Crathco Simplicity CS-3L-16 User manual

Operator Manual
Grindmaster-Cecilware
4003 Collins Lane, Louisville, KY 40245 USA
Phone: [phone] Toll Free: 800.695.4500
Fax: [phone]
Web: gmcw.com Email: [email protected]
Safety Information........................2
Specifications.................................3
Installation and Set-Up.................4
Product Preparation & Use...........7
Daily Cleaning ...............................8
Troubleshooting..........................11
Basic Machine Parts ....................14
Thank you for purchasing this quality cold beverage dispenser. For your safety and the safety of
others, read all warnings and the operator’s manual before installing or using the product. Properly
instruct all operators. Keep training records. For future reference, record serial number here:
Table of Contents
Simplicity™Bubbler
Crathco®Cold Beverage Dispensers
Grindmaster-Cecilware provides the industry’s
BEST warranty. Visit gmcw.com for warranty
terms and conditions.
Model CS-2D-16
Model CS-2E-16
©2017 Grindmaster-Cecilware
Printed in Thailand
0617 Form # CC-330-04
Part # 390-00003
(cULus certification applies only to
United States and Canada models.)
Model CS-3L-16
Activate your warranty now at
http://gmcw.com/warranty-registration

2 Crathco®Simplicity Bubbler
Lifting hazard. Single person lift could cause injury. Use assistance when moving or lifting.
Sharp edges can cause personal injury. Handle with care.
The appliance is not to be used by persons (including children 8 years and above) with reduced physical, sen-
sory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction. Be sure to provide supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
Children must be supervised to ensure they do not play with the appliance.
For safe and proper operation the appliance has to be placed in a stable horizontal position.
The appliance is only to be installed in locations where it can be overseen by trained personnel.
Safety Information
Observe machine voltage configuration. Do not apply improper voltage to machine or damage to machine will
occur.
Do not use extension cord.
Do not operate the appliance below 1.7°C (35°F) or above 40°C (104°F).
Clean and sanitize unit before first use.
NOTICE/ AVIS/ AVISO
The appliance is not intended for outdoor use.
Do not clean with a water jet or use in an area where a water jet may be used.
Cleaning and maintenance shall be made only by properly trained persons with supervision.
Important Safety Information
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
For your safety and the safety of others, read all warnings and the operator manual before installing or using
the product.
DANGER: This term warns the user of imminent hazard that will result in serious injury or death.
WARNING: This term refers to a potential hazard or unsafe practice, which could result in serious injury or death.
CAUTION: This term refers to a potential hazard or unsafe practice, which could result in minor or moderate
injury.
NOTICE: This term refers to information that needs special attention or must be fully understood.
CAUTION/ ATTENTION/ ATENCIÓN
WARNING/ AVERTISSEMENT/ ADVERTENCIA

Simplicity Bubbler Crathco®3
Specifications
Northern America
Export
Model Description Dimensions (H x W x D) Electrical Certifications/
Declarations
CS-2E-10 (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 100V / 50/60 HZ / 3.6A NSF
agitator model. 70 cm x 27 cm x 45 cm
CS-2E-10-S (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 100V / 50/60 HZ / 3.6A NSF
spray model. 70 cm x 27 cm x 45 cm
CS-2E-22 (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 230V / 50/60 HZ / 1.5A NSF, CE
agitator model. 70 cm x 27 cm x 45 cm
CS-2E-22-S (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 230V / 50/60 HZ / 1.5A NSF, CE
spray model. 70 cm x 27 cm x 45 cm
CS-4E-22 (4) 2.4 gallon (9L) bowls, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
agitator model. 65 cm x 52 cm x 45 cm
CS-4E-22-S (4) 2.4 gallon (9L) bowls, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
spray model. 70 cm x 52 cm x 45 cm
CS-1D-22 (1) 4.75 gallon (18L) bowl, 27.5” x 10.5” x 17.75” 230V / 50/60 HZ / 1.5A NSF, CE
agitator model. 70 cm x 27 cm x 45 cm
CS-1D-22-S (1) 4.75 gallon (18L) bowl, 27.5” x 10.5” x 17.75” 230V / 50/60 HZ / 1.5A NSF, CE
spray model. 70 cm x 27 cm x 45 cm
CS-2D-22 (2) 4.75 gallon (18L) bowls, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
agitator model. 70 cm x 52 cm x 45 cm
CS-2D-22-S (2) 4.75 gallon (18L) bowls, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
spray model. 65 cm x 52 cm x 45 cm
CS-3D-22 (1) 4.75 gallon (18L) bowl, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
(2) 2.4 gallon (9L) bowls, 70 cm x 52 cm x 45 cm
agitator model.
CS-3D-22-S (1) 4.75 gallon (18L) bowl, 27.5” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
(2) 2.4 gallon (9L) bowls, 70 cm x 52 cm x 45 cm
spray model.
CS-3L-22 (3) 4.75 gallon (18L) bowls, 31.3” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
agitator model. 80 cm x 52 cm x 45 cm
CS-3L-22-S (3) 4.75 gallon (18L) bowls, 31.3” x 20.5” x 17.75” 230V / 50/60 HZ / 4A NSF, CE
spray model. 80 cm x 52 cm x 45 cm
Model Description Dimensions (H x W x D) Electrical Certifications
CS-2E-16 (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 120V / 60 Hz / 3.6A C-UL US, NSF
agitator model.
CS-2E-16-S (2) 2.4 gallon (9L) bowls, 27.5” x 10.5” x 17.75” 120V / 60 Hz / 3.6A C-UL US, NSF
spray model.
CS-4E-16 (4) 2.4 gallon (9L) bowls, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
agitator model.
CS-4E-16-S (4) 2.4 gallon (9L) bowls, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
spray model.
CS-1D-16 (1) 4.75 gallon (18L) bowl, 27.5” x 10.5” x 17.75” 120V / 60 Hz / 3.6A C-UL US, NSF
agitator model.
CS-1D-16-S (1) 4.75 gallon (18L) bowl, 27.5” x 10.5” x 17.75” 120V / 60 Hz / 3.6A C-UL US, NSF
spray model.
CS-2D-16 (2) 4.75 gallon (18L) bowls, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
agitator model.
CS-2D-16-S (2) 4.75 gallon (18L) bowls, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
spray model.
CS-3D-16 (1) 4.75 gallon (18L) bowl, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
(2) 2.4 gallon (9L) bowls,
agitator model.
CS-3D-16-S (1) 4.75 gallon (18L) bowl, 27.5” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
(2) 2.4 gallon (9L) bowls,
spray model.
CS-3L-16 (3) 4.75 gallon (18L) bowls, 31.3” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
agitator model.
CS-3L-16-S (3) 4.75 gallon (18L) bowls, 31.3” x 20.5” x 17.75” 120V / 60 Hz / 8.5A C-UL US, NSF
spray model.

4 Crathco®Simplicity Bubbler
Installation and Set-Up
1.
2.
Place machine on counter with proper spacing.
• The appliance must be placed in a horizontal position.
• The appliance is suitable for indoor use only.
a. Place dispenser on
stable counter strong
enough to support
its weight.
b. Allow 5” (13 cm) on sides
and 6” (15 cm) on back
for proper ventilation.
c. Position machine away
from heat emitting
objects (i.e. ovens, grills,
refrigeration equipment).
Install power cord.
a.
Do not use extension cord.
Failure to follow proper installation
guidelines can damage equipment
and void warranty.
Plug cord into power outlet.
b.
Note proper voltage.
Observe machine voltage configuration.
Do not apply improper voltage to
machine or damage to machine will
occur.
1. This appliance is not intended for the use by persons (including children) with reduced physical, sensory, or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the appliance.
3. This appliance is only to be installed in locations where it can be overseen by trained personnel.
5”
(13 cm)
5”
(13 cm)
6”
(15 cm)
6” (15 cm) minimum
machine spacing from
wall
5” (13 cm) minimum
machine spacing from
wall or other machines
Recommended ambient temperature 75° F
(25° C).
Top View
Front View
CAUTION/ ATTENTION/
ATENCIÓN

Simplicity Bubbler Crathco®5
Installation - Agitator Function (Model CS-XX-YY)
1. 2.
4.
3.
5. 7.
8.
6.
9. 10.
Install mixing impeller.
Install bowl gasket.
Place o-ring on dispense valve
(check if nicked or twisted). Place in
bowl.
Install assembled bowl.
NOTICE:
Machine must be OFF.
Insert bowl lip underneath
of lock position on the back
of top tray.
Then, press down on the
front of the bowl until
you hear a click indicating
the bowl is locked proper-
ly in place.
Install handle. Flip out support bracket for
drip tray.
Place drip tray
cover on drip
tray.
Install drip tray.
Mix product in clean container.
Fill bowl with product.
Install bowl cover. Turn power “on”.
a. b.
a. b.
CAUTION/ ATENCIÓN/
ATTENTION
Sharp edges can
cause personal injury. Handle
with care.
Replace axle if flange
thickness is less than
0.75mm
(0.03 inch)
thick.
Replace impeller if
bearing surface is
worn more than
0.5mm (0.02 inch).
Inspect for wear.
NOTICE/ AVIS/ AVISO:

6 Crathco®Simplicity Bubbler
1.
3. 4. 5.
Install pump cover.
Place o-ring on dispense valve
(check if nicked or twisted).
Place in bowl.
Install assembled bowl.
Machine must be OFF.
Insert bowl lip underneath
of lock position on the
back of top tray.
Then, press down on the
front of the bowl until
you hear a click indicating
the bowl is locked proper-
ly in place.
6. 7. 8. 9.
10. 11. 12.
Install spray tube to fit
with Pump cover.
Install handle. Flip out support bracket
for drip tray.
Install drip tray and cover.
Mix product in clean container.
Fill bowl with product.
Install bowl cover. Turn power “on”.
Installation - Spray Function (Model CS-XX-YY-S)
b.
a.
b.
2.
Install mixing impeller. Install bowl gasket.
CAUTION/ ATENCIÓN/
ATTENTION
Sharp edges can
cause personal injury. Handle
with care.
Replace axle if flange thick-
ness is less than 0.75mm
(0.03 inch) thick.
Replace impeller if
bearing surface is
worn more than
0.5mm (0.02 inch).
Inspect for wear.
a.
NOTICE/ AVIS/
AVISO:

Simplicity Bubbler Crathco®7
Product Preparation & Use
1. Wash hands thoroughly when handling
dispenser and product. 2.
Pail
Wire whisk
Measuring pitcher
3. 4.
5.
Pour concentrate into dispenser and then add
remaining water per product label.
7.
Turn on main power
switch.
Correct way
to dispense.
Install lid.
8. 18L
Bowl 9L
Bowl
Min.
(1-1/2L)
Max.
To ensure safe and quality beverage, use only
reliable, purified, or potable water source to
prepare the product.
Prepare concentrate by mixing powder with water
using wire whisk until completely dissolved. Follow
recommended dilution per product label.
Always observe minimum 3 liter (18L bowl) or 1-1/2
liter (9L bowl) fill level to prevent foaming of
product at low level.
Min.
(3L)
Max.
6.
Incorrect way
to dispense.
Mixing tools.
Use only clean mixing tools to prepare product.
9. PRODUCT PREPARATION AND USE
1. Prepare concentrate by mixing powder with water using wire whisk until completely
dissolved. Follow recommended dilution per product label.
2. Pour concentrate into dispenser and then add remaining water per product label.
3. Install lid and turn on main power switch.
4. 25~30° C (77~86° F) ambient temperature is suitable for the operation.
5. This machine maintains beverage temperature of 1~5° C (34~41° F).
6. The dispenser is not for dispensing potentially hazardous beverage.

8 Crathco®Simplicity Bubbler
Daily Cleaning
Machine Disassembly
1. 2.
3. 4. 5.
6.
7. 9.
DAILY
12345
6 7 8 9 10 11 12
13 14 15 16 17 18 19
20 21 22 23 24 25 26
27 28 29 30
FRAGILE!
8.
Turn power “off”. Remove drip tray and cover.
Rotate support brackets for
drip tray.
Drain bowl. Remove handle.
Remove bowl cover. Press release latch on front of the
machine before removing the bowl.
Do not drop.
Remove valve with seal. Remove bowl gasket. Remove mixing impeller.
NOTICE/ AVIS/ AVISO:

Simplicity Bubbler Crathco®9
Daily Cleaning (cont.)
Cleaning Procedures
Cleaning Materials & Tools
Take parts to sink.
4.
Units with spray agitators:
Remove pump cover and spray
tube.
Lift out dispense valve and
remove o-ring.
Wash with detergent
and warm water.
2. 3. 50°C (122°F)
Maximum water
temperature for
cleaning.
75mm (3 inch)
Maximum
water level for
cleaning
Rinse with clean water. Wipe evaporator plate with
detergent and warm water.
6.5.
8. 9.
liquid detergent
(do not use laundry bar/
powdered detergents)
long brush
foam/sponge
(do not use abrasive)
sprayer
toothbrush
sanitizer
(chlorine based)
paper towels
Clean front panel, exterior panels
and release latch.
7.
1.
a. b.
Clean counter and bottom part
of dispenser with paper towel.
ABRASIVES WILL SCRATCH PLASTIC
PARTS. WASH BOWL LIDS IN COOL OR LUKEWARM WATER TO
AVOID LEAKS DUE TO SEALED SURFACE BEING DAMAGED.
The appliance is not suitable for
installation in an area where a water jet could be used. The
appliance must not be cleaned by water jet.
THOROUGHLY CLEAN ALL PARTS IN WARM WATER USING A MILD
NON-ABRASIVE DETERGENT AND RINSE THOROUGHLY.
NOTICE/ AVIS/ AVISO:
NOTICE/ AVIS/ AVISO:

10 Crathco®Simplicity Bubbler
2.
Daily Cleaning (cont.)
Daily Sanitizing
DAILY
12345
678910 11 12
13 14 15 16 17 18 19
20 21 22 23 24 25 26
27 28 29 30 Prepare 8L of chlorine-based
sanitizing solution (to 100 ppm) per
package instructions.
Submerge parts in solution for 15
minutes.
5.
Spray inside of lid with sanitizer.
3. 4.
Air dry parts overnight.
1.
Spray inside of bowl with sanitizer.
XII

Simplicity Bubbler Crathco®11
Leaking
No product agitation
1.
a. O-ring nicked,
deformed, or
twisted? Cracked bowl? Replace bowl.
1. 2.
Impeller and/or axle worn? Replace worn parts.
See routine maintenance.
?
Replace pump
axle if flange
thickness is
less than
.75mm
(0.03 inch)
thick.
Replace
impeller if
bearing
surface is
worn.
a.b.
5.
Valve securely in place? Push
and twist to seat.
Gasket secured in place? Push to
seat.
b. Foreign particles on
bowl valve seat?
2. 3.
Drain tray overflow? Empty tray.
4.
3.
Impeller installed correctly?
Pump motor magnet needs adjustment?
(Call for service.
Troubleshooting

12 Crathco®Simplicity Bubbler
Troubleshooting (cont.)
No refrigeration
1.
Plugged in to wall outlet?
2.
3. Compressor does not operate;
fan does?
(Call for service.
4.
Poor refrigeration
1.
2. 3.
4. 5.
?
No product agitation?
See previous page.
Faulty thermostat?
Machine will not operate.
(Call for service.
Dirty condenser filter and condenser?
Clean condenser or (call for service.
Compressor does not operate;
fan does not operate.
Faulty fan motor?
(Call for service.
Impeller does not spin. Faulty
pump motor?
(Call for service.
Faulty thermostat or improper
setting?
(Call for service.
Power switch on?
?

Simplicity Bubbler Crathco®13
Troubleshooting (cont.)
Noisy machine
3.
2.
4.
Bowl or pump installed while unit in “on” position?
Turn unit off. Reinstall parts.
6. Fan blade bent?
Unplug unit, remove side panel, inspect fan blade.
Faulty pump motor bearings.
(Call for service.
5.
Impeller and/or axle worn? Replace worn parts.
See routine maintenance.
Broken impeller? Replace it.
1.
Impeller installed correctly in bowl?
Chattering impeller? Ensure
correct drive magnet height or
(Call for service.
7. MAINTENANCE
1. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a
similarly qualified persons in order to avoid a hazard.
2. When freezing occurs, the appliance must be powered off.
3. Access to the service area is restricted to persons having knowledge and practical experience of the
appliance, in particular as far as safety and hygiene are concerned.
Replace pump
axle if flange
thickness is
less than
.75mm
(0.03 inch)
thick.
Replace
impeller if
bearing
surface is
worn.

14 Crathco®Simplicity Bubbler
Basic Machine Parts
CS-2E, CS-1D

Simplicity Bubbler Crathco®15
Basic Machine Parts (continued)
Parts List
Simplicity Mini Twin (CS-1D / CS-2E)
Item Description CS-2E-16 CS-1D-16 CS-2E-10 CS-1D-10 CS-2E-22 CS-1D-22
BASE ASSEMBLY PARTS
1 Base Structure, Mini Twin 200-00048 200-00048 200-00048 200-00048 200-00048 200-00048
2 Front Panel assembly with magnet, Mini Twin 231-00006 231-00006 231-00006 231-00006 231-00006 231-00006
3 Screw Truss Head SS. (Mat. 420)8-32 x 1/2" 0069 0069 0069 0069 0069 0069
6 Screw, Support Drip Tray Bracket 220-00013 220-00013 220-00013 220-00013 220-00013 220-00013
7 Bracket, Support Drip Tray Lt. 200-00053 200-00053 200-00053 200-00053 200-00053 200-00053
8 Washer, Spring DIN 137B 99299 99299 99299 99299 99299 99299
9 Sleeve, Bracket Support Drip Tray 210-00119 210-00119 210-00119 210-00119 210-00119 210-00119
10 Bracket, Support Drip Tray Rt. 200-00052 200-00052 200-00052 200-00052 200-00052 200-00052
11 Screw, TPH M4x15 Plastite SS 99306 99306 99306 99306 99306 99306
12 Leg, 2" Adjustable W/Rubber Pad 220-00021 220-00021 220-00021 220-00021 220-00021 220-00021
12 Leg, 4" Adjustable W/Rubber Pad (Set of 4) M005SA M005SA M005SA M005SA M005SA M005SA
13 Screw,14 x 1/2,Type "B",Hex Hd 0063 0063 0063 0063 0063 0063
14 Condenser Filter, Mini Twin 210-00118 210-00118 210-00118 210-00118 210-00118 210-00118
15 Bracket, Switch 200-00058 200-00058 200-00058 200-00058 200-00058 200-00058
16 On-Off Switch Rocker 99066 99066 99066 99066 99066 99066
17 Right Side Panel, Simplicity 200-00056 200-00056 200-00056 200-00056 200-00056 200-00056
18 Temperature Control 1059 1059 1059 1059 1059 1059
19 Screw, M4x8mm,TH,PH,Trilobe,Blk 99059 99059 99059 99059 99059 99059
20 Access Panel Screw 220-00012 220-00012 220-00012 220-00012 220-00012 220-00012
21 Back Panel, Mini Twin 200-00055 200-00055 200-00055 200-00055 200-00055 200-00055
22 Wire Saddle Locking Top Teardrop 354-00002 354-00002 354-00002 354-00002 354-00002 354-00002
23 Dryer, E27, E275/6, CS-2E 1891 1891 1891 1891 1891 1891
24 Compressor 330-00002 330-00002 99628 99628 330-00001 330-00001
25 Nut, Hex, Lock, 1/4-20 "K" Type 0055 0055 0055 0055 0055 0055
26 Pump Motor, Agitator models Assembly 231-00413 231-00413 231-00413 231-00413 231-00413 231-00413
26a Magnet, Drive Assy 2049 2049 2049 2049 2049 2049
26b Nut, M4, Nylon, A4SS 99406 99406 99406 99406 99406 99406
26c Bracket, Pump Motor (agitator model) 200-00533 200-00533 200-00533 200-00533 200-00533 200-00533
26c Bracket, Pump Motor (spray model) 200-00059 200-00059 200-00059 200-00059 200-00059 200-00059
26d Pump Motor, Low Speed, 300 RPM 260-00027 260-00027 260-00027 260-00027 260-00027 260-00027
27 Evaporator Assembly, CS-2E 231-00007 231-00007 231-00007 231-00007 231-00007 231-00007
28 Seal, Bearing Sleeve 290-00005 290-00005 290-00005 290-00005 290-00005 290-00005
29 Bearing Sleeve, Agitator models 220-00305 220-00305 220-00305 220-00305 220-00305 220-00305
Bearing Sleeve, Spray models 220-00295 220-00295 220-00295 220-00295 220-00295 220-00295
30 Cam-Lock Remove Bowl Assembly 231-00204 231-00204 231-00204 231-00204 231-00204 231-00204
31 Screw, JT4x50, SUS 350-00016 350-00016 350-00016 350-00016 350-00016 350-00016
32 Compact Fan Motor 3338 3338 3338 3338 260-00002 260-00002
33 Copper, Discharge, Mini Twin 362-00067 362-00067 362-00067 362-00067 362-00014 362-00014
34 Condenser, CS-2E 332-00001 332-00001 332-00001 332-00001 332-00001 332-00001
35 Left Side Panel, simplicity 200-00057 200-00057 200-00057 200-00057 200-00057 200-00057
36 Grommet, for Plastic Sides 2679 2679 2679 2679 2679 2679
37 Pump Motor, Spray models Assembly 231-00194 231-00194 231-00194 231-00194 231-00139 231-00139
37a Pump Motor, Spray models, 1500 RPM 260-00013 260-00013 260-00013 260-00013 260-00014 260-00014
38 Drainage channel silicone, CS-2E 290-00099 290-00099 290-00099 290-00099 290-00099 290-00099
BOWL ASSEMBLY PARTS
4 Cover, Drip Tray Mini Twin 200-00062 200-00062 200-00062 200-00062 200-00062 200-00062
5 Drip Tray, Mini Twin 210-00127 210-00127 210-00127 210-00127 210-00127 210-00127
39 Impeller, Mixing (agitator model) 210-00130 210-00130 210-00130 210-00130 210-00130 210-00130
40 Gasket, Bowl 290-00006 290-00006 290-00006 290-00006 290-00006 290-00006
41 Push Handle(Cup Activated) 200-00063 200-00063 200-00063 200-00063 200-00063 200-00063
42 Bowl 18 Liters (4.8 Gallon) (agitator model) 231-00010 231-00010 231-00010
43 Bowl Cover, 18 Liters (agitator model) 210-00126 210-00126 210-00126
44 Bowl 9 Liters (2.4 Gallon) (agitator model) 231-00009 231-00009 231-00009
45 Valve, Dispense with Seal 99464 99464 99464 99464 99464 99464
46 Bowl Cover, 9 Liters (agitator model) 210-00125 210-00125 210-00125
47 Bowl Cover, 18 Liters, Insulated (spray model) 231-00403 231-00403 231-00403
48 Bowl Cover, 9 Liters, Insulated (spray model) 231-00402 231-00402 231-00402
49 Spray Tube (spray model) 210-00276 210-00276 210-00276 210-00276 210-00276 210-00276
50 Pump Cover (spray model) 210-00128 210-00128 210-00128 210-00128 210-00128 210-00128
51 Impeller,Magnetic Over Mold (spray model) 210-00255 210-00255 210-00255 210-00255 210-00255 210-00255
52 Valve, Dispense 99463 99463 99463 99463 99463 99463
53 Seal, Valve 99380 99380 99380 99380 99380 99380

16 Crathco®Simplicity Bubbler
Basic Machine Parts (continued)
CS-3L
44
4
5
4
6
49
50
43
51
52
42
4
7
4
8
41
3
7a
3
7
39
38
41
29
28
3
2
a
32b
3
1
2
5
33
30
26
c
26b
26a
2
6
27
26b
32c
4
0
35
34
32
24
26d
22
23
25
1
2
36
19
20
2
1
3
4
5
1
7
19
1
8
6
7
11
9
8
10
12
1
3
1
5
16
14
11

Simplicity Bubbler Crathco®17
Basic Machine Parts (continued)
Parts List
Simplicity Triple 18L, Bowl (CS-3L)
Item Description CS-3L-16 CS-3L-22
BASE ASSEMBLY PARTS
1 Base Structure, Mini Quad 200-00142 200-00142
2 Front Panel assembly with magnet, CS-3L 231-00392 231-00392
3 Screw Truss Head SS. (Mat. 420)8-32 x 1/2" 0069 0069
6 Screw, Support Drip Tray Bracket 220-00013 220-00013
7 Bracket, Support Drip Tray Lt. 200-00053 200-00053
8 Washer, Spring DIN 137B 99299 99299
9 Sleeve, Bracket Support Drip Tray 210-00119 210-00119
10 Bracket, Support Drip Tray Rt. 200-00052 200-00052
11 Screw, TPH M4x15 Plastite SS 99306 99306
12 Leg, 2" Adjustable W/Rubber Pad 200-00021 220-00021
Leg, 4" Adjustable W/Rubber Pad M005SA M005SA
13 Screw,14 x 1/2,Type "B",Hex Hd 0063 0063
14 Condenser Filter, CS-3L 210-00585 210-00585
15 Bracket, Switch 200-00058 200-00058
16 On-Off Switch Rocker 99066 99066
17 Right Side Panel, Simplicity 200-00056 200-00056
18 Temperature Control 1059 1059
19 Screw, M4x8mm,TH,PH,Trilobe,Blk 99059 99059
20 Access Panel Screw 220-00012 220-00012
21 Back Panel, Mini Quad 200-00145 200-00145
22 Wire Saddle Locking Top Teardrop 354-00002 354-00002
23 Dryer, D35, CS-4E 1451 1451
24 Compressor 3253 330-00006
25 Nut, Hex, Lock, 1/4-20 "K" Type 0055 0055
26 Pump Motor, Agitator models Assembly 231-00381 231-00381
26a Magnet, Drive Assy 2049 2049
26b Nut, M4, Nylon, A4SS 99406 99406
26c Bracket, Pump Motor 200-00648 200-00648
26d Pump Motor, Low Speed, 300 RPM 260-00027 260-00027
27 Evaporator Assembly, CS-3L 231-00405 231-00405
28 Seal, Bearing Sleeve 290-00005 290-00005
29 Bearing Sleeve, Agitator models 220-00305 220-00305
Bearing Sleeve, Spray models 220-00295 220-00295
30 Cam-Lock Remove Bowl Lt. Assembly (Double Cam - Lock) 231-00433 231-00433
31 Cam-Lock Remove Bowl Rt. Assembly (Single Cam-Lock) 231-00434 231-00434
32 Fan Motor Assembly 3432 231-00212
32a Fan blade 1460 1460
32b Fan Motor 3430 1585
32c Bracket, Fan Motor 3429 3429
33 Copper, Discharge 3763-2 3763-2
34 Condenser, CS-4E 332-00003 332-00003
35 Left Side Panel, Simplicity 200-00057 200-00057
36 Grommet, for Plastic Sides 2679 2679
37 Pump Motor, Spray models Assembly 231-00382 231-00382
37a Pump Motor, Spray models, 1500 RPM 260-00028 260-00028
38 Drainage channel silicone, CS-4E 290-00100 290-00100
39 Drainage channel silicone, CS-3L 290-00106 290-00106
40 Wide Wire Saddle #WWS-A-2-01 354-00001 354-00001
BOWL ASSEMBLY PARTS
4 Cover, Drip Tray Mini Quad 200-00143 200-00143
5 Drip Tray, Mini Quad 210-00252 210-00252
41 Impeller, Mixing 210-00130 210-00130
42 Gasket, Bowl 18L, Tall 290-00089 290-00089
43 Bowl Cover, 18 Liters, Tall, Insulated 231-00406 231-00406
44 Bowl 18 Liters, Tall (4.8 Gallon) 231-00404 231-00404
45 Valve, Dispense with Seal 99464 99464
46 Bowl Cover, 18 Liters, Tall 210-00495 210-00495
47 Valve, Dispense 99463 99463
48 Seal, Valve 99380 99380
49 Spray Tube 210-00410 210-00410
50 Pump Cover 210-00409 210-00409
51 Impeller,Magnetic Over Mold (spray model) 210-00255 210-00255
52 Push Handle (Cup Activated) 200-00063 200-00063

18 Crathco®Simplicity Bubbler
Basic Machine Parts (continued)
CS-4E, CS-2D, CS-3D
4
47
48
44
43
4
5
46
51
49
50
42
5
2
53
54
41
40
29
28
32a
37a
37
39
38
26a
28
27
3
2
c
32a
3
2b
25
33
24
30
26d
26c
26b
25
26
26b
31
36
35
b
34
32
24
22
23
21
1
3
2
1
9
1
8
20
4
5
11
17
6
11
9
8
1
0
7
12
1
31
5
1
6
14

Simplicity Bubbler Crathco®19
Basic Machine Parts (continued)
Parts List
Simplicity Mini Quad (CS-4E /CS-2D / CS-3D)
Item Description CS-4E-16 CS-4E-22 CS-2D-16 CS-2D-22 CS-3D-16 CS-3D-22
BASE ASSEMBLY PARTS
1 Base Structure, Mini Quad 200-00142 200-00142 200-00142 200-00142 200-00142 200-00142
2 Front Panel assembly with magnet, Mini Quad 231-00287 231-00287 231-00287 231-00287 231-00287 231-00287
3 Screw Truss Head SS. (Mat. 420)8-32 x 1/2" 0069 0069 0069 0069 0069 0069
6 Screw, Support Drip Tray Bracket 220-00013 220-00013 220-00013 220-00013 220-00013 220-00013
7 Bracket, Support Drip Tray Lt. 200-00053 200-00053 200-00053 200-00053 200-00053 200-00053
8 Washer, Spring DIN 137B 99299 99299 99299 99299 99299 99299
9 Sleeve, Bracket Support Drip Tray 210-00119 210-00119 210-00119 210-00119 210-00119 210-00119
10 Bracket, Support Drip Tray Rt. 200-00052 200-00052 200-00052 200-00052 200-00052 200-00052
11 Screw, TPH M4x15 Plastite SS 99306 99306 99306 99306 99306 99306
12 Leg, 2" Adjustable W/Rubber Pad 220-00021 220-00021 220-00021 220-00021 220-00021 220-00021
12 Leg, 4" Adjustable W/Rubber Pad (Set of 4) M005SA M005SA M005SA M005SA M005SA M005SA
13 Screw,14 x 1/2,Type "B",Hex Hd 0063 0063 0063 0063 0063 0063
14 Condenser Filter, Mini Quad 210-00585 210-00585 210-00585 210-00585 210-00585 210-00585
15 Bracket, Switch 200-00058 200-00058 200-00058 200-00058 200-00058 200-00058
16 On-Off Switch Rocker 99066 99066 99066 99066 99066 99066
17 Right Side Panel, Simplicity 200-00056 200-00056 200-00056 200-00056 200-00056 200-00056
18 Temperature Control 1059 1059 1059 1059 1059 1059
19 Screw, M4x8mm,TH,PH,Trilobe,Blk 99059 99059 99059 99059 99059 99059
20 Access Panel Screw 220-00012 220-00012 220-00012 220-00012 220-00012 220-00012
21 Back Panel, Mini Quad 200-00145 200-00145 200-00145 200-00145 200-00145 200-00145
22 Wire Saddle Locking Top Teardrop 354-00002 354-00002 354-00002 354-00002 354-00002 354-00002
23 Dryer, D35, CS-4E 1451 1451 1451 1451 1451 1451
24 Compressor 3253 330-00006 3253 330-00006 3253 330-00006
25 Nut, Hex, Lock, 1/4-20 "K" Type 0055 0055 0055 0055 0055 0055
26 Pump Motor, Agitator models Assembly 231-00413 231-00413 231-00413 231-00143 231-00413 231-00413
26a Magnet, Drive Assy (Agitator model) 2049 2049 2049 2049 2049 2049
26a Magnet, Drive Assy (Spray model) 2049 2049 2049 2049 2049 2049
26b Nut, M4, Nylon, A4SS 99406 99406 99406 99406 99406 99406
26c Bracket, Pump Motor (Agitator model) 200-00533 200-00533 200-00533 200-00533 200-00533 200-00533
26c Bracket, Pump Motor (Spray model) 200-00059 200-00059 200-00059 200-00059 200-00059 200-00059
26d Pump Motor, Low Speed, 300 RPM (Agitator model) 260-00027 260-00027 260-00027 260-00027 260-00027 260-00027
27 Evaporator Assembly, CS-4E 231-00288 231-00228 231-00288 231-00228 231-00288 231-00228
28 Seal, Bearing Sleeve 290-00005 290-00005 290-00005 290-00005 290-00005 290-00005
29 Bearing Sleeve, Agitator models 220-00305 220-00305 220-00305 220-00305 220-00305 220-00305
Bearing Sleeve, Spray models 220-00295 220-00295 220-00295 220-00295 220-00295 220-00295
30 Cam-Lock Remove Bowl Assembly 231-00204 231-00204 231-00204 231-00204 231-00204 231-00204
31 Wide Wire Saddle #WWS-A-2-01 354-00001 354-00001 354-00001 354-00001 354-00001 354-00001
32 Fan Motor Assembly 3432 231-00212 3432 231-00212 3432 231-00212
32a Fan blade 1460 1460 1460 1460 1460 1460
32b Fan Motor 3430 1585 3430 1585 3430 1585
32c Bracket, Fan Motor 3429 3429 3429 3429 3429 3429
33 Copper, Discharge 3763-2 3763-2 3763-2 3763-2 3763-2 3763-2
34 Condenser, CS-4E 332-00003 332-00003 332-00003 332-00003 332-00003 332-00003
35 Left Side Panel, Simplicity 200-00057 200-00057 200-00057 200-00057 200-00057 200-00057
36 Grommet, for Plastic Sides 2679 2679 2679 2679 2679 2679
37 Pump Motor, Spray models Assembly 231-00194 231-00139 231-00194 231-00139 231-00194 231-00139
37a Pump Motor, Spray models, 1500 RPM 260-00013 260-00014 260-00013 260-00014 260-00013 260-00014
38 Drainage channel silicone, CS-4E 290-00100 290-00100 290-00100 290-00100 290-00100 290-00100
39 Drainage channel silicone, CS-2E 290-00099 290-00099 290-00099 290-00099 290-00099 290-00099
BOWL ASSEMBLY PARTS
4 Cover, Drip Tray Mini Quad 200-00143 200-00143 200-00143 200-00143 200-00143 200-00143
5 Drip Tray, Mini Quad 210-00252 210-00252 210-00252 210-00252 210-00252 210-00252
40 Impeller, Mixing (Agitator model) 210-00130 210-00130 210-00130 210-00130 210-00130 210-00130
41 Gasket, Bowl 290-00006 290-00006 290-00006 290-00006 290-00006 290-00006
42 Bowl 18 Liters (4.8 Gallon) 231-00010 231-00010 231-00010 231-00010
43 Bowl Cover, 18 Liters (Agitator model) 210-00126 210-00126 210-00126 210-00126
44 Bowl 9 Liters (2.4 Gallon) 231-00009 231-00009 231-00009 231-00009
45 Valve, Dispense with Seal 99464 99464 99464 99464 99464 99464
46 Bowl Cover, 9 Liters (Agitator model) 210-00125 210-00125 210-00125 210-00125
47 Bowl Cover, 18 Liters, Insulated (Spray model) 231-00403 231-00403 231-00403 231-00403
48 Bowl Cover, 9 Liters, Insulated (Spray model) 231-00402 231-00402 231-00402 231-00402
49 Valve, Dispense 99463 99463 99463 99463 99463 99463
50 Seal, Valve 99380 99380 99380 99380 99380 99380
51 Spray Tube (Spray model) 210-00276 210-00276 210-00276 210-00276 210-00276 210-00276
52 Pump Cover (Spray model) 210-00128 210-00128 210-00128 210-00128 210-00128 210-00128
53 Impeller,Magnetic Over Mold (Spray model) 210-00255 210-00255 210-00255 210-00255 210-00255 210-00255
54 Push Handle (Cup Activated) 200-00063 200-00063 200-00063 200-00063 200-00063 200-00063

20 Crathco®Simplicity Bubbler
Spacer Bracket Installation
Installed Standoff Bracket Overview
Rear View
5 inch
rear distance
e
g
Left Rear Corner View
1 inch side spacing
allows 2 Bubblers to sit
side-by-side to allow a
total 2 inch clearance
Left Side View
Bracket extends
3.5 inches
down each side
Left Rear Corner View
Recommended Spacing:
Place Bubblers side-by-side in available
space then center them in total
available space.
1. 2. 3.
Tools needed:
Phillips head screw driver
Flathead screw driver
Rotate unit so that there is easy
access to each side and rear of unit.
(Recommended attaching spacer
during cleaning of unit during
closing or during opening).
Total attachment time is 15 minutes.
Orientation of bracket is with all 4
screw tabs against the base, as
shown.
Remove protective film from
bracket and discard film.
