Cradlepoint AER 2100 User manual

All-in-One, Cloud-Managed Networking Solution
Quick Start Guide

2
CradlePoint
The best in wireless WAN … meets the best in wireless LAN.
Integrated 4G LTE Dual-Band Concurrent WiFi
with 802.11ac
•Combines Integrated 4G LTE and Dual-Band Concurrent WiFi with 802.11ac
•Failover/failback and load balancing: 4G LTE + Ethernet + WiFi as WAN
•Enterprise-level security and features, including: VPN, VLAN, VRRP, BGP, OSPF, RIP, and more
•Dynamic Management with CradlePoint Enterprise Cloud Manager

Accessories
• Power adapters and international power cords
• External modem antennas and cabling
• Rack mounting bracket
CradlePoint Enterprise Cloud Manager
Use CradlePoint Enterprise Cloud Manager for rapid deployment, dynamic management, and enhanced intelligence of
CradlePoint enterprise network solutions. Visit www.cradlepoint.com/ecm to learn more.
Enterprise Support
For enhanced services including enterprise-level support, extended warranties, site surveys, and expert installation, check out CradlePoint’s
CradleCare suite of services. Visit www.cradlepoint.com/cradlecare to learn more.
3
CradlePoint
What’s In The Box
CradlePoint AER 2100 Dual-Band 2.4/5 GHz
WiFi Antennas
12V 3A AC/DC
Power Supply
Ethernet Cable Quick Start GuideMultipurpose Retaining Tool
with screws for securing
Integrated 3G/4G Modem
with Antennas

4
Hardware
USB 2.0 Port
LEDs
(see pages 12-13 for descriptions)
Lock Slot
10/100/1000 Ethernet Port
(Configurable: LAN or WAN
Default: WAN)
Reset
USB 2.0 Port
Power
Switch and Port
LEDs
(see pages 12-13 for descriptions)
Ground Screw
Front Panel
Back Panel
10/100/1000 Ethernet Ports
(Configurable: LAN or WAN
Default: LAN)

5
Hardware
Left Side Right Side
Modem Port
(USB 2.0)
Modem Port
(USB 3.0)
Modem Port
(USB 2.0)
With Cover
Cover Removed
With Integrated Modem
3G/4G Antenna Connectors
(SMA)
WiFi Antenna Connectors
(Reverse SMA)
WiFi Modem
When connecting the provided antennas, review the connection points.
•WiFi antennas have flat circular bases (RSMA).
•Modem antennas have protruding pins (SMA).
Integrated modem antennas include symbols to indicate the cellular technology:
• = LTE/EVDO for Verizon
• = LTE/HSPA+ for AT&T/Canada
• = LTE/HSPA+ for Europe

6
Getting Started
1. Insert an activated SIM.
A wireless broadband data plan must be added to your CradlePoint AER 2100. Wireless broadband data plans are available from
wireless carriers such as Verizon, AT&T, Sprint, EE, and Vodafone. The SIM must be provisioned with the carrier. Contact your
carrier for details about selecting a data plan and about the process for provisioning your SIM.
Once you have an activated SIM, insert it into the integrated modem. Be sure to insert the card with the notch-end first and the
gold contacts facing down – it will click into place.
Gold contacts must
face down
Notch-end goes
in first
Sample SIM card

7
Getting Started (continued)
2. Attach the integrated modem.
Follow these steps to attach the integrated modem:
1. Remove the left side panel cover from the router. Use a Phillips screwdriver to remove the screws, and use the
Multipurpose Retaining Tool (included in the router package) to remove the cover.
2. Slide the modem into the side of the router. The protruding section of the green board fits into the groove.
3. Reattach the panel cover and screw it back on. (When necessary, remove the cover and modem using the
Multipurpose Retaining Tool.)

8
Getting Started (continued)
3. Attach the WiFi and modem antennas.
Attach the three WiFi antennas (included) and two modem antennas to the connectors. Antennas are jointed, which enables
you to position them for optimal signal. To attach, hold the antenna straight and twist the base of the antenna to connect, folding
the joint if needed.
Examples of suggested antenna orientations:
Care should be taken to ensure that the router antennas are not near metal or other RF reflective surfaces.
Wall Mount
Desk Mount

9
Getting Started (continued)
4. Connect the power source.
Plug the provided power supply (12V DC wall adapter) into an electrical outlet. Then connect the power supply to the router.
Ensure power is switched on:
•O = OFF
•I = ON
When you set the power switch to the ON ( I ) position, watch for the power LED to illuminate.
If you would like to secure the power supply cord, attach the Multipurpose Retaining
Tool as shown. Secure with included screws.
Power Switch Power
Supply Port

5. Connect to a computer or other network equipment.
In order to access the CradlePoint AER 2100, establish a connection to the router. Connect wirelessly to the WiFi broadcast or
with an Ethernet cable connected to your computer and then plugged into one of the Ethernet LAN ports (numbered 1–4).
The default WiFi network name broadcast is “2100-xxx”, where “xxx” is the last three characters of your router’s MAC
address (this is the SSID on the product label). To connect to the WiFi, you will need to input the DEFAULT PASSWORD
when prompted. The DEFAULT PASSWORD is provided on the product label found on the bottom of your router.
Accessing the Administration Pages
Once you are connected, open the CradlePoint AER 2100’s GUI-
based administration pages to make configuration changes to your
router.
1. Open a browser window and type “ cp/ ” or
“ 192.168.0.1 ” in the address bar. Press ENTER/
RETURN .
2. When prompted for your password, type the eight character
DEFAULT PASSWORD found on the product label.
10
Getting Started (continued)
Made in Taiwan
RoHS
Part No.: 2100
www.cradlepoint.com
H/W ver.1.0
12V 3A (max 4A)
FCC ID:UXX-S4A340A
IC:6921A-S4A340A
Model No.: S4A340A
Default Password:440c1fc1
MAC Address: 0030440c1fc1
Serial No.:MM130167900418
SSID: 2100-fc1
