PEDAL EXERCISER
ENTRENADOR DE PEDAL
English....Page 06
Español...Página 25
For review R7
Contents
Overview..............................................................................3
Use........................................................................................4
Product contents/Device parts............................................6
General information ............................................................7
Reading and storing the user manual...................................7
Explanation of symbols............................................................7
Safety ...................................................................................8
Proper use................................................................................. 8
Safety notes .............................................................................. 8
First use...............................................................................12
Checking the pedal exerciser and the product contents....12
Mounting the support feet .................................................... 12
Mounting the pedals .............................................................. 13
Inserting batteries .................................................................. 13
Indicators and functions of the computer........................... 13
Switching the computer on and off...................................... 14
Adjusting the level of resistance........................................... 14
Adjusting the pedal loops...................................................... 14
Workout.............................................................................. 14
Workout goals.......................................................................... 14
Important advice for an effective workout ......................... 14
Who can workout?...................................................................15
Exertion ....................................................................................15
Tips for an effective, healthy workout.................................. 15
Warm-up exercises..................................................................16
Stretching exercises................................................................16
Workout instructions............................................................... 17
Cleaning and maintenance ............................................... 18
Storage............................................................................... 19
Troubleshooting ................................................................ 19
Technical data.................................................................... 19
Disposal..............................................................................20
Disposing of the packaging.................................................. 20
Disposing of old appliances.................................................. 20
Warranty card .....................................................................21
Warranty condition............................................................ 22
Equipment parts list .......................................................... 23
For review R7
3
USA
A
1
2
3
4
6
5
®
For review R7
4
USA
B
7 8
9
10
11
12
C
For review R7
5
USA
FE G
D
613
15
4
min. 2 ft.
14
5
For review R7
6
USA
Product contents⁄Device parts
1Pedal exerciser
2Pedals, 2×
3Pedal receptacle
4Set screw
5Button
6Computer
7Spanner
8Hex key with cross-head screwdriver
9Cross-slotted screws, 4×
10 Washers, 4×
11 Large support foot (rear)
12 Small support foot (front)
13 Sensor
14 Locking screw
15 Pedal loop
The product contents include a type AAA 1.5 V battery.
For review R7
AFTER SALES SUPPORT
USA
General information
7
USA
General information
Reading and storing the user manual
This user manual accompanies this pedal exerciser. It contains import-
ant information on start-up and handling.
Before using the pedal exerciser, read the user manual carefully. This
particularly applies for the safety notes. Failure to comply with this user manual
may result in severe injury or damage to the pedal exerciser.
Store the user manual for further use. If you pass the pedal exerciser on to third
parties, please be absolutely sure to include this user manual.
Explanation of symbols
The following symbols and signal words are used in this user manual, on the
pedal exerciser or on the packaging.
WARNING!
This signal symbol/word designates a hazard with moderate risk, which may
result in death or severe injury if not avoided.
CAUTION!
This signal symbol/word designates a hazard with low risk that, if not avoided,
may result in minor or moderate injury.
NOTICE!
This signal word warns against potential damages to property.
This symbol provides you with useful supplementary information
on assembly or operation.
Do not use the device while standing!
The certified safety seal (GS mark) certifies that a product
meets the requirements of the German Product Safety Act
(ProdSG). The GS mark indicates that the safety and health of
persons will not be jeopardised if used in a proper or
foreseeable manner.
For review R7
Safety
USA
AFTER SALES SUPPORT
8
USA
(800) 407 1458
Safety
Proper use
The pedal exerciser is only designed for improving your fitness and stamina. It is
only intended for private use and is not suitable for commercial use.
Only use the pedal exerciser as described in this user manual. Any other use
is deemed improper and may result in damage to property or even personal
injury. The pedal exerciser is not a children’s toy.
The manufacturer or vendor cannot be held liable for damages incurred
through improper or incorrect use.
Safety notes
WARNING!
Danger for children and persons with impaired physical,
sensory or mental capacities (e.g. partially disabled
persons, older persons with reduced physical and mental
capacities) or lack of experience and knowledge (e.g.
older children).
− This pedal exerciser can be used by children, ages 14 and
above, as well as persons with impaired physical, sensory
or mental capacities or those lacking experience and
knowledge if they are supervised or have been instructed
in how to safely use the pedal exerciser and have
understood the risks associated with operating it. Children
must not play with the pedal exerciser and the parts.
Cleaning and user maintenance must not be performed
by unsupervised children.
− Do not leave the pedal exerciser unattended while in op-
eration.
− Do not allow children to play with the packaging material.
Children may get caught in it when playing and suffocate.
− Make sure that children do not swallow small parts like
screws.
For review R7
AFTER SALES SUPPORT
USA
Safety
9
USA
WARNING!
Danger of explosion!
Batteries may explode if they are excessively heated up.
− Don’t heat up the batteries and don’t throw them in an
open fire.
− Do not short circuit the batteries.
− Make sure that the batteries are inserted with the correct
polarity ( + and – ).
− Do not charge non-rechargeable batteries.
− Never mix batteries of different types or from different
manufacturers. Replace all batteries of a set at the same
time.
− Do not weld or solder directly on batteries.
− Do not disassemble the batteries.
− Keep batteries out of the reach of children.
− Do not allow children to change batteries if they are not
supervised.
− Store unused batteries in the original packaging and keep
them away from metallic objects.
− Take the batteries out of the pedal exerciser if you are not
using it for a prolonged period of time.
− Never touch leaky batteries without protection. Always
wear protective gloves when handling leaky batteries.
If leaked battery fluid comes into contact with your skin,
immediately rinse the affected area of your skin with
water. If the liquid comes into contact with your eyes or
mouth, immediately consult a physician.
− Batteries that are swallowed could pose a risk of death.
Keep batteries away from children.
For review R7
Safety
USA
AFTER SALES SUPPORT
10
USA
(800) 407 1458
CAUTION!
Risk of injury!
Make sure that you have read through these precautions so
that you do not injure yourself.
− Ask your family physician before using the pedal ex-
erciser. Pregnant women should be especially careful.
Ask your doctor to perform a general fitness check before
beginning any workout program.
− Consult with your doctor before your first workout if there
is a history of heart, circulatory, orthopedic or other health
problems.
− Discontinue workout immediately if dizziness, nausea,
chest pain or other unusual symptoms arise. Immediately
consult a physician.
− Always start your workout with a warm-up.
− Always wear appropriate sports wear and shoes when
working out with the pedal exerciser.
− Wear shoes with non-slip rubber soles.
− Always be aware of your body tension during your
workout. Always keep your back straight. Do not let your
buttocks sag and avoid arching your back.
− Once you finished your workout, leave the pedal exerciser
so that there is no risk of anyone injuring themselves on
protruding parts.
− An inappropriate exercise area can lead to injury. Make
sure that your exercise area has sufficient space, is level
and slip-proof.
− Make sure that the pedal exerciser is in a stable position.
Only work out on a solid, level and non-slip surface.
− Injury to health attributed to working out improperly or
excessively cannot be ruled out.
− If you experience pain, nausea, dizziness, feelings of
weakness or chest paints, immediately discontinue the
workout and consult your physician.
For review R7
AFTER SALES SUPPORT
USA
Safety
11
USA
− The body weight of the user must not exceed 220 lbs
(100 kg). Otherwise there is a risk of injury or damage to
property.
NOTICE!
Risk of damage!
Improper handling of the pedal exerciser may cause damage
to the pedal exerciser.
− The pedal exerciser is a class C device that is not suitable
for therapeutic or other commercial purposes. Only one
person may work out with the pedal exerciser.
− Before each use, check all parts, particularly the pedals,
for wear and also check to make sure they are secure.
− Have all defective parts replaced immediately; the pedal
exerciser must not be used until it has been repaired.
− Do not use the pedal exerciser while standing.
− The pedal exerciser must always be located on a flat, level
surface.
− This pedal exerciser is dependent on speed, that is, as the
number of rotations increases, the work done increases
and as the number of rotations decreases, the work done
decreases.
− The braking system for the pedal exerciser can be
adjusted with the set screw.
For review R7
First use
USA
AFTER SALES SUPPORT
12
USA
(800) 407 1458
First use
Checking the pedal exerciser and the product
contents
NOTICE!
Risk of damage!
If you are not cautious when opening the packaging with a
sharp knife or other pointy objects, you may quickly damage
the pedal exerciser.
− For this reason, be very careful when opening it.
1. Take the pedal exerciser 1out of the packaging and check whether the
pedal exerciser or the individual parts exhibit damages. If this is the case, do
not use the pedal exerciser. Contact the manufacturer at the service address
specified on the warranty card.
2. Check to make sure that the delivery is complete (see fig.A and B).
Mounting the support feet
Follow these instructions step by step to avoid errors when setting up and using
the device. The pedal exerciser is pre-assembled so it can be put together in
only a few steps.
1. Take the pre-assembled pedal exerciser 1out of the packaging and place
it on a stable, level base.
2. Fit the small support foot 12 on the front holder (see fig. C)
3. Put one washer 10 on each of the cross-slotted screws 9 .
The washers should prevent the cross-slotted screws from coming loose due
to vibrations produced when using the pedal exerciser.
4. Use the enclosed hex key with cross-head screwdriver 8to screw the
small support foot tight with two cross-slotted screws (see fig. C)
5. Repeat the last two work steps for the large support foot 11 on the rear
holder.
For review R7
AFTER SALES SUPPORT
USA
First use
13
USA
Mounting the pedals
The pedals and the pedal receptacles are marked with “L” for left and “R” for
right. Make sure that these marks match up when mounting the pedals.
− Insert the pedals 2in the pedal receptacles 3and use the enclosed
spanner 7to tighten the pedals. The right pedal marked with “R”
is tightened by turning it clockwise. The left pedal marked with “L” is
tightened by turning it counterclockwise.
Inserting batteries
1. Use a flat tool without sharp edges, e.g. a large flat-headed screwdriver
(see fig. D), to carefully lift the computer 6. Then carefully lift the computer
out of the frame.
2. Insert the battery with the correct polarity ( + and – ). Pay attention to the
specification on the battery and the battery compartment.
3. Make sure that the computer sensor 13 is correctly positioned in the
housing and put the computer back in place. The button 5must be
pointing down (see fig. D).
4. You must insert new batteries as soon as the display becomes dim. All saved
data will be deleted.
The pedal exerciser is now operational.
Indicators and functions of the computer
The computer has a two-line display for showing the different functions. The
speed is shown on the top line. Various indicators are available on the bottom
line.
Speed Speed in mph.
TIME Workout time in minutes and seconds.
ODO (Total counts) Total distance covered since the batteries were inserted.
RPM (Counts) Pedal revolutions per minute.
DIST (Distance) Distance in miles covered since starting the workout.
CAL (Calories) Approximate calories burned.
SCAN Every indicator appears for a few seconds.
For review R7
Workout
USA
AFTER SALES SUPPORT
14
USA
(800) 407 1458
Clearing the values
To clear all values, hold the button 5down for approx.
3 seconds.
Switching the computer on and off
The computer will automatically activate and start the measurement as soon as
you start your workout on the pedal exerciser. If the pedal exerciser is not used
for longer than 4 minutes, the computer will automatically switch off.
Adjusting the level of resistance
For an effective workout, you can adjust the level of resistance. To do so, simply
turn the set screw 4(see fig. E).
• Minus = less resistance (for beginners).
• Plus = more resistance (for advanced users and pros).
Adjusting the pedal loops
You can adjust the pedal loops as you like.
1. To loosen them, turn the locking screw 14 counterclockwise. Pull the pedal
loop 15 to adjust the length (see fig. F).
2. Then turn the locking screw clockwise to fix the length of the pedal loop.
Workout
Workout goals
• build muscle,
• improve overall fitness,
• improve stamina,
• improve overall well-being.
Important advice for an effective workout
• Workout regularly.
• Monitor your progress from workout to workout.
• Eat a balanced diet.
For review R7
AFTER SALES SUPPORT
USA
Workout
15
USA
Who can workout?
Generally speaking, any person in good physical health, whether young or old,
can work out to improve their fitness.
Exertion
CAUTION!
Risk of injury!
Start your workout slowly.
− You should not start your workout too abruptly. Before
you start with the actual exercises, you should begin
by warming up at a slower pace and with less exertion.
Towards the end of your workout, continue to work out for
several minutes at a reduced speed and lower exertion.
Finish by performing some exercises to loosen up.
The body, particularly your heart and circulatory system, need time to adjust
to the changes brought about by the workout. It is therefore very important to
start your workout at low exertion and to gradually increase it. You must also
be sure to take proper breaks both during the workout and after it. Begin by
working out at a pace that is pleasant for you. After regular training, you can
increase the duration of your workout or configure the pedal exerciser to make
your workout more challenging.
Tips for an effective, healthy workout
• Wear suitable clothing (e.g. a track suit) for your workout. It is important
that your clothing is comfortable and breathable.
• Never work out on a full stomach.
• Do not work out if you are already tired or exhausted.
• Always keep in mind that your body needs plenty of liquids during athletic
activity. Be sure to drink enough.
For review R7
Workout
USA
AFTER SALES SUPPORT
16
USA
(800) 407 1458
Warm-up exercises
In general, you should always warm up before performing any athletic activity.
Warming up stimulates and improves all performance-related physical and
mental faculties. Warming up properly also significantly reduces the risk of
injury. The movement from performing the following exercises will warm up
your major muscle groups.
Run easily on the spot or around the room for about 5–10 minutes. Include a few
twist and hip jumps.
Stretching exercises
The following exercises contain light, but effective movements for activating
your body, gently stimulating your circulatory system and limbering up your
joints. Perform the stretching exercises several times before each workout and
only once you have finished the warm-up exercises.
Calves:
Lean against a wall with both hands. Bend your right leg to the front while
keeping your left leg straight. Push your left heel all the way down to the floor.
Hold this position for approx. 15–20 seconds. Repeat this exercise with your left
leg.
Thighs:
Stand with your face to the wall and your right or left leg facing forward. Bend
your hips and support your entire weight on your hands. Keep your legs
straight at the same time. Hold this position for approx. 15–20 seconds. Repeat
this exercise with your legs the other way around.
Thighs:
Lean against a wall with your right hand. Hold your left foot with your left hand
and slowly pull it towards your buttocks. Pull your foot towards your buttocks
and not to the side. Hold this position for approx. 15–20 seconds. Repeat this
exercise with your right foot.
Back:
Stand straight and place your right arm behind your head. With your left hand,
hold your right elbow and gently pull the elbow while bending your torso to the
left. Do not bend your hips in the process. Hold this position for approx. 15–20
seconds. Repeat this exercise with your left arm.
For review R7
AFTER SALES SUPPORT
USA
Workout
17
USA
Back:
Lay down with your back on the floor. Cross your right leg over the left one and
slowly pull your knee towards the floor. At the same time, make sure that you do
not lift your shoulders off the floor. Hold this position for approx.
15 – 30 seconds. Repeat this exercise with your left leg.
Thighs⁄adductors:
Sit down on the floor. Hold both heels and push the soles of your feet together
so that they are touching. From your hips, bend forward while keeping your
back straight. Hold this position for approx. 15–30 seconds.
Back and shoulders:
Sit in an upright position on the floor with your legs crossed (crossed legged).
Fold your hands and stretch your arms over your head so that they are straight.
Keep your chin up at the same time. Hold this position for approx. 15–30 seconds.
Workout instructions
CAUTION!
Risk of injury!
Pay attention to any physical symptoms.
− Immediately stop your workout if you feel weak or dizzy.
Immediately consult your physician if you experience
nausea, pain in your chest or limbs, heart palpitations or
other symptoms.
Once you have warmed up, you can start performing the exercises.
For review R7
Cleaning and maintenance
USA
AFTER SALES SUPPORT
18
USA
(800) 407 1458
Leg muscles
Make sure you have enough unobstructed room!
There should be at least 2 feet (0.60 m) of space around the
workout area (see fig. G).
Place the pedal exerciser 1on a secure, level, non-slip floor and sit
down on a chair or armchair. Place your feet on the pedals 2. Make
sure that your feet are securely held by the pedal loops 15 and cannot
slip away. There should be enough space between the chair and the de-
vice so that you can keep one leg bent and the other extended. You can
start your leg workout. You can turn the pedals forwards or backwards.
Arm muscles
Place the pedal exerciser 1in front of you on a table. Firmly wrap your hands
around the pedals 2. You can start working your arms. You can turn the ped-
als forwards or backwards.
Cleaning and maintenance
NOTICE!
Risk of damage!
Improperhandlingofthepedalexercisermayresultindamage.
− Do not use any aggressive cleaners, sharp or metallic
cleaning utensils such as knives, hard scrapers or similar.
They could damage the surfaces.
1. At regular intervals (every 1–2 months) or after a prolonged period of not
using the pedal exerciser 1, check that all screws and plug connections
are secure and check wearable parts for visual signs of wear or breaks.
2. Wipe the pedal exerciser off with a damp cloth. Then let all parts dry
completely.
For review R7
AFTER SALES SUPPORT
USA
Storage
19
USA
Storage
Store the pedal exerciser and the accessories in a dry area at approx. 68 °F
(20 °C) so that they are not accessible for children.
Troubleshooting
Problem Possible cause Solution
There is no speed mea-
surement on the display
although the pedals are
moving.
The sensor is not
properly fitted in
the display holder.
Use a flat tool without sharp
edges e.g. a large cross-slotted
screwdriver, to carefully lift the
computer up. Then carefully
lift the computer out of the
frame. Turn the computer
over and correctly secure the
sensor in the display holder.
The batteries are
empty.
Insert new batteries.
Technical data
Model: ANS-15-038
Weight:
Weight of the flywheel system:
approx. 10.8 lbs (4.9 kg)
approx. 3.3 lbs (1.5 kg)
Dimensions: approx. 16.5 × 15 × 12.2 inches
(42 × 38 × 31 cm)
Product code: 93311
Housing material:
Support feet material:
Pedal material:
Crank material:
Flywheel:
Size of the LC display:
ABS
PP
TPR
Steel
Cast iron
approx. 2 x 2 inches (5 × 5 cm)
For review R7
Disposal
USA
AFTER SALES SUPPORT
20
USA
(800) 407 1458
Disposal
Disposing of the packaging
Sort the packaging before you dispose of it. Dispose of paperboard
and cardboard with the recycled paper service and wrappings
with appropriate collection service.
Disposing of old appliances
Old appliances may not be disposed of in the household garbage!
Should the pedal exerciser no longer be capable of being used at some point in
time dispose of it in accordance with the regulations in force in your federal
state or country. This ensures that old appliances are recycled in a professional
manner and also rules out negative consequences for the environment. For this
reason, electrical equipment is marked with the symbol shown here.
Please ensure your recycling information does apply to the local regulations and
the EPA recommendations (www.epa.gov).
Batteries and rechargeable batteries may not be disposed of with house-
hold waste!
As the end user you are required by law to bring all batteries and storage batter-
ies, regardless whether they contain harmful substances* or not, to a collection
point run by the city, county or state or to a retailer, so that they can be disposed
of in an environmentally friendly manner.
* labeled with: Cd = cadmium, Hg = mercury, Pb = lead
For review R7
Table of contents
Languages:
Other Crane Exercise Bike manuals
