Craftsman 82005 User manual

Owner's Manual
Autoranging
Industrial Multimeter
Model No.
82005
Sears, Roebuck and Co., Hoffman Estates, IL 60179
www.craftsman.com 061510
Safety
Operation
Maintenance
Español
CAUTION
: Read, understand and
follow Safety Rules and Operating
Instructions in this manual before
using this product.

2
TABLE OF CONTENTS Page
Warranty 2
Safety Instructions 3
Safety Symbols 4
Control, Jacks, & Display 5
Specifications 6
Battery Installation 9
Fuse Installation 10
Operating Instructions 11
DC Voltage Measurements 11
AC Voltage Measurements 12
DC Current Measurements 13
AC Current Measurements 14
Resistance and Continuity Measurements 15
Diode tests 16
Capacitance Measurements 17
Frequency/Duty Cycle Measurements 17
Autoranging 18
Relative, Backlight, Hold, Auto Off, Low Battery 19
Maintenance 20
Troubleshooting 22
Service and Parts 22
ONE YEAR FULL WARRANTY
ONE YEAR Full WARRANTY ON CRAFTSMAN MULTIMETER
If this CRAFTSMAN MULTIMETER fails to give complete satisfaction
within one year from the date of purchase, RETURN IT TO THE
NEAREST SEARS STORE OR OTHER CRAFTSMAN OUTLET IN
THE UNITED STATES, and Sears will replace it, free of charge.
If this CRAFTSMAN MULTIMETER is used for commercial or rental
purposes, this warranty applies for 90 days from the date of
purchase.
This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state
Sears, Roebuck and Co., Dept. 817WA, Hoffman Estates, IL
60179
For Customer Assistance Call 9am-5 PM (EST)
Monday through Friday 1-888-326-1006

3
WARNING: USE EXTREME CAUTION IN THE USE OF
THIS DEVICE. Improper use of this device can result in
injury or death. Follow all safeguards suggested in this
manual in addition to the normal safety precautions used in
working with electrical circuits. DO NOT service this device if
you are not qualified to do so.
SAFETY INSTRUCTIONS
This meter has been designed for safe use, but must be
operated with caution. The rules listed below must be carefully
followed for safe operation.
1. NEVER apply voltage or current to the meter that
exceeds the specified maximum:
Input Limits
Function Maximum Input
V DC, V AC 1000V DC/AC rms
mAAC/DC 400mAAC/DC
A AC/DC 10AAC (20A 30secs.)
Frequency, Resistance,
Capacitance, Diode, Continuity
600V DC/ACrms
2. USE EXTREME CAUTION working with high voltages.
3. DO NOT measure voltage if the voltage on the "COM"
input jack exceeds 600V above earth ground.
4. DO NOT measure current of circuits whose voltage is
greater than 1000V.
5. NEVER connect the meter leads across a voltage source
while the function switch is in the current, resistance, or
diode mode. Doing so can damage the meter.
6. ALWAYS discharge filter capacitors in power supplies
and disconnect the power when making resistance or
diode tests.
7. ALWAYS turn off the power and disconnect the test leads
before opening the covers to replace the fuse or batteries.
8. NEVER operate the meter unless the back cover is in
place and fastened securely.

4
SAFETY SYMBOLS
This symbol adjacent to another symbol,
terminal or operating device indicates that
the operator must refer to an explanation in
the Operating Instructions to avoid personal
injury or damage to the meter.
This WARNING symbol indicates a
potentially hazardous situation, which if not
avoided, could result in death or serious
injury.
This CAUTION symbol indicates a
potentially hazardous situation, which if not
avoided, may result in damage to the meter.
This symbol advises the user that the
terminal(s) so marked must not be
connected to a circuit point at which the
voltage, with respect to earth ground,
exceeds (in this case) 1000 VAC or VDC.
This symbol adjacent to one or more
terminals identifies them as being
associated with ranges that may, in normal
use, be subjected to particularly hazardous
voltages. For maximum safety, the meter
and its test leads should not be handled
when these terminals are energized.
This symbol indicates that a device is
protected throughout by double insulation
or reinforced insulation.
WARNING
CAUTION
MAX
1000V

5
CONTROLS, JACKS, AND DISPLAY
1. 4,000 count LCD display
2. RANGE button
3. Hz and % button
4. Mode button
5. Function switch
6. mA, µA and 10A input
jacks
7. COM input jack
8. Positive input jack
9. Backlight button
10. RELATIVE button
11. HOLD button
Note: Tilt stand and battery compartment are on rear of unit.
•))) Continuity
Diode test
Battery status
n nano (10-9) (capacitance)
µ micro (10-6) (amps)
m milli (10-3) (volts, amps)
A Amps
k kilo (103) (ohms)
F Farads (capacitance)
M mega (106) (ohms)
 Ohms
Hz Hertz (frequency) V Volts
% Percent (duty ratio) REL Relative
AC Alternating current Auto Autoranging
DC Direct current HOLD Display hold

6
SPECIFICATIONS
Function Range Resolution Accuracy
DC Voltage 400mV 0.1mV (0.5% reading + 2 digits)
4V 0.001V
(1.2% reading + 2 digits)
40V 0.01V
400V 0.1V
1000V 1V (1.5% reading + 2 digits)
AC Voltage 400mV 0.1mV (2.0% reading + 10 digits)
4V 0.001V
(2.0% reading + 5 digits)
40V 0.01V
400V 0.1V
1000V 1V (2.5% reading + 5 digits)
DC Current 400A 0.1A(1.0% reading + 5 digits)
4000A 1A
(1.5% reading + 3 digits)
40mA 0.01mA
400mA 0.1mA
10A 0.01A (2.5% reading + 5 digits)
AC Current 400A 0.1A(2.5% reading + 10 digits)
4000A 1A
(2.5% reading + 5 digits)
40mA 0.01mA
400mA 0.1mA
10A 0.01A (3.0% reading + 7 digits)
Resistance 4000.1(1.2% reading + 4 digits)
4k0.001k(1.0% reading + 2 digits)
40k0.01k
(1.2% reading + 2 digits)
400k0.1k
4M0.001M
40M0.01M(2.0% reading + 3 digits)
Capacitance 40nF 0.01nF (5.0% reading + 7 digits)
400nF 0.1nF
(3.0% reading + 5 digits)
4F 0.001F
40F 0.01F

7
100F 0.1F(5% reading + 5 digits)
Frequency 5.999Hz 0.001Hz (1.5% reading + 1 digits)
59.99Hz 0.01Hz
599.9Hz 0.1Hz
(1.2% reading + 3 digits)
5.999kHz 0.001kHz
59.99kHz 0.01kHz
599.9kHz 0.1kHz
5.999MHz 0.001MHz (1.5% reading + 4 digits)
9.999MHz 0.001MHz
Sensitivity: 0.5V rms <500kHz; 3V rms >500kHz
Duty Cycle 0.1 to
99.9% 0.1% (1.2% reading + 2 digits)
Pulse width: 100µs to 100ms, Frequency: 5Hz
to 150kHz
NOTE: Accuracy is stated at 65oF to 83oF (18oC to 28oC) and
less than 75% RH.
Note: Accuracy specifications consist of two elements:
(% reading) – This is the accuracy of the measure circuit.
(+ digits) – This is the accuracy of the A/D converter.
Enclosure Double molded, waterproof (IP67)
Shock (Drop Test) 6.5 feet (2 meters)
Diode Test Test current of 0.3mA typical, open
circuit voltage 1.5V DC typical
Continuity Check Audible signal will sound if the
resistance is less than 100
(approx.), test current <0.3mA
Input Impedance 7.8MΩ
AC Response Average responding
ACV Bandwidth 50Hz to 400Hz
Crest Factor ≤3 at full scale up to 500V,
decreasing linearly to ≤1.5 at
1000V
Display 4,000 count backlit liquid crystal
Overrange indication “OL” is displayed
Auto Power Off 30 minutes (approximately)

8
Polarity Automatic (no indication for
positive); Minus (-) sign for negative
Measurement Rate 2 times per second, nominal
Low Battery Indication “ ” is displayed if battery voltage
drops below operating voltage
Battery One 9 volt (NEDA 1604) battery
Fuses mA, µA ranges; 0.5A/1000V
ceramic fast blow
A range; 10A/1000V ceramic fast
blow
Operating Temperature 41F to 104F (5C to 40C)
Storage Temperature -4F to 140F (-20C to 60C)
Operating Humidity Max 80% up to 87F (31C)
decreasing linearly to 50% at 104F
(40C)
Storage Humidity <80%
Operating Altitude 7000ft. (2000meters) maximum.
Weight 0.753lb (342g) (includes holster).
Size 7.2” x 3.2” x 2.2” (182 x 82 x 55mm)
Safety This meter is intended for origin of
installation use and protected,
against the users, by double
insulation per EN61010-1 and
IEC61010-1 2nd Edition (2001) to
Category IV 600V and Category III
1000V; Pollution Degree 2. The
meter also meets UL 61010-1, 2nd
Edition (2004), CAN/CSA C22.2 No.
61010-1 2nd Edition (2004), and UL
61010B-2-031, 1st Edition (2003)
Approvals UL CE
UL Listed The UL mark does not indicate that
this product has been evaluated for
the accuracy of its readings.

9
BATTERY INSTALLATION
BATTERY INSTALLATION
WARNING: To avoid electric shock, disconnect the test
leads from any source of voltage before removing the battery
cover.
1.Turn power off and disconnect the test leads from the
meter.
2.Open the rear battery cover by removing two screws (B)
using a Phillips head screwdriver.
3.Insert the battery into battery holder, observing the correct
polarity.
4.Put the battery cover back in place. Secure with the
screws.
WARNING: To avoid electric shock, do not operate the
meter until the battery cover is in place and fastened
securely.
NOTE: If your meter does not work properly, check the fuses
and batteries to make sure that they are still good and
that they are properly inserted.

10
REPLACING THE FUSES
WARNING: To avoid electric shock, disconnect the test
leads from any source of voltage before removing the fuse
cover.
1.Disconnect the test leads from the meter.
2.Remove the battery cover (two “B” screws) and the battery.
3.Remove the six “A” screws securing the rear cover.
4.Gently remove the old fuse and install the new fuse into
the holder.
5.Always use a fuse of the proper size and value
(0.5A/1000V fast blow for the 400mA range [SIBA 70-172-
40], 10A/1000V fast blow for the 20A range [SIBA 50-199-
06]).
6.Replace and secure the rear cover, battery and battery
cover.
WARNING: To avoid electric shock, do not operate your
meter until the fuse cover is in place and fastened securely.

11
OPERATING INSTRUCTIONS
WARNING: Risk of electrocution. High-voltage circuits,
both AC and DC, are very dangerous and should be
measured with great care.
NOTES:
1. ALWAYS turn the Function switch to the OFF position
when the meter is not in use.
2. If “ 1 ” appears in the display during a measurement, the
value exceeds the range you have selected. Change to a
higher range.
DC VOLTAGE MEASUREMENTS
WARNING: Risk of Electrocution. The probe tips may not
be long enough to contact the live parts inside some 240V
outlets for appliances because the contacts are recessed
deep in the outlets. As a result, the reading may show 0
volts when the outlet actually has voltage on it. Make sure
the probe tips are touching the metal contacts inside the
outlet before assuming that no voltage is present.
1.Set the function switch to the VDC or mVDC
position.
2.Insert the black test lead banana plug into
the negative COM jack.
Insert the red test lead banana plug into the
positive Vjack.
3.Touch the black test probe tip to the
negative side of the circuit.
Touch the red test probe tip to the positive
side of the circuit.
4.Read the voltage in the display.

12
AC VOLTAGE (FREQUENCY, DUTY CYCLE)
MEASUREMENTS
WARNING: Risk of Electrocution. The probe tips may not
be long enough to contact the live parts inside some 240V
outlets for appliances because the contacts are recessed
deep in the outlets. As a result, the reading may show 0
volts when the outlet actually has voltage on it. Make sure
the probe tips are touching the metal contacts inside the
outlet before assuming that no voltage is present.
CAUTION: Do not measure AC voltages if a motor on the
circuit is being switched ON or OFF. Large voltage surges
may occur that can damage the meter.
1.Set the function switch to the VAC position.
2.Insert the black test lead banana plug into
the negative COM jack.
Insert red test lead banana plug into the
positive Vjack.
3.Touch the black test probe tip to the
neutral side of the circuit.
Touch the red test probe tip to the “hot”
side of the circuit.
4.Read the voltage in the display.
5.Press the HZ/% button to indicate “Hz”.
6.Read the frequency in the display.
7.Press the Hz/% button again to indicate
“%”.
8.Read the % of duty cycle in the display.

13
DC CURRENT MEASUREMENTS
CAUTION: Do not make 20A current measurements for
longer than 30 seconds. Exceeding 30 seconds may
cause damage to the meter and/or the test leads.
1.Insert the black test lead banana plug into
the negative COM jack.
2.For current measurements up to 4000µA
DC, set the function switch to the µA
position and insert the red test lead
banana plug into the µA/mA jack.
3.For current measurements up to 400mA
DC, set the function switch to the mA
position and insert the red test lead
banana plug into the µA/mA jack.
4.For current measurements up to 10A DC,
set the function switch to the 10A position
and insert the red test lead banana plug
into the 10A jack.
5.Press the MODE button to indicate “DC”
on the display.
6.Remove power from the circuit under test, then open up
the circuit at the point where you wish to measure current.
7.Touch the black test probe tip to the negative side of the
circuit.
Touch the red test probe tip to the positive side of the
circuit.
8.Apply power to the circuit.
9.Read the current in the display.

14
AC CURRENT (FREQUENCY, DUTY CYCLE)
MEASUREMENTS
CAUTION: Do not make 20A current measurements for
longer than 30 seconds. Exceeding 30 seconds may
cause damage to the meter and/or the test leads.
1. Insert the black test lead banana plug into the negative
COM jack.
2. For current measurements up to 4000µA
AC, set the function switch to the µA
position and insert the red test lead
banana plug into the µA/mA jack.
3. For current measurements up to 400mA
AC, set the function switch to the mA
position and insert the red test lead
banana plug into the µA/mA jack.
4. For current measurements up to 10A AC,
set the function switch to the 10A position
and insert the red test lead banana plug
into the 10A jack.
5. Press the MODE button to indicate “AC”
on the display.
6. Remove power from the circuit under test,
then open up the circuit at the point where you wish to
measure current.
7. Touch the black test probe tip to the neutral side of the
circuit.
Touch the red test probe tip to the “hot” side of the circuit.
8. Apply power to the circuit.
9. Read the current in the display.
10.Press the Hz/% button to indicate “Hz”.
11.Read the frequency in the display.
12.Press the Hz/% button again to indicate “%”.
13.Read the % duty cycle in the display.
14.Press the Hz/% button to return to current measurement.

15
RESISTANCE MEASUREMENTS
WARNING: To avoid electric shock, disconnect power to
the unit under test and discharge all capacitors before
taking any resistance measurements. Remove the
batteries and unplug the line cords.
1.Set the function switch to the ΩCAP
position.
2.Insert the black test lead banana plug into
the negative COM jack.
Insert the red test lead banana plug into
the positive jack.
3.Press the MODE button to indicate
“"on the display.
4.Touch the test probe tips across the
circuit or part under test. It is best to
disconnect one side of the part under test
so the rest of the circuit will not interfere
with the resistance reading.
5.Read the resistance in the display.
CONTINUITY CHECK
WARNING: To avoid electric shock, never measure
continuity on circuits or wires that have voltage on them.
1.Set the function switch to the ΩCAP
position.
2.Insert the black lead banana plug into the
negative COM jack.
Insert the red test lead banana plug into
the positive jack.
3.Press the MODE button to indicate”
"and “Ω” on the display
4.Touch the test probe tips to the circuit or
wire you wish to check.
5.If the resistance is less than
approximately 100, the audible signal
will sound. If the circuit is open, the
display will indicate “OL”.

16
DIODE TEST
1.Set the function switch to the ΩCAP
position.
2.Insert the black test lead banana plug
into the negative COM jack and the red
test lead banana plug into the positive V
jack.
3.Press the MODE button to indicate
and Von the display.
4.Touch the test probes to the diode under
test. Forward voltage will typically
indicate 0.400 to 0.700V. Reverse
voltage will indicate “OL”. Shorted
devices will indicate near 0V and an open
device will indicate “OL” in both polarities.

17
CAPACITANCE MEASUREMENTS
WARNING: To avoid electric shock, disconnect power to
the unit under test and discharge all capacitors before
taking any capacitance measurements. Remove the
batteries and unplug the line cords.
1.Set the rotary function switch to the Ω CAP position.
2.Insert the black test lead banana plug into the
negative COM jack.
Insert the red test lead banana plug into the
positive Vjack.
3.Press the MODE button to indicate “nF” on
the display.
4.Touch the test leads to the capacitor to be
tested.
5.The test may take up to 3 minutes or more for
large capacitors to charge. Wait until the
readings settle before ending the test.
6.Read the capacitance value in the display
Note: Upon entering the capacitance mode and
with no component connected, the meter will autorange to
the 0.000nF range. This is not a measurement range, but
is used to establish a zero reference.
FREQUENCY/DUTY CYCLE MEASUREMENTS
(ELECTRONIC)
1.Set the rotary function switch to the “Hz %”
position.
2.Press the Hz/% button to indicate “Hz” in the
display.
3.Insert the black lead banana plug into the
negative COM jack and and red test lead
banana plug into the positive Hz jack.
4.Touch the test probe tips to the circuit under
test.
5.Read the frequency on the display.
6.Press the Hz/% button again to indicate “%” on
the display.
7.Read the % of duty cycle on the display.

18
FREQUENCY SENSITIVITY (ELECTRICAL)
The frequency sensitivity is range dependent when the Hz
function is selected while in the voltage or current measuring
mode. Below are typical sensitivities for the “electrical”
measurement modes.
Range
( DC/AC ) Sensitivity Frequency bandwidth
4V ≥1.5V rms 5Hz~10kHz
40V, 400V ≥10V rms 5Hz~20kHz
≥20V rms 5Hz~200kHz
1000V/1000V ≥420V rms 50Hz~1kHz
400mA ≥45mA rms 5Hz~5kHz
10A ≥4A rms 5Hz~1kHz
AUTORANGING/MANUAL RANGE SELECTION
When the meter is first turned on, it automatically goes into
Autoranging. This automatically selects the best range for
the measurements being made and is generally the best
mode for most measurements. For measurement situations
requiring that a range be manually selected, perform the
following:
1.Press the RANGE key. The “Auto” display indicator will
turn off.
2.Press the RANGE key to step through the available
ranges. Observe the decimal point and units displayed
until the preferred range is located.
3.To exit the Manual Ranging mode and return to
Autoranging, press and hold the RANGE key for 2
seconds.
Note: Manual ranging does not apply for the Capacitance
and Frequency functions or for the mV range.

19
RELATIVE MODE
The relative measurement feature allows you to make
measurements relative to a stored zero reference value. A
reference voltage, current, etc. can be stored and
measurements made in comparison to that value. The
displayed value is the difference between the reference
value and the measured value.
1.Perform the measurement as described in the operating
instructions.
2.Press the REL button to store (zero) the reading in the
display and the "REL" indicator will appear on the display.
3.The display will now indicate the difference between the
stored value and the measured value.
4.Press the REL button to exit the relative mode.
Note: The Relative function does not operate in the
Frequency function.
DISPLAY BACKLIGHT
Press the backlight button for >2 second to turn on.
Press the button again to turn the backlight off.
HOLD
The hold function freezes the reading in the display. Press
the HOLD key momentarily to activate or to exit the HOLD
function.
AUTO POWER OFF
The auto off feature will turn the meter off after 30 minutes.
To disable the auto power off feature, hold down the MODE
button and turn the meter on.
LOW BATTERY INDICATION
The icon will appear in the display when the battery
voltage becomes low. Replace the battery when this
appears.

20
MAINTENANCE
WARNING: To avoid electric shock, disconnect the test
leads from any source of voltage before removing the back
cover or the battery or fuse covers.
WARNING: To avoid electric shock, do not operate your
meter until the battery and fuse covers are in place and
fastened securely.
This MultiMeter is designed to provide years of dependable
service, if the following care instructions are performed:
1.KEEP THE METER DRY. If it gets wet, wipe it off.
2.USE AND STORE THE METER IN NORMAL
TEMPERATURES. Temperature extremes can shorten
the life of the electronic parts and distort or melt plastic
parts.
3.HANDLE THE METER GENTLY AND CAREFULLY.
Dropping it can damage the electronic parts or the case.
4.KEEP THE METER CLEAN. Wipe the case occasionally
with a damp cloth. DO NOT use chemicals, cleaning
solvents, or detergents.
5.USE ONLY FRESH BATTERIES OF THE
RECOMMENDED SIZE AND TYPE. Remove old or weak
batteries so they do not leak and damage the unit.
6.IF THE METER IS TO BE STORED FOR A LONG
PERIOD OF TIME, the batteries should be removed to
prevent damage to the unit.
