CP TECHNOLOGIES NVR-0204 User manual

NVR-0204/0208/0216
4/8/16-CH Network Video Recorder
Quick Installation Guide v1.0

2
NVR-02 Series Quick Installation Guide
Package Contents
Network Video Recorder
RJ-45 Ethernet LAN cable
Power cord
Quick Installation Guide
CD Manual/Utility
Default Settings
IP Address DHCP address
Username root
Password root
If the NVR detects no DHCP server on the LAN environment,
then the NVR’s IP will be static IP [192.168.101.50]
This guide covers only the most common situations. All detailed
information is described in the user manual.

NVR-02 Series Quick Installation Guide
3
System Overview
Channel LED
Power LED
Status LED
Network LED
HDD1 LED
HDD2 LED
Alarm LED
Reset
Button
Buzzer Stop
Button
Power
Button
USB Port
Ethernet
Power
Connector
RS-232
GP I/O

4
NVR-02 Series Quick Installation Guide
HDD Installation
1. Start by removing the screws on the side.
2. Push the top housing forward then lift it up.
3. Locate the hard drive tray and slide the HDD firmly into the SATA connector
making sure the HDD is correctly aligned with the SATA connector.
4. Secure the HDD with the screw provided.
5. Place the top housing back and secure it with the bottom housing.

NVR-02 Series Quick Installation Guide
5
Connect to the NVR
There are various ways you can connect to the NVR and below are the
suggested methods for different network setup:
Use LevelOne Device Search Utility
If the NVR is placed in a corporate network or a local area network where a
DHCP server is already presented, run the “LevelOne Device Search” utility
from a computer that is on the same network and locate the NVR with its IP
address that is assigned by the top-level DHCP server.
To begin, launch the “Device Search” utility from the CD and proceed with the
installation:
Once the installation is complete, check the “Launch the program” option and
click “Finish”.
The search should start automatically and its status should be displayed.

6
NVR-02 Series Quick Installation Guide
The NVR should be located and its IP address should be displayed.
Double-click on an NVR and the search program should automatically access the
NVR’s web administration page from your default browser.
You should be prompted for the NVR’s username and password. Enter its default
username “root” and password “root” and then click ”OK” to enter the system.
Double-click

NVR-02 Series Quick Installation Guide
7
Access the NVR with its default IP address
The NVR comes with a pre-configured static IP “192.168.101.50”. However, it is
only used when there is no DHCP server presented in the network. The NVR will
turn on its DHCP server function and act as the DHCP server in the network.
To connect to the NVR, connect the PC directly to the NVR using a crossover
CAT5 Ethernet cable. Simply access the NVR from your web browser with its IP
address.
Again, you should be prompted for the username and password. Enter its default
username “root” and password “root” and then click ”OK” to enter the system.

8
NVR-02 Series Quick Installation Guide
Add a Camera
Automatic Search
1. Click the “Search” button to perform the camera search.
2. You should be prompted to install Active Control component in order for the
search to function properly. Go ahead and click “Install”.
3. After that, the search should begin and its status should be displayed:

NVR-02 Series Quick Installation Guide
9
4. Found cameras should be listed and simply select a camera from the list and
press “Configure”.
5. The camera's information should be displayed in the “Camera Information”
section. Enter its username and password and select the channel ID and name
the camera.
6. Click on “Detect” to establish connection between the recorder and the camera.
If connection establishes successfully, camera’s detailed information should be
polled and displayed as below.
1
2

10
NVR-02 Series Quick Installation Guide
7. Adjust its video format, frame rate, resolution or bitrate...etc if you wish and
then click “Add” to finish adding the camera.
Add a camera manually
Simply follow the instruction described above but instead of using the “Search”
function, enter the camera’s IP address and credential in the “Camera
Information” manually, then follow steps 6 ~ 7 described above.
2
1
Enter manually
