Crane Weinman ULL Series User manual

A Crane Co. Company
INSTALLATION AND OPERATION MANUAL
SOLIDS HANDLING DRY PIT PUMPS
FOR LIFT STATION SERVICE
IMPORTANT! Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notification.
420 Third Street 83 West Drive, Bramton
Piqua, Ohio 45356 Ontario, Canada L6T 2J6
Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone]
www.cranepumps.com Form No. 119981-Rev. E
Series: ULL and ULL-VM
Section: 1420
Manual Index

2
Please Read This Before Installing Or Operating Pump.
This information is provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS. To help recognize this information,
observe the following symbols:
IMPORTANT! Warns about hazards that can result
in personal injury orIndicates factors concerned with
assembly, installation, operation, or maintenance which
could result in damage to the machine or equipment if
ignored.
CAUTION! Warns about hazards that can or will cause minor
personal injury or property damage if ignored. Used with symbols
below.
WARNING! Warns about hazards that can or will cause serious
personal injury, death, or major property damage if ignored. Used
with symbols below.
Only qualified personnel should install, operate and repair
pump. Any wiring of pumps should be performed by a qualified
electrician.
WARNING ! To reduce risk of electrical shock, pumps
and control panels must be properly grounded in
accordance with the National Electric Code (NEC) or
the Canadian Electrical Code (CEC) and all applicable
state, province, local codes and ordinances. Improper
grounding voids warranty.
WARNING! To reduce risk of electrical shock, always
disconnect the pump from the power source before
handling or servicing. Lock out power and tag.
WARNING! Operation against a closed
discharge valve will cause premature bearing
and seal failure on any pump, and on end
suction and self priming pump the heat build
may cause the generation of steam with resulting dangerous
pressures. It is recommended that a high case temperature
switch or pressure relief valve be installed on the pump body.
CAUTION ! Pumps build up heat and pressure
during operation-allow time for pumps to cool
before handling or servicing.
WARNING ! Do not pump hazardous materials
(flammable, caustic, etc.) unless the pump is specifically
designed and designated to handle them.
WARNING ! Do not wear loose clothing that may
become entangled in moving parts.
WARNING ! Keep clear of suction and discharge
openings. DO NOT insert fingers in pump with power
connected.
Always wear eye protection when working on pumps.
Make sure lifting handles are securely fastened each
time before lifting. DO NOT operate pump without safety
devices in place. Always replace safety devices that
have been removed during service or repair. Secure the
pump in its operating position so it can not tip over, fall
or slide.
DO NOT exceed manufacturers recommendation for
maximum performance, as this could cause the motor
to overheat.
WARNING ! To reduce risk of electrical shock, all wiring
and junction connections should be made per the NEC
or CEC and applicable state or province and local
codes. Requirements may vary depending on usage
and location.
WARNING! Products returned must be cleaned,
sanitized, or decontaminated as necessary prior to
shipment, to insure that employees will not be exposed
to health hazards in handling said material. All Applicable
Laws And Regulations Shall Apply.
Bronze/brass and bronze/brass fitted pumps may
contain lead levels higher than considered safe for
potable water systems. Lead is known to cause cancer
and birth defects or other reproductive harm. Various
government agencies have determined that leaded
copper alloys should not be used in potable water
applications. For non-leaded copper alloy materials of
construction, please contact factory.
Crane Pumps & Systems, Inc. is not responsible for
losses, injury, or death resulting from a failure to observe
these safety precautions, misuse or abuse of pumps or
equipment.
SAFETY FIRST!
Hazardous fluids can
cause fire or explo-
sions, burnes or death
could result.
Extremely hot - Severe
burnes can occur on contact.
Biohazard can cause
serious personal injury.
Hazardous fluids can Hazard-
ous pressure, eruptions or ex-
plosions could cause personal
injury or property damage.
Rotating machinery
Amputation or severe
laceration can result. Hazardous voltage can
shock, burn or cause death.
Other brand and product names are trademarks or registered trademarks of their respective holders.
Weinman® is a registered trademark of Crane Pumps & Systems, Inc.
1997, 7/06, 9/06 Alteration Rights Reserved

3
A - GENERAL INFORMATION
TO THE PURCHASER:
Congratulations! You are the owner of one of the finest
pumps on the market today. These pumps are products
engineered and manufactured of high quality components.
With years of pump building experience along with a
continuing quality assurance program combine to produce
a pump which will stand up to the toughest applications.
Check local codes and requirements before installation.
Servicing should be performed by knowledgeable pump
service contractors or authorized service stations.
RECEIVING:
Upon receiving the pump, it should be inspected for
damage or shortages. If damage has occurred, file a claim
immediately with the company that delivered the pump.
If the manual is removed from the crating, do not lose or
misplace.
STORAGE:
Short Term - Pumps are manufactured for efficient
performance following long inoperative periods in storage.
For best results, pumps can be retained in storage, as
factory assembled, in a dry atmosphere with constant
temperatures for up to six (6) months.
Long Term - Any length of time exceeding six (6) months,
but not more than twenty four (24) months. The units
should be stored in a temperature controlled area, a roofed
over walled enclosure that provides protection from the
elements (rain, snow, wind blown dust, etc..), and whose
temperature can be maintained between +40 deg. F and
+120 deg. F. Pump should be stored in its original shipping
container and before initial start up, rotate impeller by hand
to assure seal and impeller rotate freely.
SERVICE CENTERS:
For the location of the nearest Weinman Service Center,
check your Weinman representative or Crane Pumps &
Systems, Inc., Service Department in Piqua, Ohio, telephone
[phone] or Crane Pumps & Systems Canada, Inc.,
Bramton, Ontario, [phone].
B - INSTALLATION
These pumps are designed for pumping raw or treated
sewage, light sludge, Industrial wastes, drainage and
similar liquids containing solids.
MOUNTING:
The pump has been assemble, adjusted and lubricated
at the factory before shipment. Refer to “Lubrication” for
proper lubrication of the shaft seal and motor bearings.
Pumps may be installed on any sufficiently solid support
since pump and motor are rigidly aligned. The Fig. 7171-
7172 series pumps may be mounted in a vertical position,
with the motor above the pump liquid end, if vertical
mounting is preferred.
PIPING:
Suction and discharge piping should be direct with as
few fittings as possible. Pipe and fittings must be properly
supported near the pump so their weight does not
cause strain on the pump flanges. DO NOT pull pipes
into position with flange bolts as this may cause pump
misalignment. Flexible connectors should have limiting
bolts to contain hydraulic forces.
PUMP ROTATION:
Pumps may be furnished for right hand (clockwise) or left
hand (counter-clockwise) rotation when viewed from above
the motor. See rotation arrow and pump name-plates.
Connect power leads to motor according to motor wiring
diagram and jog starter testing for rotation. If rotation is
incorrect, rotation may be reversed by interchanging any
two main power leads at starter (3 phase only).
PRIMING:
It is important that all trapped air be removed from the
suction pipe and pump casing before operating the pump.
A. On Fig. ULL remove the pipe plug (216) at the top
of the casing (1)
B. On Fig. ULL-VM remove pipe plug (208) from
adapter (71). Replace pipe plug after the liquid rises
and displaces all air.
LUBRICATION:
These pumps are normally fitted with a double mechanical
shaft seal. The seal chamber of the adapter (71) must be
pressurized with a clean, compatible liquid to cool and
lubricate the seal faces.
For optimum service, the liquid should be circulated thru
the seal chamber at a pressure equal to or 15 to 20 PSI
higher than the maximum pressure at the pump discharge.
Lubrication may be provided by one of the following
methods.
A. With liquid from the pump discharge to the seal
chamber thru a filter assembly having a 25 micron
filter.
B. With clean compatible liquid, under pressure, from
an outside source.
C. With water seal unit to provide clean water, under
pressure, from a potable source of supply.
Motor bearings should have periodic lubrication and
inspection according to the motor manufacturer’s
recommendations.

4
IMPELLER ADJUSTMENT:
Eventual impeller wear or impeller replacement may
require adjustment of the clearance between impeller
inlet and face of the suction cover (9). Recommended
clearance at this point is .020” and is maintained by
varying the thickness of the casing gasket set (283). A
spare set of gaskets (283) having thickness from .005” to
1/16”, should be available at all times. To adjust clearance,
proceed as follows:
1. Disconnect power to motor and remove power
leads to motor.
2. Unscrew casing capscrews (212) and remove
motor and rotating assembly from casing (1).
3. Hold a straight edge across the impeller (2) inlet
and measure the distance from the straight edge to
the machined face of the flange of the adapter (71).
4. Next place the straight edge across the top of the
casing (1) and measure the distance from the
straight edge to the face of the suction cover (9) at
the inlet.
5. The difference between the two dimensions
indicates the required gasket thickness minus
.020”. Make up gasket set (283) equal to twice this
thickness as gaskets will compress about half their
original thickness when installed.
NOTE: If pump has been disconnected from the suction
and discharge piping, a feeler gauge may be inserted
thru the suction inlet to measure the impeller to suction
clearance.
6. Place gasket set (283) on casing (1) or adapter
(71) and mount rotating assembly onto casing.
Replace and tighten cap screws (212).
GENERAL MAINTENANCE:
Unless the casing (1) or suction cover (9) is damaged, it is
not necessary to disconnect suction or discharge piping,
however, if suction cover wearing ring (when furnished) is
to be replaced, it is advisable to remove the suction cover
from the pump.
To completely dismantle the pump, follow to order listed
below or select sections applicable to make required
repairs. All gaskets and o-rings should be replaced with
new parts at reassembly.
DISASSEMBLY:
A. To inspect or replace impeller and suction cover,
impeller or suction cover rings (if furnished). Remove drain
plugs and any external piping.
Fig. ULL
1. Remove capscrews (215) and suction cover (9).
2. Remove capscrews (212) and casing (1).
3. Unscrew and remove impeller screw (26) and
impeller washer (270). It may be necessary to
block the impeller (2) while turning the impeller
screw,
4. Insert pry bar behind the impeller shround (2) and
carefully exert pressure against the impeller at
several points, forcing the impeller from the shaft.
Fig. ULL-VM
1. Place support under the suction elbow (57) and
remove capscrews (226) then remove cap screws
and washers (221 and 229) from base (53).
2. Lift pump from base. Proceed as above to
dismantle liquid end.
B.Wearing Rings
Fig. ULL - 7181-82
If pump is fitted with wearing rings on suction cover (9) or
impeller (2), these may be replaced as follows:
1. Impeller wearing ring (not shown) is pressed onto
the impeller at the suction inlet. Place a wedge
tipped or pointed cold chisel against the wearing
ring and tap chisel sharply with a hammer, forcing
the wearing ring from impeller.
2. Install new wearing ring by pressing it onto the
impeller.
3. Suction cover wearing ring (not shown) is held in
position by machine screws. Remove original
machine screws from wearing ring and press
wearing ring from suction cover.
4. Press new wearing ring into suction cover, aligning
mounting holes with tapped holes in cover and
insert and tighten machine screws which must be
flush with the surface of the wearing ring.
DETAILS OF DOUBLE SEAL ASSEMBLY OPTIONAL WEARING RING CONSTRUCTION
Item
No.
Name Of Part
8
25
Impeller Wearing Ring
Suction Cover Wearing Ring

5
C. Mechanical Shaft Seal:
Fig. ULL, ULL-VM
1. To inspect or replace mechanical shaft seal (89)
proceed with removal of casing and impeller.
CAUTION: Do Not scratch or chip the lapped
faces of the seal parts as this will prevent
proper sealing.
2. Unscrew the machine screws (245) and remove
seal retainer (230).
3. Remove capscrews (219) and carefully slide the
adapter (71) and double seal (89) from the motor
and shaft sleeve (14). NOTE: It may be necessary
to firmly twist the exposed end of the rotating seal
assembly to break the seal between the seal
bellows and the shaft sleeve. The inboard seal seat
and rotating assembly will be removed with the
adapter (71).
4. With a tube of the proper size, push the stationary
seal seat from the adapter (71) and seal retainer
(230).
5. Deflector (40) may now be removed.
D. Shaft Sleeve Removal
Shaft sleeve (14) is mounted on the motor shaft by means
of heat shrink fit. To remove the shaft sleeve, dismantle the
liquid end and seal assembly as in A and C and proceed
as follows:
1. With a hand grinder and thin grinding wheel
(approx. 1/8” wide), cut a groove axially along the
sleeve to the shoulder of the motor shaft. Grind
groove as deep as possible (over 2/3 of sleeve
wall) without damaging the motor shaft.
2. After groove has been cut, place a block support
under shaft sleeve and insert a wedge tipped cold
chisel into the groove at the impeller end of the
sleeve. Tap chisel sharply with a hammer until a
crack occurs along the base of the groove.
3. Pry the groove apart and remove the sleeve from
the motor shaft.
REASSEMBLY
E. Shaft Sleeve Replacement
1. After old sleeve has been removed clean shaft
with rmery cloth and wipe thoroughly to remove
metal particales also wipe inside of new sleeve to
be sure that it is clean.
2. Note that new shaft sleeve (14) is chamfered on
end. This end will be installed toward the motor.
3. Place the shaft sleeve in a preheated oven set
at 650ºF to 700ºF for 1½ hours to allow sleeve to
heat uniformly and expand.
4. Place motor in a vertical position with impeller end
of shaft upward.
5. Remove shaft sleeve from the oven and drop
sleeve, chamfered end first, over the shaft; making
certain that end of sleeve is seated against
shoulder of motor shaft.
Note: This operation must be done rapidly without
allowing the shaft sleeve to cool. Do Not allow the
sleeve to stop before it is properly seated.
6. Hold shaft sleeve snug against the shaft shoulder
until shrink begins. Allow the sleeve to cool below
100ºF before proceeding with pump assembly.
7. Replace deflector (40) on the motor shaft.
F. Installing Shaft Seal (89)
If reinstalling old seal, carefully inspect the lapped faces
of the seal members and bellows for damage or wear
and replace if worn. Seals are available as complete seal
assembly only.
Before installing the seal remove any burrs or nicks from
shaft sleeve (14) or exposed end of motor shaft also clean
seal cavity of adapter and retainer.
1. Oil the outer surface of the seal seat o-ring; cover
the seal face with cardboard or heavy paper and
carefully press seat into the adapter (71) with a
piece of tubing having end cut square. Wipe face
of seat.
2. Repeat above, installing seal seat in seal retainer
(230).
3. Lightly oil the shaft sleeve and inside of the seal
bellows. Slide the adapter (71) over the shaft and
replace capscrews (219). Slide the seal rotating
assembly over the shaft sleeve (using a piece of
tubing slightly larger than the shaft sleeve) and
position against seal seat.
4. Replace gasket (233) on seal retainer (230) and
mount on adapter with machine screws (245).
Rotate shaft several times to seat seal faces.
5. Test seal for leakage by applying 20 PSI of water
pressure to seal cavity thru pipe nipple (271).
G. Liquid End
1. Spread a drop of Locite® #601 over the exposed
end of motor shaft and insert impeller key (32) into
the keyway.
2. Clean bore of impeller hub with emery cloth and
wipe clean. Replace impeller (2) on end of motor
shaft. If fit of the impeller onto the shaft is tight,
heat impeller in an oven to 200F to 250F before
placing on shaft. Be sure impeller is seated against
end of shaft sleeve (14).
CAUTION! - DO NOT drive the impeller onto the
shaft as this may damage motor bearings and
shaft seal.
3. Refer to impeller Adjustment and place proper
gasket (283) on casing (1) or adapter flange (71)
and replacing casing capscrews (212).
4. Place gasket (73) on casing (1) or suction cover
(9) and attach suction cover to casing with
capscrews (215). Replace drain plugs and any
external piping to seal chamber.

6
Fig. ULL-VM
Mount assembled pump on base (53), reversing
disassembly instructions.
5. Install pump according to instruction on pages 3
and 4.
SERVICE GUIDE
TROUBLE AND CAUSE REMEDY
1. Failure to pump
a. Pump not properly primed
b. Suction lift too great
c. Speed too slow
d. Motor running in wrong direction
a. Be sure that pump case and suction line are full of water. See priming
instructions.
b. Locate the pump closer to the water source. Make sure that the suction
piping diameter is large enough.
c. Check the voltage at motor terminals and at the meter when the pump is
operating. Check for loose connections. If voltage is low, contact your
Power company. Be sure that wire size is adequate.
d. Check the wiring diagram on the motor nameplate. If it is a 3-Phase
motor, refer to the Wiring instructions.
2. Reduced Capacity and/or Head
a. Clogged impeller
b. Air pockets or leaks in suction line
c. Strainer too small or clogged
d. Insufficient subergence of suction
pipe
e. Excessive suction lift
f. Excessively worn impeller
a. Remove and clean
b. Check the line for air leakes for excessive lift.
c. Check the end of the suction pipe or foot valve to see that it is not plugged
or buried in mud or sediment. When installing in pond or lake, support the
suction line so that it will be submerged in water, but nut imbedded in mud
or sediment. A strainer with greater screen area may be required.
d. Add sufficient pipe to keep the submerged end well below
the water surface.
e. If caused by suction pipe friction, increase the size of the pipe; otherwise
move the pump closer to the water level.
f. Order replacement parts. See repair list.
3. Pump Losses Prime
a. Air leaks in suction line
b. Excessive suction lift and
operating too near shut-off point
c. Water level drops while pumping,
exposing suction pipe or strainer
a. Check suction piping. Piping might have frozen, causing it to split.
b. Move the pump closer to the water level.
c. Check the water supply. Add a length of pipe to the suction line to keep the
submerged end under water.
4. Motor Will Not Start
a. Blown fuses
b. No electric current at motor
c. Motor hums but will not start
d. Motor damaged by lightning or
voltage surge
a. Replace with new fuses.
b. The power supply may be off, the connections may be loose or incorrect,
or the wire may have been chewed by rodents.
c. Turn power off. Check the rotating element of the pump to see that it turns
freely.
d. Take the motor to any authorized motor repair shop

7
Item No. Name Of Part
1
2
9
14
*26
32
40
53
57
59
71
*73
*89
208
212
215
216
217
218
219
220
221
223
224
226
*227
228
229
230
231
*233
240
245
264
*270
271
*283
Casing
Impeller
Suction Cover
Shaft Sleeve
Impeller Screw
Impeller Key
Deflector
Base
Suction Elbow
Handhole Cover
Adapter - Seal Head
Gasket
Shaft Seal
Pipe Plug
Cap Screw
Cap Screw
Pipe Plug
O-ring
Cap Screw
Cap Screw
O-ring
Cap Screw
Handhole Cover
Cap Screw
Cap Screw
Gasket
Motor
Washer
Seal Retainer
Pipe Plug
Gasket
Pipe Plug
Machine Screw
Pipe Plug
Impeller Washer
Pipe Nipple
Gasket (Set)
(*) Recommended Spare Parts
Figure ULL
Figure ULL-VM

A Crane Co. Company 420 Third Street 83 West Drive, Brampton
Piqua, Ohio 45356 Ontario, Canada L6T 2J6
Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone]
www.cranepumps.com
Limited 24 Month Warranty
Crane Pumps & Systems warrants that products of our manufacture will be free of defects in material and workmanship
under normal use and service for twenty-four (24) months after manufacture date, when installed and maintained
in accordance with our instructions.This warranty gives you specific legal rights, and there may also be other rights
which vary from state to state. In the event the product is covered by the Federal Consumer Product Warranties Law
(1) the duration of any implied warranties associated with the product by virtue of said law is limited to the same
duration as stated herein, (2) this warranty is a LIMITED WARRANTY, and (3) no claims of any nature whatsoever
shall be made against us, until the ultimate consumer, his successor, or assigns, notifies us in writing of the defect,
and delivers the product and/or defective part(s) freight prepaid to our factory or nearest authorized service station.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply.
THE SOLE AND EXCLUSIVE REMEDY FOR BREACH OF ANY AND ALL WARRANTIES WITH RESPECT TO ANY
PRODUCT SHALL BE TO REPLACE OR REPAIR AT OUR ELECTION, F.O.B. POINT OF MANUFACTURE OR
AUTHORIZED REPAIR STATION, SUCH PRODUCTSAND/OR PARTS AS PROVEN DEFECTIVE. THERE SHALLBE
NO FURTHER LIABILITY, WHETHER BASED ON WARRANTY, NEGLIGENCE OR OTHERWISE. Unless expressly
stated otherwise, guarantees in the nature of performance specifications furnished in addition to the foregoing material
and workmanship warranties on a product manufactured by us, if any, are subject to laboratory tests corrected for
field performance. Any additional guarantees, in the nature of performance specifications must be in writing and such
writing must be signed by our authorized representative. Due to inaccuracies in field testing if a conflict arises between
the results of field testing conducted by or for user, and laboratory tests corrected for field performance, the latter
shall control. RECOMMENDATIONS FOR SPECIAL APPLICATIONS OR THOSE RESULTING FROM SYSTEMS
ANALYSES AND EVALUATIONS WE CONDUCT WILL BE BASED ON OUR BEST AVAILABLE EXPERIENCE AND
PUBLISHED INDUSTRY INFORMATION. SUCH RECOMMENDATIONS DO NOT CONSTITUTE A WARRANTY OF
SATISFACTORY PERFORMANCE AND NO SUCH WARRANTY IS GIVEN.
This warranty shall not apply when damage is caused by (a) improper installation, (b) improper voltage (c) lightning
(d) excessive sand or other abrasive material (e) scale or corrosion build-up due to excessive chemical content. Any
modification of the original equipment will also void the warranty. We will not be responsible for loss, damage or labor
cost due to interruption of service caused by defective parts. Neither will we accept charges incurred by others without
our prior written approval.
This warranty is void if our inspection reveals the product was used in a manner inconsistent with normal industry practice
and\or our specific recommendations. The purchaser is responsible for communication of all necessary information
regarding the application and use of the product. UNDER NO CIRCUMSTANCES WILL WE BE RESPONSIBLE FOR
ANY OTHER DIRECT OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO TRAVEL EXPENSES,
RENTED EQUIPMENT, OUTSIDE CONTRACTOR FEES, UNAUTHORIZED REPAIR SHOP EXPENSES, LOST
PROFITS, LOST INCOME, LABOR CHARGES, DELAYS IN PRODUCTION, IDLE PRODUCTION, WHICH DAMAGES
ARE CAUSED BY ANY DEFECTS IN MATERIAL AND\OR WORKMANSHIP AND\OR DAMAGE OR DELAYS IN
SHIPMENT. THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY OTHER EXPRESS OR IMPLIED WARRANTY,
INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
No rights extended under this warranty shall be assigned to any other person, whether by operation of law or otherwise,
without our prior written approval.

RETURNED GOODS
RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”.
CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR.
Products Returned Must Be Cleaned, Sanitized,
Or Decontaminated As Necessary Prior To Shipment,
To Insure That Employees Will Not Be Exposed To Health
Hazards In Handling Said Material. All Applicable Laws
And Regulations Shall Apply.
IMPORTANT!
WARRANTY REGISTRATION
Your product is covered by the enclosed Warranty.
To complete the Warranty Registration Form go to:
http://www.cranepumps.com/ProductRegistration/
If you have a claim under the provision of the warranty, contact your local
Crane Pumps & Systems, Inc. Distributor.

START-UP REPORT
General Information
Pump Owner’s Name: __________________________________________________________
Address: ____________________________________________________________________
Location of Installation: _________________________________________________________
Contact Person:__________________________________Phone: _______________________
Purchased From: _____________________________________________________________
Nameplate Data
Pump Model #: ___________________ Serial #:_____________________________________
Part #: __________________________ Impeller Diameter: ____________________________
Voltage: _________ Phase: _____ Ø Hertz: ____________Horsepower: _______________
Full Load Amps:___________________ Service Factor Amps: __________________________
Motor Manufacturer: ___________________________________________________________
Controls
Control panel manufacturer: _____________________________________________________
Model/Part number:____________________________________________________________
Number of pumps operated by control panel: ________________________________________
Short circuit protection? YES___ NO___ Type: _________________________________
Number and size of short circuit device(s): ___________ Amp rating: ___________________
Overload Type: _____________ Size: ______________ Amp rating: ___________________
Do protection devices comply with pump and motor Amp rating? YES___ NO___
Are all electrical and panel entry connections tight? YES___ NO___
Is the interior of the panel dry? YES___ NO___
Liquid level Control Brand and Model:______________________________________________
Pre-Startup
All Pumps
Type of equipment: NEW___ REBUILT___ USED___
Condition of equipment at Start-Up: DRY___ WET___ MUDDY___
Was Equipment Stored? YES___ NO___ Length of Storage: ______________________
Liquid being pumped: __________________ Liquid Temperature: _____________________
Supply Voltage/Phase/Frequency matches nameplate? YES___ NO___
Shaft turns freely? YES___ NO___
Direction of rotation verified for 3Ø motors? YES___ NO___
Debris in piping or wet well? YES___ NO___
Debris removed in your presence? YES___ NO___
Pump case/wet well filled with liquid before startup? YES___ NO___
Is piping properly supported? YES___ NO___
Non-Submersible Pumps
Is base plate properly installed / grouted? YES___ NO___ N/A___
Coupling Alignment Verified per I&O Manual? YES___ NO___ N/A___
Grease Cup/Oil Reservoir Level checked? YES___ NO___ N/A___
A Crane Co. Company

Submersible Pumps
Resistance of cable and pump motor (measured at pump control):
Red-Black:_______Ohms(Ω) Red-White:_______Ohms(Ω) White-Black:_______Ohms(Ω)
Resistance of Ground Circuit between Control Panel and outside of pump:__________Ohms(Ω)
MEG Ohms check of insulation:
Red to Ground: _________ White to Ground: __________ Black to Ground: ____________
Operational Checks
Is there noise or vibration present? YES___ NO___ Source of noise/vibration: ___________
Does check valve operate properly? YES___ NO___ N/A___
Is system free of leaks? YES___ NO___ Leaks at: ______________________________
Does system appear to operate at design flow rate? YES___ NO___
Nominal Voltage: _____________________ Phase: 1Ø 3Ø (select one)
Voltage Reading at panel connection, Pump OFF: L1, L2 _____ L2, L3 ____ L1, L3 _____
Voltage Reading at panel connection, Pump ON: L1, L2 ______ L2, L3 ____ L1, L3 _____
Amperage Draw, Pump ON: L1 ____________ L2 _____________ L3 _____________
Submersible Pumps
Are BAF and guide rails level / plumb? YES___ NO___
Is pump seated on discharge properly? YES___ NO___
Are level controls installed away from turbulence? YES___ NO___
Is level control operating properly? YES___ NO___
Is pump fully submerged during operation? YES___ NO___
Follow up/Corrective Action Required
YES___ NO___
Additional Comments:
____________________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
Startup performed by: _____________________ Date: ______________________________
Present at Start-Up
( ) Engineer: ____________________________ ( ) Operator: ________________________
( ) Contactor:____________________________ ( ) Other:___________________________
All parties should retain a copy of this report for future trouble shooting/reference
A Crane Co. Company 420 Third Street 83 West Drive, Brampton
Piqua, Ohio 45356 Ontario, Canada L6T 2J6
Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone]
www.cranepumps.com

Notes
