CRAFTSMAN
19.2 VOLT RECIPROCATING SAW
MODEL NO. 315.COHR1000
REPAIR SHEET

2
CRAFTSMAN 19.2 VOLT RECIPROCATING SAW — MODEL NO. 315.COHR1000
1
2
5
3
4See Note
Note: The assembly shown represents an important part of the double insulated system. To avoid the possibility of alteration or damage to the sys-
tem, service should be performed by your nearest Sears Repair Center. Contact your nearest Sears retail store for service center information.
Key Part
No. Number Description Qty.
1 690292006 Saw Blade (Metal Cutting) 1
2 690291006 Saw Blade (Wood Cutting) 1
3 940207041 Logo Label 1
4 940207042 Data Label 1
5 940207040 Warning Label 1
PARTS LIST

3
CRAFTSMAN 19.2 VOLT RECIPROCATING SAW — MODEL NO. 315.COHR1000
25
3
4
4
4
5
6
6
20
11 12 13
14
15 16 17 18 19
7
7
9
7
7
8
1
2
23
22
31
24
35
34
32
27
28
10
21
21
33
26
26
29
30
SECTION A

4
CRAFTSMAN 19.2 VOLT RECIPROCATING SAW — MODEL NO. 315.COHR1000
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding
your RECIPROCATING SAW or when ordering repair parts.
PARTS LIST FOR SECTION A
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 660414014 Screw (M4 x 20 mm) ..................................... 2
2 660414015 Screw (M4 x 14 mm) ..................................... 1
3 670030009 Spring Washer ............................................... 3
4 660024044 Screw (M4 x 16 mm) ..................................... 4
5 303726001 Gear Cover Assembly (Inc. Key No. 9)..........1
6 560020001 Rubber Pin.....................................................2
7 660439002 Screw (M4 x 8 mm, Hex Soc. Hd.)................4
8 303727001 Gear Case Assembly..................................... 1
9 672089001 Ball Bearing (606ZZ)...................................... 1
10 340171001 Front Cover....................................................1
11 6939601 Retaining Ring ............................................... 1
12 514778002 Spring Cover ................................................. 1
13 672186001 Torsion Spring ............................................... 1
14 691261001 Lock Pin.........................................................1
15 672200001 Sleeve............................................................1
16 672193001 Rear Cam ......................................................1
17 672192002 Front Cam......................................................1
18 672297001 Retaining Ring ............................................... 1
19 672250001 Shoe .............................................................. 1
20 902446001 Felt Seal......................................................... 1
21 303739001 Housing Assembly......................................... 1
22 632939001 Washer ..........................................................1
23 303738001 Bevel Pinion Assembly..................................1
24 562459001 O-Ring ........................................................... 1
25 270017383 Switch Assembly ........................................... 1
26 660208052 Screw (M4 x 16 mm) ..................................... 8
27 670998005 Spring ............................................................ 1
28 519154001 Lock-Off Button............................................. 1
29 6627201 Screw (M4 x 14 mm) .....................................1
30 940207042 Data Label .....................................................1
31 940207040 Warning Label ............................................... 1
32 940207041 Logo Label.....................................................1
33 230237001 Motor Assembly ............................................ 1
34 690291006 Saw Blade (Wood Cutting) ............................ 1
35 690292006 Saw Blade (Metal Cutting).............................1
NOT SHOWN:
987000933 Operator’s Manual
4-12-10
(Rev:03)

CRAFTSMAN 19.2 VOLT RECIPROCATING SAW —MODEL NO. 315.COHR1000
5
WIRING DIAGRAM
MOTOR
BLACK
CONTACT PLATE
SWITCH
RED
ORANGE
BLACK
BLUE
BLACK
RED
