FLORABEST 78961 User manual

IAN 78961
K
Garden Pump Set
Operation and Safety Notes
Original operating instructions
V
Komplet z vrtno črpalko
Navodila za upravljanje in varnostna opozorila
Originalna navodila za uporabo
D
Zahradní čerpadlo
Pokyny pro obsluhu a bezpečnostní pokyny
Originální návod k obsluze
W
Súprava záhradného čerpadla
Pokyny pre obsluhu a bezpečnostné pokyny
Originálny návod na obsluhu
T
Zestaw dla pomp ogrodowych
Wskazówki dotyczące obsługi i bezpieczeństwa
Instrukcją oryginalną
F A C
Gartenpumpen-Set
Bedienungs- und Sicherheitshinweise
Originalbetriebsanleitung
V D
W T
Garden Pump Set FGPA 1000 A1
Anleitung_4180303.indb 1Anleitung_4180303.indb 1 21.09.12 10:4321.09.12 10:43

- 2 -
K
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
V
Pred branjem stran s slikami odprite navzven in se nato seznanite z vsemi funkcijami naprave.
D
Před čtením si otevřete stranu s obrázky a potom se seznamte se všemi funkcemi přístroje.
W
Pred čítaním si odklopte stranu s obrázkami a potom sa oboznámte so všetkými funkciami prístroja.
T
Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie proszę zapoznać się z
wszystkimi funkcjami urządzenia.
F A C
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit
allen Funktionen des Gerätes vertraut.
GB Operation and Safety Notes Page 5
SI Navodila za upravljanje in varnostna opozorila Stran 14
CZ Pokyny pro obsluhu a bezpečnostní pokyny Strana 23
SK Pokyny pre obsluhu a bezpečnostné pokyny Strana 33
PL Wskazówki dotyczące obsługi i bezpieczeństwa Strona 43
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 53
Anleitung_4180303.indb 2Anleitung_4180303.indb 2 21.09.12 10:4321.09.12 10:43

- 3 -
1
2
42 1
3
9
6 8
5
7
3
13 11
12
3
10
Anleitung_4180303.indb 3Anleitung_4180303.indb 3 21.09.12 10:4321.09.12 10:43

- 4 -
Anleitung_4180303.indb 4Anleitung_4180303.indb 4 21.09.12 10:4421.09.12 10:44

GB
- 5 -
Table of contents
The reprinting or reproduction by any other means, in whole or in part, of documentation and papers
accompanying products is permitted only with the express consent of the iSC GmbH.
Subject to technical changes
1. Introduction.................................................................................................................................................. 6
2. Safety regulations ....................................................................................................................................... 6
3. Layout and items supplied.......................................................................................................................... 7
4. Intended use................................................................................................................................................ 7
5. Technical data............................................................................................................................................. 8
6. Operating instructions................................................................................................................................. 8
7. Fitting the carry handle............................................................................................................................... 8
8. Fitting the suction hose................................................................................................................................ 8
9. Mains connection ....................................................................................................................................... 8
10. Fitting a suction pipe................................................................................................................................... 8
11. Fitting a pressure pipe................................................................................................................................. 9
12. Starting up ................................................................................................................................................... 9
13. Cleaning and maintenance........................................................................................................................ 9
14. Replacing the mains cable......................................................................................................................... 9
15. Storage ......................................................................................................................................................10
16. Ordering spare parts................................................................................................................................10
17. Disposal and recycling.............................................................................................................................10
18. Troubleshooting guide................................................................................................................................11
19. Declaration of conformity......................................................................................................................... 12
20. Warranty certificate.................................................................................................................................. 13
Anleitung_4180303.indb 5Anleitung_4180303.indb 5 21.09.12 10:4421.09.12 10:44

GB
- 6 -
1.Introduction
Congratulations on your new purchase.
You have decided in favor of a high-quality pro-
duct. The operating instructions are a part of this
product. They contain information of importance
for your safety, for the use of the product and for
its disposal. Before you use the product, acquaint
yourself with all the information concerning its
operation and safety. Use the product only as
described and only for the listed areas of applica-
tion. If you hand on the product to other people,
give them all the documentation as well.
2.Safety regulations
Caution!
Read all safety regulations and instruc-
tions.
Any errors made in following the safety regu-
lations and instructions may result in an electric
shock, fire and/or serious injury.
Keep all safety regulations and instruc-
tions in a safe place for future use.
Protect yourself and your environment from risks
and accidents by taking the appropriate precauti-
onary measures.
• This equipment is not designed to be used by
people (including children) with limited physi-
cal, sensory or mental capacities or those with
no experience and/or knowledge unless they
are supervised by a person who is responsib-
le for their safety or they have received inst-
ructions from such a person in to how to use
the equipment safely. Children must always be
supervised in order to ensure that they do not
play with the equipment.
• Keep the plastic packaging out of the reach of
babies and children.
Risk of suffocation!
• The operator is responsible for the safety of
other people in the work area.
• Before starting, a test must be carried out by a
specialist to ensure that the required electrical
safety measures are in place.
•  Caution!
In stagnant water bodies, garden ponds,
swimming ponds and their surrounding areas
the pump may only be used with an earth-
leakage circuit breaker with an actuating ra-
ted fault current of up to 30 mA (as stipulated
in VDE 0100 parts 702 and 738).
• The pump is not designed for use in any kind
of swimming pools and paddling pools or in
other bodies of water in which people or ani-
mals may be present during its operation.
• It is prohibited to operate the pump if a per-
son or animal is in the danger zone. Ask your
electrician!
• Always inspect the equipment visually before
using it. Do not use the equipment if safety
devices are damaged or worn. Never disable
any safety devices.
• Use the equipment only for the purposes indi-
cated in these original operating instructions.
• You are responsible for safety in the operating
area.
• If the power cable for this machine is dama-
ged, it must be replaced by the manufacturer
or the manufacturer’s after-sales service or by
similarly trained personnel to avoid danger.
• The voltage of 230 V alternating voltage spe-
cified on the rating plate of the pump must be
the same as the mains voltage.
• Never use the power cable to lift, transport or
secure the pump.
• Ensure that the electrical plug connections are
in areas that are not at risk of flooding and
protect them from moisture.
• Always pull out the power plug before doing
any work on the pump!
• Do not expose the pump to a direct jet of
water.
• The operator is responsible for complying with
local safety and installation regulations (ask
an electrician if you are in any doubt).
• The user is required to take suitable measures
(e.g. installing an alarm system or a reserve
pump, etc.) to prevent damage arising as a
result of flooded rooms in the event of faults
with the pump.
• In the event of a failure of the pump, repair
work may only be carried out by an electrici-
Anleitung_4180303.indb 6Anleitung_4180303.indb 6 21.09.12 10:4421.09.12 10:44

GB
- 7 -
an or by ISC after-sales service personnel.
• Use only original spare parts.
• The pump must never run dry or be used
when the intake line is fully closed. The
manufacturer’s warranty does not cover
damage caused to the pump as a result of
running it dry.
• The pump must not be used to operate swim-
ming pools.
• The pump must not be installed in the drinking
water pipeline.
• The maximum temperature of the fluid must not
exceed +35°C.
• Do not use this equipment to pump inflamma-
ble, gassing or explosive fluids.
• The pumping of aggressive liquids (acid,
alkali, silo seepage, etc.) and liquids with
abrasive (emerizing) substances (sand) must
likewise be avoided.
3.Layout and items supplied
3.1 Layout (Fig. 1)
1. Garden pump
2. On/Off switch
3. Mounting holes
4. Water drain screw
5. Suction connector
6. Water filler screw
7. Pressure connector
8. Carry handle
9. Screw (2x)
10. Suction hose 4m
11. Connection adapter approx. 33.3 mm (R1)
male thread and approx. 42 mm (R1 1/4)
male thread
12. Sealing ring
13. Non-return valve and intake filter
3.2 Items supplied
• Open the packaging and take out the equip-
ment with care.
• Remove the packaging material and any
packaging and/or transportation braces (if
present).
• Check to see if all the items are supplied.
• Inspect the equipment and accessories for
damage in transit.
• If possible, keep the packaging until the end
of the guarantee period.
Important
The equipment and packaging material
are not toys! Do not let children play with
plastic bags, plastic sheets and small
parts! There is a risk of choking and suf-
focating!
• Garden pump
• Carry handle
• Screw (2x)
• Suction hose 4m
• Connection adapter approx. 33.3 mm (R1)
male thread and approx. 42 mm (R1 1/4)
male thread
• Non-return valve and intake filter
• Original operating instructions
4.Intended use
Range of applications
• For irrigating and watering landscaped areas,
vegetable beds and gardens.
• For operating lawn sprinklers.
• With preliminary filter for drawing water from
ponds, streams, rainwater butts, rainwater
cisterns and wells.
Pumping media
For the pumping of clear water (freshwater), rain-
water and mild suds/ service water.
• The maximum temperature of the fluid must not
exceed +35°C.
• Do not use this equipment to pump inflamma-
ble, gassing or explosive fluids.
Anleitung_4180303.indb 7Anleitung_4180303.indb 7 21.09.12 10:4421.09.12 10:44

GB
- 8 -
• The pumping of aggressive liquids (acid,
alkali, silo seepage, etc.) and liquids with
abrasive (emerizing) substances (sand) must
likewise be avoided.
5.Technical data
Mains connection: ...........................230V ~ 50 Hz
Power rating:..............................................1000 W
Max. delivery rate................................... 4600 l/h
Max. delivery head.........................................45 m
Max. delivery pressure...........4.5 bar (0.45 MPa)
Max. suction height ........................................... 7 m
Pressure and suction connector: ..............................
..................... approx. 33.3 mm (R1 female thread)
Max. water temperature.................................35°C
Sound pressure level LpA ....................72.03 dB (A)
Uncertainty KpA .......................................... 3 dB (A)
Peak noise level:
Measured........................................... 84.62 dB (A)
Uncertainty KWA.......................................... 3 dB (A)
Guaranteed..............................................86 dB (A)
Protection class.........................................................I
Protection type ..................................................IPX4
Weight ............................................................8.9 kg
6.Operating instructions
As a basic principle, we recommend the use of
a preliminary filter and a suction set with suction
hose, intake cage and non-return valve, in order
to prevent long priming periods and unnecessary
damage to the pump as a result of stones and so-
lid foreign bodies.
7. Fitting the carry handle
Fasten the carry handle with the 2 screws
supplied (see Fig. 2).
8.Fitting the suction hose
Fit the suction hose as illustrated in Fig. 3.
Make sure that the end of the adapter (Fig. 1/
Item 11) with the sealing ring (Fig. 1/Item 12) is
screwed into the equipment.
9.Mains connection
• The mains connection needs a 230 V ~ 50 Hz
shock-proof socket. Minimum 10-amp fuse
required. Please ensure that the power socket
is easily accessible.
• Switch on/off at the built-in switch (see Fig.
1/Item 2).
• The motor is protected from overload or blo-
ckage by a built-in temperature monitor. In
case of overheating the temperature monitor
automatically switches the pump off. After the
equipment has cooled down, the pump will
switch on again automatically.
10.Fitting a suction pipe
• Screw a suction pipe (min. 19 mm (3/4“)
plastic pipe with spiral reinforcement) either
directly or with the aid of a threaded nipple
approx. 33 mm (R1) male thread onto the
intake line connection approx. 33 mm (R1)
female thread of the pump (Fig. 1/Item 5).
• The suction hose should have an intake valve.
If the intake valve cannot be used then a non-
return valve should be installed in the intake
line.
• Position the intake line so that it rises from the
water withdrawal point to the pump. Avoid
positioning the intake line higher than the
pump as this would delay the escape of air
bubbles from the intake line and impede the
priming process.
• Install the intake and discharge lines in such
a way that they do not exert any mechanical
pressure on the pump.
• The intake valve should be low enough in the
water to ensure that the pump will not run dry
if the water level falls.
Anleitung_4180303.indb 8Anleitung_4180303.indb 8 21.09.12 10:4421.09.12 10:44

GB
- 9 -
• A leaking intake line will draw in air and
therefore not draw in any water.
• Take measures to prevent the intake of foreign
bodies (sand, etc.). If necessary install a coar-
se filter.
11. Fitting a pressure pipe
• The discharge line min. 19 mm (3/4“) must
be connected either directly or with the aid
of a threaded nipple approx. 33.3 mm (R1)
female thread to the discharge line connec-
tion approx. 33 mm (R1) female thread of the
pump (Fig. 1/Item 7) .
• You can also use a pressure hose of approx.
13 mm (1/2“) with the relevant couplings. The
pump rate is reduced when using the smaller
discharge line.
• During the priming process, the shut-off
devices present in the discharge line (spray
nozzles, valves, etc.) must be completely
open so that the air in the intake line can es-
cape freely.
12.Starting up
• Place the pump on a firm and level surface.
• Before starting the pump, it must be securely
mounted on the surface using the holes in
the stand (see Fig. 1/Item 3).
• Fit intake line so that it is ready for use.
• Fill pump with water at the filler screw (Fig. 1/
Item 6) up to the full point.
• During the priming process, the shut-off
devices present in the discharge line (spray
nozzles, valves, etc.) must be completely
open so that the air in the intake line can es-
cape freely.
• The initial intake process can take approx. 30
seconds to 5 minutes, depending on the suc-
tion height and volume of air in the intake line.
The pump should be topped up with water if
the priming time is longer.
• If the pump is removed after use, it is essential
that it is filled with water again the next time it
is connected and started.
• Establish electrical connection.
13.Cleaning and maintenance
• The pump is largely maintenance-free. In or-
der to ensure a long service life, however, we
recommend regular checks and product care.
Caution!
The pump must be disconnected from
the power supply by removing the
power plug before carrying out any
maintenance.
• Before lengthy periods of inactivity or winter
storage rinse the pump thoroughly, empty it
completely and store it in a dry place.
• To drain the pump housing, undo the water
drain screw (Fig. 1/Item 4) and tilt the pump
slightly.
• The pump must be completely emptied if there
is a risk of frost.
• After relatively long periods of storage, switch
on and off briefly to check whether the rotor is
turning properly.
• If the pump is clogged, connect the discharge
line to the water line and disconnect the in-
take line. Open the water line. Switch on the
pump several times for approx. two seconds.
This should resolve the majority of clog-rela-
ted problems.
• We recommend lukewarm water to clean the
motor and pump housing.
14.Replacing the mains cable
Caution!
Disconnect the unit from the power sup-
ply! A defective mains cable may only be
replaced by a qualified electrician.
Anleitung_4180303.indb 9Anleitung_4180303.indb 9 21.09.12 10:4421.09.12 10:44

GB
- 10 -
15.Storage
Store the equipment and accessories out of reach
of children in a dark and dry place above free-
zing.
The ideal storage temperature is between 5 and
30 °C. Store the equipment in its original pa-
ckaging.
16.Ordering spare parts
Please provide the following information when
ordering spare parts:
• Model/type of unit
• Article number of unit
• ID number of unit
For current prices and information please visit
www.isc-gmbh.info
17.Disposal and recycling
The equipment is supplied in packaging to prevent
it from being damaged in transit. The raw materi-
als in this packaging can be reused or recycled.
The equipment and its accessories are made
of various types of material, such as metal and
plastic. Defective components must be disposed
of as special waste. Ask your dealer or your local
council.
For EU countries only
Never place any electric power tools in your
household refuse.
To comply with European Directive 2002/96/EC
concerning old electric and electronic equipment
and its implementation in national laws, old elec-
tric power tools have to be separated from other
waste and disposed of in an environment-friendly
fashion, e.g. by taking to a recycling depot.
Recycling alternative to the return request:
As an alternative to returning the equipment to the
manufacturer, the owner of the electrical equip-
ment must make sure that the equipment is proper-
ly disposed of if he no longer wants to keep the
equipment. The old equipment can be returned to
a suitable collection point that will dispose of the
equipment in accordance with the national recyc-
ling and waste disposal regulations. This does not
apply to any accessories or aids without electrical
components supplied with the old equipment.
Anleitung_4180303.indb 10Anleitung_4180303.indb 10 21.09.12 10:4421.09.12 10:44

GB
- 11 -
18. Troubleshooting guide
Motor not running
Cause Remedy
- Power supply not connected
- Impeller blocked, thermostat has switched off
- Check voltage supply
- Take pump apart and clean it
Pump not priming
Cause Remedy
- Intake valve not in the water
- No water in the pump chamber
- Air in the intake line
- Intake valve leaking
- Intake cage (intake valve) blocked
- Max. intake height exceeded
- Place intake valve in water
- Fill pump housing with water
- Check sealing of intake line
- Clean intake valve
- Clean intake cage
- Check intake height
Insufficient pumping rate
Cause Remedy
- Intake height too high
- Intake cage soiled
- Water level falling rapidly
- Pump performance reduced by foreign bodies
(sand, stones, etc.)
- Check intake height
- Clean intake cage
- Place intake valve lower down
- Clean pump and replace wearing parts
Thermostat switches off the pump
Cause Remedy
- Motor overloaded, excessive friction caused
by foreign bodies
- Dismantle and clean pump, prevent intake of
foreign bodies (filter)
Caution! The pump must not run dry.
Anleitung_4180303.indb 11Anleitung_4180303.indb 11 21.09.12 10:4421.09.12 10:44

GB
- 12 -
19.Declaration of conformity
Wang/Product-ManagementWeichselgartner/General-Manager
Derklärt folgende Konformität gemäß EU-Richtlinie und
Normen für Artikel
GB explains the following conformity according to EU directi-
ves and norms for the following product
Fdéclare la conformité suivante selon la directive CE et les
normes concernant l’article
Idichiara la seguente conformità secondo la direttiva UE e
le norme per l’articolo
NL verklaart de volgende overeenstemming conform EU
richtlijn en normen voor het product
Edeclara la siguiente conformidad a tenor de la directiva y
normas de la UE para el artículo
Pdeclara a seguinte conformidade, de acordo com a
directiva CE e normas para o artigo
DK attesterer følgende overensstemmelse i medfør af
EU-direktiv samt standarder for artikel
Sförklarar följande överensstämmelse enl. EU-direktiv och
standarder för artikeln
FIN vakuuttaa, että tuote täyttää EU-direktiivin ja standardien
vaatimukset
EE tõendab toote vastavust EL direktiivile ja standarditele
CZ vydává následující prohlášení o shoděpodle směrnice EU
a norem pro výrobek
SLO potrjuje sledečo skladnost s smernico EU in standardi za
izdelek
SK vydáva nasledujúce prehlásenie o zhode podľa smernice
EÚ a noriem pre výrobok
Ha cikkekhez az EU-irányvonal és Normák szerint a
következőkonformitást jelenti ki
PL deklaruje zgodność wymienionego poniżej artykułu z
następującymi normami na podstawie dyrektywy WE.
BG декларира съответното съответствие съгласно
Директива на ЕС инорми за артикул
LV paskaidro šādu atbilstību ES direktīvai un standartiem
LT apibūdina šįatitikimąEU reikalavimams ir prekės normoms
RO declarăurmătoarea conformitate conform directivei UE şi
normelor pentru articolul
GR δηλώνει την ακόλουθη συμμόρφωση σύμφωνα με την
Οδηγία ΕΚ και τα πρότυπα για το προϊόν
HR potvrđuje sljedeću usklađenost prema smjernicama EU i
normama za artikl
Izjava o sukladnosti za ovaj proizvod dostupna je na
internet stranici www.lidl.hr.
BIH potvrđuje sljedeću usklađenost prema smjernicama EU i
normama za artikl
RS potvrđuje sledeću usklađenost prema smernicama EZ i
normama za artikal
RUS следующим удостоверяется, что следующие продукты
соответствуют директивам инормам ЕС
UKR проголошує про зазначену нижче відповідність виробу
директивам та стандартам ЄС на виріб
MK ја изјавува следната сообрзност согласно
ЕУ-директивата инормите за артикли
TR Ürünü ile ilgili AB direktifleri ve normlarıgereğince aşağıda
açıklanan uygunluğu belirtir
Nerklærer følgende samsvar i henhold til EU-direktivet og
standarder for artikkel
IS Lýsir uppfyllingu EU-reglna og annarra staðla vöru
Konformitätserklärung
Gartenpumpe FGPA 1000 A1 (Florabest)
87/404/EC_2009/105/EC
2005/32/EC_2009/125/EC
X2006/95/EC
2006/28/EC
X2004/108/EC
2004/22/EC
1999/5/EC
97/23/EC
90/396/EC_2009/142/EC
89/686/EC_96/58/EC
X2011/65/EC
2006/42/EC
Annex IV
Notified Body:
Notified Body No.:
Reg. No.:
X2000/14/EC_2005/88/EC
XAnnex V
Annex VI
Noise measured: LWA = 84,62 dB (A); guaranteed LWA = 86 dB (A)
P = KW; L/Ø = cm
Notified Body:
2006/28/EC
Emission No.:
Standard references: EN 60335-1; EN 60335-2-41; EN 62233;
EN 55014-1; EN 55014-2; EN 61000-3-2; EN 61000-3-3
Landau/Isar, den 03.09.2012
First CE: 12 Archive-File/Record: NAPR005890
Art.-No.: 41.803.13 I.-No.: 11012 Documents registrar: Helmut Bauer
Subject to change without notice Wiesenweg 22, D-94405 Landau/Isar
Einhell Germany AG · Wiesenweg 22 · D-94405 Landau/Isar
Anleitung_4180303.indb 12Anleitung_4180303.indb 12 21.09.12 10:4421.09.12 10:44

GB
20. Warranty certificate
Dear Customer,
All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely event
that your device develops a fault, please contact our service department at the address shown on this guarantee card.
Of course, if you would prefer to call us then we are also happy to offer our assistance under the service number prin-
ted below. Please note the following terms under which guarantee claims can be made:
1. These guarantee terms cover additional guarantee rights and do not affect your statutory warranty rights. We do
not charge you for this guarantee.
2. Our guarantee only covers problems caused by material or manufacturing defects, and it is restricted to the rec-
tification of these defects or replacement of the device. Please note that our devices have not been designed for
use in commercial, trade or industrial applications. Consequently, the guarantee is invalidated if the equipment
is used in commercial, trade or industrial applications or for other equivalent activities. The following are also
excluded from our guarantee: compensation for transport damage, damage caused by failure to comply with
the installation/assembly instructions or damage caused by unprofessional installation, failure to comply with the
operating instructions (e.g. connection to the wrong mains voltage or current type), misuse or inappropriate use
(such as overloading of the device or use of non-approved tools or accessories), failure to comply with the main-
tenance and safety regulations, ingress of foreign bodies into the device (e.g. sand, stones or dust), effects of
force or external influences (e.g. damage caused by the device being dropped) and normal wear resulting from
proper operation of the device. This applies in particular to rechargeable batteries for which we nevertheless
issue a guarantee period of 12 months. The guarantee is rendered null and void if any attempt is made to tamper
with the device.
3. The guarantee is valid for a period of 3 years starting from the purchase date of the device. Guarantee claims
should be submitted before the end of the guarantee period within two weeks of the defect being noticed. No
guarantee claims will be accepted after the end of the guarantee period. The original guarantee period remains
applicable to the device even if repairs are carried out or parts are replaced. In such cases, the work performed
or parts fitted will not result in an extension of the guarantee period, and no new guarantee will become active
for the work performed or parts fitted. This also applies when an on-site service is used.
4. In order to assert your guarantee claim, please send your defective device postage-free to the address shown
below. Please enclose either the original or a copy of your sales receipt or another dated proof of purchase.
Please keep your sales receipt in a safe place, as it is your proof of purchase. It would help us if you could de-
scribe the nature of the problem in as much detail as possible. If the defect is covered by our guarantee then your
device will either be repaired immediately and returned to you, or we will send you a new device.
Of course, we are also happy offer a chargeable repair service for any defects which are not covered by the scope
of this guarantee or for units which are no longer covered. To take advantage of this service, please send the device
to our service address.
- 13 -
IAN 78961
Anleitung_4180303.indb 13Anleitung_4180303.indb 13 21.09.12 10:4421.09.12 10:44

SI
- 14 -
Vsebina
Ponatis ali kakršnokoli razmnoževanje dokumentacije in spremljajočih papirjev o proizvodu, tudi po
izvlečkih, je dovoljeno samo z izrecnim soglasjem ISC GmbH.
Pridržana pravica do tehničnih sprememb
1. Uvod .......................................................................................................................................................... 15
2. Varnostni napotki ...................................................................................................................................... 15
3. Opis aparata in obseg dobave............................................................................................................... 16
4. Predpisana namenska uporaba............................................................................................................... 16
5. Tehnični podatki ........................................................................................................................................ 17
6. Navodila za uporabo .............................................................................................................................. 17
7. Montaža nosilnega ročaja....................................................................................................................... 17
8. Montaža priložene sesalne cevi.............................................................................................................. 17
9. Električni priključek ................................................................................................................................... 17
10. Montaža sesalne napeljave .................................................................................................................... 17
11. Montaža tlačne napeljave....................................................................................................................... 18
12. Prvi zagon.................................................................................................................................................. 18
13. Čiščenje in vzdrževanje............................................................................................................................ 18
14. Menjava omrežne napeljave................................................................................................................... 18
15. Skladiščenje .............................................................................................................................................. 19
16. Naročanje nadomestnih delov................................................................................................................ 19
17. Odstranjevanje in ponovna uporaba...................................................................................................... 19
18. Načrt iskanja napak.................................................................................................................................20
19. Izjava o skladnosti.................................................................................................................................... 21
20. Garancijska listina ..................................................................................................................................22
Anleitung_4180303.indb 14Anleitung_4180303.indb 14 21.09.12 10:4421.09.12 10:44

SI
- 15 -
1.Uvod
Čestitamo vam za nakup vaše nove naprave.
Odločili ste se za kakovosten izdelek. Navodila
za uporabo so sestavni del tega izdelka. Vsebu-
jejo pomembne napotke o varnosti, uporabi in
odstranjevanju naprave. Pred uporabo izdelka
se seznanite z vsemi napotki za upravljanje in
varnost. Izdelek vedno uporabljajte le v skladu z
opisom in za navedene namene. Če boste izdelek
izročili drugi osebi, ji predajte tudi vso dokumen-
tacijo.
2.Varnostni napotki
Opozorilo!
Preberite varnostne napotke in navodila.
Neupoštevanje varnostnih napotkov in navodil
ima lahko za posledico električni udar, požar in/
ali hude poškodbe. Shranite vse varnostne
napotke in navodila za kasnejšo upora-
bo.
Zaščitite sebe in Vaše okolje s primernimi varnost-
nimi ukrepi pred nevarnostjo nezgod.
• Ta naprava ni namenjena za to, da bi jo upo-
rabljale osebe (vključno otroci) z omejenimi
fizičnimi, senzoričnimi ali duševnimi sposob-
nostmi ali osebe s pomanjkljivimi izkušnjami
in/ali znanji razen, če so za lastno varnost
pod nadzorom odgovorne osebe ali pa so
od le-te dibile navodila za uporabo naprave.
Otroci morajo biti pod nadzorom, da bo za-
gotovljeno, da naprave ne bodo uporabljali
kot igrače.
• Folijo, ki se uporablja za pakiranje, hranite
zunaj dosega dojenčkov in otrok.Nevarnost
zadušitve!
• Uporabnik je na delovnem področju naprave
odgovoren za tretje osebe.
• Pred zagonom naj strokovnjak zagotovi, da
obstajajo vsi zahtevani električni varnostni
ukrepi.
•  Opozorilo!
Uporaba črpalke na stoječi vodi, v vrtnih ali
plavalnih ribnikih in v okolici je dovoljena le z
zaščitnim stikalom za okvarni tok z izmerjenim
okvarnim tokom do 30 mA (po VDE 0100
dela 702 in 738).
• Črpalka ni primerna za uporabo v plavalnih
bazenih, bazenčkih za otroke kakršnekoli vrs-
te in drugih vodi, v kateri se med delovanjem
naprave lahko nahajajo ljudje ali živali.
• Delovanje črpalke ni dovoljeno, če se v pre-
delu nevarnosti zadržujejo ljudje ali živali.
Posvetujte se s svojim električarjem!
• Pred vsako uporabo izvršite vizuelno kontrolo
naprave. Naprave ne uporabljajte, če je
zaščitna oprema poškodovana ali izrabljena.
Nikoli ne izklapljajte varnostne opreme.
• Napravo uporabljajte izključno za namene, ki
so opisani v originalnih navodilih za uporabo.
• Vi ste odgovorni za varnost v delovnem
območju.
• Če se priključek za omrežje te naprave
poškoduje, ga mora zamenjati izdelovalec,
izdelovalčev servis za stranke ali druga
ustrezno usposobljena oseba, da ne pride do
nevarnih situacij.
• Navedena napetost 230 voltov izmeničnega
toka, ki je navedena na tipski tablici črpalke,
mora ustrezati napetosti obstoječega omrežja.
• Črpalke nikoli ne dvigajte, transportirajte ali
pritrjujte z omrežnim kablom.
• Zagotovite, da so vtične povezave zaščitene
pred poplavljenjem ali vlago.
• Pred vsemi delu na črpalki izvlecite omrežno
stikalo!
• Preprečite izpostavljenost črpalke neposred-
nemu vodnemu curku.
• Za upoštevanje krajevnih varnostnih in vgrad-
nih določil je odgovoren uporabnik (za nas-
vet vprašajte električarja).
• Posledične škode zaradi poplavljenosti pros-
torov pri motnja na črpalki mora uporabnik
izključiti z ustreznimi ukrepi (npr. namestitev
alarmne naprave, rezervne črpalke ali po-
dobnega).
• Pri morebitnem črpalke naprave sme popra-
vila izvajati le električar ali služba za stranke
ISC.
• Uporabite samo originalne nadomestne dele.
• Črpalka ne sme nikoli delovati na suhem ali s
Anleitung_4180303.indb 15Anleitung_4180303.indb 15 21.09.12 10:4421.09.12 10:44

SI
- 16 -
povsem zaprto sesalno napeljavo. Za škodo
na črpalki, ki nastane zaradi suhega teka,
ugasne garancija proizvajalca.
• Črpalke ni dovoljeno uporabljati za bazene.
• Črpalke ne smete vgraditi v krogotok pitne
vode.
• Najvišja temperatura črpane tekočine ne sme
presegati +35 °C.
• S to črpalko ne smete prenašati gorljivih,
eksplozivnih tekočin in tekočin, ki tvorijo pline.
• Preprečite tudi prenos agresivnih tekočin (kis-
lin, lugov, tekočin, ki pronicajo iz silosov ipd.)
ter tekočin z abrazivnimi (hrapavimi) snovmi
(pesek).
3.Opis aparata in obseg
dobave
3.1 Opis naprave (slika 1)
1. Vrtna črpalka
2. Stikalo za vklop/izklop
3. Pritrdilne luknje
4. Vijak za izpust vode
5. Sesalni priključek
6. Vijak za dolivanje vode
7. Tlačni priključek
8. Nosilni ročaj
9. 2 vijaka
10. Sesalna cev 4 m
11. Priključni adapter ca. 33,3 mm (R1) zunanji
navoj in ca. 42 mm (R1 1/4) zunanji navoj
12. Tesnilni obroč
13. Povratni ventil in sesalni filter
3.2 Obseg dobave
• Odprite embalažo in previdno vzemite napra-
vo iz embalaže.
• Odstranite embalažni material in embalažne
in transportne varovalne priprave (če obsta-
jajo).
• Preverite, če je obseg dobave popoln.
• Preverite morebitne poškodbe naprave in
delov pribora, do katerih bi lahko prišlo med
transportom.
• Po možnosti shranite embalažo do poteka
garancijskega roka.
Opozorilo
Naprava in embalažni material nista
igrača za otroke! Otroci se ne smejo
igrati s plastičnimi vrečkami, folijo in
malimi deli opreme! Obstaja nevarnost
zadušitve in zaužitja takšnih delov ma-
teriala!
• Vrtna črpalka
• Nosilni ročaj
• 2 vijaka
• Sesalna cev 4 m
• Priključni adapter ca. 33,3 mm (R1) zunanji
navoj in ca. 42 mm (R1 1/4) zunanji navoj
• Povratni ventil in sesalni filter
• Originalna navodila za uporabo
4.Predpisana namenska
uporaba
Območje uporabe
• Za navodnjavanje in zalivanje zelenic, zelen-
javnih gredic in vrtov.
• Za škropilnike zelenic.
• S predfiltrom za odvzem vode iz ribnikov,
potokov, sodov za deževnico, cistern za
deževnico in vodnjakov.
Mediji črpanja
Za črpanje bistre vode (sladka voda), deževnice
ali blagega luga za pranje/porabne vode.
• Najvišja temperatura črpane tekočine ne sme
presegati +35 °C.
Anleitung_4180303.indb 16Anleitung_4180303.indb 16 21.09.12 10:4421.09.12 10:44

SI
- 17 -
• S to črpalko ne smete prenašati gorljivih,
eksplozivnih tekočin in tekočin, ki tvorijo pline.
• Preprečite tudi prenos agresivnih tekočin (kis-
lin, lugov, tekočin, ki pronicajo iz silosov ipd.)
ter tekočin z abrazivnimi (hrapavimi) snovmi
(pesek).
5.Tehnični podatki
Električni priključek: .......................230 V ~ 50 Hz
Poraba energije: ........................................1000 W
Črpalka količina maks............................. 4600 l/h
Črpalna višina maks. .......................................45 m
Črpalki tlak maks. .................. 4,5 bar (0,45 MPa)
Sesalna višina maks........................................... 7 m
Tlak in sesalni
priključek: ...........................pribl. 33,3 mm (R1 IG)
Temperatura vode maks .................................35°C
Nivo zvočnega tlaka LpA ...................72,03 dB (A)
Negotovost KpA .......................................... 3 dB (A)
Jakost zvočnega tlaka:
Izmerjena............................................84,62 dB (A)
Negotovost KWA ......................................... 3 dB (A)
Zagotovljena............................................86 dB (A)
Razred zaščite..........................................................I
Vrsta zaščite.......................................................IPX4
Teža ............................................................... 8,9 kg
6.Navodila za uporabo
Načeloma priporočamo uporabo predfiltra in
sesalne garniture s sesalno cevjo, sesalno košaro
in protipovratnim ventilom. S tem preprečite dol-
go čakanje na ponovno sesanje in nepotrebne
poškodbe črpalke zaradi kamnov in trdih tujkov.
7. Montaža nosilnega ročaja
Nosilni ročaj morate montirati z 2
priloženima vijakoma (glejte sliko 2).
8.Montaža priložene sesalne
cevi
Sesalno cev montirajte, kot je prikazano na sliki 3.
Pazite, da boste stran na adapterju (sl. 1/poz.
11) privijačili v napravo s tesnilnim obročem (sl.
1/poz. 12).
9.Električni priključek
• Omrežni priključek je na vtičnico z zaščitnim
kontaktom 230 V ~ 50 Hz. Varovalka mora
imeti vsaj 10 amperov. Zagotovite dobro
dostopnost vtičnice.
• Vklop in izklop poteka z vgrajenim stikalom
(glejte sliko 1/poz. 2).
• Vgrajeno temperaturno stikalo ščiti motor pred
preobremenitvami ali blokado. V primeru pre-
gretja temperaturno stikalo samodejno izklopi
črpalko in jo spet vklopi, ko se ohladi.
10.Montaža sesalne napeljave
• Sesalno cev (plastično cev z vsaj 19 mm
(3/4”) s spiralno ojačitvijo) priključite nepos-
redno ali z navojnim nastavkom ca. 33,3 mm
(R1) zunanji navoj na priključek sesalne na-
peljave ca. 33 mm (R1 notranji navoj) črpalke
(sl. 1/poz. 5).
• Uporabljena sesalna cev mora imeti sesalni
ventil. Če sesalnega ventila ne morete upo-
rabiti, morate v sesalno napeljavo namestiti
protipovratni ventil.
• Sesalno napeljavo položite tako, da se od
odvzema vode do črpalke vzpenja. Sesal-
ne napeljave nikoli ne položite nad višino
črpalke, saj zračni mehurčki v sesalni napelja-
vi ovirajo in zakasnijo postopek sesanja.
• Sesalno in tlačno napeljavo namestite tako,
da ne izvajata mehanskega pritiska na
črpalko.
• Sesalni ventil mora biti dovolj globoko v vodi,
da z nižanjem vodostaja preprečite suhi tek
črpalke.
• Netesna sesalna naprava preprečuje sesanje
Anleitung_4180303.indb 17Anleitung_4180303.indb 17 21.09.12 10:4421.09.12 10:44

SI
- 18 -
vode, saj se vsesava zrak.
• Preprečite vsesavanje tujkov (peska ipd.); po
potrebi namestite predfilter.
11. Montaža tlačne napeljave
• Tlačna napeljava (naj bo vsaj 19 mm (3/4”))
mora biti priključena neposredno na ali prek
navojnega spojnika ca. 33,3 mm (R1) zunanji
navoj na priključek tlačne napeljave ca. 33
mm (R1 notranji navoj) črpalke (sl. 1/poz. 7).
• Z ustreznimi privijačenji lahko uporabite tudi
ca. 13 mm (1/2”) tlačno cev. Zmogljivost
prenosa se z manjšo tlačno cevjo zmanjša.
• Med postopkom sesanja povsem odprite
zaporne elemente (brizgalne šobe, ventile
ipd.) v tlačni napeljavi, da lahko zrak prosto
uhaja iz sesalne napeljave.
12.Prvi zagon
• Črpalko postavite samo na čvrsto in ravno
podlago.
• Pred zagonom morate črpalko dobro pri-
trditi na podlago s pomočjo pritrdilnih lukenj
v oporni nogi (glejte sliko 1/poz. 3).
• Namestite sesalne napeljave, pripravljene na
delovanje.
• Črpalko napolnite z vodo na vijaku za vlivan-
je vode (slika 1/poz. 6) do mesta polnjenja.
• Med postopkom sesanja povsem odprite
zaporne elemente (brizgalne šobe, ventile
ipd.) v tlačni napeljavi, da lahko zrak prosto
uhaja iz sesalne napeljave.
• Glede na višino sesanja in količino zraka v
sesalni napeljavi lahko prvi postopek sesanja
traja pribl. 0,5 min - 5 min. Pri daljšem času
sesanja ponovno napolnite z vodo.
• Če črpalko po uporabi ponovno odstranite,
jo morate pri ponovnem priključku in zagonu
obvezno napolniti z vodo.
• Vzpostavite električni priključek.
13.Čiščenje in vzdrževanje
• Črpalka je skoraj brez vzdrževanja. Za daljšo
življenjsko dobo priporočamo, da jo redno
pregledujete in negujete.Opozorilo!
Pred vsakim vzdrževanjem mora-
te črpalko izklopiti iz električnega
omrežja; izvlecite omrežno stikalo
črpalke iz vtičnice.
• Pred daljšo neuporabo ali prezimovanjem
črpalko temeljito splaknite z vodo, jo popol-
noma izpraznite in shranite na suhem.
• Za praznjenje ohišja črpalke odpustite vijak
za izpust vode (slika 1/poz. 4) in črpalko
nekoliko nagnite.
• Če obstaja nevarnost zmrzali, črpalko pov-
sem izpraznite.
• Po daljših obdobjih mirovanja s kratkim vklo-
pom/izklopom preverite, ali se rotor brezhib-
no obrača.
• Pri morebitni zamašitvi črpalke priključite
tlačno napeljavo na vodno napeljavo in sne-
mite sesalno cev. Odprite vodno napeljavo.
Črpalko večkrat vklopite za ca. dve sekundi.
Na tak način lahko v večini primerov odstra-
nite vzrok zamašitve.
• Za čiščenje ohišja motorja in črpalke
priporočamo mlačno vodo.
14.Menjava omrežne
napeljave
Opozorilo!
Napravo izključite iz električnega
omrežja! Če je omrežna napeljava ok-
varjena, jo lahko menja samo električar.
Anleitung_4180303.indb 18Anleitung_4180303.indb 18 21.09.12 10:4421.09.12 10:44

SI
- 19 -
15.Skladiščenje
Napravo in pribor za napravo skladiščite na
temnem, suhem in pred mrazom zaščitenem in za
otroke nedostopnem mestu.
Optimalna temperatura shranjevanja je med 5 in
30 ˚C. Napravo shranjujte v originalni ovojnini.
16.Naročanje nadomestnih
delov
Pri naročanju nadomestnih delov je potrebno na-
vesti naslednje navedbe:
• Tip naprave
• Art. številko naprave
• Ident- številko naprave
Aktualne cene in informacije najdete na spletni
strani www.isc-gmbh.info
17.Odstranjevanje in ponovna
uporaba
Naprava se nahaja v embalaži, da ne bi prišlo
do poškodb med transportom. Ta embalaža je
surovina in s tem ponovno uporabna ali pa jo
je možno reciklirati. Naprava in njen pribor sta
izdelana iz različnih materialov kot npr. kovine
in plastika. Pokvarjene sestavne dele odstranite
med posebne odpadke. V ta namen povprašajte v
tehnični trgovini ali na občinski upravi!
Samo za dežele EU
Električnega orodja ne mečite med gospodinjske
odpadke!
Vskladu zevropsko smernico 2002/96/EG
o starih električnih in elektronskih napravah in
vskladu zizvajanjem nacionalne zakonodaje
morate ločeno zbirati izrabljena električna orodja
in jih predati vokoljsko varno ponovno predela-
vo.
Reciklažna alternativa za poziv za vračanje:
Lastnik električne naprave je alternativno zave-
zan, da namesto vračanja sodeluje pri pri stro-
kovno ustreznem recikliranju vprimeru predaje
lastnine. Staro napravo se lahko v ta namen tudi
prepusti na odvzemnem mestu, ki izvaja odstran-
jevanje vsmislu nacionalne zakonodaje o od-
stranjevanju takšnih odpadkov. To se ne nanaša
na starim napravam priložene dele pribora in
opreme brez električnih komponent.
Anleitung_4180303.indb 19Anleitung_4180303.indb 19 21.09.12 10:4421.09.12 10:44

SI
- 20 -
18.Načrt iskanja napak
Ni teka motorja
Vzrok Odpravljanje
- Ni omrežne napetosti
- Kolo črpalke je blokirano, termo stikalo je iz-
klopilo
- Preverite napetost
- Razstavite in očistite črpalko
Črpalka ne sesa
Vzrok Odpravljanje
- Sesalni ventil ni v vodi
- Prostor črpalke nima vode
- V sesalni napeljavi je zrak
- Sesalni ventil ne tesni
- Sesalna košara (sesalni ventil) je zamašena
- Maks. sesalna višina je prekoračena
- Sesalni ventil dajte v vodo
- Ohišje črpalke napolnite z vodo
- Preverite tesnost sesalnih napeljav
- Očistite sesalni ventil
- Očistite sesalno košaro
- Preverite sesalno višino
Količina črpanja ne zadošča
Vzrok Odpravljanje
- Višina črpanja je previsoka
- Sesalna košara je umazana
- Vodni nivo naglo upada
- Zmogljivost črpalke je zmanjšana zaradi tujkov
(pesek, kamenje ipd.)
- Preverite sesalno višino
- Očistite sesalno košaro
- Sesalni ventil položite nižje
- Črpalko očistite in zamenjajte obrabne dele
Temperaturno stikalo črpalko izklaplja
Vzrok Odpravljanje
- Motor preobremenjen, trenje zaradi tujkov pre-
veliko
- Črpalko demontirajte in očistite, preprečite vse-
savanje tujkov (filter)
Opozorilo! Črpalka ne sme delati na suho.
Anleitung_4180303.indb 20Anleitung_4180303.indb 20 21.09.12 10:4421.09.12 10:44
