Crathco Simplicity CS-2E-16 User manual

Operator Manual
Grindmaster-Cecilware
4003 Collins Lane, Louisville, KY 40245 USA
Phone: [phone] Toll Free: 800.695.4500
Fax: [phone]
Web: gmcw.com Email: [email protected]
Safety Information........................2
Specifications.................................3
Installation and Set-Up.................4
Installation - Agitator Function ...5
Installation - Spray Function ........6
Product Preparation & Use...........7
Daily Cleaning ...............................8
Basic Machine Parts ....................11
Troubleshooting..........................12
Thank you for purchasing this quality cold beverage dispenser. For your safety and the safety of
others, read all warnings and the operator’s manual before installing or using the product. Properly
instruct all operators. Keep training records. For future reference, record serial number here:
Table of Contents
Simplicity™Bubbler
Crathco®Cold Beverage Dispensers
Grindmaster-Cecilware provides the industry’s
BEST warranty. Visit gmcw.com for warranty
terms and conditions.
Model CS-2D-16
Model CS-2E-16
©2014 Grindmaster-Cecilware
Printed in Thailand
0915 Form # CC-330-02
Part # 390-00003
(cULus certification applies only to
United States and Canada models.)

2 Crathco®Simplicity Bubbler
Lifting hazard. Single person lift could cause injury. Use assistance when moving or lifting.
Sharp edges can cause personal injury. Handle with care.
The appliance is not to be used by persons (including children 8 years and above) with reduced physical, sen-
sory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction. Be sure to provide supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
Children must be supervised to ensure they do not play with the appliance.
For safe and proper operation the appliance has to be placed in a stable horizontal position.
The appliance is only to be installed in locations where it can be overseen by trained personnel.
Safety Information
Observe machine voltage configuration. Do not apply improper voltage to machine or damage to machine will
occur.
Do not use extension cord.
Do not operate the appliance below 1.7°C (35°F) or above 40°C (104°F).
NOTICE/ AVIS/ AVISO
The appliance is not intended for outdoor use.
Do not clean with a water jet or use in an area where a water jet may be used.
Cleaning and maintenance shall be made only by properly trained persons with supervision.
Important Safety Information
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
For your safety and the safety of others, read all warnings and the operator’s manual before installing or using
the product.
DANGER: This term warns the user of imminent hazard that will result in serious injury or death.
WARNING: This term refers to a potential hazard or unsafe practice, which could result in serious injury or death.
CAUTION: This term refers to a potential hazard or unsafe practice, which could result in minor or moderate
injury.
NOTICE: This term refers to information that needs special attention or must be fully understood.
CAUTION/ ATTENTION/ ATENCIÓN
WARNING/ AVERTISSEMENT/ ADVERTENCIA

Simplicity Bubbler Crathco®3
Specifications
Northern America
Model Description Dimensions (H x W x D) Electrical Certifications
CS-2E-16 (2) 2.4 gallon (9L) bowls, 25.3” x 10.5” x 17.6” 115V / 60 Hz / 3.6A C-UL US, NSF
agitator model.
CS-2E-16-S (2) 2.4 gallon (9L) bowls, 25.3” x 10.5” x 17.6” 115V / 60 Hz / 3.6A C-UL US, NSF
spray model.
CS-4E-16 (4) 2.4 gallon (9L) bowls, 25.5” x 20.4” x 17.7” 115V / 60 Hz / 8.5A C-UL US, NSF
agitator model.
CS-4E-16-S (4) 2.4 gallon (9L) bowls, 25.5” x 20.4” x 17.7” 115V / 60 Hz / 8.5A C-UL US, NSF
spray model.
CS-1D-16 (1) 4.75 gallon (18L) bowl, 25.3” x 10.5” x 17.6” 115V / 60 Hz / 3.6A C-UL US, NSF
agitator model.
CS-1D-16-S (1) 4.75 gallon (18L) bowl, 25.3” x 10.5” x 17.6” 115V / 60 Hz / 3.6A C-UL US, NSF
spray model.
CS-2D-16 (2) 4.75 gallon (18L) bowls, 25.5” x 20.4” x 17.7” 115V / 60 Hz / 8.5A C-UL US, NSF
agitator model.
CS-2D-16-S (2) 4.75 gallon (18L) bowls, 25.5” x 20.4” x 17.7” 115V / 60 Hz / 8.5A C-UL US, NSF
spray model.
CS-3D-16 (1) 4.75 gallon (18L) bowl, 25.5” x 20.4” x 17.7” 115V / 60 Hz / 8.5A C-UL US, NSF
(2) 2.4 gallon (9L) bowls,
agitator model.
CS-3D-16-S (1) 4.75 gallon (18L) bowl, 25.5” x 20.4” x 17.7” 115V / 60 Hz / 8.5A C-UL US, NSF
(2) 2.4 gallon (9L) bowls,
spray model.
Export
Model Description Dimensions (H x W x D) Electrical Certifications/
Declarations
CS-2E-10 (2) 2.4 gallon (9L) bowls, 25.3” x 10.5” x 17.6” 100V / 50/60 HZ / 3.6A NSF
agitator model. 64 cm x 27 cm x 45 cm
CS-2E-10-S (2) 2.4 gallon (9L) bowls, 25.3” x 10.5” x 17.6” 100V / 50/60 HZ / 3.6A NSF
spray model. 64 cm x 27 cm x 45 cm
CS-2E-22 (2) 2.4 gallon (9L) bowls, 25.3” x 10.5” x 17.6” 230V / 50/60 HZ / 1.5A NSF, CE
agitator model. 64 cm x 27 cm x 45 cm
CS-2E-22-S (2) 2.4 gallon (9L) bowls, 25.3” x 10.5” x 17.6” 230V / 50/60 HZ / 1.5A NSF, CE
spray model. 64 cm x 27 cm x 45 cm
CS-4E-22 (4) 2.4 gallon (9L) bowls, 25.5” x 20.4” x 17.7” 230V / 50/60 HZ / 4A NSF, CE
agitator model. 65 cm x 52 cm x 45 cm
CS-4E-22-S (4) 2.4 gallon (9L) bowls, 25.5” x 20.4” x 17.7” 230V / 50/60 HZ / 4A NSF, CE
spray model. 65 cm x 52 cm x 45 cm
CS-1D-22 (1) 4.75 gallon (18L) bowl, 25.3” x 10.5” x 17.6” 230V / 50/60 HZ / 1.5A NSF, CE
agitator model. 64 cm x 27 cm x 45 cm
CS-1D-22-S (1) 4.75 gallon (18L) bowl, 25.3” x 10.5” x 17.6” 230V / 50/60 HZ / 1.5A NSF, CE
spray model. 64 cm x 27 cm x 45 cm
CS-2D-22 (2) 4.75 gallon (18L) bowls, 25.5” x 20.4” x 17.7” 230V / 50/60 HZ / 4A NSF, CE
agitator model. 65 cm x 52 cm x 45 cm
CS-2D-22-S (2) 4.75 gallon (18L) bowls, 25.5” x 20.4” x 17.7” 230V / 50/60 HZ / 4A NSF, CE
spray model. 65 cm x 52 cm x 45 cm
CS-3D-22 (1) 4.75 gallon (18L) bowl, 25.5” x 20.4” x 17.7” 230V / 50/60 HZ / 4A NSF, CE
(2) 2.4 gallon (9L) bowls, 65 cm x 52 cm x 45 cm
agitator model.
CS-3D-22-S (1) 4.75 gallon (18L) bowl, 25.5” x 20.4” x 17.7” 230V / 50/60 HZ / 4A NSF, CE
(2) 2.4 gallon (9L) bowls, 65 cm x 52 cm x 45 cm
spray model.

4 Crathco®Simplicity Bubbler
Installation and Set-Up
1.
2.
Place machine on counter with proper spacing.
• The appliance must be placed in a horizontal position.
• The appliance is suitable for indoor use only.
a. Place dispenser on
stable counter strong
enough to support
its weight.
b. Allow 13 cm (5”) on sides
and 15 cm (6”) on back
for proper ventilation.
c. Position machine away
from heat emitting
objects (i.e. ovens, grills,
refrigeration equipment).
Install power cord.
a.
Do not use extension cord.
Failure to follow proper installation
guidelines can damage equipment
and void warranty.
Plug cord into power outlet.
b.
Note proper voltage.
Observe machine voltage configuration.
Do not apply improper voltage to
machine or damage to machine will
occur.
1. This appliance is not intended for the use by persons (including children) with reduced physical, sensory, or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. This appliance is only to be installed in locations where it can be overseen by trained personnel.
5”
(13 cm)
5”
(13 cm)
6”
(15 cm)
6” (15 cm) minimum
machine spacing from
wall
5” (13 cm) minimum
machine spacing from
wall or other machines
Recommended ambient temperature 75° F
(25° C).
Top View
Front View
CAUTION/ ATTENTION/
ATENCIÓN

Simplicity Bubbler Crathco®5
Installation - Agitator Function
1. 2.
4.
3.
5. 7.
8.
6.
9. 10.
Install mixing impeller.
Install bowl gasket.
Place o-ring on dispense valve
(check if nicked or twisted). Place in
bowl.
Install assembled bowl.
NOTICE:
Machine must be OFF.
Insert bowl lip underneath
of lock position on the back
of top tray.
Then, press down on the
front of the bowl until
you hear a click indicating
the bowl is locked proper-
ly in place.
Install handle. Flip out support bracket for
drip tray.
Place drip tray
cover on drip
tray.
Install drip tray.
Mix product in clean container.
Fill bowl with product.
Install bowl cover. Turn power “on”.
a. b.
a. b.
CAUTION/ ATENCIÓN/
ATTENTION
Sharp edges can
cause personal injury. Handle
with care.
Replace bearing sleeve if
flange thickness is less
than 0.75mm
(0.03 inch)
thick.
Replace impeller if
bearing surface is
worn more than
0.5mm (0.02 inch).
Inspect for wear.
NOTICE/ AVIS/ AVISO:

6 Crathco®Simplicity Bubbler
1.
3. 4. 5.
Install pump cover.
Place o-ring on dispense valve
(check if nicked or twisted).
Place in bowl.
Install assembled bowl.
Machine must be OFF.
Insert bowl lip underneath
of lock position on the
back of top tray.
Then, press down on the
front of the bowl until
you hear a click indicating
the bowl is locked proper-
ly in place.
6. 7. 8. 9.
10. 11. 12.
Install spray tube to fit
with Pump cover.
Install handle. Flip out support bracket
for drip tray.
Install drip tray and cover.
Mix product in clean container.
Fill bowl with product.
Install bowl cover. Turn power “on”.
Installation - Spray Function
b.
a.
b.
2.
Install mixing impeller. Install bowl gasket.
CAUTION/ ATENCIÓN/
ATTENTION
Sharp edges can
cause personal injury. Handle
with care.
Replace bearing sleeve if
flange thickness is less than
0.75mm
(0.03 inch) thick.
Replace impeller if
bearing surface is
worn more than
0.5mm (0.02 inch).
Inspect for wear.
a.
NOTICE/ AVIS/
AVISO:

Simplicity Bubbler Crathco®7
Product Preparation & Use
1. Wash hands thoroughly when handling
dispenser and product. 2.
Pail
Wire whisk
Measuring pitcher
3. 4.
5.
Pour concentrate into dispenser and then add
remaining water per product label.
7.
Turn on main power
switch.
Correct way
to dispense.
Install lid.
8. 18L
Bowl 9L
Bowl
Min.
(1-1/2L)
Max.
To ensure safe and quality beverage, use only
reliable, purified, or potable water source to
prepare the product.
Prepare concentrate by mixing powder with water
using wire whisk until completely dissolved. Follow
recommended dilution per product label.
Always observe minimum 3 liter (18L bowl) or 1-1/2
liter (9L bowl) fill level to prevent foaming of
product at low level.
Min.
(3L)
Max.
6.
Incorrect way
to dispense.
Mixing tools.
Use only clean mixing tools to prepare product.
9. PRODUCT PREPARATION AND USE
1. Prepare concentrate by mixing powder with water using wire whisk until completely
dissolved. Follow recommended dilution per product label.
2. Pour concentrate into dispenser and then add remaining water per product label.
3. Install lid and turn on main power switch.
4. 25~30° C (77~86° F) ambient temperature is suitable for the operation.
5. This machine maintains beverage temperature of 1~5° C (34~41° F).
6. The dispenser is not for dispensing potentially hazardous beverage.

8 Crathco®Simplicity Bubbler
Daily Cleaning
Machine Disassembly
1. 2.
3. 4. 5.
6.
7. 9.
DAILY
12345
6 7 8 9 10 11 12
13 14 15 16 17 18 19
20 21 22 23 24 25 26
27 28 29 30
FRAGILE!
8.
Turn power “off”. Remove drip tray and cover.
Rotate support brackets for
drip tray.
Drain bowl. Remove handle.
Remove bowl cover. Press release latch on front of the
machine before removing the bowl.
Do not drop.
Remove valve with seal. Remove bowl gasket. Remove mixing impeller.
NOTICE/ AVIS/ AVISO:

Simplicity Bubbler Crathco®9
Daily Cleaning (cont.)
Cleaning Procedures
Cleaning Materials & Tools
Take parts to sink.
4.
Units with spray agitators:
Remove pump cover and spray
tube.
Lift out dispense valve and
remove o-ring.
Wash with detergent
and warm water.
2. 3. 50°C (122°F)
Maximum water
temperature for
cleaning.
75mm (3 inch)
Maximum
water level for
cleaning
Rinse with clean water. Wipe evaporator plate with
detergent and warm water.
6.5.
8. 9.
liquid detergent
(do not use laundry bar/
powdered detergents)
long brush
foam/sponge
(do not use abrasive)
sprayer
toothbrush
sanitizer
(chlorine based)
paper towels
Clean front panel, exterior panels
and release latch.
7.
1.
a. b.
Clean counter and bottom part
of dispenser with paper towel.
ABRASIVES WILL SCRATCH PLASTIC
PARTS. WASH BOWL LIDS IN COOL OR LUKEWARM WATER TO
AVOID LEAKS DUE TO SEALED SURFACE BEING DAMAGED.
The appliance is not suitable for
installation in an area where a water jet could be used. The
appliance must not be cleaned by water jet.
THOROUGHLY CLEAN ALL PARTS IN WARM WATER USING A MILD
NON-ABRASIVE DETERGENT AND RINSE THOROUGHLY.
NOTICE/ AVIS/ AVISO:
NOTICE/ AVIS/ AVISO:

10 Crathco®Simplicity Bubbler
2.
Daily Cleaning (cont.)
Daily Sanitizing
DAILY
12345
678910 11 12
13 14 15 16 17 18 19
20 21 22 23 24 25 26
27 28 29 30 Prepare 8L of chlorine-based
sanitizing solution (to 100 ppm) per
package instructions.
Submerge parts in solution for 15
minutes.
5.
Spray inside of lid with sanitizer.
3. 4.
Air dry parts overnight.
1.
Spray inside of bowl with sanitizer.
XII

Simplicity Bubbler Crathco®11
Item Part Number Description Item Part Number Description
1 200-00063 Push Handle 12 210-00125 Cover, Bowl 9 Liters
2 290-00006 Gasket, Bowl 13 231-00009 Bowl 9 Liters
3 210-00130 Impeller mixing for Low speed motor 14 231-00028 Merchandiser assembly (Optional)
4 210-00200 Impeller mixing for High speed motor 15 210-00201 Cover, side merchandiser (Optional)
5 210-00128 Pump Cover (Optional) 16 210-00132 Merchandiser right side (Optional)
6 210-00129 Spray Tube (optional) 17 350-00017 Screw, JF 4x12 SUS (Optional)
7 231-00010 Bowl 18 Liter 18 210-00202 Cover, rear merchandiser (Optional)
8 210-00126 Cover, Bowl 18 Liters 19 210-00134 Merchandiser rear side (Optional)
9 99380 Seal, Valve Dispense 20 210-00133 Merchandiser left side (Optional)
10 99463 Valve, Dispense 21 230-00402 Cover, Bowl 9 Liters insulated
11 99464 Dispense valve with seal 22 230-00403 Cover, Bowl 18 Liters insulated
Basic Machine Parts
Bowl Assembly
Bowl Assembly Parts List

12 Crathco®Simplicity Bubbler
Leaking
No product agitation
1.
a. O-ring nicked,
deformed, or
twisted? Cracked bowl? Replace bowl.
1. 2.
Impeller and/or axle worn? Replace worn parts.
See routine maintenance.
?
Replace pump
axle if flange
thickness is
less than
.75mm
(0.03 inch)
thick.
Replace
impeller if
bearing
surface is
worn.
a.b.
5.
Valve securely in place? Push
and twist to seat.
Gasket secured in place? Push to
seat.
b. Foreign particles on
bowl valve seat?
2. 3.
Drain tray overflow? Empty tray.
4.
3.
Impeller assembled correctly?
Pump motor magnet needs adjustment?
(Call for service.
Troubleshooting

Simplicity Bubbler Crathco®13
Troubleshooting (cont.)
No refrigeration
1.
Plugged in to wall outlet?
2.
3. Compressor does not operate;
fan does?
(Call for service.
4.
Poor refrigeration
1.
2. 3.
4. 5.
?
No product agitation?
See previous page.
Faulty thermostat?
Machine will not operate.
(Call for service.
Dirty condenser filter and condenser?
Clean condenser or (call for service.
Compressor does not operate;
fan does not operate.
Faulty fan motor?
(Call for service.
Impeller does not spin. Faulty
pump motor?
(Call for service.
Faulty thermostat or improper
setting?
(Call for service.
Power switch on?
Operator Manual
Grindmaster-Cecilware
4003Collins Lane, Louisville, KY 40245 USA
Phone: [phone] Toll Free: 800.695.4500
Fax:[phone]
Web:gmcw.com Email: [email protected]
Safety Information........................2
Specifications.................................3
Installation and Set-Up.................4
Installation - Agitator Function...5
Installation - Spray Function........6
Product Preparation & Use...........7
Daily Cleaning ...............................8
Basic Machine Parts....................11
Troubleshooting..........................12
Thankyou for purchasing this quality cold beverage dispenser. For your safety and the safety of
others,read all warnings and the operator’s manual before installing or using the product. Properly
instructall operators. Keep training records. For future reference, record serial number here:
Table of Contents
Simplicity™Bubbler
Crathco®ColdBeverage Dispensers
Grindmaster-Cecilware provides the industry’s
BEST warranty. Visit gmcw.com for warranty
terms and conditions.
Model CS-2D-16
Model CS-2E-16
©2014Grindmaster-Cecilware
Printedin Thailand
0915Form # CC-330-02
Part# 390-00003
?

14 Crathco®Simplicity Bubbler
Troubleshooting (cont.)
Noisy machine
3.
2.
4.
Bowl or pump installed while unit in “on” position?
Turn unit off. Reinstall parts.
6. Fan blade bent?
Unplug unit, remove side panel, inspect fan blade.
Faulty pump motor bearings.
(Call for service.
5.
Impeller and/or axle worn? Replace worn parts.
See routine maintenance.
Broken impeller? Replace it.
1.
Impeller installed correctly in bowl?
Chattering impeller? Ensure
correct drive magnet height or
(Call for service.
7. MAINTENANCE
1. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a
similarly qualified persons in order to avoid a hazard.
2. When freezing occurs, the appliance must be powered off.
3. The appliance is suitable for liquid juice concentrate and beverage mixing powder.
4. Access to the service area is restricted to persons having knowledge and practical experience of the
appliance, in particular as far as safety and hygiene are concerned.
Replace pump
axle if flange
thickness is
less than
.75mm
(0.03 inch)
thick.
Replace
impeller if
bearing
surface is
worn.

Simplicity Bubbler Crathco®15
If you still need help, call Grindmaster-Cecilware Technical Service Department, [phone] or [phone]
(USA & Canada only) (Monday through Friday 8 AM - 6 PM EST). Please have the model and serial number ready
so that accurate information can be given.
Prior authorization must be obtained from Grindmaster-Cecilware for all warranty claims.
Grindmaster-Cecilware provides the industry’s BEST warranty. Visit our website at GMCW.com for
warranty terms and conditions.
Troubleshooting (cont.)

©2014 Grindmaster-Cecilware
Printed in Thailand
0915 Form # CC-330-02
Part # 390-00003
Grindmaster-Cecilware
4003 Collins Lane, Louisville, KY 40245 USA
Phone: [phone] Toll Free: 800.695.4500
Fax: [phone]
Web: gmcw.com Email: [email protected]
