONTACT AND SUPPORT
5.1 General.......................................................104
5.2 Contact options ..........................................104

Page 5
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
1. General
1.1 About this document
1.1.1 Retention and use
This document is to be kept in the vicinity of the equipment for future reference and explanation of the operation of
the device. This document is to be delivered and kept with the equipment in case of change of location and/or user.
1.1.2 Copyright
Reprinting, copying, also partially, usage for other purposes as foreseen of this manual are forbidden and breach
may lead to legal process.
1.1.3 Validity
This manual is valid for the following equipment:
Model Article nr. (1 Model Article nr. (1 Model Article nr. (1
PSB 9060-120 3U 30000319 PSB 9080-240 3U 30000306 PSB 9200-210 3U 30000313
PSB 9080-120 3U 30000301 PSB 9200-140 3U 30000307 PSB 9360-120 3U 30000314
PSB 9200-70 3U 30000302 PSB 9360-80 3U 30000308 PSB 9500-90 3U 30000315
PSB 9360-40 3U 30000303 PSB 9500-60 3U 30000309 PSB 9750-60 3U 30000316
PSB 9500-30 3U 30000304 PSB 9750-40 3U 30000310 PSB 91000-40 3U 30000317
PSB 9750-20 3U 30000305 PSB 9060-360 3U 30000321 PSB 91500-30 3U 30000318
PSB 9060-240 3U 30000320 PSB 9080-360 3U 30000312
(1 Article number of the standard models (380/400/480 V), the 208 V models have a di󰀨erent article number with “8” at the 5th position, for example 30008319
1.1.4 Symbols and warnings
Warning and safety notices as well as general notices in this document are shown in a box with a symbol as follows:
Symbol for a life threatening danger
Symbol for general safety notices (instructions and damage protection bans) or important infor-
mation for operation
Symbol for general notices
1.2 Warranty
EA Elektro-Automatik guarantees the functional competence of the applied technology and the stated performance
parameters. The warranty period begins with the delivery of free from defects equipment.
Terms of guarantee are included in the general terms and conditions (TOS) of EA Elektro-Automatik.
1.3 Limitation of liability
All statements and instructions in this manual are based on current norms and regulations, up-to-date technology
and our long term knowledge and experience. The manufacturer accepts no liability for losses due to:
• Usage for purposes other than designed
• Use by untrained personnel
• Rebuilding by the customer
• Technical changes
• Use of not authorized spare parts
The actual delivered device(s) may di󰀨er from the explanations and diagrams given here due to latest technical
changes or due to customized models with the inclusion of additionally ordered options.

Page 6
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
1.4 Disposal of equipment
A piece of equipment which is intended for disposal must, according to European laws and regulations (ElektroG,
WEEE) be returned to the manufacturer for scrapping, unless the person operating the piece of equipment or an-
other, delegated person is conducting the disposal. Our equipment falls under these regulations and is accordingly
marked with the following symbol:
1.5 Product key
Decoding of the product description on the label, using an example:
PSB 9 080 - 360 3U xxx
US208V = US model for 208 V three-phase supply
Construction (not always given):
3U = 19" frame with 3U
Maximum current of the device in Ampere
Maximum voltage of the device in Volt
Series: 9= Series 9000
Type identication:
PSB = Power Supply Bidirectional, always programmable
1.6 Intended usage
The equipment is intended to be used only as a variable voltage and current source or only as a variable current sink.
Typical application for a voltage source is DC power supply to any relevant user, including when used as battery
charger to test charge various battery types, and for current sinks the replacement of an ohmic resistor by an
adjustable electronic DC load in order to load relevant voltage and current sources of any type.
• Claims of any sort due to damage caused by non-intended usage will not be accepted
• All damage caused by non-intended usage is solely the responsibility of the operator

Page 7
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
1.7 Safety
1.7.1 Safety notices
Mortal danger - Hazardous voltage
• Electrical equipment operation means that some parts can be under dangerous voltage.
Therefore all parts under voltage must be covered! This basically applies to all models,
though 60 V models according to SELV can’t generate hazardous DC voltage.
• Never touch cables or connectors directly after unplugging from mains supply as the
danger of electric shock remains!
• Never touch the contacts on DC terminal directly after switching the device o󰀨, because
when running in source mode there still can be dangerous voltage present, sinking more
or less slowly depending on the load!
• There can be dangerous potential between DC minus to PE or DC plus to PE due to
charged X capacitors, even when the DC output/input is not switched on and the device is
still running. Never touch PE and any of the DC poles at the same time with bare hands!
• Always follow 5 safety rules when working with electric devices:
• Disconnect completely
• Secure against reconnection
• Verify that the system is dead
• Carry out earthing and short-circuiting
• Provide protection from adjacent live parts
• In situations where the device works in source mode, with a voltage > 0 adjusted and
the DC terminal being on, the output voltage can remain at the last setting after switch-
ing the DC output o󰀨 again, in case the set value of current for the internal load (sink
mode) is set to 0
• Even with the DC terminal being switched o󰀨, the device can generate a small, not load-
able voltage (< 2 V) on the DC terminal!)
• The equipment must only be used as intended
• The equipment is only approved for use within the connection limits stated on the product label.
• Do not insert any object, particularly metallic, through the ventilator slots
• Avoid any use of liquids near the equipment. Protect the device from wet, damp and conden-
sation.
• When operating the device as power supply: do not connect loads, particularly low resistance,
to the device while the DC output is switched on; sparking may occur which can cause burns
as well as damage to the equipment and to the loads.
• When operating the device as electronic load: do not connect power sources to the device while
the DC input is switched on; sparking may occur which can cause burns as well as damage to
the equipment and to the source.
• ESD regulations must be applied when plugging interface cards or modules into the relative slot
• Interface cards or modules may only be attached or removed after the device is switched o󰀨.
It is not necessary to open the device.
• Do not connect external power sources with reversed polarity to the DC terminal! The equip-
ment will be damaged, even when completely powered o󰀨.
• Never connect external power sources to the DC terminal that can generate a higher voltage
than the rated voltage of the device!
• Never insert a network cable which is connected to Ethernet or its components into the master-
slave sockets on the back side of the device!
• Always congure the various protecting features against overcurrent, overpower etc. for sensi-
tive loads to what the target application requires!
• When operating the device as electronic load: always make sure that the energy recovery can
feed back the inverted energy and that it does not switch to isolated operation. For situations
of isolated operation a supervision device (AIU, grid and plat protection) has to be installed
• It is not allowed to run the device on AC sources such as generators or UPS equipment. It must
only be connected to a power grid!

Page 8
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
1.7.2 Responsibility of the user
The equipment is in industrial operation. Therefore the operators are governed by the legal safety regulations.
Alongside the warning and safety notices in this manual the relevant safety, accident prevention and environmental
regulations must also be applied. In particular the users of the equipment:
• must be informed of the relevant job safety requirements
• must work to the dened responsibilities for operation, maintenance and cleaning of the equipment
• before starting work must have read and understood the operating manual
• must use the designated and recommended safety equipment.
Furthermore, anyone working with the equipment is responsible for ensuring that the device is at all times techni-
cally t for use.
1.7.3 Responsibility of the operator
Operator is any natural or legal person who uses the equipment or delegates the usage to a third party, and is
responsible during its usage for the safety of the user, other personnel or third parties.
The equipment is in industrial operation. Therefore the operators are governed by the legal safety regulations.
Alongside the warning and safety notices in this manual the relevant safety, accident prevention and environmental
regulations must also be applied. In particular the operator has to
• be acquainted with the relevant job safety requirements
• identify other possible dangers arising from the specic usage conditions at the work station via a risk assessment
• introduce the necessary steps in the operating procedures for the local conditions
• regularly control that the operating procedures are current
• update the operating procedures where necessary to reect changes in regulation, standards or operating con-
ditions.
• dene clearly and unambiguously the responsibilities for operation, maintenance and cleaning of the equipment.
• ensure that all employees who use the equipment have read and understood the manual. Furthermore the users
are to be regularly schooled in working with the equipment and the possible dangers.
• provide all personnel who work with the equipment with the designated and recommended safety equipment
Furthermore, the operator is responsible for ensuring that the device is at all times technically t for use.
1.7.4 User requirements
Any activity with equipment of this type may only be performed by persons who are able to work correctly and
reliably and satisfy the requirements of the job.
• Persons whose reaction capability is negatively inuenced by e.g. drugs, alcohol or medication may not operate
the equipment.
• Age or job related regulations valid at the operating site must always be applied.
Danger for unqualied users
Improper operation can cause person or object damage. Only persons who have the neces-
sary training, knowledge and experience may use the equipment.
Delegated persons are those who have been properly and demonstrably instructed in their tasks and the atten-
dant dangers.
Qualied persons are those who are able through training, knowledge and experience as well as knowledge of
the specic details to carry out all the required tasks, identify dangers and avoid personal and other risks.
All work on electrical equipment may only be performed by qualied electricians.

Page 9
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
1.7.5 Alarm signals
The equipment o󰀨ers various possibilities for signalling alarm conditions, however, not for danger situations. The
signals may be optical (on the display as text), acoustic (piezo buzzer) or electronic (pin/status output of an analog
interface). All alarms will cause the device to switch o󰀨 the DC terminal.
The meaning of the signals is as follows:
Signal OT
(OverTemperature)
• Overheating of the device
• DC terminal will be switched o󰀨
• Non-critical
Signal OVP
(OverVoltage)
• Overvoltage shutdown of the DC terminal due to high voltage entering the device or
generated by the device itself due to a defect
• Critical! The device and/or the load could be damaged
Signal OCP
(OverCurrent)
• Shutdown of the DC terminal due to excess of the preset limit
• Non-critical, protects the load or source from excessive current consumption
Signal OPP
(OverPower)
• Shutdown of the DC terminal due to excess of the preset limit
• Non-critical, protects the load or source from excessive power consumption
Signal PF
(Power Fail)
• DC terminal shutdown due to AC undervoltage or defect in the AC section
• Critical on overvoltage! AC section could be damaged
1.8 Technical Data
1.8.1 Approved operating conditions
• Use only inside dry buildings
• Ambient temperature 0-50°C (32-122 °F)
• Operational altitude: max. 2000 m (1.242 mi) above sea level
• Max 80% relative humidity, not condensing
1.8.2 General technical data
Display: Colour TFT touch screen with gorilla glass, 4.3”, 480pt x 272pt, capacitive
Controls: 2 rotary knobs with pushbutton function, 1 pushbutton
The nominal values for the device determine the maximum adjustable ranges.

Page 10
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
1.8.3 Specic technical data (400V / 480 V models)
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: an 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to di󰀨er max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20MHz
(3 The display error adds to the error of the related actual value on the DC terminal
5 kW Model 400 V / 480 V
PSB 9060-120 PSB 9080-120 PSB 9200-70 PSB 9360-40 PSB 9500-30
AC supply
Voltage range (L-L), frequency 342...528 V AC, 45 - 66 Hz
Connection 2ph, PE
Leak current < 3.5 mA
Phase current max. 16 A
Power factor ≈0.99
E󰀩ciency of energy recovery ≤ 92.5% ≤ 92.5% ≤ 93.5% ≤ 93.5% ≤ 94.5%
DC terminal
Max. voltage UMax 60 V 80 V 200 V 360 V 500 V
Max. current IMax 120 A 120 A 70 A 40 A 30 A
Max. power PMax 5000 W 5000 W 5000 W 5000 W 5000 W
Overvoltage protection range 0...66 V 0...88 V 0...220 V 0...396 V 0...550 V
Overcurrent protection range 0...132 A 0...132 A 0...77 A 0...44 A 0...33 A
Overpower protection range 0…5500 W 0…5500 W 0…5500 W 0…5500 W 0…5500 W
Temperature coe󰀩cient for set
values Δ/K Voltage / current: 100 ppm
Capacitance (approx.) 7990 μF 7990 μF 2520 μF 390 μF 180 μF
Voltage regulation (general)
Adjustment range 0...61.2 V 0...81.6 V 0...204 V 0...367.2 V 0...510 V
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.1% UMax < 0.1% UMax < 0.1% UMax < 0.1% UMax < 0.1% UMax
Line regulation at ±10% ΔUAC < 0.02% UMax < 0.02% UMax < 0.02% UMax < 0.02% UMax < 0.02% UMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax
Remote sensing compensation Max. 5% UMax Max. 5% UMax Max. 5% UMax Max. 5% UMax Max. 5% UMax
Voltage regulation (power supply)
Load regulation at 0...100% ΔIOUT < 0.05% UMax < 0.05% UMax < 0.05% UMax < 0.05% UMax < 0.05% UMax
Rise time 10...90% ΔUOUT Max. 30 ms Max. 30 ms Max. 30 ms Max. 30 ms Max. 30 ms
Transient time after ΔIOUT < 1.5 ms < 1.5 ms < 1.5 ms < 1.5 ms < 1.5 ms
Ripple (2 < 200 mVPP
< 16 mVRMS
< 200 mVPP
< 16 mVRMS
< 300 mVPP
< 40 mVRMS
< 320 mVPP
< 55 mVRMS
< 350 mVPP
< 70 mVRMS
Fall time at no load after switching
DC output o󰀨 Down from 100% to <60 V: less than 10 s
Voltage regulation (el. load)
Load regulation at 0...100% ΔU < 0.05% UMax < 0.05% UMax < 0.05% UMax < 0.05% UMax < 0.05% UMax
Current regulation (general)
Adjustment range 0...122.4 A 0...122.4 A 0...71.4 A 0...40.8 A 0...30.6 A
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.2% IMax < 0.2% IMax < 0.2% IMax < 0.2% IMax < 0.2% IMax
Line regulation at ±10% ΔUAC < 0.05% IMax < 0.05% IMax < 0.05% IMax < 0.05% IMax < 0.05% IMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax
Current regulation (power supply)
Load regulation at 0...100% ΔUOUT < 0.15% IMax < 0.15% IMax < 0.15% IMax < 0.15% IMax < 0.15% IMax
Current regulation (el. load)
Load regulation at 0...100% ΔUIN < 0.15% IMax < 0.15% IMax < 0.15% IMax < 0.15% IMax < 0.15% IMax
Ripple (2 < 80 mARMS < 80 mARMS < 22 mARMS < 18 mARMS < 16 mARMS

Page 11
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
5 kW Model 400 V / 480 V
PSB 9060-120 PSB 9080-120 PSB 9200-70 PSB 9360-40 PSB 9500-30
Power regulation
Adjustment range 0…5100 W 0…5100 W 0…5100 W 0…5100 W 0…5100 W
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 1% PMax < 1% PMax < 1% PMax < 1% PMax < 1% PMax
Line regulation at ±10% ΔUAC < 0.05% PMax < 0.05% PMax < 0.05% PMax < 0.05% PMax < 0.05% PMax
Load reg. at 10-90% ΔUDC * ΔIDC < 0.75% PMax < 0.75% PMax < 0.75% PMax < 0.75% PMax < 0.75% PMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (2 ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax
E󰀩ciency (5 ≈ 93% ≈ 93% ≈ 95% ≈ 95% ≈ 95,5%
Resistance regulation
Adjustment range 0.02...25 Ω 0.02...25 Ω 0.1...150 Ω 0.3...520 Ω 0.5...1000 Ω
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) ≤1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Analog interface (3
Signals See „3.6.4.4. Analog interface specication“
Galvanic isolation to the device Max. 1500 V DC
Sample rate of inputs & outputs 500 Hz
Insulation Allowed potential shift (oating voltage) on the DC terminal:
Negative DC to PE Max. ±400 V DC ±400 V DC ±725 V DC ±725 V DC ±1500 V DC
Positive DC to PE Max. ±400 V DC ±400 V DC ±1000 V DC ±1000 V DC ±1800 V DC
AC input <-> PE 2.5 kV DC
AC input <-> DC terminal 2.5 kV DC
Miscellaneous
Cooling Temperature controlled fans, front inlet, rear exhaust
Ambient temperature 0...50 °C (32...133 °F)
Storage temperature -20...70 °C (-4...158 °F)
Humidity < 80%, not condensing
Standards EN 61010-1, EN 50160:2011-02, EN 61000-6-2:2016-05, EN 61000-6-3:2011-09
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m (1.242 mi)
Digital interfaces
Featured 1x USB-B for communication, 1x USB-A for functions, 1x GPIB (optional)
Slot (standard version) Optional: CANopen, Probus, Pronet, RS232, CAN, Ethernet, ModBus TCP, Ether-
CAT
Galvanic isolation from device Max. 1500 V DC
Terminals
Rear side Share Bus, DC terminal, AC supply, remote sensing, analog interface, USB, master-
slave bus, interface module slot (standard version) or GPIB (optional)
Front side USB for sticks
Dimensions
Enclosure (W x H x D) 19“ x 3U x 670 mm (26.4”)
Total (W x H x D) 483 x 133 x 775 mm (19” x 5.2” x 30.5”)
Weight ≈18 kg (39.7 lb) ≈18 kg (39.7 lb) ≈18 kg (39.7 lb) ≈18 kg (39.7 lb) ≈18 kg (39.7 lb)
Article number (4 30000319 30000301 30000302 30000303 30000304
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value. With the resistance, the
accuracy rating already includes the error of the actual resistance display.
(2 The display error adds to the error of the related actual value on the DC terminal
(3 For technical specications of the analog interface see „3.6.4.4 Analog interface specication“ on page 64
(4 Article number of the standard version, devices with options will have a di󰀨erent number
(5 Typical value at 100% voltage and 100% power

Page 12
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
5 kW / 10 kW Model 400 V / 480 V
PSB 9750-20 PSB 9060-240 PSB 9080-240 PSB 9200-140 PSB 9360-80
AC supply
Voltage range (L-L), frequency 342...528 V AC, 45 - 66 Hz
Connection 2ph, PE 3ph, PE 3ph, PE 3ph, PE 3ph, PE
Leak current < 3.5 mA < 3.5 mA < 3.5 mA < 3.5 mA < 3.5 mA
Phase current max. 16 A max. 28 A max. 28 A max. 28 A max. 28 A
Power factor ≈0.99
E󰀩ciency of energy recovery ≤ 94.5% ≤ 92.5% ≤ 92.5% ≤ 93.5% ≤ 93.5%
DC terminal
Max. voltage UMax 750 V 60 V 80 V 200 V 360 V
Max. current IMax 20 A 240 A 240 A 140 A 80 A
Max. power PMax 5000 W 10000 W 10000 W 10000 W 10000 W
Overvoltage protection range 0...825 V 0...66 V 0...88 V 0...220 V 0...396 V
Overcurrent protection range 0...22 A 0...264 A 0...264 A 0...154 A 0...88 A
Overpower protection range 0…5500 W 0…11000 W 0…11000 W 0…11000 W 0...11000 W
Temperature coe󰀩cient for set
values Δ/K Voltage / current: 100 ppm
Capacitance (approx.) 180 μF 15980 μF 15980 μF 5040 μF 780 μF
Voltage regulation (general)
Adjustment range 0...765 V 0...61.2 V 0...81.6 V 0...204 V 0...367.2 V
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.1% UMax < 0.1% UMax < 0.1% UMax < 0.1% UMax < 0.1% UMax
Line regulation at ±10% ΔUAC < 0.02% UMax < 0.02% UMax < 0.02% UMax < 0.02% UMax < 0.02% UMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax
Remote sensing compensation Max. 5% UMax Max. 5% UMax Max. 5% UMax Max. 5% UMax Max. 5% UMax
Voltage regulation (power supply)
Load regulation at 0...100% ΔIOUT < 0.05% UMax < 0.05% UMax < 0.05% UMax < 0.05% UMax < 0.05% UMax
Rise time 10...90% ΔUOUT Max. 30 ms Max. 30 ms Max. 30 ms Max. 30 ms Max. 30 ms
Transient time after ΔIOUT < 1.5 ms < 1.5 ms < 1.5 ms < 1.5 ms < 1.5 ms
Ripple (2 < 800 mVPP
< 200 mVRMS
< 320 mVPP
< 25 mVRMS
< 320 mVPP
< 25 mVRMS
< 300 mVPP
< 40 mVRMS
< 320 mVPP
< 55 mVRMS
Fall time at no load after switching
DC output o󰀨 Down from 100% to <60 V: less than 10 s
Voltage regulation (el. load)
Load regulation at 0...100% ΔU < 0.05% UMax < 0.05% UMax < 0.05% UMax < 0.05% UMax < 0.05% UMax
Current regulation (general)
Adjustment range 0...20.4 A 0...244.8 A 0...244.8 A 0...142.8 A 0...81.6 A
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.2% IMax < 0.2% IMax < 0.2% IMax < 0.2% IMax < 0.2% IMax
Line regulation at ±10% ΔUAC < 0.05% IMax < 0.05% IMax < 0.05% IMax < 0.05% IMax < 0.05% IMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax
Current regulation (power supply)
Load regulation at 0...100% ΔUOUT < 0.15% IMax < 0.15% IMax < 0.15% IMax < 0.15% IMax < 0.15% IMax
Current regulation (el. load)
Load regulation at 0...100% ΔUIN < 0.15% IMax < 0.15% IMax < 0.15% IMax < 0.15% IMax < 0.15% IMax
Ripple (2 < 16 mARMS < 160 mARMS < 160 mARMS < 44 mARMS < 35 mARMS
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: an 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to di󰀨er max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20MHz
(3 The display error adds to the error of the related actual value on the DC terminal

Page 13
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
5 kW / 10 kW Model 400 V / 480 V
PSB 9750-20 PSB 9060-240 PSB 9080-240 PSB 9200-140 PSB 9360-80
Power regulation
Adjustment range 0…5100 W 0…10200 W 0…10200 W 0…10200 W 0…10200 W
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 1% PMax < 1% PMax < 1% PMax < 1% PMax < 1% PMax
Line regulation at ±10% ΔUAC < 0.05% PMax < 0.05% PMax < 0.05% PMax < 0.05% PMax < 0.05% PMax
Load reg. at 10-90% ΔUDC * ΔIDC < 0.75% PMax < 0.75% PMax < 0.75% PMax < 0.75% PMax < 0.75% PMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (2 ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax
E󰀩ciency (5 ≈ 94% ≈ 93% ≈ 93% ≈ 95% ≈ 93%
Resistance regulation
Adjustment range 1.2...2200 Ω 0.01...13 Ω 0.01...13 Ω 0.06...75 Ω 0.15...260 Ω
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) ≤1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Analog interface (3
Signals See „3.6.4.4. Analog interface specication“
Galvanic isolation to the device Max. 1500 V DC
Sample rate of inputs & outputs 500 Hz
Insulation Allowed potential shift (oating voltage) on the DC terminal:
Negative DC to PE Max. ±1500 V DC ±400 V DC ±400 V DC ±725 V DC ±725 V DC
Positive DC to PE Max. ±1800 V DC ±400 V DC ±600 V DC ±1000 V DC ±1000 V DC
AC input <-> PE 2.5 kV DC
AC input <-> DC terminal 2.5 kV DC
Miscellaneous
Cooling Temperature controlled fans, front inlet, rear exhaust
Ambient temperature 0...50 °C (32...133 °F)
Storage temperature -20...70 °C (-4...158 °F)
Humidity < 80%, not condensing
Standards EN 61010-1, EN 50160:2011-02, EN 61000-6-2:2016-05, EN 61000-6-3:2011-09
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m (1.242 mi)
Digital interfaces
Featured 1x USB-B for communication, 1x USB-A for functions, 1x GPIB (optional)
Slot (standard version) Optional: CANopen, Probus, Pronet, RS232, CAN, Ethernet, ModBus TCP, Ether-
CAT
Galvanic isolation from device Max. 1500 V DC
Terminals
Rear side Share Bus, DC terminal, AC supply, remote sensing, analog interface, USB, master-
slave bus, interface module slot (standard version) or GPIB (optional)
Front side USB for sticks
Dimensions
Enclosure (W x H x D) 19“ x 3U x 670 mm (26.4”)
Total (W x H x D) 483 x 133 x 775 mm (19” x 5.2” x 30.5”)
Weight ≈18 kg (39.7 lb) ≈25 kg (55.1 lb) ≈25 kg (55.1 lb) ≈25 kg (55.1 lb) ≈25 kg (55.1 lb)
Article number (4 30000305 30000320 30000306 30000307 30000308
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value. With the resistance, the
accuracy rating already includes the error of the actual resistance display.
(2 The display error adds to the error of the related actual value on the DC terminal
(3 For technical specications of the analog interface see „3.6.4.4 Analog interface specication“ on page 64
(4 Article number of the standard version, devices with options will have a di󰀨erent number
(5 Typical value at 100% voltage and 100% power

Page 14
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
10 kW / 15 kW Model 400 V / 480 V
PSB 9500-60 PSB 9750-40 PSB 9060-360 PSB 9080-360
AC supply
Voltage range (L-L), frequency 342...528 V AC, 45 - 66 Hz
Connection 3ph, PE 3ph, PE 3ph, PE 3ph, PE
Leak current < 3.5 mA < 3.5 mA < 3.5 mA < 3.5 mA
Phase current max. 28 A max. 28 A max. 28 A max. 28 A
Power factor ≈0.99
E󰀩ciency of energy recovery ≤ 94.5% ≤ 94.5% ≤ 92.5% ≤ 92.5%
DC terminal
Max. voltage UMax 500 V 750 V 60 V 80 V
Max. current IMax 60 A 40 A 360 A 360 A
Max. power PMax 10000 W 10000 W 15000 W 15000 W
Overvoltage protection range 0...550 V 0...825 V 0...66 V 0...88 V
Overcurrent protection range 0...66 A 0...44 A 0...396 A 0...396 A
Overpower protection range 0…11000 W 0…11000 W 0…16500 W 0…16500 W
Temperature coe󰀩cient for set
values Δ/K Voltage / current: 100 ppm
Capacitance (approx.) 360 μF 360 μF 23970 μF 23970 μF
Voltage regulation (general)
Adjustment range 0...510 V 0...765 V 0...61.2 V 0...81.6 V
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.1% UMax < 0.1% UMax < 0.1% UMax < 0.1% UMax
Line regulation at ±10% ΔUAC < 0.02% UMax < 0.02% UMax < 0.02% UMax < 0.02% UMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax
Remote sensing compensation Max. 5% UMax Max. 5% UMax Max. 5% UMax Max. 5% UMax
Voltage regulation (power supply)
Load regulation at 0...100% ΔIOUT < 0.05% UMax < 0.05% UMax < 0.05% UMax < 0.05% UMax
Rise time 10...90% ΔUOUT Max. 30 ms Max. 30 ms Max. 30 ms Max. 30 ms
Transient time after ΔIOUT < 1.5 ms < 1.5 ms < 1.5 ms < 1.5 ms
Ripple (2 < 350 mVPP
< 70 mVRMS
< 800 mVPP
< 200 mVRMS
< 320 mVPP
< 25 mVRMS
< 320 mVPP
< 25 mVRMS
Fall time at no load after switching
DC output o󰀨 Down from 100% to <60 V: less than 10 s
Voltage regulation (el. load)
Load regulation at 0...100% ΔU < 0.05% UMax < 0.05% UMax < 0.05% UMax < 0.05% UMax
Current regulation (general)
Adjustment range 0...61.2 A 0...40.8 A 0...367.2 A 0...367.2 A
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.2% IMax < 0.2% IMax < 0.2% IMax < 0.2% IMax
Line regulation at ±10% ΔUAC < 0.05% IMax < 0.05% IMax < 0.05% IMax < 0.05% IMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax
Current regulation (power supply)
Load regulation at 0...100% ΔUOUT < 0.15% IMax < 0.15% IMax < 0.15% IMax < 0.15% IMax
Current regulation (el. load)
Load regulation at 0...100% ΔUIN < 0.15% IMax < 0.15% IMax < 0.15% IMax < 0.15% IMax
Ripple (2 < 32 mARMS < 32 mARMS < 240 mARMS < 240 mARMS
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: an 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to di󰀨er max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20MHz
(3 The display error adds to the error of the related actual value on the DC terminal

Page 15
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
10 kW / 15 kW Model 400 V / 480 V
PSB 9500-60 PSB 9750-40 PSB 9060-360 PSB 9080-360
Power regulation
Adjustment range 0…10200 W 0…10200 W 0…15300 W 0…15300 W
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 1% PMax < 1% PMax < 1% PMax < 1% PMax
Line regulation at ±10% ΔUAC < 0.05% PMax < 0.05% PMax < 0.05% PMax < 0.05% PMax
Load reg. at 10-90% ΔUDC * ΔIDC < 0.75% PMax < 0.75% PMax < 0.75% PMax < 0.75% PMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (2 ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax
E󰀩ciency (5 ≈ 95% ≈ 94% ≈ 93% ≈ 93%
Resistance regulation
Adjustment range 0.25...500 Ω 0.43...550 Ω 0.006...10 Ω 0.006...10 Ω
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) ≤1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Analog interface (3
Signals See „3.6.4.4. Analog interface specication“
Galvanic isolation to the device Max. 1500 V DC
Sample rate of inputs & outputs 500 Hz
Insulation Allowed potential shift (oating voltage) on the DC terminal:
Negative DC to PE Max. ±1500 V DC ±1500 V DC ±400 V DC ±400 V DC
Positive DC to PE Max. ±1800 V DC ±1800 V DC ±400 V DC ±400 V DC
AC input <-> PE 2.5 kV DC
AC input <-> DC terminal 2.5 kV DC
Miscellaneous
Cooling Temperature controlled fans, front inlet, rear exhaust
Ambient temperature 0...50 °C (32...133 °F)
Storage temperature -20...70 °C (-4...158 °F)
Humidity < 80%, not condensing
Standards EN 61010-1, EN 50160:2011-02, EN 61000-6-2:2016-05, EN 61000-6-3:2011-09
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m (1.242 mi)
Digital interfaces
Featured 1x USB-B for communication, 1x USB-A for functions, 1x GPIB (optional)
Slot (standard version) Optional: CANopen, Probus, Pronet, RS232, CAN, Ethernet, ModBus TCP, Ether-
CAT
Galvanic isolation from device Max. 1500 V DC
Terminals
Rear side Share Bus, DC terminal, AC supply, remote sensing, analog interface, USB, master-
slave bus, interface module slot (standard version) or GPIB (optional)
Front side USB for sticks
Dimensions
Enclosure (W x H x D) 19“ x 3U x 670 mm (26.4”)
Total (W x H x D) 483 x 133 x 775 mm (19” x 5.2” x 30.5”)
Weight ≈25 kg (55.1 lb) ≈25 kg (55.1 lb) ≈ 32 kg (70.5 lb) ≈ 32 kg (70.5 lb)
Article number (4 30000309 30000310 30000321 30000312
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value. With the resistance, the
accuracy rating already includes the error of the actual resistance display.
(2 The display error adds to the error of the related actual value on the DC terminal
(3 For technical specications of the analog interface see „3.6.4.4 Analog interface specication“ on page 64
(4 Article number of the standard version, devices with options will have a di󰀨erent number
(5 Typical value at 100% voltage and 100% power

Page 16
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
15 kW Model 400 V / 480 V
PSB 9200-210 PSB 9360-120 PSB 9500-90
AC supply
Voltage range (L-L), frequency 342...528 V AC, 45 - 66 Hz
Connection 3ph, PE 3ph, PE 3ph, PE
Leak current < 3.5 mA < 3.5 mA < 3.5 mA
Phase current max. 28 A max. 28 A max. 28 A
Power factor ≈0.99
E󰀩ciency of energy recovery ≤ 93.5% ≤ 93.5% ≤ 94.5%
DC terminal
Max. voltage UMax 200 V 360 V 500 V
Max. current IMax 210 A 120 A 90 A
Max. power PMax 15000 W 15000 W 15000 W
Overvoltage protection range 0...220 V 0...396 V 0...550 V
Overcurrent protection range 0...231 A 0...132 A 0...99 A
Overpower protection range 0…16500 W 0…16500 W 0…16500 W
Temperature coe󰀩cient for set
values Δ/K Voltage / current: 100 ppm
Capacitance (approx.) 7560 μF 1170 μF 540 μF
Voltage regulation (general)
Adjustment range 0...204 V 0...367.2 V 0...510 V
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.1% UMax < 0.1% UMax < 0.1% UMax
Line regulation at ±10% ΔUAC < 0.02% UMax < 0.02% UMax < 0.02% UMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax
Remote sensing compensation Max. 5% UMax Max. 5% UMax Max. 5% UMax
Voltage regulation (power supply)
Load regulation at 0...100% ΔIOUT < 0.05% UMax < 0.05% UMax < 0.05% UMax
Rise time 10...90% ΔUOUT Max. 30 ms Max. 30 ms Max. 30 ms
Transient time after ΔIOUT < 1.5 ms < 1.5 ms < 1.5 ms
Ripple (2 < 300 mVPP
< 40 mVRMS
< 320 mVPP
< 55 mVRMS
< 350 mVPP
< 70 mVRMS
Fall time at no load after switching
DC output o󰀨 Down from 100% to <60 V: less than 10 s
Voltage regulation (el. load)
Load regulation at 0...100% ΔU < 0.05% UMax < 0.05% UMax < 0.05% UMax
Current regulation (general)
Adjustment range 0...214.2 A 0...122.4 A 0...91.8 A
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.2% IMax < 0.2% IMax < 0.2% IMax
Line regulation at ±10% ΔUAC < 0.05% IMax < 0.05% IMax < 0.05% IMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax
Current regulation (power supply)
Load regulation at 0...100% ΔUOUT < 0.15% IMax < 0.15% IMax < 0.15% IMax
Current regulation (el. load)
Load regulation at 0...100% ΔUIN < 0.15% IMax < 0.15% IMax < 0.15% IMax
Ripple (2 < 66 mARMS < 50 mARMS < 48 mARMS
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: an 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to di󰀨er max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20MHz
(3 The display error adds to the error of the related actual value on the DC terminal

Page 17
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
15 kW Model 400 V / 480 V
PSB 9200-210 PSB 9360-120 PSB 9500-90
Power regulation
Adjustment range 0…15300 W 0…15300 W 0…15300 W
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 1% PMax < 1% PMax < 1% PMax
Line regulation at ±10% ΔUAC < 0.05% PMax < 0.05% PMax < 0.05% PMax
Load reg. at 10-90% ΔUDC * ΔIDC < 0.75% PMax < 0.75% PMax < 0.75% PMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (2 ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax
E󰀩ciency (5 ≈ 95% ≈ 94% ≈ 95%
Resistance regulation
Adjustment range 0.033...50 Ω 0.1...180 Ω 0.16...340 Ω
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) ≤1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Analog interface (3
Signals See „3.6.4.4. Analog interface specication“
Galvanic isolation to the device Max. 1500 V DC
Sample rate of inputs & outputs 500 Hz
Insulation Allowed potential shift (oating voltage) on the DC terminal:
Negative DC to PE Max. ±725 V DC ±725 V DC ±1500 V DC
Positive DC to PE Max. ±1000 V DC ±1000 V DC ±1800 V DC
AC input <-> PE 2.5 kV DC
AC input <-> DC terminal 2.5 kV DC
Miscellaneous
Cooling Temperature controlled fans, front inlet, rear exhaust
Ambient temperature 0...50 °C (32...133 °F)
Storage temperature -20...70 °C (-4...158 °F)
Humidity < 80%, not condensing
Standards EN 61010-1, EN 50160:2011-02, EN 61000-6-2:2016-05, EN 61000-6-3:2011-09
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m (1.242 mi)
Digital interfaces
Featured 1x USB-B for communication, 1x USB-A for functions, 1x GPIB (optional)
Slot (standard version) Optional: CANopen, Probus, Pronet, RS232, CAN, Ethernet, ModBus TCP, Ether-
CAT
Galvanic isolation from device Max. 1500 V DC
Terminals
Rear side Share Bus, DC terminal, AC supply, remote sensing, analog interface, USB, master-
slave bus, interface module slot (standard version) or GPIB (optional)
Front side USB for sticks
Dimensions
Enclosure (W x H x D) 19“ x 3U x 670 mm (26.4”)
Total (W x H x D) 483 x 133 x 775 mm (19” x 5.2” x 30.5”)
Weight ≈ 32 kg (70.5 lb) ≈ 32 kg (70.5 lb) ≈ 32 kg (70.5 lb)
Article number (4 30000313 30000314 30000315
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value. With the resistance, the
accuracy rating already includes the error of the actual resistance display.
(2 The display error adds to the error of the related actual value on the DC terminal
(3 For technical specications of the analog interface see „3.6.4.4 Analog interface specication“ on page 64
(4 Article number of the standard version, devices with options will have a di󰀨erent number
(5 Typical value at 100% voltage and 100% power

Page 18
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
15 kW Model 400 V / 480 V
PSB 9750-60 PSB 91000-40 PSB 91500-30
AC supply
Voltage range (L-L), frequency 342...528 V AC, 45 - 66 Hz
Connection 3ph, PE 3ph, PE 3ph, PE
Leak current < 3.5 mA < 3.5 mA < 3.5 mA
Phase current max. 28 A max. 28 A max. 28 A
Power factor ≈0.99
E󰀩ciency of energy recovery ≤ 94.5% ≤ 93.5% ≤ 94.5%
DC terminal
Max. voltage UMax 750 V 1000 V 1500 V
Max. current IMax 60 A 40 A 30 A
Max. power PMax 15000 W 15000 W 15000 W
Overvoltage protection range 0...825 V 0...1100 V 0...1650 V
Overcurrent protection range 0...66 A 0...44 A 0...33 A
Overpower protection range 0…16500 W 0…16500 W 0…16500 W
Temperature coe󰀩cient for set
values Δ/K Voltage / current: 100 ppm
Capacitance (approx.) 540 μF 130 μF 60 μF
Voltage regulation (general)
Adjustment range 0...765 V 0...1020 V 0...1530 V
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.1% UMax < 0.1% UMax < 0.1% UMax
Line regulation at ±10% ΔUAC < 0.02% UMax < 0.02% UMax < 0.02% UMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% UMax ≤ 0.2% UMax ≤ 0.2% UMax
Remote sensing compensation Max. 5% UMax Max. 5% UMax Max. 5% UMax
Voltage regulation (power supply)
Load regulation at 0...100% ΔIOUT < 0.05% UMax < 0.05% UMax < 0.05% UMax
Rise time 10...90% ΔUOUT Max. 30 ms Max. 30 ms Max. 30 ms
Transient time after ΔIOUT < 1.5 ms < 1.5 ms < 1.5 ms
Ripple (2 < 800 mVPP
< 200 mVRMS
< 1600 mVPP
< 300 mVRMS
< 2400 mVPP
< 400 mVRMS
Fall time at no load after switching
DC output o󰀨 Down from 100% to <60 V: less than 10 s
Voltage regulation (el. load)
Load regulation at 0...100% ΔU < 0.05% UMax < 0.05% UMax < 0.05% UMax
Current regulation (general)
Adjustment range 0...61.2 A 0...40.8 A 0...30.6 A
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.2% IMax < 0.2% IMax < 0.2% IMax
Line regulation at ±10% ΔUAC < 0.05% IMax < 0.05% IMax < 0.05% IMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (3 ≤ 0.2% IMax ≤ 0.2% IMax ≤ 0.2% IMax
Current regulation (power supply)
Load regulation at 0...100% ΔUOUT < 0.15% IMax < 0.15% IMax < 0.15% IMax
Current regulation (el. load)
Load regulation at 0...100% ΔUIN < 0.15% IMax < 0.15% IMax < 0.15% IMax
Ripple (2 < 48 mARMS < 16 mARMS < 26 mARMS
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: an 80 V model has min. 0.1% voltage accuracy, that is 80 mV. When adjusting the voltage to 5 V, the actual value is allowed to di󰀨er max. 80 mV, which
means it might be between 4.92 V and 5.08 V.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20MHz
(3 The display error adds to the error of the related actual value on the DC terminal

Page 19
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
15 kW Model 400 V / 480 V
PSB 9750-60 PSB 91000-40 PSB 91500-30
Power regulation
Adjustment range 0…15300 W 0…15300 W 0…15300 W
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 1% PMax < 1% PMax < 1% PMax
Line regulation at ±10% ΔUAC < 0.05% PMax < 0.05% PMax < 0.05% PMax
Load reg. at 10-90% ΔUDC * ΔIDC < 0.75% PMax < 0.75% PMax < 0.75% PMax
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Display: Accuracy (2 ≤ 0.8% PMax ≤ 0.8% PMax ≤ 0.8% PMax
E󰀩ciency (5 ≈ 94% ≈ 94% ≈ 95%
Resistance regulation
Adjustment range 0.4...740 Ω 0.8...1300 Ω 2.5...3000 Ω
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) ≤1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section „1.9.6.4. Resolution of the displayed values“
Analog interface (3
Signals See „3.6.4.4. Analog interface specication“
Galvanic isolation to the device Max. 1500 V DC
Sample rate of inputs & outputs 500 Hz
Insulation Allowed potential shift (oating voltage) on the DC terminal:
Negative DC to PE Max. ±1500 V DC ±1500 V DC ±1500 V DC
Positive DC to PE Max. ±1800 V DC ±1800 V DC ±1800 V DC
AC input <-> PE 2.5 kV DC
AC input <-> DC terminal 2.5 kV DC
Miscellaneous
Cooling Temperature controlled fans, front inlet, rear exhaust
Ambient temperature 0...50 °C (32...133 °F)
Storage temperature -20...70 °C (-4...158 °F)
Humidity < 80%, not condensing
Standards EN 61010-1, EN 50160:2011-02, EN 61000-6-2:2016-05, EN 61000-6-3:2011-09
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m (1.242 mi)
Digital interfaces
Featured 1x USB-B for communication, 1x USB-A for functions, 1x GPIB (optional)
Slot (standard version) Optional: CANopen, Probus, Pronet, RS232, CAN, Ethernet, ModBus TCP, Ether-
CAT
Galvanic isolation from device Max. 1500 V DC
Terminals
Rear side Share Bus, DC terminal, AC supply, remote sensing, analog interface, USB, master-
slave bus, interface module slot (standard version) or GPIB (optional)
Front side USB for sticks
Dimensions
Enclosure (W x H x D) 19“ x 3U x 670 mm (26.4”)
Total (W x H x D) 483 x 133 x 775 mm (19” x 5.2” x 30.5”)
Weight ≈ 32 kg (70.5 lb) ≈ 32 kg (70.5 lb) ≈ 32 kg (70.5 lb)
Article number (4 30000316 30000317 30000318
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value. With the resistance, the
accuracy rating already includes the error of the actual resistance display.
(2 The display error adds to the error of the related actual value on the DC terminal
(3 For technical specications of the analog interface see „3.6.4.4 Analog interface specication“ on page 64
(4 Article number of the standard version, devices with options will have a di󰀨erent number
(5 Typical value at 100% voltage and 100% power

Page 20
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 9000 3U Series
1.8.4 Specic technical data (208 V models)
The so-called US models di󰀨er from the EU models, as listed in section 1.8.3, only in a few technical specications,
so only the di󰀨ering specications are listed here. The rest can be found in 1.8.3.
These models are only for the use on 208 V three-phase grid.
2.5 kW / 5 kW Model 208 V
PSB 9080-120 PSB 9750-20 PSB 9060-240 PSB 9080-240 PSB 9360-80
AC supply
Voltage range (L-L), frequency 187...228 V AC, 45 - 66 Hz
Connection 2ph, PE 2ph, PE 3ph, PE 3ph, PE 3ph, PE
Phase current max. 16 A max. 16 A max. 28 A max. 28 A max. 28 A
DC terminal
Max. power PMax 2500 W 2500 W 5000 W 5000 W 5000 W
Overpower protection 0...2750 W 0...2750 W 0...5500 W 0...5500 W 0...5500 W
Power regulation
Adjustment range 0...2550 W 0...2550 W 0…5100 W 0…5100 W 0…5100 W
Article number (4 30008301 30008305 30008320 30008306 30008308
5 kW / 7.5 kW Model 208 V
PSB 9500-60 PSB 9080-360 PSB 9200-210 PSB 9360-120 PSB 9500-90
AC supply
Voltage range (L-L), frequency 187...228 V AC, 45 - 66 Hz
Connection 3ph, PE
Phase current max. 28 A
DC terminal
Max. power PMax 5000 W 7500 W 7500 W 7500 W 7500 W
Overpower protection 0...5500 W 0...8250 W 0...8250 W 0...8250 W 0...8250 W
Power regulation
Adjustment range 0…5100 W 0…7650 W 0…7650 W 0…7650 W 0…7650 W
Article number (4 30008309 30008312 30008313 30008314 30008315
7.5 kW Model 208 V
PSB 9750-60 PSB 91000-40 PSB 91500-30
AC supply
Voltage range (L-L), frequency 187...228 V AC, 45 - 66 Hz
Connection 3ph, PE
Phase current max. 28 A
DC terminal
Max. power PMax 7500 W 7500 W 7500 W
Overpower protection 0...8250 W 0...8250 W 0...8250 W
Power regulation
Adjustment range 0…7650 W 0…7650 W 0…7650 W
Article number (4 30008316 30008317 30008318
