Cowon CR5 User manual

User Guide 1.0EN
CR5
COWON

2
COWON CR5
+ Package Contents
*Actual package contents may differ from the above images.
COWON
C
R
5
Quic
k
Guid
e
COWON CR5 Portable Charging Cradle Quick Guide
Small(2EA) Medium(2EA) Large(2EA)
Ear Tips Micro USB Cable

2 3
COWON CR5
+ Before you start _ Names of Parts and
Functions
CR5 Charging Cradle
For charging please remove the protective film from the
earphone charging terminal.
+ Before you start _ Precautions
Microphone
LED LED
Multi-Function Button
Power / Call / Pairing
Play / Previous · Next Track
Charging Port (L) Charging Port (R)
Micro USB Port

4
COWON CR5
+ Before you start _ Charging + Using the Product _ Power On / Off
CR5 Charging
Charging : The white LED
Indicator on your earphones
turns on
Charging Complete : The white
LED Indicator on your earphones
turns off
Charge the
Charging Cradle
Auto
Manual
Charging Status : Charging
cradle LED Indicator blink blue
0%~25% = 1time
25%~50% = 2times
50%~75% = 3times
75%~100% = 4times
Fully Charged = Stays solid Power On / Off : 4 Sec Press
In : Power Off
Out : Power On
*Please charge the charging cradle periodically. When the cradle battery is
discharged, the earphone units may turn-on instead of being charged, causing
the earphone to be discharged.

4 5
COWON CR5
Dual Mode Single Mode
+ Using the Product _ Pairing & connection
1. When both earphones are removed at the same time from the charging
cradle, they will automatically turn on , connect to each other, and enter
pairing mode following an audible beep.
2. Turn on Bluetooth on your smartphone or Bluetooth-capable device,
and select ‘CR5 Bluetooth L’ from the list of detected devices to pair
and connect automatically.
*To use Dual Mode, both the left and right earphones must be
turned on.
1. Pair the CR5 in Dual Mode as previously shown.
2. Turn off both the left and right earphones.
3. Press and hold the button on the right earphone for
6 seconds to enter pairing mode for only the right
earphone. (Even if you have heard the “Power On” voice,
please continue to press until you hear “Pairing Mode”.)
Pair the detected right earphone(CR5 Bluetooth R) to your
smartphone.
You can now turn on and use only the desired unit.
After the initial pairing, the CR5 and your smartphone will connect automatically when the CR5 is on and Bluetooth is
enabled on your phone.
Dual Mode : The CR5’s left and right earphones can be used together
in stereo.
Single Mode : The CR5’s left and right earphones can be used
individually in mono.
+
L R LL RR
6 Sec PressOff OffOff

6
COWON CR5
+ Using the Product _ Listening to Music·Calling
*Press and hold the multifunction button for 1 second to launch the voice
recognition feature of your smartphone or tablet. (Android OS : Google Assistant
/ iOS : Siri / Window OS : Cortana - Except during calls)
*When using Dual Mode, the sound can be heard from both left and right
earphones during calls. Mic only operates on left earphone so make sure to put
the left earphone near your mouth during calls.
*In Single Mode, each earphone will output sound with both microphones
enabled for use.
Answering
a call
·
Ending
a call
Rejecting
a call
Play
·
Pause
Next
Track
Previous
Track
Listening to Music Calling
*In Dual Mode, L unit connects to your smartphone.
*By using the CR5 in Single Mode, you can alternate between charging the left
and right earphones for extended use. (Audio books, Podcasts, etc.)
*Since Single Mode uses only one earphone, you can stay aware of
environmental sounds and use the device more safely when walking or
bicycling.
*Keep the product and a mobile phone within 1 meter when pairing.
*If passkey input is required, enter a password or a PIN No.‘0000’.
*When the CR5 is off, press and hold the multifunction button for 6 seconds
to enter pairing mode.
*When powered on, the earphones will automatically connect to the most
recently connected devices.

6 7
COWON CR5
+ Status LED + Voice Prompts
Status Blinking Pattern
CR5
Earbuds
Charging White LED stays on
Charging Complete White LED turns off
Power On Blue LED Blinks once
Power Off White LED Blinks once
Pairing Mode White and blue LED blinks
alternately
Play / Standby Mode Blue LED blinks every 7
seconds
Status Battery
Power Blinking Pattern
Charging
Cradle
Charging
0~25%
25~50%
50~75%
75~100%
White LED blinks once
White LED blinks twice
White LED blinks three times
White LED blinks four times
Charging
Complete 100% White LED stays on
Status Voice Prompts
CR5
Earbuds
Power On/ Power Off “Power ON” / “Power Off”
Pairing Mode “Pairing Mode”
L, R Connection (Dual
Mode)
L : “Left Channel”
R : “Right Channel”
Connected to Bluetooth
Device “Pairing Successful”
Bluetooth Connection
(Dual Mode) “Connected”
Disconnected “Disconnected”
Incoming call “Incoming Call” *
Low Battery “Battery Low”
*For iPhone, user ringtone will be applied.

8
COWON CR5
+ Specification
Bluetooth Version V5.0
Bluetooth Profiles HSP / HFP / A2DP / AVRCP
Standby Time Up to 150 hours
Music-Playing Time Single Mode : About 7.5 hours
Dual Mode : About 5 hours
Charging Time CR5 : About 1 hours *
Charging Cradle : About 1 hours
Battery CR5: 3.7V / 50mAh
Charging Cradle : 5V / 500mAh
Input DC 5V / 500mA
Operating Distance Up to 10m (Free space)
Weight CR5 : 4g x 2
Charging Cradle : 41g
*Number of available CR5 charges using charging cradle (500mAh) : 3~4 times (with fully charged charging cradle)
