CPI INDICO 100 Series User manual

CPI INDICO 100 SERIES
X-RAY GENERATOR
+
+
+
+
IIIIII
Indico 100
+
+
+
OPERATOR’S MANUAL
PREPARED BY:
COMMUNICATIONS & POWER INDUSTRIES CANADA INC.
45 RIVER DRIVE
GEORGETOWN, ONTARIO, CANADA L7G 2J4
TELEPHONE: [phone]
OPERATOR’S MANUAL P/N 740953-00

(This page intentionally left blank)

CPI Canada Inc
Indico 100 Series Operator Manual 740953-00 Rev. A Page 3
INTRODUCTION
1¾
INDICO 100
OPERATOR
SAFETY AND SPECIFICATIONS
2¾
MANUAL
CONSOLE CONTROLS
3¾
P.N. #740953
REMOTE FLUORO CONTROLLER
4¾
PROGRAMMING THE CONSOLE
5¾
ERROR CODES AND MESSAGES
6¾
GENERATOR EXPOSURE TABLES
7¾
MAINTENANCE SCHEDULE
8¾
X-RAY TUBE DATA
9¾
The original version of this manual (15 September 2000)
has been drafted in the English language by:
Communications & Power Industries
communications & medical products division.

CPI Canada Inc
Page 4 Rev. A Indico 100 Series Operator Manual 740953-00
(This page intentionally left blank)

CPI Canada Inc
Indico 100 Series Operator Manual 740953-00 Rev. A Page 5
INTRODUCTION 1
Congratulations!
You have acquired the CPI Indico 100 series high frequency X-ray generator. This generator features
state-of-the-art computer-based control to ensure minimum patient dose, excellent repeatability, and
superior contrast. The operator control functions are designed to be simple and user-friendly.
The AEC (Automatic Exposure Control) and APR (Anatomical Programming) features give you controlled
exposure factors, automatically optimized for the radiological study selected.
INDICO 100 MAIN FEATURES
• Models available in maximum output power of 30 to 80 kW, in both radiographic and fluoroscopic models.
• Full 150 kV capability for all models.
• Smaller, lighter modular design.
• Constant dose output due to kVp and mA regulation during exposures.
• User-friendly controls.
• Large LCD panel display for APR and utility routines.
• User-friendly system configuration.
• APR techniques may be modified by the operator.
• ms and mAs limits for AEC may be operator set.
• Provisions for APR / tube downloading.
• Extensive self-diagnostics with operator prompt messages.
• Serial RS232 communications interface.
• May be programmed for APR operation only or both APR and manual technique selection.
• Time and mA / mAs selections are to IEC standards.
• Programmable setup, calibration and APR routines (using an external computer).
• Choice of six fluoro kV to rad kV transfer curves (R & F units only).
• Choice of four kV vs mA curves for ABS (automatic brightness stabilization) circuits (R & F units only).
OPTIONS
• Dual speed starter for automatic high / low speed selection.
• Two-tube capability.
• Pedestal mount for operator control console.
• Automatic Brightness Stabilization (ABS) for consistent imaging (AUTO kV / mA or kV only).
• Remote fluoro controller for R & F table side operation.
• Digital imaging interface.
• Trauma control console.
• Remote exposure hand switch.
• High level fluoro for therapy simulators.
SAFETY NOTICE: This manual contains important operating and safety information. An understanding
of this information is critical to the safe operation and long term reliability of your
equipment. Please ensure that you read the warning notices before using this
equipment.

1Introduction CPI Canada Inc
Page 6 Rev. A Indico 100 Series Operator Manual 740953-00
(This page intentionally left blank)

CPI Canada Inc
Indico 100 Series Operator Manual 740953-00 Rev. A Page 7
S
SS
SA
AA
AF
FF
FET
ETET
ETY
YY
Y AN
ANAN
AND SPE
D SPED SPE
D SPEC
CC
CIF
IFIF
IFI
II
ICA
CACA
CAT
TT
TI
II
ION
ONON
ONS
SS
S 2
22
2
Keep this operator’s manual with the equipment at all times, and periodically review the operating and safety
instructions.
SAFETY / WARNING SYMBOLS
Warning symbol used to indicate a potential hazard
to operators, service personnel or to the equipment.
It indicates a requirement to refer to the
accompanying documentation for details.
Radiation exposure symbol used on operator
console. Lights to indicate that an exposure is in
progress. This is accompanied by an audible tone
from the console.
Fluoro radiation exposure symbol used on operator
console and on optional remote fluoro control unit.
Lights to indicate that a fluoro exposure is in
progress. This is accompanied by an audible tone
from the console.
WARNING THIS X-RAY UNIT MAY BE
DANGEROUS TO PATIENT AND
OPERATOR UNLESS SAFE
EXPOSURE FACTORS AND
OPERATING INSTRUCTIONS
ARE OBSERVED.
Radiation warning label on console, used in certain
jurisdictions.
Never allow unqualified personnel to operate the X-
ray generator.
WARNING: PROPER USE AND SAFE OPERATING PRACTICES WITH RESPECT TO X-RAY
GENERATORS ARE THE RESPONSIBILITY OF THE USERS OF SUCH GENERATORS. CPI
CANADA INC. PROVIDES INFORMATION ON ITS PRODUCTS AND ASSOCIATED
HAZARDS, BUT ASSUMES NO RESPONSIBILITIES FOR AFTER-SALE OPERATING AND
SAFETY PRACTICES.
CPI CANADA INC. ACCEPTS NO RESPONSIBILITY FOR ANY GENERATOR NOT
MAINTAINED OR SERVICED ACCORDING TO THE SERVICE AND INSTALLATION MANUAL
OR ANY GENERATOR THAT HAS BEEN MODIFIED IN ANY WAY.
CPI CANADA INC. ALSO ASSUMES NO RESPONSIBILITY FOR X-RAY RADIATION
OVEREXPOSURE OF PATIENTS OR PERSONNEL RESULTING FROM POOR OPERATING
TECHNIQUES OR PROCEDURES.
WARNING: THIS X-RAY UNIT MAY BE DANGEROUS TO PATIENT AND OPERATOR UNLESS SAFE
EXPOSURE FACTORS AND OPERATING INSTRUCTIONS ARE OBSERVED.

2Safety and Specifications CPI Canada Inc
Page 8 Rev. A Indico 100 Series Operator Manual 740953-00
X-ray radiation exposure may be damaging to health, with some effects being cumulative and extending over
periods of many months or even years. X-ray operators should avoid any exposure to the primary beam and
take protective measures to safeguard against scatter radiation. Scatter radiation is caused by any object in the
path of the primary beam and may be of equal or less intensity than the primary beam that exposes the film.
No practical design can incorporate complete protection for operators or service personnel who do not take
adequate safety precautions. Only authorized and properly trained service and operating personnel should
be allowed to work with this X-ray generator equipment. The appropriate personnel must be made aware of
the inherent dangers associated with the servicing of high voltage equipment and the danger of excessive
exposure to X-ray radiation during system operation.
• Wear protective clothing. Protective aprons with an equivalent of a minimum of 1/64” (0.35 mm) of lead are
recommended.
• To protect the patient against radiation, always use radiation protection accessories in addition to devices
which are fitted to the X-ray equipment.
• Keep as large a distance as possible away from the object being exposed and the X-ray tube assembly.
• This X-ray equipment may only be operated in medical rooms which meet IEC requirements.
• Never operate this X-ray equipment in areas where there is a risk of explosion. Detergents and disinfectants,
including those used on patients, may create explosive mixtures of gases. Please observe the relevant
regulations.
• The operator console, or anything electrically connected to it, must never be used within 6 ft (1.8 m) of the
patient environment.
• Only trained maintenance staff may remove the covers of the generator cabinet and the control console.
Do not connect unapproved equipment to the rear of the console: J5 is for the interconnect
cable to the generator main cabinet, J2 is a serial port for use by an external computer, and
J13 is for connection of an external hand switch and / or foot switch. INCORRECT
CONNECTIONS OR USE OF UNAPPROVED EQUIPMENT MAY RESULT IN INJURY OR
EQUIPMENT DAMAGE.
CONSULT YOUR SERVICE REPRESENTATIVE IF EXTERNAL EQUIPMENT IS TO
BE CONNECTED TO THIS SYSTEM. PERIPHERAL DEVICES SHOULD BE IEC 601-1
APPROVED IF LOCATED IN THE PATIENT AREA, AND IEC 950 APPROVED IF OUTSIDE
THE PATIENT AREA.
CAUTION: DO NOT EXCEED THE TUBE MAXIMUM OPERATING LIMITS SHOWN IN THE SECTION X-
RAY TUBE DATA AT THE END OF THE OPERATOR’S MANUAL. INTENDED LIFE AND
RELIABILITY WILL NOT BE OBTAINED UNLESS GENERATORS ARE OPERATED WITHIN
PUBLISHED SPECIFICATIONS.

CPI Canada Inc Safety and Specifications 2
Indico 100 Series Operator Manual 740953-00 Rev. A Page 9
APPLICABLE STANDARDS
The Indico 100 family of generators complies with the following regulatory requirements and design standards:
• FDA Center for Devices & Radiological Health (CDRH) - 21 CFR title 21 subchapter J (USA).
• Radiation Emitting Devices Act - C34 (Canada).
• Medical Device Regulations (Canada).
• EC Directive 93/42/EEC concerning Medical Devices (European Community).
• IEC 601.1, IEC 601.2.7:1998, CSA 601.1, UL2601.1
-Type of protection against electric shock: Class I equipment.
-Degree of protection against electric shock: Not classified.
-Degree of protection against harmful ingress of water: Ordinary equipment.
-Mode of operation: Continuous operation with intermittent loading (standby - exposure).
-Equipment not suitable for use in presence of a FLAMMABLE ANESTHETIC MIXTURE WITH AIR
OR WITH OXYGEN OR NITROUS OXIDE.
• IEC 601.1.2
Immunity:
IEC1000-4-2 Electrostatic discharge
IEC1000-4-3 Radiated RF field
IEC1000-4-4 Electrical fast transient
IEC1000-4-5 Surge
IEC1000-4-6 Conducted RF immunity
IEC1000-4-8 Magnetic field immunity
IEC1000-4-11 Voltage dips, interrupts and variations
Emission:
EN55011 (CISPR Publications II Emission Standards, Group 1 Class A).
ELECTROMAGNETIC COMPATIBILITY (EMC)
In accordance with the intended use, this X-ray generator complies with the European Council Directive
concerning Medical Devices. The CE marking affixed to this product signifies this. One of the harmonized
standards of this Directive defines the permitted levels of electromagnetic emission from this equipment and its
required immunity from the electromagnetic emissions of other devices.
It is not possible, however, to exclude with absolute certainty the possibility that other high frequency electronic
equipment, which is fully compliant to the EMC regulations, will not adversely affect the operation of this generator.
If the other equipment has a comparatively high level of transmission power and is in close proximity to the
generator, these EMC concerns (the risk of interference) may be more pronounced. It is therefore recommended
that the operation of equipment of this type such as mobile telephones, cordless microphones and other similar
mobile radio equipment be restricted from the vicinity of this X-ray generator.

2Safety and Specifications CPI Canada Inc
Page 10 Rev. A Indico 100 Series Operator Manual 740953-00
OUTPUT PARAMETERS
• kVp range: Radiography 40 to 150 kVp.
Fluoroscopy 40 to 125 kVp.
• kVp accuracy: ±(5% + 1) kVp.
• mA range: Radiography 10 to 320 mA (30 kW), 10 to 400 mA (37.5 kW), 10
to 630 mA (50 kW), 10 to 800 mA (65 kW), and 10 to 1000 mA (80
kW).
Fluoroscopy 0.5 to 6.0 mA.
• mA accuracy: ±(5% +1.0) mA for all mA values.
• mAs range: Tube dependent, max 1000 mAs.
• Time range: Radiography 2.0 to 6300 ms.
Fluoroscopy 0 to 5 or 0 to 10 minutes.
• Lowest current - time
product:
0.5 mAs.
• Loading factors which
will allow lowest
current - time product:
All mA values ≤250 mA. Refer to table 1 in section 7.

CPI Canada Inc Safety and Specifications 2
Indico 100 Series Operator Manual 740953-00 Rev. A Page 11
OUTPUT PARAMETERS (Continued)
OUTPUT PARAMETER MODE GENERATOR SERIES LOADING FACTOR
Maximum X-ray tube
voltage and highest X-ray
tube current at that
voltage
Radiographic
(Intermittent) 80 kW 65 kW
50 kW
37.5 kW
30 kW
150 kV, 500 mA
150 kV, 400 mA
150 kV, 320 mA
150 kV, 250 mA
150 kV, 200 mA
Maximum X-ray tube
voltage and highest X-ray
tube current at that
voltage
Fluoroscopic
(Continuous) 80 kW 65 kW
50 kW
37.5 kW
30 kW
125 kV, 6 mA
125 kV, 6 mA
125 kV, 6 mA
125 kV, 6 mA
125 kV, 6 mA
Maximum X-ray tube
current and highest X-ray
tube voltage at that
current
Radiographic
(Intermittent) 80 kW 65 kW
50 kW
37.5 kW
30 kW
1000 mA, 80 kV
800 mA, 80 kV
630 mA, 80 kV
400 mA, 90 kV
320 mA, 90 kV
Maximum X-ray tube
current and highest X-ray
tube voltage at that
current
Fluoroscopic
(Continuous) 80 kW 65 kW
50 kW
37.5 kW
30 kW
6 mA, 125 kV
6 mA, 125 kV
6 mA, 125 kV
6 mA, 125 kV
6 mA, 125 kV
Combination of X-ray tube
current and X-ray tube
voltage resulting in
highest output power
Radiographic
(Intermittent) 80 kW 65 kW
50 kW
37.5 kW
30 kW
1000 mA, 80 kV
800 mA, 80 kV
630 mA, 80 kV
250 mA, 150 kV
200 mA, 150 kV
Combination of X-ray tube
current and X-ray tube
voltage resulting in
highest output power
Fluoroscopic
(Continuous) 80 kW 65 kW
50 kW
37.5 kW
30 kW
6 mA, 125 kV
6 mA, 125 kV
6 mA, 125 kV
6 mA, 125 kV
6 mA, 125 kV
Highest constant output
power at 100 kV, 0.1 sec Radiographic
(Intermittent) 80 kW
65 kW
50 kW
37.5 kW
30 kW
80 kW (800 mA,
100 kV, 0.1 s)
63 kW (630 mA,
100 kV, 0.1 s)
50 kW (500 mA,
100 kV, 0.1 s)
32 kW (320 mA,
100 kV, 0.1 s)
25 kW (250 mA,
100 kV, 0.1 s)
Nominal shortest
irradiation time
(AEC exposures)
AEC All models 15 ms

2Safety and Specifications CPI Canada Inc
Page 12 Rev. A Indico 100 Series Operator Manual 740953-00
ENVIRONMENTAL SPECIFICATIONS
OPERATING
Ambient temperature range: 10 to 40 °C.
Relative humidity: 30 to 75%.
Atmospheric pressure range: 500 to 1060 hPa (375 to 795 mm Hg).
TRANSPORT AND STORAGE
Ambient temperature range: -20 to 70 °C.
Relative humidity: 10 to 95%, including condensation.
Atmospheric pressure range: 500 to 1060 hPa (375 to 795 mm Hg).
This information is provided to help you establish safe operating conditions for both you and your CPI X-
ray generator.
Do not operate this X-ray generator except in accordance with information included in this section, and any
additional information provided by the X-ray generator manufacturer and/or competent safety authorities.
Address any questions regarding X-ray generator operation to:
Marketing Department,
CPI Canada Incorporated,
45 River Drive
Georgetown, Ontario, Canada L7G 2J4
Telephone: [phone].
Fax: [phone]
Attention: Customer Support
Department
E-mail: [e-mail]
Attention: Customer Support
Department

CPI Canada Inc
Indico 100 Series Operator Manual 740953-00 Rev. A Page 13
CONSOLE CONTROLS 3
OPERATOR CONTROL PANEL
+
+
+
+
IIIIII
Indico 100
+
+
+
FILE: IN_CONS.CDR
1. Power ON, power OFF buttons.
2. Radiography controls and display.
3. Image receptor buttons.
4. Anatomical programming display and control.
5. Fluoroscopy controls and display.
6. Prep and exposure buttons and exposure indicator LED.
NOTE: THIS MANUAL REFERS TO THE INDICO 100 R & F CONSOLE. FOR RAD ONLY UNITS,
IGNORE REFERENCES TO THE FLUOROSCOPY FUNCTION.

3Console Controls CPI Canada Inc
Page 14 Rev. A Indico 100 Series Operator Manual 740953-00
POWER AND EXPOSURE CONTROLS
Power ON / Power OFF buttons
Press to switch the X-ray generator on. The
console will light up and a self check will be
performed.
Press to switch the generator off.
Prep / Exposure Buttons and Exposure Indicator LED
Press and hold the prep button to spin the rotor.
While pressing the prep button, press and hold the
exposure button to make an X-ray exposure.
The X-ray exposure indicator will light when an
X-ray exposure is being taken.
Pressing the exposure button only will cycle the
generator through prep and then exposure.
When the prep button is pressed, SPINNING
ROTOR will be displayed in the APR window.
When the prep cycle is complete, X-RAY READY
will be displayed in the APR window.
During the X-ray exposure, X-RAY ON will be
displayed in the APR window.

CPI Canada Inc Console Controls 3
Indico 100 Series Operator Manual 740953-00 Rev. A Page 15
RADIOGRAPHY CONTROLS AND DISPLAY
+
+
+
+
IIIIII
1. Field select buttons and indicators (for AEC only).
2. Film / Screen select button and indicators (for AEC only).
3. Technique select button and indicators.
4. Focus select button and indicators.
5. kV up / down buttons.
6. mA and mAs up / down buttons.
7. Time (ms) up / down buttons.
8. Density up / down buttons.
9. Radiography display panel: kV, mA / mAs, Post mAs / ms, and density.

3Console Controls CPI Canada Inc
Page 16 Rev. A Indico 100 Series Operator Manual 740953-00
Field Select Buttons and Indicators (for AEC only)
Press the appropriate field select button(s) to select the
desired field or combination of fields. The adjacent LED(s)
will light to indicate the selected field(s). All three fields
may not be deselected.
Operates only when AEC is selected.
Film / Screen Select Button and Indicators (for AEC only)
IIIIII
Press the film / screen select button to select the desired
film / screen combination. The appropriate LED will light to
indicate the desired selection.
•
I
for film / screen I.
•
II
for film / screen II.
•
III
for film / screen III.
Operates only when AEC is selected.
Technique Select Button and Indicators
This function may be disabled in programming.
Press the technique select button until the appropriate
LED lights to indicate the desired technique.
• for Automatic Exposure Control (1 point technique).
• mAs for mAs technique (2 point technique).
• mA/ms for mA and ms technique (3 point technique).
Focus Select Button and Indicators
Press the focus select button until the appropriate LED
lights to indicate the desired focal spot.
• for small focus.
• for large focus.
This function may be programmed for auto focal spot
selection.

CPI Canada Inc Console Controls 3
Indico 100 Series Operator Manual 740953-00 Rev. A Page 17
Note: The rate of scrolling for the kV, mA and time display increases if the
buttons are pressed continuously. To return to the slowest scroll rate,
release the button(s) and start again.
kV up / down buttons and display
+
To increase kV, press +.
To decrease kV, press -.
Displays demanded kVp of the exposure.
mA and mAs up / down buttons and display
+
To increase mA or mAs, press +.
To decrease mA or mAs, press -.
Displays mA when AEC or mA/ms selected.
Displays mAs when mAs is selected.
Time (ms) up / down buttons and post-mAs / ms display
+
To increase time (ms), press +.
To decrease time (ms), press -.
Displays AEC, or shows backup mAs or
backup ms when AEC selected.
No display when mAs selected.
Displays time (ms) when mA/ms selected.
Displays POST mAs after an AEC exposure
is completed.
Density up / down buttons and display
+
Buttons operate only in AEC mode.
To increase dose, press +.
To decrease dose, press -.
The range is typically -5 to +5. (Installer
programmable to have a range of up to -8 to
+8).
Varies the optical density by changing the dose.
Each density step will change the dose by
approximately 10% (Installer programmable).

3Console Controls CPI Canada Inc
Page 18 Rev. A Indico 100 Series Operator Manual 740953-00
IMAGE RECEPTOR BUTTONS AND INDICATORS
1. Table, with Bucky, image receptor select
2. Table, no Bucky, image receptor select
3. Vertical image receptor select
4. Linear tomographic receptor select
5. Under-table R/F and remote R/F select
6. Auxiliary image receptor select
Note: Image Receptors (1-6) are depicted as the product is shipped from the
factory. These receptors may have been reprogrammed for different
functions during installation, and therefore may contain symbols different
from those shown.
Table with Bucky Image Receptor
Press this button to select over-table X-ray tube with table image
receptor. The adjacent indicator will light.
Used for Bucky / AEC techniques.
Table no Bucky image Receptor
Press this button to select over-table X-ray tube when no image
receptor is required. The adjacent indicator will light. Used for table
top and off table techniques.

CPI Canada Inc Console Controls 3
Indico 100 Series Operator Manual 740953-00 Rev. A Page 19
Vertical Image Receptor
Press this button to select vertical (wall) image receptor or
cassette holder. The adjacent indicator will light. Used for Bucky /
AEC or cassette only techniques.
Linear Tomographic Receptor
Press this button to select the linear tomographic receptor. The
adjacent indicator will light.
Under-Table R/F and Remote R/F
Press this button to select the fluoroscopy function (radiographic /
fluoroscopic models only). The adjacent indicator will light and the
fluoroscopy display will light.
Auxiliary
Press this button to select the auxiliary image receptor. The
adjacent indicator will light. This may be programmed for R & F
applications and digital applications.
Note: The image receptors may have been reprogrammed for your installation.

3Console Controls CPI Canada Inc
Page 20 Rev. A Indico 100 Series Operator Manual 740953-00
FLUOROSCOPY CONTROLS AND DISPLAY
+
+
+
1. Fluoroscopy display: kV, mA, time (min), PPS
2. Fluoro ON indicator
3. Fluoro kV up / down buttons
4. Fluoro mA up / down buttons
5. Time zero and accumulated time buttons
6. Pulsed fluoro frame rate buttons
7. I.I. magnification select button
8. Delta dose select button
9. Automatic brightness stabilization (ABS) select button
10. Pulse fluoro ON / OFF button
