Crate AIO CASE User manual

© 2017 Crate Computers, LLC.
All rights reserved. Crate Computers, the sails logo, and Crate
Computers logo are registered trademarks of Crate Computers in the
United States. All other trademarks are the property of their respective
owners. Product may vary slightly from those pictured.
INSTALLATION GUIDE
Crate Computers AIO Case
Lake Forest • California • 92630 • USA | cratecomputers.com

1
Table of Contents
Case Specifications................................................................................2
Case features..........................................................................................4
Accessory kit...........................................................................................6
Connecting the Stand...........................................................................8
Installing the motherboard.................................................................10
Installing the PSU..................................................................................12
Installing the PCI-E card.......................................................................14
Installing 2.5" drive(s)...........................................................................16
Powering the case fans.........................................................................18
Wiring the power switch.......................................................................20
Additional configuration ideas............................................................22
New build checklist................................................................................23

2
Case specifications

3
Maximum GPU Length: 266mm
Maximum CPU Cooler Height: 40mm
Maximum PSU Length:230 mm
Maximum Fan Depth: 25mm

4
Case features
Protectiveplate
Fangrill
DualSATAdriveenclosure
Motherboardtray

5
PWMFanheader
CrateComputerstand
CrateComputer
enclosure

6
Vesa to Crate Computer
Mount
2x Cable Management Kits
Power Switch and Cable

7
Accessory kit
6 x M3 Thumb Screws
6 x #6-32 Screws
16 x M3 Screws
5 x M3 Screws
4 x Crate Computer VESA
Mount Screws
2 x PCI Covers

8
Connecting the Stand
Slide the stand into the slot on the bottom of the enclosure.
Once you have inserted the stand inside the enclosure use the
pan-headed screws to attach the stand to the enclosure.
*Be sure to note the holes needed when you are ready to affix
the motherboard tray to the enclosure, this will need to be done
while the monitor is removed!

9
Once the stand and enclosure have been screwed together place
the VESA mount on the front of the enclosure next, using the
four large screws included. Now you can simply attach the
bracket to your display and hang it to your Crate Computer. Do
not forget to place the set-screw back and to make sure you
tighten all screws well.

10
Installingthemotherboard
Bottom
Linethe
motherboardup
tothe
motherboard
tray.
Oncelinedup
screwtheboard
downonthefour
mountsnotedhere.

11
Oncetheboardhasbeen
mountedconnectthePCI
extendertotheboard.

12
InstallingthePowersupply
Front
1:Placethepowersupplyintheenclosure.
2:Slidethepowersupplydownandtightenthescrewson
thebottomoftheenclosure
Bottom

13
1
2

14
Installingthevideocard
Be sure to install the
motherboard tray before
you install the video card.
The video card riser card is
lined up to use the top two
(or more) I/O slots.

15
Installingthevideocard
Be sure to install the
motherboard tray before
you install the video card.
The video card riser card is
lined up to use the top two
(or more) I/O slots.

16
Installingthe2.5"drives
On the motherboard tray you will see
the drive tray. This tray can support
two 2.5" drives, simply pull the locking
latch on the end to pull the tab out.
Once the tab is extended you can push
it into the enclosure to release the
drive. To connect the drives to your
MB look to the rear of the dive tray to
see the two SATA connectors and one
power connector.

17

18
Wiringthecasefans
With the fan grill removed
install your four 120mm fans.
You can utilize the included
fan hub if you wish.
