Craftsman 172.27696 User manual

Model No,
172.27696
CAUTION: Read, understand and follow
all Safety Rules and Operating Instruc_Jons
in this manual before using th_s product.
, SAFETY
•OPERATION
•MAINTENANCE
•ESPANOL
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.

Warranty. ....................................................................... Page
Safety Instructions ...................................................... Pages
Safety Symbols ....................................................... Page
Assembly. ...................................................................... Page
Operation .................................................................. Pages
Maintenance ................................................................. Pages
Accessories .................................................................. Page
2
3-7
7
8-9
11
12-13
14-15
16
ONE FULL YEAR WARRANTY ON CRAFTSMAN PROFESSIONAL TOOL
If this Craftsman Professfonal Tool fails to give complete satisfaction within one
year from the date of purchase, RETURN ITTOTHE NEAREST SEARS STORE
IN THE UNITED STATES, and Sears will replace it, free of charge.
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
Sears, Roebuck and Coo,Dept. 817 WA, Hoffman Estates, IL 60179
SAVE THESE INSTRUCTIONS!
READ ALL INSTRUCTIONS!

WARNING: BE SURE to read and understand all instructions. Failure
to follow all instructions listed below may result in electric shock, fire
and/or serious personal injury.
WORK AREA SAFETY
i. ALWAYS keep your work area clean and well lit. Cluttered benches and dark
areas inviteaccidents°
2. DO NOT operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Powertoolscreatesparks which
may ignite the dust or fumes°
3. ALWAYS keep bystanders, children, and visitors away while operating a
power tool. Distractions can cause you to lose control°
ELECTRICAL SAFETY
I. Double insulated tools are equipped with a polarized plug (one blade is
wider than the other.) This plug will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician to install a polarized outlet. DO NOT
change the plug In any way.
2. Double insulationQeliminates the need for thethree wire grounded power cord
and grounded power supply system. Applicable only to Class ii (double insulated)
tools°
3. Before plugging in the tool, BE SURE that the outlet vollage supplied is within the
voltage marked on the tool's data plate. DO NOT use "AC only" rated tools with a
DC power supply.
4. ALWAYS avoid body contact with grounded surfaces such as pipes,
radiators, ranges and refrigerators, There isan increased risk of electric shock
if your body is grounded.
5. If operating the power tool in damp locations is unavoidable, ALWAYS use a
Ground Fault Circuit Interrupter to supply power to your tool. ALWAYS wear
electrician's rubber gloves and footwear in damp conditions.
6. DO NOT expose power tools to rain or wet conditions. Water entering a power
toot will increasethe risk of electric shock°
7. DO NOT abuse the cord. NEVER use the cord to carry the tools or pull the
plug from the outlet. Keep cord away from heat, oil, sharp edges or moving
parts. Replace damaged cords immediately. Damaged cords increase the risk
of electric shock°
8. When operating a power tool outside, At.WAYS use an outdoor extension
cord marked "W-A" or "W". These cords are rated for outdoor use and reduce
the risk of electric shock_
NOTE: The extension cord must have adequate wire size AWG (American Wire
Gauge) for safe, efficientuse° Smaller gauge wires have greater capacity (16 gauge
wire has more capacity than 18 gauge wire).

PERSONAL SAFETY
1.ALWAYS stay alert, watch what you are doing and use common sense when
operating a power tool. DO NOT use tool while tired or under the influence of
drugs, alcohol or medication. A moment ofinattentionwhile operating power
tools may result in serious personal injury_
2. ALWAYS dress properly. DO NOT wear loose clothing or jewelry. Pull back
long hair, Keep your hair, clothing and gloves away from moving parts. Loose
clothing, jewelry or long hair can be caught inmoving parts.
3. ALWAYS avoid accidental starting. BE SURE switch is in the "Off" position
before plugging in. Carrying tools with your finger on the switch or plugging in
tools that have the switch in the "On" position invitesaccidents,
4. ALWAYS remove adjusting keys or wrenches before turning the tool on.
A wrench or a key that is left attached to a rotating part of the tool may result in
personal injury.
5. DO NOT overreach. ALWAYS keep proper footing and balance at all times.
Proper footingand balance enables better control of the tool in unexpected
situations.
6. ALWAYS use safety equipment. ALWAYS wear eye protection. Dust mask,
non-skid safety shoes, hard hat, or hearing protection must be used for
appropriate conditions
TOOL USE AND CARE SAFETY
1. ALWAYS use clamps or other practical ways to secure and support the
workpiece to a stable platform. Holdingthe work by hand or againstyour body
is unstable and may lead to loss of control.
2. DO NOT force the tool. Use the correct tool for your application. The correct
tool will do thejob better and safer at the rate forwhich itis designed.
3. DO NOT use the tool if the switch does not turn it "On" or "Off", Any tool that
cannot be controlled with the switch is dangerous and must be repaired.
4. ALWAYS disconnect the plug from the power source before making any
adjustments, changing accessories or storing the tool. Such preventive safety
measures reduce the risk of starting the tool accidentally.
5. ALWAYS store idle tools out of the reach of children and other untrained
persons. Tools are dangerous in the hands of untrained users°
6, ALWAYS maintain tools with care. Keep cutting tools sharp and clean.
Properly maintained tools with sharp cutting edges are less likely to bind and are
easier to control.
7. ALWAYS check for misalignment or binding of moving parts, breakage of
parts, and any other condition that may affect the tool's operation. If
damaged, have the tool serviced before using. Many accidents are caused by
poorly maintained tools.

TOOL USE AND CARE SAFETY CONT.
.....................................
Z_WARNING: USE OF ACCESSORIESTHAT ARE NOT RECOMMENDED
FOR USE WITH THIS TOOL MAY CREATE A HAZARDOUS CONDITION.
8. ALWAYS use only accessories that are recommended for this tool.
Accessories that may be suitable for one toolcan become hazardous
when used on another toolo
i
SERVICE SAFETY
1. If any part of this sander is missing or should break, bend, or fail in any way;
or should any electrical component fail to perform properly: ALWAYS shutoff
the power switch and remove the saw plug from the power source and have the
missing, damaged or failed parts replaced BEFORE resuming operation.
2. Tool service must be performed only at a Sears Service Center. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
SAFETY RULES FOR SANDERS
1. NEVER use this or any power sander for wet sanding or liquid polishing,
Failure to follow this rute willincrease the riskof electrical shock,
ADDITIONAL RULES FOR SAFE OPERATION
, ,, ,,,, ,, , ,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,,
_WARNING: BE SURE to read and understand all instructions. Failure
to follow all instructions listed below may result in electric shock, fire and/or
serious personal injury.
illll i,i J/illJJJJiiJl/iJllJJiJii
1. Know your power tool. Read operator's manual carefully. Learn the
applications and limitations, as well as the specific potential hazards related
to this tool.
2. ALWAYS wear safety glasses or eye shields when using this sander.
Everyday eyeglasses have only impact-resistant lenses; they are NOT safety
glasses.
3. ALWAYS protect your lungs.Wear a face mask or dust mask if the operation
is dusty.
4. ALWAYS protect your hearing.Wear hearing protection during extended
periods of operation.
5. ALWAYS inspect the tool cords periodically and if damaged have them
repaired at your nearest Sears Service Center or other qualified Service
Facility, ALWAYS be aware of the cord location.
6. ALWAYS check for damaged parts. Before further use of the tool, a guard or
other part that is damaged should be carefully checked to determine if it will
operate properly and perform its intended function. Check for misalignment
or binding of moving parts, breakage of parts, and any other condition that
may affect the tool's operation. A guard or other part that is damaged,
should be properly repaired or replaced at an qualified Service Center.

ADDITIONALRULESFORSAFEOPERATIONCONT.
7.DONOT abuse the cord, NEVER use the cord to carry the tools or pull the
plug from the outlet. Keep cord away from heat, oil, sharp edges or moving
parts. Replace damaged cords immediately. Damaged cords increase the risk
of electricshock,
8, ALWAYS make sure that your extension cord is in good condition. When
using an extension cord be sure to use one that is heavy enough to carry
the current that your tool will draw. A wire gauge size (A,W.G,) of at least 16
is recommended for an extension 100 feet or less in length. Using an
extension cord that is over 100 feet in length is not recommended. If in
doubt, use the next heavier gauge. Smaller gauge wires, have greater
capacity (16 gauge wire has more capacity than 18 gauge wire).
An undersized cord will cause a drop in fine voltage, resulting in toss of power
and overheating,
9. ALWAYS inspect and remove all nails from lumber before sanding.
10. DO NOT use the tool while tired or under the influence of drugs, alcohol or
any medication.
11.SAVE THESE INSTRUCTIONS. Refer to them frequently and use them to
instruct others who may use this tool. If someone borrows this tool, make
sure they have these instructions also.
Z_WARNING; Some dust particles created by power sanding, sawing;
grinding, drilling and other construction jobs contain chemicals known to
cause cancer, birth defects or other reproductive harm, Some examples of
these chemicals are:
• Lead from lead-based paints,
°Crystalline silica from bricks and cement and other masonry products°
•Arsenic and chromium from chemically treated lumber,
Your risk from these exposuresvaries, depending upon how often you do this
type of work. To reduce your exposure to these chemicals:
° Work in a well-ventilated area.
• Work with approved safety equipment, such as those dust masks thatare
specially designed to filter out microscopic particles.

ADDITIONAL RULES FOR SAFE OPERATION CONT.
WEAR YOUR WARNING: The operation of any sander can
result in foreign objects being thrown into your eyes,
which can result in severe eye damage. Before
beginning power tool operation, ALWAYS wear safety
goggles or safety glasses with side shield and a full face
shield when needed. We recommend a Wide Vision
Safety' Mask for use over eyeglasses or standard safety
glasses with side shield, available at Sears Retail Stores.
The label of your tool may include the following symbols:
V........................................................... Volts
A........................................................... Amps
Hz ......................................................... Hertz
W.......................................................... Watts
min ........................................................Minutes
,-,,., ....................................................... Alternating current
......................................................... .Direct current
Hz ........................................................... Frequency
no ........................................................ .No-load speed
[] .......................................................... Class II Construction
..Jmin .................................................... Revolutions or Strokes per minute
OPM ...................................................... Obits Per Minute
Z_ ........................................................... Indicates Danger, Warning or
Caution. It means attention!
Your safety is involved.
IMPORTANT! READ ALL iNSTRUCTIONS!
7

KNOWYOUR SANDER (SEE FIG.l)
This sander is ideal for sanding with fine, medium and coarse grit sandpaper,,
it produces 11,000 orbits per minute with 1/lO-in, orbit diameter to provide fast
material removal and a fine, smooth finish on all wood surfaces, The precision-tuned
counterbalanced design reduces vibration for smooth operation and reduced
operator fatigue,,
Trigger Switch
The sander trigger switch is located under the rear handle. Toturn the sander "ON",
simply squeeze the trigger switch,To turn the sander "OFF", release the trigger
switch°This sander also has a Lock-On Button on the side of the rear handle for
continuous sanding operations,To activate the Lock-On feature, simply squeeze the
trigger switch to turn sander "ON" and push inthe Lock-On Button,,To deactivate
lock-on feature, simply press and release trigger switch,
Dust Collection
Your sander includesa dust bag assembly that isdesigned to help remove
accumulated dust from the sanding area.
Fig 1 Button Handle
Front
Handle Trigger
Switch
Paper Clamp,,_,
'Cushion
.,Dust Bag
Assembly
Electrical Connection
Your sander has a precision-builtelectric motor and it should only be connected to a
120-volt, 60-Hz. power supply (normal household current). DO NOT operate on
direct current (DC). This large voltage drop will cause a loss of power that will
overheat the motor, If your sander does not operate when plugged into an outlet,
check the power supply,
No-load Speed 11,000 OPM (Orbits Per Minute)
Rating ..........120 Volts, 60 Hz AC
Input 3.3 Amps
Orbit Diameter 1/10 in. ".........
.......Paper Size 1/2 Sheet
Paper Type Non-Adhesive Sandpaper & Adhesive Sandpaper

WARNING: Your sander should NEVER be connected to the power
source when you are assembling parts, making adjustments, installing or
removing sandpaper, cleaning or when it is not in use. Disconnecting the sander
will prevent accidental starting, that could cause serious personal injury.
INSTALLING THE SANDPAPER (See Figs, 2 & 3)
This sander has a cushion that allows you to use: either non-adhesive sandpaper,
pressure-sensitive sandpaper or adhesive-backed sandpaper_The nomadhesive
sandpaper clamps to the ptatem Adhesive-backed sandpaper sticks to the cushiom
NOTE: This sander has dust collection, so we recommend that you use
sandpaper with pre-punched holes that wilI line up with the holes in the cushion,
Installing Non-Adhesive Sandpaper (See Fig. 2 on next page)
ALWAYS inspectthe sandpaper before installing.DO NOT use if broken or defective.
1. Unplug the sander_
J Z_ WAR NING: Failure to unplug the sander could result in accidental J
starting causing possible serious personal injury_
2. Remove dust bag assembly.
3, If replacing sandpaper, remove old sandpaper°
4. To remove old sandpaper, raise the levers on each side of the sander to release
the paper clamps holding the sandpaper. Then remove old sandpaper.
5. Insert the end of the new sandpaper approximately 1/2-inch under the front paper
clamp.
6. Lift up the lever on the left side of the sander and lock it into the slot on the platen°
Apply downward pressure to tighten sandpaper to the platen_
7. Wrap remaining sandpaper around the cushion and insert the loose end of the
sandpaper under the rear paper clamp. Fit the sandpaper against the cushion as
tightly as possible_
8. Lift up the lever on the right side of the sander and lock it int_othe slot on the
platen°
9. Replace the dust bag assembly

Installing Adhesive-Backed Sandpaper (See Fig, 3 on next page)
ALWAYS inspect the sandpaper before installing°DO NOT use ifbroken or defective,
1.Unplugthesander.
_ WARNING: Failure to unplug the sander could result in accidental ! starting causing possible serious personal injury°
2. If replacing adhesive-backed sandpaper, remove old sandpaper by peeling it off
the cushion,
3. If replacing non-adhesive sandpaper, release paper clamp by lifting up on each
lever,Then remove sandpaper,
4, Place levers back in locked position (see Steps 6 and 8 on Installing
Non-Adhesive Sandpaper).
NOTE: ALWAYS be sure that both levers are in the locked position before starting
sander,
5. CAREFULLY peel adhesive backing from the new 1/2-sheet sandpaper.
6. Place sandpaper in position. ALWAYS make sure that the front edge of the
sandpaper is carefully aligned with the front edge of the cushion,Then carefully
press the sticky side of the sandpaper onto the cushion°
NOTE: The sandpaper MUST be aligned with the front edge of the cushion in order
for the sander to properly function when flush sanding,
NOTE: We recommend that you clean the cushion occasionally by brushing it gently
with a small brush, Dust build-up on the cushion will cause the sandpaper to net stick
properly_
Fig 3
Cushion
Adhesive-Backed
10

PAPER PUNCH (See Figure 4)
A paper punch template has been supplied withyour sander, Itshould be used for
aligning and punchingholes in the sandpaper to align with the holes In the cushion.
Punching holes properly is a necessary step for your sander to collect the dust in the
dust bag°
Fig4
Orient Paper Punch
as shown
ATTACHING DUST BAG ASSEMBLY (See Fig, 5)
WARNING: To prevent the possibility of sanding dust or other
foreign objects being thrown into your face or eyes NEVER try to operate
your sander without the dust bag assembly properly Installed. Sanding dust
or foreign objects thrownintoyourface or eyes couldresult in serious personal
injury,
1. Unplug the sander,
I_ WARNING: Failureto unplug the sander could result in accidental
starting causing possible'serious Personat injury_ ,
2. Insert dust bag adapter intodust exhaust hole (see Fig, 5)°
3, Push in adapter until the raised edges on the top and bottom of the adapter snap
intothe grooves in the dust exhaust hole.
4. Your sander is now ready to use°
NOTE; For more efficient operation, we recommend that you empty the dust bag
when it is no more than half fulLThis will allow the air to flow through the bag better_
ALWAYS empty and clean the dust bag thoroughly when you've finished sanding
and before you store the sander,
Fig 5
i
Dust Bag
Dust
ExhaustHole
11

TO REMOVE AND EMPTY DUST BAG (See Fig. 6)
1. Unplug thesander.
L_ WARNING: Failure tounplug thesander could result in accidental
starting causing possible serious personal injury.
lllllll llllll lllllll lllll i ill ill i i i i
2. Remove dust bag assembly from sander by firmly holding the adapter and pulling
straight out.
3, Remove dust bag from adapter (see Fig. 6).
4. Shake dust bag to empty.
5oPlace dust bag back onto the adapter.
6, Attach dust bag assembly back onto sander.
Fig 6
I
Dust Bag
Dust ?/_
Exhaus!Hole
ATTACHING THE VACUUM HOSE ADAPTER (See Fig. 7)
Your sander includes a vacuum hose adapterthat easily attaches to the sander.
The adapter allows you to hook your sander up to your wet dry vac (sold separately).
1,Unplugthesander..
L_ WAR NING: Failure to unplug thesander could result in accidental starting
causing possible serious personal injury..
i
2, Remove dust bag assembly from the sander by firmly holding the adapter and
pulling itstraight out.
3. Insert vacuum hose adapter into the dust exhaust hole.
4. Push in adapter until the raised edges on the top and bottom of the adapter snap
into the grooves in the dust exhaust hole.
5, Firmly attach the vacuum hose adapter to your vacuum hose.
6. Attach vacuum hose to vac.
Fig 7
Dust Exhaust Hole
_ Vacuum
Hose Adapler
12

Before attempting to use any toot, be sure to familiarize yourself with all the
operating features and safety instructions,
iwARNING: IFAN', PARTSARE MISSING,DO ,,lOTOPERATEYOUR
SANDER UNTILTHE MISSING PARTS ARE REPLACED, FAILURETO
FOLLOWTHIS RULE COULD RESULT IN SERIOUS PERSONAL INJURY,
WARNING: DO NOT tet familiarity with your sander make you careless° I
Remember that a careless fraction of a second is sufficient to cause severe injury, I
WEAR YOUR Z_ WARNING: ALWAYS wear safety goggles or safety
glasses with side shield and a full face shield when
operating your sander,
Failure to do so could result in foreign objects being thrown into
your eyes, resulting in possible serious injury, If the sanding
operation isdusty, also wear a face or dust mask°
i,i I,IlllII,/ll,HIH/U,/,/,I IJ,H,H,,,H,,l,,,H,,,
APPLICATIONS
Only use your sander for the applications listed below.
1. Sanding wood surfaces with various grits of sandpaper.
2. Removing rust from steel surfaces with special sandpaper. ,i i H, 'Hlll,I /llll II,,_
!_ CAUTION: ALWAYS careful let hand cover the air vents, I
be not to your
i
I, ALWAYS clamp or otherwise secure the workpiece to prevent tt from moving
under your sander.
l"Z_"WARN'NG: Unsecured w°rk c°uld be thr°wn t°wards the °perat°r causing i,njury.
2. ALWAYS hold your sander in front and away from you, keeping it ctear of the
workpiece.
3. Start the sander by squeezing the trigger switch and then let the motor come up
to maximum speed_
4. Gradually lower the sander onto the workpiece with a slight forward movement°
(See Fig, 7°)
5. Move it slowly, using Fig 8
forward and backward
strokes°
13

SANDINGTIPS
1. DO NOT force the sander. The weightof the sander supplies adequate pressure_
Let the sander and the sandpaper do the work.
A. Applying additional pressure will only slow the motor, wear the sandpaper out
faster and reduce sander speed.
B. Excessive pressure will overload the motor and cause possible damage to the
sander from the motor overheating.
C. Excessive pressure will also result in inferiorwork°
2. Any existing finish or resin on wood may soften from the heat of the friction°
3. DO NOT sand in one spot for too long a time because the the sander's rapid
action may remove too much material and make the surface uneven.
SELECTING THE RIGHT SANDPAPER
NOTE:This sander has dust collection, so we recommend that you use sandpaper
with pre-punched holes that wilt line up with the holes in the cushion.
Selecting the correct grit and type of sandpaper is an extremely important decision
that wilt allow you to achieve the best quality sanding finish°
1. Aluminum oxide, silicon carbide and other synthetic abrasives are best for power
sanding.
2oNatural abrasives such as flint and garnet are too soft for economical use in power
sanding.
3. Coarse grit will remove the most material and finer grit will give you the best finish
in all sanding operations°
4. The condition of the surface to be sanded will determine which grit win do the job_
5. If the surface Is rough:
A. Start with a coarse grit and sand until the surface is uniform.
B. Then use medium to remove any scratches left by the coarse grit.
C. Then use a finer grit for finishing the surface.
NOTE: ALWAYS continue sanding with each grit until the surface is uniform°
NOTE: DO NOT use the sander without sandpaper. This will damage the cushion..
i n,,,,l,,,,,Huu,,,,lluulllll ul,uu,
WARNING: DO NOT wear loose clothing orjewelry when operating i
sander. They could get caught in moving parts, causing serious injury. Keep head I
away from sander and sanding area. Hair could be drawn into sander, causing
seriousinjury. I
14

ORBITAL MOTION (See Fig. 9)
As shown in Figure 9, the orbit of the sander is 1/10-inch in diameter so the
sandpaper moves in tiny circles at high speed°
This orbital action duplicates a "hand sanding" motion for more aggressive
sanding as you push the sander forward, This powerful orbital action is ideal
for heavy-duty sanding applications, such as:
1, Removing old finishes
2. Smoothing rough wood Fig 9
3, Sanding stock down to
required dimensions
4. Finishing surfaces that
are to be painted
1/10-inOrbitat Motion
FLUSH SANDING (See Fig. 10)
Your sander will allow you
to flush sand corners.
You can use the front and
sides or your sander for
flush sanding..DO NOT
use the rear of the sander
for flush sanding.
ALWAYS remove the
sander from the workpiece
before turning it off.
REMOVE PRESSURE-SENSITIVE SANDPAPER BEFORE STORAGE
DO NOT store your sander with pressure-sensitive sandpaper still attached. The
heat generated by sanding causes the pressure-sensitive adhesive to flow and form
a tight bond between the cushion and the sandpaper.
ALWAYS remove the sandpaper soon after you have finished sanding to avoid
adhesive set up,When sandpaper islefton the cushion for an extended period of
time after use, the adhesive will set up and make the sandpaper difficult to remove.
The sandpaper may tear when removing itoIf this happens it makes it difficult to
clean the cushion for the next piece of sandpaper_
NOTE" if you do forget to remove the sandpaper after sanding, run your sander for a
few minutes to soften the adhesive backing before you try'toremove thesandpaper
15

GENERAL
I Z_ WARN ING: T° av°id accidents' ALWAYSdisc°nnect thet°°l fr°m the 1
power source BEFORE cleaning or performing any maintenance°
/_, WARNING: When servicing a tool, ALWAYSuse only identical
replacement parts, Use ofany other parts may createa risk ofelectric shock or
injury and cause product damage.
All parts represent an important part of the double insulation system and should be
serviced only at a Sears Service Center.
Avoid using solvents when cleaning plastic parts° Most plastics are susceptible to
damage from various types of commercial solvents and may be damaged by their
use. Use clean cloths to remove dirt, carbon dust, etco
WARNING: DO NOT at anytimeletbrakefluids, gasoline,petroleum-based
products, penetrating oils, etc.tocome incontact with plastic parts.They contain
chemicals that can damage, weaken or destroy plastic.Use clean clothsto remove
dirt, carbon dust, etco
Itisa known fact that electric toolsare subject to acceleratedwear and possible
premature failure when they are used to work on fiber glass,
wallboard, spackling compounds or piaster.The chips and grindings from these
materials are highly abrasive to electrical toolparts, such as bearings, brushes,
commutators, etc Consequently, it is not recommended that this tool be used for
extended work on any fiber glass material, wallboard, spackling compound, or
plaster. During any use on these materials, itis extremely important that the toolis
cleaned frequently by [blowing with an air jet.
EXTENSION CORDS
The use of any extension cord will cause some tossof power. To keep theloss at a
minimum and to prevent overheating, use an extension cord that is heavy enough to
carry the current that the tool will draw°
A wire gauge (_,;WG)of at least 16 isrecommended for an extensioncord 100 feet
or less in length. When working outdoors ALWAYS use an extension cord that is
suitable for outdoor use.The cord's jacket will be marked WAo
i=L
IZ_ CAUTION: Keepextension cords away from thecutting area, and position
Ithe cord so itwill not get caught on lumber, tools, etc. during the cutting operation_
WARNING: Check extension cords before each use. If damaged, replace
it immediately_NEVER use a toolwith a damaged cord because touching the
damaged area could cause electrical shock, resulting in serious injury
= =
16

EXTENSION CORDS CONT.
Extension cords that are suitable for use with yoursander are available at your
nearest Sears Store,
i,,,,1,1,,1,,,,i,,i,,i,iH,i,ii,,,l,,ll,,i, i,illlllill i wL,_
WARNING: ALWAYS wear safety goggles or safety glasses with side
shields when using this too! or blowing dusL If operation ts dusty, also wear a dust
mask.
LUBRICATION
All of the bearings in this toolare lubricated with a sufficient amount of high-grade
lubricant for the life of the tool under normal operating conditions, Therefore, no
further lubrication isrequired,
The following recommended accessories are currently available at your local Sears
Store.
ALUMINUM OXIDE SANDING SHEETS WITH PAPER BACKING (1/2 SHEET):
X-Fine, Fine, Medium, Coarse
PRESSURE SENSITIVE ADHESIVE PAPER BACKED SHEETS (1/2 SHEET):
X-Fine, Fine, Medium, Coarse
THE FOLLOWING STANDARD 4V_.X 11-IN. SANDING SHEETS
CAN BE CUTTO FITYOUR SANDER
NON-LOADING ALUMINUM OXIDE SANDING SHEETS
X-Fine, Fine, Medium, Coarse
..... uu,1,1,,,,11,1,
!'_ wARN |NG : The use Of attachments Or accessories that are not I
recommended might be dangerous°
17

NOTES
18

Manual dei Usuario
Lijadora De Cojin
De 1/3 De Hoja
Modelo No.
172.27696
%
ATENCION: Lea, comprenda y siga todas
las Reglas de Seguridad y las instrucciones
en este manual antes de usar esta herramienta.
•SEGURIDAD
• FUNClONAMIENTO
• MANTENIMIENTO
Sears, Roebuck and Co., Hoffman Estates, IL 60179 EE.UU.

Garantia ..................................................................... P_.gtna 2
Instrucciones de Segurida ......................................... PAginas 3-7
Sfmbotos de Seguridad .............................................. PAglna
Descripci6n ................................................................ P_glnas 8-9
Montaje ...................................................................... P_.glna
Funcionamiento .......................................................... P_,glnas
Mantenimiento ............................................................ PAg_nas
Accesorios .................................................................. P_.glna
11
12-I3
14-15
16
GARANT[A COMPLETA DE UN AI_O DE LA HERRAMIENTA
PROFESIONAL CRAFTSMAN
Si esta herramienta profesional Craftsman no es de su total satisfacct6n
durante el primer aSo a partir de la fecha de compra, DEVUELVALA A LA
TtENDA SEARS MAS CERCANA EN ESTADOS UNIDOS y Sears la
reemplazar_ sin costo alguno.
This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
Sears, Roebuck and Co., Dept, 817 WA, Hoffman Estates, IL 60179
iCONSERVE ESTAS INSTRUCCIONES!
iLEA TODAS LAS INSTRUCCIONES!
2
