Crane EE-0865 User manual

Adorable Humidifiers
1 GALLON/ 3.78 LITER
ULTRASONIC HUMIDIFIER
MODELS #EE-0865 through #EE-5058
PLEASE READ AND SAVE ALL INSTRUCTIONS TO ENSURE
THE SAFE AND EFFECTIVE USE OF THIS HUMIDIFIER.

1
TABLE OF CONTENTS
Table of Contents, Humidifier Models P. 1
Important Safety Instructions P. 2
General Safety Instructions P. 3
ist of Main Parts P. 4
Technical Specifications, Contents of
Packaging P. 5
Operation and Use P. 5-8
Maintenance P. 8-9
Trouble Shooting P. 9
Service Center P. 10
Warranty Information P. 11
Warranty Card P. 12
Order Form P. 13
HUMIDIFIER MODELS
This instruction manual applies to the following models of the Adorable Humidifiers
product line:
Animal T pe Model # Animal T pe Model #
Penguin EE-0865 Pig EE-4139
Elephant EE-3186 Cow EE-4140
Panda EE-3189 Duck EE-6369
Dog EE-3190 eopard EE-6524
Frog EE-3191 Dragon EE-5058
Tiger EE-7270
For information about all CRANE Humidifiers,
please visit http://www.crane-usa.com for retail outlet locations.

2
IMPORTANT SAFETY INSTRUCTIONS
Thank you for purchasing our CRANE Ultrasonic Humidifier. Each unit has been
manufactured to ensure safety and reliability. Before using for the first time, please read
the instructions carefully and keep them for further reference.
WARNING! READ AND SAVE THESE INSTRUCTIONS. Failure to follow all
of the instructions listed below may result in electric shock, fire and/or serious personal
injury.
1. Do not carr Water Tank b handle when it is filled with water. It is
advisable to carr filled Water Tank with two hands.
2. DO NOT operate outdoors. This humidifier is intended for indoor use onl .
3. Always have water in the Water Tank when operating the unit.
4. Use only clean, cool tap water to fill the Water Tank (filtered or distilled water is
recommended to avoid white dust if tap water is too hard; demineralization filters
are also available for purchase at www.crane-usa.com). DO NOT use hot water.
5. Be sure that the Water Tank Cap is firmly tightened on Water Tank. Always have
the Water Tank id in place while the unit is operating. Place the humidifier so the
mist aims away from children, walls, furniture and electrical appliances.
6. Use only a 110-120VAC outlet. ALWAYS plug and unplug unit with dr hands
to avoid electric shock.
7. Never operate the unit with a damaged Cord or Plug.
8. Always place the unit on a smooth, flat, lint-free, non-metallic, waterproof and
level surface and position unit away from direct sunlight. Keep the cord away from
heated surfaces and areas where it could be walked on or tripped over. Unplug the
unit when not in use and whenever you clean or move the unit.
9. Do not add medication of any type into the Water Basin or Water Tank. Do not
cover any openings on the unit or insert objects into any openings.
10. The unit should not be left unattended in a closed room as the air could become
saturated and leave condensation on walls or furniture. eave room door partly
open when humidifier is being operated.
11. When cleaning the inside of the humidifier, keep water away from the Fan Vent.
Turn off and unplug the humidifier to wipe the exterior (except the electrical
controls) with a damp cloth. Humidifier requires regular cleaning. Please refer to
the C EANING INSTRUCTIONS in this manual.
12. Do not tilt or tip the humidifier or attempt to empty or fill it while it is in operation.
13. Do not use a detergent to clean any parts of the unit that contain water. Detergent
film dissolved in the water supply can interfere with the output of the unit. Instead,
always use a few drops of white vinegar mixed with water to clean the humidifier.
SAVE THESE INSTRUCTIONS!

3
GENERAL SAFETY INSTRUCTIONS
WARNING! Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire or serious personal injury. The warnings,
cautions, and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the user that
common sense and caution are a factor which cannot be built into this product, but must
be supplied by the user.
THIS HUMIDIFIER IS NOT A TOY!
Do not let our child pla with this humidifier. Serious injury and
electrocution might be possible. This humidifier has to be operated by an adult only.
Children should be supervised to ensure that they do not play with the humidifier.
SAVE ALL INSTRUCTIONS!
CAUTION: A short Power Supply Cord is provided to reduce the risk of personal injury
resulting from becoming entangled in or tripping over a longer cord. Extension cords are
available from local hardware stores and may be used if care is exercised in their use. If
an extension cord is required, special care and caution is necessary. Also the extension
cord must be (1) marked with an electrical rating of 125 V and at least 13 A., 1625 W.,
and (2) the cord must be arranged so that it will not drape over the countertop or
tabletop where it can be pulled on by children or accidently tripped over.
ELECTRIC POWER
If the electric circuit is overloaded by other appliances, your humidifier and/or
appliances may not operate properly. The humidifier should be operated on a separate
electrical circuit from other operating appliances.
POLARIZED PLUG
This humidifier has a polarized plug (one blade is wider than the
other). As a safety feature to reduce the risk of electrical shock, this
plug is intended to fit in a polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to defeat this safety
feature.
SAFETY WARNING
Although your humidifier is easy to operate, for your safety, the below warnings must be
followed:
1. Do not place the humidifier near a heat source.
2. Never leave the humidifier unattended while connected to the electrical outlet.
3. To avoid any accidents, never cover the Mist Outlet Slots when the humidifier is in
operation.
4. Use the humidifier on a smooth, flat, lint-free, non-metallic, waterproof and level
surface away from water.
5. Do not unplug from the wall socket by pulling on the supply cord.
6. The humidifier must be unplugged:
A. Before either filling or emptying the Water Basin and/or Water Tank.
B. Before any cleaning or maintenance is performed.
C. After each use.
D. If it appears to be faulty.
THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY.

4
LIST OF MAIN PARTS
Fig. 1 (Central Body)
1. Central Body (water basin)
2. Control Knob ON/OFF
3. Power Indicator ight
(NOTE: Depending on the
model, your humidifier may
ha e one or two indicator
lights.)
1 2 3
Fig. 2 (Top of Water Tank)
4. Mist Outlet Channel
5. Water Tank Handle
(NOTE: Shape of Water Tank
depends on model #)
4 5
Fig. 3 (Water Basin)
6. Water evel Sensor
7. Nebulizer
8. Valve Opener
9. Fan Channel
10. Mist Chamber
(NOTE: Shape of Water Basin
depends on model #)
6 7 8 9 10
Fig. 4 (Bottom of Water Tank)
11. Water Tank Valve
12. Water Tank Cap
13. Mist Outlet Channel
(NOTE: Shape of Water Tank
depends on model #)
11 12 13
Fig. 5 (Water Tank Mist Lid)
14. Water Tank Mist id
15. Mist Output Slots
(NOTE: Shape of Central Body
depends on model #)
14 15

5
TECHNICAL SPECIFICATIONS:
Rating Voltage 120V
Frequency 60Hz
Water Tank Capacity Approx. 1.0 Gallon/3.78 iter
Output Per 24 Hours Approx. 2.1 Gallon/8 iter
Run Time Per Tank Max. up to 24 hours/Min 11 Hours
Humidifying Capacity Up to 250 sq.ft. /23 m2
Noise <36.5 (dB) A
CONTENTS OF PACKAGING
a. Instruction Manual
b. Central Humidifier Body
c. Water Tank
d. Water Tank Mist id with Mist Output Slots
If any of the above items are missing, please contact our Customer Service department
at 1-888-599-0992 (http://www.crane-usa.com) for replacement. Business hours:
Mon-Fri 9:00 am - 4:00 pm CT
OPERATION AND USE
BEFORE EACH USE
CHECK HUMIDIFIER PLACEMENT
Place the Humidifier on an elevated, non-metallic, lint-free, waterproof, level surface at
least 5 inches away from walls and heat sources.
DO NOT place on carpet or towel. The fan vent is located on the bottom of the water
basin. The fan vent MUST NOT be obstructed.
DO NOT place the humidifier on a wood surface or near furniture that can be damaged
by too much moisture.
CHECK WATER LEVEL SENSOR - Make sure that the Water evel Sensor is secured
properly.
CHECK FAN VENT
The Fan Vent is located on the bottom of the humidifier. The purpose of the Fan Vent is
to blow the cool mist through the Mist Outlet Slots. It is important that this part be kept
clean and free of obstructions. We recommend checking the fan vent before using this
item (i.e., free of lint, paper, etc.).
Do not place the humidifier on top of a towel or a carpeted surface. The Fan
Vent on the bottom ma become blocked and overheat the humidifier!
CAUTION:
DO NOT operate the humidifier without water in the Water Tank.
DO NOT plug or unplug the Power Cord with wet hands as electric
shock could occur.

6
ASSEMBLY
ALWAYS use fresh cool water when operating the humidifier.
1. ift the Water Tank off the Central Body.
2. Turn over the Water Tank and unscrew the Water Tank
Cap at the bottom of the tank by turning it
counterclockwise.
3. Fill Water Tank with cold water. DO NOT fill water all the
way to the rim. DO NOT CARRY FULL WATER TANK
BY HANDLE. ALWAYS HOLD WATER TANK WITH
TWO HANDS ON EITHER SIDE OF WATER TANK.
Note: To avoid possible white dust accumulation due to
hard water, it is recommended to use filtered or distilled
water. Use of an optional Crane Demineralization Filter is
available at www.crane-usa.com.
DO NOT use hot water. Use cool tap water.
DO NOT add any medication or other additives to the
water.
DO NOT pour water into Mist Outlet Channel.
4. Replace the Water Tank Cap by aligning the threads on
the Water Tank with the threads on the Cap and turning
it clockwise.
5. Turn the Water Tank over and place the full Water Tank on the Central Body, making
sure it fits perfectly. Place the Water Tank Cap with Mist Output Slots on top of the
Water Tank.
Note: Do not attempt to move the humidifier while Water Tank is placed on the
Water Basin. Doing so may cause leakage of water. Also do not place humidifier on
the floor. Place humidifier on an elevated, non-metallic, lint-free, waterproof, level
surface for best performance.
6. Plug the Power Cord into a wall socket and turn on the unit by using the Control
Knob.
7. The indicator light will turn to red. In a few seconds it will switch to green, indicating
that there is enough water in the Water Basin. Mist will begin emitting through the
Mist Output Slots.

7
8. Use the Control Knob to adjust the intensity of the mist output. Turning the knob
clockwise will increase the moisture output. Turning the knob counterclockwise will
reduce the moisture output.
Note: When set at the maximum level, it is normal to hear a faint dripping sound.
9. When the humidifier runs out of water, the indicator light will turn red and the mist
output will stop. This is a safety feature to prevent the humidifier from possibly over-
heating and damaging the Nebulizer. This safety feature uses a Water evel Sensor
to stop the Nebulizer once the water level sinks below the required level in the Water
Basin. Turn the humidifier off and unplug the unit before removing and refilling the
Water Tank. Please note that the indicator light on the humidifier water
basin will stay on. The (red) light indicates that the humidifier is turned on
and needs to be refilled.
INSERTING OPTIONAL HUMIDIFIER FILTER
(Filters are not included with the humidifier and can be purchased
separately from Crane USA.)
A humidifier filter is an optional accessory for your Crane Cool Mist Humidifier. Filters
are used to reduce white dust caused by hard water.
Soak humidifier filter in water for 30 minutes to activate
performance. Place humidifier filter inside Water Tank.
NOTE: Do not leave the filter inside humidifier longer
than the recommended time. (See filter instructions on
filter box packaging.)
SET THE CORRECT HUMIDITY OUTPUT
Alwa s place the humidifier on an
elevated, non-metallic, lint-free,
waterproof, level surface for best
performance.
Adjust the Control Knob so that the
mist rises up to be absorbed by the
room air. Do not set Control Knob too
high as the mist cannot be absorbed by
the air and may accumulate on the
surfaces around the humidifier.
If the humidifier is placed near a fan or
air conditioning outlet the mist may be
forced down by the foreign air stream.
Change the location of the humidifier or
reduce the output of the other room
conditioning appliances.
correct
wrong

8
A NOTE ABOUT HUMIDITY
It is best to keep the humidity level at about 40%-50% of relative humidity.
The comfort level of humidity will vary from room to room and with changing room
conditions.
In cold weather, windows and even some walls may fog or develop frost from
excessive indoor humidity. If this occurs, reduce the mist intensity setting to avoid
damage from condensed water dripping onto windowsills.
Too much humidity in the room may allow moisture to accumulate on surfaces where
bacteria and fungi can grow. Moisture that gathers may also damage furniture and
walls, especially wallpaper.
To reduce excessive humidity, especially in small rooms, leave the room door open
and adjust the mist intensity control setting.
MAINTENANCE
It is important to keep Cool mist humidifiers clean. Cleaning and disinfecting on a
regular basis is important for maintaining the performance of your humidifier
DO NOT leave water in Water Tank or Water Basin when unit is not in use as it
ma result in the build up of mineral deposits and bacteria that can inhibit the
output efficienc of the humidifier. PLEASE NOTE that if water remains in the
Water Tank for more than a da or two, bacterial growth is possible.
DAILY MAINTENANCE
1. Always turn off and unplug humidifier from outlet before cleaning.
2. Empty water from the Water Tank and Water Basin daily.
3. Wipe and dry Water Basin with a clean, dry cloth or paper towel.
4. Replace the clean Water Tank on the Water Basin. You are now ready to use your
humidifier.
WEEKLY MAINTENANCE
1. Always turn off and unplug humidifier from outlet before cleaning.
2. Remove the Water Tank from the Central Body and empty the water from both
the Water Tank and the Water Basin.
3. Fill the Water Tank with ½-gallon of warm water. Add 2 Tablespoons of white
vinegar. Shake vigorously and allow to sit for 20 minutes. Shake vigorously
again and empty the water. Rinse the Water Tank a few times to get rid of the
vinegar smell.
4. Make the same white vinegar water solution and pour into the Water Basin. et
sit for 20 minutes then empty. Rinse with only water a few times to remove any
vinegar smell. Wipe dry with a clean soft cloth.
5. Wipe the exterior surfaces of Water Tank and Water Basin with a soft, dry cloth.
NEVER IMMERSE WATER BASIN IN WATER.
END-OF-SEASON MAINTENANCE
1. Remove the Water Tank from the Central Body. Empty the water from the Water
Tank and the Water Basin.
2. Disinfect Water Tank and Water Basin with the white vinegar and water solution
described above.
3. Make sure that Water Tank has air dried without the Water Cap secured.
4. Make sure the Water Basin and Water Tank are completely dry before end-of-
season storage. Store the humidifier in a cool dry place.

9
Water Level Sensor
To clean the water level sensor unscrew or snap off, depending on style, the plastic cap
from the pin. Remove the water level sensor float and clean by wiping the parts with a
soft damp cloth. Replace the parts by first putting the water float onto the pin and re-
screwing the plastic cap onto pin.
TROUBLE SHOOTING
CAUTION: DO NOT attempt to repair the motor or nebulizer ourself. If the
humidifier continues to not operate please call our service center (1-888-599-
0922).
Problem
Solution
Humidifier power light is staying red and
not turning green
Humidifier is working than stops
Ensure that the water tank cap is
secured properly to water tank.
Empty out water in water basin. Place
filled water tank on to empty water
basin.
Clean Water evel Sensor.
If humidifier does not work at all
Ensure unit is properly plugged into a
power outlet.
Check that the Control Knob is turned
to the ON position.
If Power On indicator light does not
come on, contact Crane service center.
If there is a strange odor
Clean the Water Tank with the water
and vinegar solution and rinse with
clean water.
eave the empty Water Tank open for
some time (without the Water Tank
Cap attached) in a cool place.
The power light is green, but there is no
mist being emitted
Check that there is water in the Water
Tank.
Make sure that nothing blocks the Mist
Output Slots.
Check that the Fan Vent on the bottom
of the humidifier is not blocked.
Empty the humidifier and rinse the
Water Basin with cool tap water and
allow to dry for 15 to 30 minutes
before resuming normal operation.
Check for possible mineral deposits on
the Water evel Sensor or the
Nebulizer.
White dust appears and settles outside the
humidifier
Area tap water may have too many
minerals. Change to filtered or distilled
water or purchase and add a Crane
filter to the humidifier unit.
