Crary PRO User manual

RECORD SERIAL NUMBER HERE
Manual P/N: 90806-00
Rev. 090114
STRINGER TRAILER
OWNER'S/PARTS
MANUAL

© 2014, Crary Agricultural Solutions, LLC, All rights reserved. Produced and printed in the USA.
HOW TO REACH US
ADDRESS TELEPHONE
FAX NUMBER HOURS INTERNET
Tile Pro
Crary Agricultural Solutions, LLC
P.O. Box 237
Morgan, MN 56266
Monday-Friday
8 am-5pm (CST)
For Parts and Service:
Ph: 507.249.3176 •
Fax: [phone]
Online: www.crarytilepro.com
GPS/LASER CONTROLS
TECHNICAL SUPPORT PLOW SETUP/ GENERAL QUESTIONS SALES SUPPORT
Kenton Johnson
Ph: 507.430.5729
[email protected]
Wayne Weber
Ph: 507.828.4548
[email protected]
Stan Isfeld
Ph: 504.430.7677
[email protected]
DISCLAIMER
This document is based on information available at the time of its publication. While efforts have been made to be ac-
curate, the information contained herein does not purport to cover all details or variations, nor to provide for every pos-
sible contingency in connection with installation, operation, or maintenance. Features may be described herein which
are not present in all systems. Crary Agricultural Solutions assumes no obligation of notice to holders of this document
with respect to changes subsequently made.
Crary Agricultural Solutions assumes no responsibility for the accuracy, completeness, sufficiency, or usefulness of the
information contained herein.
SPECIFICATIONS AND DESIGN ARE SUBJECT TO CHANGE WITHOUT NOTICE.
Crary Agricultural Solutions is continually making improvements and developing new equipment. In doing so, we re-
serve the right to make changes or add improvements to our product without obligation for equipment previously sold.
Because modification to this machine may affect the performance, function, and safety of its operation, no modifications
are to be made without the written permission of Crary Agricultural Solutions. Part replacements should be with original
equipment supplied by Crary Agricultural Solutions.
THE CRARY AGRICULTURAL SOLUTIONS STATEMENT OF PRODUCT SAFETY
As a manufacturer of specialized agricultural equipment, Crary Agricultural Solutions fully recognizes its responsibility
of providing its customers products that perform their expected use in a reasonably safe manner. Safety considerations
shall be an integral and high priority part of all engineering/design analysis and judgments involving Crary products. It
is our stated policy that our products will be manufactured to comply with the safety standards specified by the American
Society of Agricultural Engineers, the National Electrical Code, the Society of Automotive Engineers, and/or any other
applicable recognized standards at the time manufactured. However, this statement should not be construed to mean
that our product will safeguard against a customer’s own carelessness or neglect in violating common safety practices
specified in each product’s manual, nor will we be liable for any such act.
SERIAL NUMBER LOCATION
Always give your authorized Crary dealer the serial number
of your machine when ordering parts, requesting service, or
any other information. The serial number decal is located on
the front, left hand end of the air manifold.
Please record the serial number in the space provided on
the front cover and on the warranty and registration card. Serial Number Decal

Stringer Trailer Owner’s/Parts Manual iii
PN:90806-00 R090114
LIMITED WARRANTY
This warranty applies to all Crary Tile Pro equipment manufactured by Crary Agricultural Solutions, LLC (Crary).
Crary warrants to the original owner of each new Crary Tile Pro product to be free from defects in material and
workmanship, under normal use and service. The warranty shall extend as shown below from date of delivery. The
product is warranted to the original owner as evidenced by a completed warranty registration on file at Crary and
is non-transferable beyond the initial purchaser.
THE WARRANTY REGISTRATION MUST BE COMPLETEDAND RETURNED TO CRARY WITHIN 10 DAYS OF
DELIVERY OF THE PRODUCT TO THE ORIGINAL OWNER OR THE WARRANTY WILL BE VOID.
In the event of a failure, return the product, at your cost, along with proof of purchase to the selling Crary dealer.
Crary will, at its option, repair or replace any parts found to be defective in material or workmanship. Warranty on
any repairs will not extend beyond the product warranty. Repair or attempted repair by anyone other than a Crary
dealer as well as subsequent failure or damage that may occur as a result of that work will not be paid under this
warranty. Crary does not warrant replacement components not manufactured or sold by Crary.
This warranty applies only to parts or components that are defective in material or workmanship.
This warranty does not cover wear items including but not limited to knife tips, ground engaging components,
bearings, tires etc.
1. This warranty does not cover normal maintenance, service or adjustments.
2. This warranty does not cover depreciation or damage due to misuse, negligence, accident or improper main-
tenance.
3. This warranty does not cover damage due to improper setup, installation or adjustment.
4. This warranty does not cover damage due to unauthorized modifications of the product.
5. This warranty does not cover damage, deemed by a Crary representative, due to excessive stress or by ex-
ceeding the products ability and manufacturer’s intended use of the product.
Any warranty of any grade control, hydraulic components or guidance components sold on, or installed on, Crary
products are subject to the original manufacture warranty and are not the responsibility of Crary.
Crary is not liable for any property damage, personal injury or death resulting from the unauthorized modification
or alteration of a Crary product or from the owner’s failure to assemble, install, maintain or operate the product in
accordance with the provisions of the Owner’s manual. Crary is not liable for any damages or expenses incurred
on the host machine or on any non Crary equipment through the use of these products.
New replacement parts made by Crary carry a full 90-day, parts only, warranty from the date they are purchased.
Crary is not liable for indirect, incidental or consequential damages or injuries including but not limited to loss of
crops, loss of profits, rental of substitute equipment or other commercial loss.
This warranty gives you specific legal rights. You may have other rights that may vary from area to area.
Crary makes no warranties, representations or promises, expressed or implied as to the performance of its products
other than those set forth in this warranty. Neither the dealer nor any other person has any authority to make any
representations, warranties or promises on behalf of Crary or to modify the terms or limitations of this warranty in
any way. Crary, at its discretion, may periodically offer limited, written enhancements to this warranty
CRARY AGRICULTURAL SOLUTIONS, LLC IS A WHOLLY OWNED SUBSIDIARY OF CRARY INDUSTRIES,
INCAND RESERVES THE RIGHT TO CHANGE THE DESIGN AND/OR SPECIFICATIONS OF ITS PRODUCTS
AND WARRANTIESATANYTIME WITHOUT OBLIGATION TO PREVIOUS PURCHASERS OF ITS PRODUCTS.
Product Warranty Length
Crary Tile Pro Plow 1 year
Crary Tile Pro Trailers 1 year
Crary Tile Pro Spool/Carriers 1 year

Stringer Trailer Owner’s/Parts Manual
iv PN:90806-00 R090114

Stringer Trailer Owner’s/Parts Manual v
PN:90806-00 R090114
TABLE OF CONTENTS
DESCRIPTION PAGE DESCRIPTION PAGE
INTRODUCTION....................................................1
SAFETY .................................................................2
2.1 SAFETY ALERT SYMBOL ................................................................... 2
2.2 CALL BEFORE YOU DIG..................................................................... 3
2.3 GENERAL SAFETY.............................................................................. 4
2.4 OPERATING SAFETY.......................................................................... 5
2.5 MAINTENANCE SAFETY .................................................................... 5
2.6 HYDRAULIC SAFETY.......................................................................... 6
2.7 TRANSPORT SAFETY......................................................................... 6
2.8 STORAGE SAFETY ............................................................................. 6
2.9 ASSEMBLY SAFETY............................................................................ 6
2.10 SAFETY DECALS .............................................................................. 7
2.11 SIGN-OFF FORM ............................................................................... 8
SAFETY DECALS..................................................9
ASSEMBLY..........................................................10
4.1 TRAILER SPINDLE ASSEMBLY ........................................................ 10
OPERATION ........................................................11
5.1 MACHINE COMPONENTS ................................................................ 12
5.2 PRE-OPERATION CHECKLIST......................................................... 13
5.3 LOADING TILE................................................................................... 13
5.4 STRINGING TILE ............................................................................... 14
5.5 USING OPTIONAL SPOOL................................................................ 14
5.6 CONTROLS........................................................................................ 15
5.7 BRAKE ADJUSTMENT ...................................................................... 16
5.8 ADJUSTING THE PUMP.................................................................... 17
5.9 FILLING THE PUMP .......................................................................... 17
5.10 SECURE THE JACK ......................................................................... 17
5.11 SECURE TABLE TOP....................................................................... 18
5.12 TRAILER LIGHT WIRING ................................................................ 19
5.13 WIRE CONFIGURATIONS............................................................... 20
5.13.1 WIRELESS REMOTE WIRING CONFIGURATION FOR HY-
DRAULIC PUMP ....................................................................... 20
5.13.2 WIRING CONFIGURATION FOR HYDRAULIC PUMP........ 21
5.14 RESET TRANSMITTER ................................................................... 22
5.15 INFORMATION................................................................................. 24
5.16 TRANSPORTING ............................................................................. 26
5.17 STORAGE ........................................................................................ 26
SERVICE & MAINTENANCE...............................27
6.1 MAINTENANCE CHECKLIST ............................................................ 27
6.2 FLUIDS AND LUBRICANTS............................................................... 28
6.3 GREASING......................................................................................... 28
TROUBLESHOOTING.........................................29
SPECIFICATIONS................................................30
8.1 STRINGER TRAILER SPECIFICATIONS .......................................... 30
8.2 HYDRAULIC FITTING TORQUE ....................................................... 31
8.3 BOLT TORQUE .................................................................................. 32

Stringer Trailer Owner’s/Parts Manual
vi PN:90806-00 R090114

Stringer Trailer Owner’s/Parts Manual 1
PN:90806-00 R090114
OPERATOR ORIENTATION - All references to left, right, front and rear of the equipment, as mentioned throughout the
manual, are determined by standing behind the machine and facing the direction of forward travel.
Congratulations on your choice of a new Crary Tile Pro: Stringer Trailer to complement your farming operation. This
equipment has been designed and manufactured to meet the needs of a discerning agricultural industry for the efficient
growing of crops.
Safe, efficient, and trouble free operation of your Stringer Trailer requires that you and anyone else who will be operating
or maintaining the equipment, read and understand the Safety, Operation, Maintenance and Troubleshooting information
contained within the owner’s manual. Check each item referred to and acquaint yourself with the adjustments required
to obtain efficient operation.
This manual covers Stringer Trailers manufactured by Crary Agricultural Solutions. Differences are explained where
appropriate. Use the Table of Contents as a guide to locate required information.
Keep this manual handy for frequent reference and to pass on to new operators or owners. Call your Crary Tile Pro
dealer or distributor if you need assistance, information, or additional copies of the manual.
Many people have worked on the design, production, and delivery of this machine. They have built into it the highest
quality of materials and workmanship. The information in this manual is based on the knowledge, study, and experience
of these people through years of manufacturing specialized farming machinery.
The performance of the machine depends on proper maintenance and adjustment. Even if you are an experienced
operator of this or similar equipment, we ask you to read the owner’s manual before operating the machine. Keep the
manual handy for future reference. It has been carefully prepared, organized, and illustrated to assist you in finding the
information you need. Your Crary dealer will be happy to answer any further questions you may have about the machine.
Section INTRODUCTION
1

Stringer Trailer Owner’s/Parts Manual
2PN:90806-00 R090114
This Safety Alert Symbol means:
ATTENTION! BECOME ALERT!
YOUR SAFETY IS INVOLVED!
The Safety Alert symbol identifies important
safety messages on the Stringer Trailer and
in the manual. When you see this symbol,
be alert to the possibility of personal injury or
death. Follow the instructions in the safety
message.
DANGER - Indicates an imminently hazardous situation
that, if not avoided, will result in death or serious injury.
This signal word is to be limited to the most extreme
situations, typically for machine components that, for
functional purposes, cannot be guarded.
WARNING - Indicates a potentially hazardous situation
that, if not avoided, could result in death or serious injury,
and includes hazards that are exposed when guards are
removed. It may also be used to alert against unsafe
practices.
CAUTION - Indicates a potentially hazardous situation
that, if not avoided, may result in minor or moderate
injury. It may also be used to alert against unsafe
practices.
IMPORTANT - Instructions that must be followed to
ensure proper installation/operation of equipment.
NOTE - General statements to assist the reader.
Why is SAFETY important to you?
1. Accidents Disable and Kill
2. Accidents Cost
3. Accidents Can Be Avoided
SIGNAL WORDS:
Note the use of the signal words DANGER, WARNING,
CAUTION, IMPORTANT and NOTE with the safety
messages. The appropriate signal word for each mes-
sage has been selected using the following guidelines:
3 Big Reasons
2.1 SAFETY ALERT SYMBOL
SAFETY
Section
2

Stringer Trailer Owner’s/Parts Manual 3
PN:90806-00 R090114
2.2 CALL BEFORE YOU DIG
One free, easy call gets your utility lines
marked AND helps protect you from
injury and expense.
Safe Digging Is No Accident:
Always Call 811 Before You Dig
Know what’s below. Always call 811 before you dig.
Visit call811.com for more information.
CALL
DIG
BEFORE YOU
ALWAYS
INSERT
CALL CENTER
LOGO HERE
Call 811 first.
You really have no idea what is under the ground.
It’s a free service and could save your life!
SAFETY

Stringer Trailer Owner’s/Parts Manual
4PN:90806-00 R090114
SAFETY
YOU are responsible for the SAFE operation and main-
tenance of your Stringer Trailer. You must ensure that
you and anyone else who is going to operate, maintain or
work around the machine are familiar with the operating
and maintenance procedures and related safety informa-
tion contained in this manual. This manual will alert you to
all good safety practices that should be adhered to while
operating the machine.
Remember, YOU are the key to safety. Good safety prac-
tices not only protect you but also the people around you.
Make these practices a working part of your safety program.
Be certain that EVERYONE operating this equipment is
familiar with the recommended operating and maintenance
procedures and follows all the safety precautions. Most
accidents can be prevented. Do not risk injury or death by
ignoring good safety practices.
• Owners must give operating instructions to opera-
tors or employees before allowing them to operate
the equipment, and annually thereafter per OSHA
(Occupational Safety and Health Administration)
regulation 1928.57.
• The most important safety device on this equipment
is a safe operator. It is the operator’s responsibility
to read and understand ALL Safety and Operating
instructions in the manual and to follow them.
• A person who has not read and understood all
operating and safety instructions is not qualified
to operate the equipment. An untrained operator
exposes himself and bystanders to possible seri-
ous injury or death.
• Do not modify the equipment in any way. Unauthor-
ized modification may impair the function and/or
safety and could affect the life of the equipment.
Think SAFETY! Work SAFELY!
2.3 GENERAL SAFETY
1. Read and understand the
Owner’s Manual and all safe-
ty decals before operating,
maintaining, adjusting or
servicing the machine.
2. Only trained persons shall
operate the equipment. An
untrained operator is not
qualified to operate the equipment.
3. Have a first-aid kit available for use,
should the need arise, and know how
to use it.
4. Provide a fire extinguisher for use in
case of an accident. Store in a highly
visible place.
5. Do not allow children, spectators or
bystanders within hazard area of equip-
ment.
6. Wear appropriate protective gear. This
list includes but is not limited to:
• A hard hat.
• Protective shoes with slip
resistant soles.
• Protective goggles.
• Heavy gloves.
• Hearing protection.
• Respirator or filter mask.
7. Wear suitable ear protection during
prolonged exposure to excessive
noise.
8. Place all controls in neutral or off, stop engine, set park-
ing brake, chock wheels, remove ignition key and wait
for all moving parts to stop, before servicing, adjusting,
repairing or unplugging.
9. Review safety related items annually with all personnel
who will be operating or maintaining the equipment.

Stringer Trailer Owner’s/Parts Manual 5
PN:90806-00 R090114
SAFETY
1. Follow ALL operating, maintenance, and safety informa-
tion in this manual.
2. Support the equipment with blocks or safety stands
when working around it.
3. Follow good shop practices:
• Keep service area clean
and dry.
• Be sure electrical outlets and
tools are properly grounded.
• Use adequate light for the
job at hand.
4. Use only tools, jacks and hoists of sufficient capacity
for the job.
5. Place all controls in neutral or off, stop engine, set park-
ing brake, chock wheels, remove ignition key and wait
for all moving parts to stop before servicing, adjusting,
repairing or unplugging.
6. When maintenance work is completed, install and se-
cure all guards before resuming work.
7. Relieve pressure from hydraulic circuit before servicing
or disconnecting from tractor.
8. Keep hands, feet, hair and clothing away from all mov-
ing and/or rotating parts.
9. Clear the area of bystanders, especially small children,
when carrying out any maintenance and repairs or mak-
ing any adjustments.
10. Keep safety decals clean. Replace any decal that is
damaged or not clearly visible.
11. First-class maintenance is a prerequisite for the safest
operation of your equipment. Maintenance, including
lubrications, should be performed with the equipment
stopped and locked out.
1. Read and understand the owner’s manual and all safety
decals before servicing, adjusting or repairing.
2. Install and secure all guards and shields before starting
or operating.
3. Keep hands, feet, hair and clothing away from all mov-
ing and/or rotating parts.
4. Place all controls in neutral or off, stop engine, set park-
ing brake, chock wheels, remove ignition key and wait
for all moving parts to stop before servicing, adjusting,
repairing or unplugging.
5. Clear the area of bystanders, especially small children,
before starting.
6. Keep all hydraulic lines, fittings, and couplers tight and
free of leaks before and during use.
7. Clean reflectors and lights before transporting.
8. Review safety related items annually with all personnel
who will be operating or maintaining the Stringer Trailer.
9. Shut the tractor off when connecting the equipment
hydraulics.
Think SAFETY! Work SAFELY!
2.4 OPERATING SAFETY 2.5 MAINTENANCE SAFETY

Stringer Trailer Owner’s/Parts Manual
6PN:90806-00 R090114
SAFETY
1. Always place all hydraulic controls in neutral before dis-
connecting from tractor or working on hydraulic system.
2. Make sure that all components in the hydraulic system
are kept in good condition and are clean.
3. Relieve pressure before working on the hydraulic
system.
4. Replace any worn, cut, abraded, flattened or crimped
hoses.
5. Do not attempt any makeshift repairs to the hydraulic
fittings or hoses by using tape, clamps or cements.
The hydraulic system operates under extremely high-
pressure. Such repairs will fail suddenly and create a
hazardous and unsafe condition.
6. Wear proper hand and eye protection when searching
for a high-pressure hydraulic leak.
Use a piece of wood or cardboard
as a backstop instead of hands to
isolate and identify a leak.
7. If injured by a concentrated high-
pressure stream of hydraulic fluid,
seek medical attention immedi-
ately. Serious infection or toxic re-
action can develop from hydraulic
fluid piercing the skin surface.
8. Before applying pressure to the
system, make sure all components are tight and that
lines, hoses, and couplings are not damaged.
2.6 HYDRAULIC SAFETY
Think SAFETY! Work SAFELY!
1. Make sure you are in compliance with all local regula-
tions regarding transporting equipment on public roads
and highways.
2. It is the responsibility of the owner to know the lighting
and marking requirements of the local highway authori-
ties and to install and maintain the equipment to provide
compliance with the regulations. Add extra lights when
transporting at night or during periods of limited visibility.
2.7 TRANSPORT SAFETY
2.8 STORAGE SAFETY
2.9 ASSEMBLY SAFETY
1. Store the unit in an area away from human activity.
2. Do not permit children to play on or around the stored
equipment.
1. Assemble in an area with sufficient space to handle
the largest component and access to all sides of the
equipment
2. Use only lifts, cranes and tools with sufficient capacity
for the load.
3. When necessary, have someone assist you.
4. Do not allow spectators in the working area.
5. Be sure to read the Maintenance Safety section.

Stringer Trailer Owner’s/Parts Manual 7
PN:90806-00 R090114
SAFETY
1. Keep safety decals clean and legible at all times.
2. Replace safety decals that are missing or have become
illegible.
3. Replaced parts that displayed a safety decal should
also display the current decal.
4. Decals that need to be replaced are to be placed back
in the original location.
5. Safety decals are available from your authorized dealer
or the factory.
HOW TO INSTALL SAFETY DECALS:
1. Be sure that the installation area is clean and dry.
2. Be sure temperature is above 50°F (10°C).
3. Decide on the exact position before you remove the
backing paper.
4. Remove the smaller portion of the split backing paper.
5. Align the decal over the specified area and carefully
press the small portion with the exposed sticky back-
ing in place.
6. Slowly peel back the remaining paper and carefully
smooth the remaining portion of the decal in place.
7. Small air pockets can be pierced with a pin and
smoothed out using the piece of decal backing paper.
2.10 SAFETY DECALS
Think SAFETY! Work SAFELY!

Stringer Trailer Owner’s/Parts Manual
8PN:90806-00 R090114
SAFETY
DATE EMPLOYEE SIGNATURE EMPLOYER SIGNATURE
2.11 SIGN-OFF FORM
Crary Agricultural Solutions follows the general safety standards specified by the American Society of Agricultural En-
gineers (ASAE) and the Occupational Safety and Health Administration (OSHA). Anyone who will be operating and/
or maintaining the equipment must read and clearly understand ALL safety, operating and maintenance information
presented in this manual.
Do not operate or allow anyone else to operate this equipment until such information has been reviewed. Annually review
this information before the season start-up.
Make these periodic reviews of safety and operation a standard practice for all of your equipment. An untrained operator
is unqualified to operate this equipment.
A sign-off sheet is provided for your record keeping to show that all personnel who will be working with the equipment have
read and understood the information in the owner’s manual and have been instructed in the operation of the equipment.
SIGN - OFF FORM

Stringer Trailer Owner’s/Parts Manual 9
PN:90806-00 R090114
PN: 32901-000
Good safety requires that you familiarize yourself with the various safety decals, the type of warning and the area, or
particular function related to that area, that requires your SAFETY AWARENESS.
Think SAFETY! Work SAFELY!
SAFETY DECALS
Section
3
REMEMBER - If safety decals have been damaged, removed or become illegible or parts have been replaced without
safety decals, new decals must be applied. New safety decals are available from the manufacturer or an authorized dealer.

Stringer Trailer Owner’s/Parts Manual
10 PN:90806-00 R090114
Section ASSEMBLY
4
4.1 TRAILER SPINDLE ASSEMBLY
Read all instructions to become familiar with the parts and
procedure used before starting the actual work. You may
refer to the parts catalog in the back of this manual for ad-
ditional aid.
1. Assemble in an area with sufficient space to handle
the largest component and access to all sides of
the equipment.
2. Use only lifts, cranes and tools with sufficient capac-
ity for the load.
3. When necessary, have someone assist you.
4. Do not allow spectators in the working area.
WARNING
1. Remove the securing bands, spindle and top from
stringer table.
2. Raise the table till it is perpendicular to the ground.
3. Position the trailer spindle in-line with the receiving
holes on the table either manually or with pallet forks
or a hoist.
4. Insert bolts and tighten.

Stringer Trailer Owner’s/Parts Manual 11
PN:90806-00 R090114
Follow all safety instructions exactly. Safety is everyone’s
business. By following recommended procedures, a safe
working environment is provided for the operator, bystand-
ers and the area around the work site. Untrained operators
are not qualified to operate the machine.
Many features incorporated into this equipment are the
result of suggestions made by customers like you. Read
this manual carefully to learn how to operate the machine
safely and how to set it to provide maximum efficiency. By
following the operating instructions in conjunction with a
good maintenance program, your equipment will provide
many years of trouble-free service.
It is the responsibility of the owner or operator to read this
manual and to train all other operators before they start
working with the equipment. In addition to the design and
configuration of equipment, hazard control and accident
prevention are dependent upon the awareness, concern,
and prudence of personnel involved in the operation, trans-
port, maintenance and storage of equipment or in the use
and maintenance of facilities.
1. Read and understand the owner’s manual and all
safety signs before servicing, adjusting or repairing.
2. Install and secure all guards and shields before start-
ing or operating.
3. Keep hands, feet, hair and clothing away from all
moving and/or rotating parts.
4. Place all controls in neutral or off, stop engine, set
parking brake, chock wheels, remove ignition key
and wait for all moving parts to stop before servicing,
adjusting, repairing or unplugging.
WARNING
5. Clear the area of bystanders, especially small chil-
dren, before starting.
6. Keep all hydraulic lines, fittings, and couplers tight
and free of leaks before and during use.
7. Clean reflectors and lights before transporting.
8. Review safety related items annually with all person-
nel who will be operating or maintaining the equip-
ment.
9. Shut the tractor off when connecting the equipment
hydraulics.
OPERATION
Section
5

Stringer Trailer Owner’s/Parts Manual
12 PN:90806-00 R090114
OPERATION
A
B
C
D
5.1 MACHINE COMPONENTS
A. Spool Top
B. Mast Tube
C. Stringer Table
D. Trailer Jack

Stringer Trailer Owner’s/Parts Manual 13
PN:90806-00 R090114
OPERATION
5.2 PRE-OPERATION CHECKLIST
Efficient and safe operation of the Stringer Trailer requires
that each operator reads and understands the operating
procedures and all related safety precautions outlined in this
section. A pre-operation checklist is provided for the opera-
tor. It is important for both personal safety and maintaining
the good mechanical condition of the equipment that this
checklist is followed.
Before operating the equipment and each time thereafter,
the following areas should be checked off:
1. Service the machine per the schedule outlined in the
maintenance checklist.
2. Use only a tractor of adequate power and specifications
to operate the machine.
3. Check that all guards are installed, secured and func-
tioning as intended. Do not operate with missing or
damaged shields.
4. Ensure that the equipment is properly attached to the
tractor and that mechanical retainers, such as quick
pins, are installed.
5. Visually inspect the hydraulic system for leakage, loose
fittings, and damaged hoses. Tighten fittings, replace
damaged components and wipe up leaked or excess
hydraulic fluid.
5.3 LOADING TILE
1. Hitch the trailer to an acceptable tow vehicle.
2. Rotate the trailer table so one of the folding table wings
is at the rear of the trailer.
3. Engage the table lock.
4. Remove the table wing lock and fold the wing up under
the table and secure with a snap pin.
5. Use the switch pendant to raise the trailer table so that
the trailer top is just above ground level.
6. Remove the spool top manually by lifting and pulling
until the top has been removed. Set the top aside.
7. Back the trailer spindle into center of roll of tile while
looking through viewport on table deck, so as not dam-
age tile by striking it with mast tube.
8. Back into tile until tile contacts the table.
9. Place the top ring back on trailer spindle ensuring it is
fully seated.
10. Keeping a safe operating distance raise the stringer
table and top.
11. Once fully raised release the table wing and lock upright
and remove the table lock to string tile.
NOTE
Tile stringer works best by having the outer tile wrap at
the table and the inner tile wrap at the top so the table
rotates counter clockwise.
Spool top is heavy.
CAUTION

Stringer Trailer Owner’s/Parts Manual
14 PN:90806-00 R090114
OPERATION
5.4 STRINGING TILE
1. Remove the tile tie downs and pull off enough tile to feed
down into plow boot to hookup to outlet pipe or main.
2. While carefully having someone hold the pipe begin to
drive forward slowly allowing for the table to gradually
speed up to ground speed and not stretch the tile.
3. Maintain a consistent speed to help with a constant
tile feed.
4. Use the brake by pressing the top button on the switch
pendant to slow the table to prevent uncoiling on the
ground.
5. Top extensions are used for preventing improper uncoil-
ing of the tile spool due to windy conditions and can
be extended when necessary and should be retracted
when loading tile.
6. When finished stringing tile secure the remaining tile
to the table.
NOTE
Avoid over application of the brake to prevent inconsistent
feed and stretching of the tile.
5.5 USING OPTIONAL SPOOL
1. Load the spool onto the trailer with the back wing locked
up under the table and the table raised.
2. Load tile onto the trailer and secure the spool top with
the snap pins.
3. Unload the spool to store partial tile spool until reuse.
