CPI CMP 200 User manual

CMP 200®/ CMP 200®DR SERIES
X-RAY GENERATOR
SERVICE MANUAL
PREPARED BY:
COMMUNICATIONS & POWER INDUSTRIES CANADA INC.
45 RIVER DRIVE
GEORGETOWN, ONTARIO, CANADA L7G 2J4
TELEPHONE: [phone]
901471-00
SERVICE MANUAL P/N 901471-01

CPI Canada Inc.
PRE-INSTALLATION
1¾
CMP 200®/
CMP 200®DR
INSTALLATION 2¾
SERVICE AND
INSTALLATION
INTERFACING, PROGRAMMING, AND
CALIBRATION 3¾
MANUAL ACCEPTANCE TESTING 4¾
Manual part number: 901471 TROUBLESHOOTING 5¾
REGULAR MAINTENANCE
6¾
THEORY OF OPERATION 7¾
SPARES
8¾
SCHEMATICS
9¾
The original version of this manual (April 03, 2008)
has been drafted in the English language by:
Communications & Power Industries
communications & medical products division.
CMP 200 ® X-Ray Generator Service Manual Ch # 901476-00 Rev. A Page 0-1

CPI Canada Inc.
Page 0-2 CMP 200 ® X-Ray Generator Service Manual Ch # 901476-00 Rev. A
PROPRIETARY AND CONFIDENTIAL
The design and information contained in this document is proprietary to Communications & Power Industries Canada
Inc. (CPI), has been designed and developed at private expense, and is the exclusive property of CPI. The information
contained herein is loaned in confidence solely for the installation, operation, and maintenance of CPI equipment. This
document may not be duplicated in whole or in part, or be used for re-engineering, reverse engineering, or otherwise
reproducing in any form or creating or attempting to create or permitting, allowing or assisting others to create or
manufacture CPI’s product or products derived therefrom, without the express written permission of CPI.
Copyright © 2007 by Communications & Power Industries Canada Inc. All rights reserved.

CPI Canada Inc. Pre-installation 1
Use and disclosure is subject to the restrictions on the title page of this CPI document.
CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C Page 1-1
CHAPTER 1
PRE-INSTALLATION
CONTENTS:
Section Title
1.1.0 INTRODUCTION......................................................................................................................................1-2
1.1.1 Generator Description...........................................................................................................................1-2
1.1.2 Features................................................................................................................................................1-2
1.1.3 Radiographic Performance...................................................................................................................1-3
1.1.4 Environmental Specifications................................................................................................................1-3
1.1.5 Applicable Standards............................................................................................................................1-4
1.1.6 Electromagnetic Compatibility (EMC)...................................................................................................1-8
1.1.7 RoHS Compliance ................................................................................................................................1-8
1.2.0 SAFETY....................................................................................................................................................1-9
1.2.1 Safety and Warning Symbols................................................................................................................1-9
1.2.2 Safety Notices and Warnings ...............................................................................................................1-9
1.2.3 Safety Warning Labels........................................................................................................................1-12
1.3.0 PREPARING FOR INSTALLATION.......................................................................................................1-16
1.3.1 Generator Heat Output .......................................................................................................................1-16
1.3.2 Generator Power Requirements.........................................................................................................1-16
1.3.3 Generator Ground Requirements.......................................................................................................1-20
1.3.4 Locating and Mounting the Generator................................................................................................1-21
1.3.5 Cable Entrance and Seismic Center Location....................................................................................1-22
1.3.6 Tools and test Equipment Required ...................................................................................................1-23
1.3.7 Pre-Installation Checklist ....................................................................................................................1-24
1.4.0 GENERATOR LAYOUT AND MAJOR COMPONENTS........................................................................1-24
1.5.0 COMPATIBILITY LISTING.....................................................................................................................1-27
1.6.0 RUNTIME LICENSE AGREEMENT (TOUCHSCREEN CONSOLE).....................................................1-28
1.7.0 CUSTOMER SUPPORT.........................................................................................................................1-29
1.8.0 COMPATIBILITY STATEMENT .............................................................................................................1-29

1 Pre-installation CPI Canada Inc.
Use and disclosure is subject to the restrictions on the title page of this CPI document.
Page 1-2 CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C
1.1.0 INTRODUCTION
This chapter summarizes the main features of the CMP 200®and CMP 200®DR X-ray generators
(performance, regulatory and compatibility). Safety information is provided, along with environmental,
room, and installation requirements. This chapter concludes with a pre-installation checklist and a
diagram showing the major component layout.
The information in this chapter is provided in order for the installer to be able to plan the site
layout prior to installation of the generator.
1.1.1 Generator Description
The CMP 200®X-ray generator is intended for use in film-based stationary radiographic X-ray systems,
including tomography. The CMP 200®DR X-ray generator adds a digital interface for digital radiography
(DR) equipment. The CMP 200®X-ray generator consists of a main power cabinet and an optional
membrane control console. The CMP 200®DR X-ray generator consists of a main power cabinet and an
optional membrane, touchscreen or mini-console (used with digital interface). The main power cabinet
contains the HT tank and control circuits, the filament drivers, a low speed starter (optional dual speed
starter on some models of CMP 200®DR), and interface connections to the room equipment.
The control console allows the operator to select the technique factors, image receptors, etc.,
and to initiate an X-ray exposure.
1.1.2 Features
The following are the main features of and the options available for the generator:
• Integral low speed starter, compatible with X-ray tubes with type “R” stator. Optional compatibility with
GE 23/23 Ωequal impedance “E” stator.
• Optional dual-speed starter on some models of CMP 200®DR (not available on 208 / 230 VAC, 1-
phase & 3-phase units), compatible with tube types listed in chapter 2.
• Capable of interfacing with various DR imaging systems (CMP 200®DR only).
• 24 VDC, 110, or 220 VAC power source for Buckys.
• 24 VAC 150 watts power source for collimator lamp.
• 24 VDC 45 watts power source for system locks.
• Optional AEC.
• Optional DAP (Dose-Area Product).

CPI Canada Inc. Pre-installation 1
Use and disclosure is subject to the restrictions on the title page of this CPI document.
CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C Page 1-3
1.1.3 Radiographic Performance
kVp range: 40 to 125 kV or 40 to 150 kV,
depending on model.
kVp steps: variable in 1 kV steps.
kVp accuracy: ±5 % + 1 kV.
Risetime (10-90%): <1.5 ms.
Time range: 1.0 to 6300 milliseconds.
mAs range 0.1 to 500 mAs (32/40 kW)
0.1 to 630 mAs (50 kW)
0.1 to 800 mAs (65 kW).
0.1 to 1000 mAs (80 kW)
mAs accuracy: ± (10 % + 0.2) mAs.
mA range 10 to 400 mA (32 kW)
10 to 500 mA (40 kW)
10 to 630 mA (50 kW)
10 to 800 mA (65 kW)
10 to 1000 mA (80 kW)
Coefficient of linearity: 0.05 (station to station) mAs.
Coefficient of reproducibility: kV, mAs ≤0.05.
1.1.4 Environmental Specifications
OPERATING
Ambient temperature range 10 to 40 °C (50 to 104 °F).
Relative humidity 20 to 80%, non-condensing.
Altitude -700 to 3000 meters (1100 to 700 hPa, 825 to 525 mm Hg).
TRANSPORT AND STORAGE
Ambient temperature range -25 to 70 °C (-13 to 158 °F)..
Relative humidity 5 to 95%, non-condensing.
Atmospheric pressure range -700 to 3000 meters (1100 to 700 hPa, 825 to 525 mm Hg).
• Long-term storage over 40 °C will reduce the service life of electrolytic capacitors in the
generator.
• The membrane control console is limited to a minimum temperature of -20°C, with a
maximum duration of 48 hours at that temperature. Transport and storage is limited to a
maximum duration of 120 hours between 50 and 70 °C, with an absolute humidity not to
exceed the humidity of 85% RH at 50 °C.
• Touchscreen console temperatures below -20°C and above +50°C are limited to 10 days
maximum duration, with a humidity not exceeding 50 % RH.

1 Pre-installation CPI Canada Inc.
Use and disclosure is subject to the restrictions on the title page of this CPI document.
Page 1-4 CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C
1.1.5 Applicable Standards
The CMP 200®/ CMP 200®DR series of X-ray generators comply with the regulatory requirements and
design standards in this section as follows:
• VZW2555 series: Only the standards marked with an asterisk *under SAFETY.
• VZW2556 series: All standards in this section.
A) SAFETY
• *FDA Center for Devices & Radiological Health (CDRH) - 21 CFR title 21 subchapter J (USA).
• *Radiation Emitting Devices Act - C34 (Canada).
• Medical Device Regulations (Canada).
• EC Directive 93/42/EEC concerning Medical Devices (European Community).
• *EN 60601-1/IEC 60601-1, EN 60601-2-7/IEC 60601-2-7, CSA 601.1, UL60601.1.
-Type of protection against electric shock: Class I equipment.
-Degree of protection against electric shock: Not classified.
-Degree of protection against harmful ingress of water: Ordinary equipment.
-Mode of operation: Continuous operation with intermittent loading (standby - exposure).
-Equipment not suitable for use in presence of a flammable anesthetic mixture with air or
with oxygen or nitrous oxide.
• EN 60601-1-4/IEC 60601-1-4, EN ISO 14971, EN 60601-1-6/IEC 60601-1-6 **.
** This standard applies only to X-ray generators with a CPI-supplied operator’s console. It does not
apply to “smart power supplies” in which the OEM or integrator supplies the operator’s console.
NOTE: All referenced standards are considered to be at the latest adopted revision.
The CE Mark is a declaration by the manufacturer that the product complies with
the requirements of the applicable European Union (EU) medical device directive
and that the product has been subject to conformity assessment procedures as
provided in that directive.
A CSA mark with the indicators “C” and “US” means that product is certified for
both the U.S. and Canadian markets, to the applicable U.S. and Canadian
standards.

CPI Canada Inc. Pre-installation 1
Use and disclosure is subject to the restrictions on the title page of this CPI document.
CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C Page 1-5
B) EMC (EN 60601-1-2:2001/IEC 60601-1-2:2001)
Guidance and manufacturer’s declaration – electromagnetic emissions
The VZW2556 series of X-ray generators is intended for use in the electromagnetic environment specified
below. The customer or the user of the VZW2556 series should assure that it is used in such an environment.
Emissions test Compliance Electromagnetic environment - guidance
RF emissions
CISPR 11 Group 1 The VZW2556 series of X-ray generators use RF energy only for
their internal functions. Therefore, the RF emissions are very low
and are not likely to cause any interference in nearby electronic
equipment.
RF emissions
CISPR 11 Class A
(The VZW2556
series of X-ray
generators in
combination with
shielded location)
Harmonic
emissions
IEC 61000-3-2
Not Applicable
Voltage
fluctuations/
flicker emissions
IEC 61000-3-3
Not Applicable
The VZW2556 series of X-ray generators must be used only in a
shielded location with a minimum RF shielding effectiveness and,
for each cable that exits the shielded location, a minimum RF filter
attenuation of 40dB from 30 MHz to 230 MHz and 47dB from 230
MHz to 1 GHz. (The minimum at 30 MHz is 40dB and the
minimum at 230 MHz is 47dB).
The VZW2556 series is suitable for use in all establishments other
than domestic and those directly connected to the public low-
voltage power supply network that supplies buildings used for
domestic purposes.
NOTE It is essential that the actual shielding effectiveness and filter attenuation of the shielded location be
verified to assure that they meet the minimum specifications.

1 Pre-installation CPI Canada Inc.
Use and disclosure is subject to the restrictions on the title page of this CPI document.
Page 1-6 CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C
1.1.5 Applicable Standards (Cont)
Guidance and manufacturer’s declaration – electromagnetic immunity
The VZW2556 series of X-ray generators is intended for use in the electromagnetic environment specified
below. The customer or the user of the VZW2556 series should assure that it is used in such an environment.
Immunity
test IEC 60601 test level Compliance level Electromagnetic environment – guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air ±6 kV contact ±8 kV air Floors should be wood, concrete or ceramic tile.
If floors are covered with synthetic material, the
relative humidity should be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for power
supply lines
±1 kV for
input/output lines
±2 kV for power
supply lines
±1 kV for
input/output lines
Mains power quality should be that of a typical
commercial or hospital environment.
Surge
IEC 61000-4-5 ±1 kV differential
mode
±2 kV common
mode
±1 kV differential
mode
±2 kV common
mode
Mains power quality should be that of a typical
commercial or hospital environment.
Voltage dips,
short interruption,
and voltage
variations on
power supply
input lines
IEC 61000-4-11
< 5 % UT
(> 95 % dip in UT)
for 0.5 cycle
40 % UT
(60 % dip in UT)
for 5 cycles
70 % UT
(30 % dip in UT)
< 5 % UT
(> 95 % dip in UT)
for 5 s
< 5 % UT
(> 95 % dip in UT)
for 0.5 cycle
40 % UT
(60 % dip in UT)
for 5 cycles
70 % UT
(30 % dip in UT)
< 5 % UT
(> 95 % dip in UT)
for 5 s
Mains power quality should be that of a typical
commercial or hospital environment. If the user
of the VZW2556 series X-ray generator requires
continued operation during power mains
interruptions, it is recommended that the X-ray
generator be powered from an uninterruptible
power supply or battery.
Power frequency
(50/60 Hz)
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic fields should be at
levels characteristic of a typical location in a
typical commercial or hospital environment
NOTE: UTis the A.C. mains voltage prior to application of the test level.

CPI Canada Inc. Pre-installation 1
Use and disclosure is subject to the restrictions on the title page of this CPI document.
CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C Page 1-7
1.1.5 Applicable Standards (Cont)
Guidance and manufacturer’s declaration – electromagnetic immunity
The VZW2556 series of X-ray generators is intended for use in the electromagnetic environment specified
below. The customer or the user of the VZW2556 series should assure that it is used in such an environment.
Immunity
test IEC 60601 test level Compliance level Electromagnetic environment - guidance
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to
80MHz
3 Vrms
150 kHz to
80MHz
The VZW2556 series of X-ray generators must be
used only in a shielded location with a minimum RF
shielding effectiveness and, for each cable that
enters the shielded location, a minimum RF filter
attenuation of 40dB from 30 MHz to 230 MHz and
47dB from 230 MHz to 1 GHz. (The minimum at 30
MHz is 40dB and the minimum at 230 MHz is
47dB.)
Radiated RF
IEC 61000-4-3 3 V/m 80MHz to 2.5
GHz
3 V/m
80MHz to 2.5
GHz
Field strengths outside the shielded location from
fixed RF transmitters, as determined by an
electromagnetic site survey, should be less than 3
V/m.a
Interference may occur in the vicinity of equipment
marked with the following symbol:
NOTE 1 These guidelines may not apply all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
NOTE 2 It is essential that the actual shielding effectiveness and filter attenuation of the shielded location be
verified to assure that they meet the minimum specification.
aField strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and
land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an
electromagnetic site survey should be considered. If the measured field strength in the location in which the
VZW2556 series of X-ray generators is used exceeds the applicable RF compliance level above, the X-ray
generator should be observed to verify normal operation. If abnormal performance is observed, additional
measures may be necessary, such as re-orienting or relocating the X-ray generator.

1 Pre-installation CPI Canada Inc.
Use and disclosure is subject to the restrictions on the title page of this CPI document.
Page 1-8 CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C
1.1.6 Electromagnetic Compatibility (EMC)
In accordance with the intended use, some models of this series of X-ray generators comply with the
European Council Directive concerning Medical Devices. The CE marking affixed to compliant products
signifies this. One of the harmonized standards of this Directive defines the permitted levels of
electromagnetic emission from this equipment and its required immunity from the electromagnetic
emissions of other devices.
It is not possible, however, to exclude with absolute certainty the possibility that other high frequency
electronic equipment, which is fully compliant to the EMC regulations, will not adversely affect the
operation of this generator. If the other equipment has a comparatively high level of transmission power
and is in close proximity to the generator, these EMC concerns (the risk of interference) may be more
pronounced. It is therefore recommended that the operation of equipment of this type such as mobile
telephones, cordless microphones and other similar mobile radio equipment be restricted from the vicinity
of this X-ray generator.
1.1.7 RoHS Compliance
CMP 200®/ CMP 200®DR
产品中有毒有害物质或元素的名称及含量
Table of hazardous substances’ name and concentration.
有毒有害物质或元素
Hazardous substances’ name
部件名称
Component Name
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
Generator X O O X O O
Console X O O X O O
O: 表示该有毒有害物质在该部件所有均质材料中的含量均在SJ/T11363-2006 标准规定的限量要求以下
X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出SJ/T11363-2006 标准规定的限量要求
• 此表所列数据为发布时所能获得的最佳信息
• 由于缺少经济上或技术上合理可行的替代物质或方案，此医疗设备运用以上一些有毒有害物质来实
现设备的预期临床功能，或给人员或环境提供更好的保护效果。
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for
this part is below the limit requirement in SJ/T11363-2006.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous
materials used for this part is above the limit requirement in SJ/T11363-2006.
• Data listed in the table represents best information available at the time of publication
• Applications of hazardous substances in this medical device are required to achieve its intended
clinical uses, and/or to provide better protection to human beings and/or to environment, due to
lack of reasonably (economically or technically) available substitutes.

CPI Canada Inc. Pre-installation 1
Use and disclosure is subject to the restrictions on the title page of this CPI document.
CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C Page 1-9
1.2.0 SAFETY
1.2.1 Safety and Warning Symbols
The following advisory symbols are used on the safety warning labels, and/or on circuit boards, and/or on
the operator console.
High voltage symbol used to indicate the presence of
high voltage.
Warning symbol used to indicate a potential hazard
to operators, service personnel or to the equipment.
It indicates a requirement to refer to the
accompanying documentation for details.
Radiation exposure symbol used on operator
console. Lights to indicate that an exposure is in
progress. This is accompanied by an audible tone
from the console.
WARNING THIS X-RAY UNIT MAY BE
DANGEROUS TO PATIENT
AND OPERATOR UNLESS
SAFE EXPOSURE
FACTORS, OPERATING
INSTRUCTIONS AND
MAINTENANCE SCHEDULES
ARE OBSERVED.
Radiation warning label on operator console.
Never allow unqualified personnel to operate the X-
ray generator.
1.2.2 Safety Notices and Warnings
WARNING: THIS X-RAY UNIT MAY BE DANGEROUS TO PATIENT AND OPERATOR UNLESS
SAFE EXPOSURE FACTORS, OPERATING INSTRUCTIONS AND MAINTENANCE
SCHEDULES ARE OBSERVED.
WARNING: PROPER USE AND SAFE OPERATING PRACTICES WITH RESPECT TO X-RAY
GENERATORS ARE THE RESPONSIBILITY OF USERS OF SUCH GENERATORS.
CPI CANADA INC. (“THE MANUFACTURER”) PROVIDES INFORMATION ON ITS
PRODUCTS AND ASSOCIATED HAZARDS, BUT ASSUMES NO RESPONSIBILITIES
FOR AFTER-SALE OPERATING AND SAFETY PRACTICES.
THE MANUFACTURER ACCEPTS NO RESPONSIBILITY FOR ANY GENERATOR
NOT MAINTAINED OR SERVICED ACCORDING TO THIS SERVICE AND
INSTALLATION MANUAL, OR FOR ANY GENERATOR THAT HAS BEEN MODIFIED
IN ANY WAY.
THE MANUFACTURER ALSO ASSUMES NO RESPONSIBILITY FOR X-RAY
RADIATION OVEREXPOSURE OF PATIENTS OR PERSONNEL RESULTING FROM
POOR OPERATING TECHNIQUES OR PROCEDURES.

1 Pre-installation CPI Canada Inc.
Use and disclosure is subject to the restrictions on the title page of this CPI document.
Page 1-10 CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C
1.2.2 Safety Notices and Warnings (Cont)
X-ray radiation exposure may be damaging to health, with some effects being cumulative and extending
over periods of many months or even years. Operators and service personnel should avoid any
exposure to the primary beam and take protective measures to safeguard against scatter radiation.
Scatter radiation is caused by any object in the path of the primary beam and may be of equal or less
intensity than the primary beam that exposes the film.
No practical design can incorporate complete protection for operators or service personnel who do not
take adequate safety precautions. Only authorized and properly trained service and operating
personnel should be allowed to work with this X-ray generator equipment. The appropriate
personnel must be made aware of the inherent dangers associated with the servicing of high voltage
equipment and the danger of excessive exposure to X-ray radiation during system operation.
DO NOT CONNECT UNAPPROVED EQUIPMENT TO THE REAR OF THE
CONSOLE.
For the membrane console, J3 is for connection of an external hand switch, J4 is a
serial port for use by an external computer, and J8 is for the interconnect cable to the
main cabinet.
For the touchscreen console, GEN on the rear of the touchscreen is for the
interconnect cable to the generator, HS is for connection of an external hand switch,
COM 1 & COM 2 are serial ports for use by external devices, LO (3.5 mm stereo jack)
is for customer supplied speakers (minimum 8 ohms, do not use externally amplified
speakers), ETH is a standard 10/100 Ethernet connection, USBA and USBB are USB
ports for connection of external devices, CF is for the compact flash memory card
which holds the touchscreen software, and SW1 is the console upgrade button.
INCORRECT CONNECTIONS OR USE OF UNAPPROVED EQUIPMENT MAY
RESULT IN INJURY OR EQUIPMENT DAMAGE.
CAUTION: DO NOT EXCEED THE TUBE MAXIMUM OPERATING LIMITS. INTENDED LIFE AND
RELIABILITY WILL NOT BE OBTAINED UNLESS GENERATORS ARE OPERATED
WITHIN PUBLISHED SPECIFICATIONS.

CPI Canada Inc. Pre-installation 1
Use and disclosure is subject to the restrictions on the title page of this CPI document.
CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C Page 1-11
1.2.2 Safety Notices and Warnings (Cont)
WARNING: HAZARDOUS VOLTAGES EXIST INSIDE THE GENERATOR WHENEVER THE MAIN
POWER DISCONNECT IS SWITCHED ON. THESE AREAS INCLUDE, BUT ARE NOT
LIMITED TO, THE MAIN FUSE HOLDER AND ASSOCIATED CIRCUITS ON THE H.V.
AUXILIARY BOARD, THE AUXILIARY TRANSFORMER, AND THE MAIN POWER
CONTACTOR.
LED DS1 ON THE H.V. AUXILIARY BOARD INDICATES THE PRESENCE OF THE
+24 VDC SUPPLY.
THE CONSOLE ON/OFF SWITCH DOES NOT DISCONNECT THE MAIN POWER
FROM THE ABOVE AREAS INSIDE THE GENERATOR.
THE DC BUS CAPACITORS, LOCATED IN THE MAIN CABINET PRESENT A
SAFETY HAZARD FOR AT LEAST 5 MINUTES AFTER THE POWER HAS BEEN
REMOVED FROM THE UNIT. CHECK THAT THESE CAPACITORS ARE
DISCHARGED BEFORE SERVICING THE GENERATOR.
AN LED CONNECTED ACROSS THE DC BUS INDICATES THE PRESENCE OF HIGH
VOLTAGE. THIS LED IS MOUNTED ON THE EMC CAPACITOR BOARD (ON SOME
MODELS, THE EMC CAPACITOR BOARD DOES NOT CONTAIN ANY
COMPONENTS OTHER THAN THE LED AND THE SERIES RESISTORS).
DO NOT RELY SOLELY ON BLEEDER CIRCUITS AND HIGH-VOLTAGE ON
INDICATORS IN THE GENERATOR TO PROTECT YOU. DUE TO THE
POSSIBILITY OF COMPONENT FAILURE, IT MUST NEVER BE ASSUMED
THAT AN UNLIT LED ENSURES THAT NO HIGH VOLTAGE IS PRESENT.
USING A VOLTMETER, CONFIRM THAT NO HIGH VOLTAGE IS PRESENT
BEFORE ATTEMPTING ANY SERVICE.
The following notes apply to the touchscreen console only.
WARNING: THE TOUCHSCREEN CONSOLE HAS NO USER SERVICEABLE PARTS. DO NOT
ATTEMPT TO OPEN THE TOUCHSCREEN CONSOLE.
NOTE: WHEN ATTACHING THE BASE TO THE TOUCHSCREEN CONSOLE, ENSURE THAT
THE TOUCHSCREEN IS RESTING ON A FLAT, CLEAN SURFACE WITH A PIECE OF
NON-ABRASIVE MATERIAL BETWEEN THE TOUCHSCREEN AND THE SURFACE.
NOTE: TO AVOID ACCIDENTAL CONTACT WITH ENERGIZED CIRCUITRY INSIDE THE
TOUCHSCREEN CONSOLE, THE MAXIMUM BACK-PLATE SCREW LENGTH MUST BE
LIMITED TO 25 mm (1 INCH).
NOTE: FOR WALL MOUNTED TOUCHSCREEN CONSOLES, ENSURE THAT THE BASE IS
SECURED PROPERLY TO A WALL STUD.
WARNING: PLEASE ENSURE THERE IS SUFFICIENT AREA AROUND THE VENTING SLOTS
OF THE TOUCHSCREEN CONSOLE TO ALLOW PROPER COOLING OF THE
INTERNAL COMPONENTS.

1 Pre-installation CPI Canada Inc.
Use and disclosure is subject to the restrictions on the title page of this CPI document.
Page 1-12 CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C
1.2.2 Safety Notices and Warnings (Cont)
NOTE: THE SET SCREW COLLAR MUST BE POSITIONED ON THE UPPER HALF OF THE
TILT ARM TO PREVENT PERSONAL INJURY SHOULD THE TOUCHSCREEN SLIP
WHILE ADJUSTING THE VIEWING HEIGHT.
USE THE PROVIDED ALLEN KEY TO ENSURE THAT THE SET SCREW COLLAR IS
LOCKED INTO POSITION SUCH THAT THERE IS NO LESS THAN 25 mm (1 INCH)
OF CLEARANCE BETWEEN THE BOTTOM EDGE OF THE TOUCHSCREEN
CONSOLE AND THE TOUCHSCREEN BASE PLATE WHEN THE TOUCHSCREEN IS
ADJUSTED TO ITS MINIMUM HEIGHT.
PLEASE BE SURE TO SUPPORT THE TOUCHSCREEN CONSOLE WHEN
ADJUSTING ITS VIEWING POSITION.
1.2.3 Safety Warning Labels
This subsection defines the safety labels used inside and outside the generator cabinet.
NOTE: THESE LABELS AND WARNINGS ARE PROVIDED TO ALERT SERVICE
PERSONNEL THAT SERIOUS INJURY WILL RESULT IF THE HAZARD IDENTIFIED
IS IGNORED.
WARNING: SWITCH OFF THE MAIN POWER DISCONNECT AND ALLOW SUFFICIENT TIME
FOR ALL CAPACITORS TO DISCHARGE BEFORE REMOVING ANY COVERS.
WARNING: IF ANY COVERS MUST BE REMOVED FOR SERVICE, TAKE ALL REQUIRED
PRECAUTIONS WITH RESPECT TO THE HAZARD(S) AND IMMEDIATELY
REPLACE THE COVERS WHEN THE NEED FOR REMOVAL IS COMPLETED.
This information is provided to help you establish safe operating conditions for both you and your X-ray
generator. Do not operate this X-ray generator except in accordance with these instructions, and any
additional information provided by the X-ray generator manufacturer and / or competent safety
authorities.
Weight Label
This label is attached to the main generator cabinet and to the HT tank, and states the approximate
weight of the main cabinet with the HT tank, and the weight of the HT tank separately. Do not attempt to
lift these items without proper assistance.

CPI Canada Inc. Pre-installation 1
Use and disclosure is subject to the restrictions on the title page of this CPI document.
CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C Page 1-13
1.2.3 Safety Warning Labels (Cont)
Caution HV/High Energy Warning Label
This label is attached to the generator cabinet and on the inside of the back cover above the HT tank.
The DC bus capacitors (approximately 300 to 670 VDC, depending on model) will remain charged for up
to 5 minutes after the AC mains is disconnected or the console is switched off.
Caution HV Behind Cover Label
This label is attached to the outside of the generator cabinet, the cover over the inverter assembly, the
cover over the DSS board and the fan cover. Mains voltage is present inside the cabinet whenever the
main disconnect is switched on. Additionally, the DC bus capacitors will remain charged for up to 5
minutes after the AC mains is disconnected or the console is switched off.
WARNING: WAIT A MINIMUM OF 5 MINUTES AFTER THE INPUT MAINS POWER HAS BEEN
REMOVED BEFORE REMOVING ANY COVERS. ONCE THE COVER(S) ARE
REMOVED. CHECK THAT THE VOLTAGE ACROSS THE DC BUS CAPACITORS IS
NEAR ZERO BEFORE SERVICING. IF THIS VOLTAGE EXCEEDS 48 VDC, THE
CAPACITORS MUST BE MANUALLY DISCHARGED BY QUALIFIED SERVICE
PERSONNEL.

1 Pre-installation CPI Canada Inc.
Use and disclosure is subject to the restrictions on the title page of this CPI document.
Page 1-14 CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C
1.2.3 Safety Warning Labels (Cont)
HT Tank - Transformer Terminals Notice
This notice is printed on the HT tank lid and cautions against over-tightening the nuts on the transformer
feedthrough terminals (for the primary of the HT transformers).
Danger High Tension Notice
This notice is printed on the HT tank lid. High voltage may be present at the primary terminals on the tank
lid board, at the output high voltage connectors, and at the mA/mAs measuring jacks if the shorting link is
opened for mA/mAs measurements.
Auxiliary Transformer Labels
These labels are fixed on the outer face of the auxiliary transformer and indicate the presence of high
voltage taps on the primary of 120, 200, 240, 400 and 480 VAC. Ensure the main power disconnect is
switched off and appropriate documentation is consulted before attempting to service this component.
HIGH VOLTAGE HAZARD: Be certain that you are aware of all potential high voltage
locations and hazards as detailed in this section before removing any covers, or attempting
any service on this X-ray generator.

CPI Canada Inc. Pre-installation 1
Use and disclosure is subject to the restrictions on the title page of this CPI document.
CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C Page 1-15
1.2.3 Safety Warning Labels (Cont)
FUSE RATINGS:
LOCATION 1 PHASE UNITS 3 PHASE UNITS
MAIN LINE FUSES: F1, F2: FRN-R-50 * F1, F2, F3: AG40 * for
(32/40 kW 400/480 V
units).
SC60 * for 32/40 kW
208-230 V 3 phase
units).
OTN60 *for 50 kW
208/230 V units.
SC60 * for 50 kW
400/480 and all 65 kW
units.
OTS60 * for 80 kW units.
GENERATOR CONTROL BOARD: F2: GDC-2 * F2: GDC-2 *
F3: GDC-500mA * F3: GDC-500mA *
CONSOLE BOARD: F1: GDC-1A * F1: GDC-1A *
ALL 208/230 V UNITS ALL 400/480 V UNITS
H.V. AUXILIARY BOARD: F1, F6, F7: S506-8A * F1, F6, F7: S506-8A *
F2, F3: GDC-5A * F2, F3: GDC-5A *
F4, F5, F11: GDC-6.3A * F4, F5: FNQ-1 *
F8, F9, F12: GDC-2A * F8, F9: FNQ 2 *
F10: GDC-1A * F10: GDC-1A *
F11: GDC-6.3A *
F12: GDC-2A *
DUAL SPEED STARTER BOARD N/A F1, F2: A70QS10-14F *
*Refer to chapter 8, spares list, for CPI part number for these fuses.
HIGH VOLTAGE HAZARD: Approximately 400 VAC is present on the membrane console
board in the area of T1, C36, and J5. This is a high voltage source for the fluorescent
backlight on the LCD display.
HIGH VOLTAGE HAZARD: AC mains voltage and / or DC bus voltage (approximately 325 to
670 VDC, depending on model) is present on the H.V. auxiliary board whenever the AC mains
is energized. Ensure that the AC mains is switched off and locked out before servicing this
board. See the note below regarding the DC bus voltage.
HIGH VOLTAGE HAZARD: High voltage is present on all components connected to the AC
mains (line fuses, auxiliary transformer, H.V. auxiliary board, main power contactor, etc)
whenever the AC mains is switched on. Additionally, DC bus voltage is present on certain
components (mains rectifier assembly, DC bus capacitors, inverter assembly, HT tank, H.V.
auxiliary board, etc) whenever the generator is switched on, and will remain on for up to 5
minutes after the console is switched off or the AC mains is switched off or disconnected.
HIGH VOLTAGE HAZARD: Approximately 600 VDC is present on the dual speed starter
board whenever the generator is switched on. This voltage is sourced from the DC bus
capacitors in the generator, and therefore the high voltage hazard will remain for up to 5
minutes after the generator has been switched off.

1 Pre-installation CPI Canada Inc.
Use and disclosure is subject to the restrictions on the title page of this CPI document.
Page 1-16 CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C
1.2.3 Safety Warning Labels (Cont)
DANGEROUS
VOLTAGE
High voltage (approximately 325 to 670 VDC, depending on model) is present on the inverter
assembly and associated components whenever the AC mains is energized and the console
is switched on, and for up to 5 minutes after the console is switched off or the AC mains is
disconnected. THIS COMBINATION OF HIGH VOLTAGE AND HIGH CURRENT IS
POTENTIALLY LETHAL. USE EXTREME CAUTION WHEN SERVICING THIS UNIT.
1.3.0 PREPARING FOR INSTALLATION
1.3.1 Generator Heat Output
The maximum heat output of the main generator cabinet is less than 1000 BTU / hour in normal clinical
use, with a maximum of 70 BTU / hour heat output for the console. The console is convection-cooled, and
the main cabinet is fan cooled. The console and main cabinet should never be covered when the
generator is switched on, as any covering may interfere with the cooling.
1.3.2 Generator Power Requirements
The tables in this section show mains power requirements for various configurations of CMP 200®and
CMP 200®DR X-ray generators. The installer must ensure that the generator is connected to the proper
mains voltage as per the nameplate on the generator.
The table below depicts the power requirements for the 32 kW CMP 200®/ CMP 200®DR X-ray
generators.
Line Voltage 208 VAC - 5% to 230 VAC + 10%, 1 phase.
208 VAC - 5% to 230 VAC + 10%, 3 phase.
400 VAC ±10%, 3 phase.
480 VAC ±10%, 3 phase.
Line Frequency 50/60 Hz.
Momentary Current 200 Amps at 230 VAC (1 phase).
110 Amps/phase at 230 VAC (3 phase).
65 Amps/phase at 400 VAC.
55 Amps/phase at 480 VAC.
Nominal Current *≤5 Amps.
Momentary Power Consumption 45 kVA.

CPI Canada Inc. Pre-installation 1
Use and disclosure is subject to the restrictions on the title page of this CPI document.
CMP 200 ® X-Ray Generator Service Manual Ch # 901476-01 Rev. C Page 1-17
1.3.2 Generator Power Requirements (Cont)
The table below depicts the power requirements for the 40 kW CMP 200®/ CMP 200®DR X-ray
generators.
Line Voltage 208 VAC - 5% to 230 VAC + 10%, 1 phase.
208 VAC - 5% to 230 VAC + 10%, 3 phase.
400 VAC ±10%, 3 phase.
480 VAC ±10%, 3 phase.
Line Frequency 50/60 Hz.
Momentary Current 250 Amps at 230 VAC (1 phase).
135 Amps/phase at 230 VAC (3 phase).
80 Amps/phase at 400 VAC.
65 Amps/phase at 480 VAC.
Nominal Current *≤5 Amps.
Momentary Power Consumption 55 kVA.
The table below depicts the power requirements for the 50 kW CMP 200®/ CMP 200®DR X-ray
generators.
Line Voltage 208 VAC - 5% to 230 VAC + 10%, 3 phase.
400 VAC ±10%, 3 phase.
480 VAC ±10%, 3 phase.
Line Frequency 50/60 Hz.
Momentary Current 145 Amps/phase at 230 VAC.
100 Amps/phase at 400 VAC.
80 Amps/phase at 480 VAC.
Nominal Current *≤5 Amps.
Momentary Power Consumption 65 kVA.
The table below depicts the power requirements for the 65 kW CMP 200®DR X-ray generators.
Line Voltage 400 VAC ±10%, 3 phase.
480 VAC ±10%, 3 phase.
Line Frequency 50/60 Hz.
Momentary Current 125 Amps/phase at 400 VAC.
105 Amps/phase at 480 VAC.
Nominal Current *≤5 Amps.
Momentary Power Consumption 85 kVA.
