Pressing [S], [P], or [9] will end scan mode and the last
input showing will remain selected.
Storing a Scan Sequence Into Memory, An Example
Say we want to store a scan sequence into memory
scanning the even inputs only leaving each input con-
nected for 30 seconds. First we need to select a preset
to store the sequence. In this example, let’s use preset 1.
Press [P], then press [1]. The display should blink ‘P’.
Next we must enter the time in 3 digits, in this example,
we chose 30 seconds. Therefore, we must enter 0 – 3 –
0. Press [0], the display will show ‘0’, then return to a
blinking ‘P’. Now press [3], the display will show ‘3’, then
return to a blinking ‘P’. Next press [0], the display will
show ‘0’ then return to a blinking ‘P’. The time of 30 sec-
onds has been saved.
Next, we need to enter the video sequence. In this exam-
ple, we chose the even inputs. Press [2], then [4], then
[6]. The display should behave as it did for entering the
time. Finally, to end program mode and store the se-
quence, press [P]. The display will stop blinking ‘P’ and
return to the input that is currently selected. By pressing
[S] or [9] will also end program mode.
The sequence is now stored in preset position ‘1’, and is
ready to be placed in scan mode. When this position is
chosen to be scanned, it will show input 2 for 30 seconds
then switch to input 4, wait 30 seconds, and so on. After
showing input 6 for 30 seconds, it will roll around back to
input 2, and then continue on until scan mode is stopped.
8
String Message ‘Software Version *.*’
•Applies after the version command. Displays the current
software version of the internal firmware.
String Message ‘Program Status’
•Applies after the status command.
•Displays a chart of the stored scan sequences.
PRESET TIME SEQUENCE STEPS
0 3 1 2 3 4 5 6 0 0 8
1 30 2 4 6 3
The TIME is represented in seconds. SEQUENCE represents the
input switch sequence. STEPS shows how many inputs have been
selected for that particular sequence.
In this Program Status Display, PRESET 1 will show input 2 for 30
seconds, then switch the input 4. After another 30 seconds, it will
switch to input 6. After another 30 seconds, it will recycle back to in-
put 2 and continue through the sequence until SCAN Mode is
stopped.
String Message ‘Gain Setting *’
•Sent after a gain setting command.
•Signifies the gain level setting shown by the *.
String Message ‘Black Level’
•Sent after the Black Level Select command.
•Notifies the user that the reference voltage is now at Black
Level.
String Message ‘Sync Tip’
•Sent after a Sync Tip Clamp Select Command.
•Notifies the user that the reference voltage is now sync tip
clamped.
String Message ‘Auto Sense *’
•Sent after the Auto Sense Command.
•Notifies the user that Auto Sense is ON or OFF.
