Crathco E-49 Mini-Quad User manual

tem # ________________________________
Project _______________________________
Date _________________________________
Model # E49 Mini-Quad
Premi Dispensers
Features
•Compact size saves valuable counter space
• Dispense 4 flavors in less than 21 inches
• Famous two-piece stainless steel dripless pouring
valves are sanitary and easy to use and maintain
• Large capacity drip pans hold more
• Generous, yet compact, 9 liter (2.4 gallon) easy
clean bowls
• Unique evaporator and high efficiency pump
design cools faster and more efficiently for faster
start-ups
• Superior engineering allows full beverage cooling
right down to the last drink
• Super-strong, virtually unbreakable polycarbonate
bowls and covers give lasting durability
• Modern styling, better design and more use
of stainless steel allow easier cleaning and
less maintenance
• Second-to-none quality control with “field
condition” testing
• Agitators are included with each unit for fresh
juices, coffees or teas
• World-wide sales and service assure customer
satisfaction
Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines
Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems
Tel [phone] • Fax [phone] • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: [e-mail]

Specifications E49 (115V/60Hz) E495 (230V/50Hz) E496 (230V/60Hz)
# Bowls 4 4 4
Bowl Capacity (per bowl) 2.4 gallons (9L) 2.4 gallons (9L) 2.4 gallons (9L)
Refrigeration 1/5 hp 1/5 hp 1/5 hp
Volts / Hz / Amps 115V / 60Hz / 5.5Amp 230V / 50Hz / 2.7Amp 230V / 60Hz / 2.7Amp
Dimensions
(H x W x D)
25 1/2” x 20 1/2” x 15”
(65 cm x 52 cm x 38 cm)
25 1/2” x 20 1/2” x 15”
(65 cm x 52 cm x 38 cm)
25 1/2” x 20 1/2” x 15”
(65 cm x 52 cm x 38 cm)
Ship Dimensions (2 Boxes)
(H x W x D)
Base: 22 1/4” x 25 1/4” x 15 1/4”
57cm x 64cm x 39cm
Bowl: 26 1/8” x 25 1/4” x 15 1/4”
66cm x 64cm x 39cm
Base: 22 1/4” x 25 1/4” x 15 1/4”
57cm x 64cm x 39cm
Bowl: 26 1/8” x 25 1/4” x 15 1/4”
66cm x 64cm x 39cm
Base: 22 1/4” x 25 1/4” x 15 1/4”
57cm x 64cm x 39cm
Bowl: 26 1/8” x 25 1/4” x 15 1/4”
66cm x 64cm x 39cm
Ship Weight 91 lbs (base: 67, bowls: 21)
41.2 kg (base: 30.4, bowls: 10.8 )
91 lbs (base: 67, bowls: 21)
41.2 kg (base: 30.4, bowls: 10.8)
91 lbs (base: 67, bowls: 21)
41.2 kg (base: 30.4, bowls: 10.8)
Cup Height 8” (20 cm) 8” (20 cm) 8” (20 cm)
Listings UL, NSF, CUL NSF, CE NSF, CE
Options* Mini-Quad Models
Side panels & drip trays -3 Stainless steel material (additional charge), -4 off-white high impact plastic (standard - no
additional charge)
Valve cap (part# 2039) mproves sealing of valve when using pulpy products
Valve locking box (part# 2502) (use w/ standard handle) Secures the valve from dispensing during off-hours - not to be used with non-contact handle
Liquid Auto Fill (part# 90295) Ensures proper product and mixing consistency, maintains optimum product level in bowls,
eliminates need for frequent manual mixing
Low Foam mpeller (part# 3709) Use with iced tea and milk based drinks to minimize foaming
Milk Fat mpellers (part# 1161M Lg Blue or #1008M Sm Red) Use with milkbased products, and/or products with heavy pulp
*Extra cost for options listed above
Specifications are subject to improvement or change without notice.
Ask about the Grindmaster Corporation’s line of Coffee Grinders, Coffee Brewers, Coffee Urns, Coffee Shuttles, Coffee Grinderbrewers, Espresso Grinders, Espresso
Brewers, Beverage Dispensers, Granita Machines and Beverage Freezers.
Model # E49 Mini-Quad
Premi Dispensers
20 1/2 [52]
15 1/2 [40]
10 3/4 [28]
25 1/2 [65]
Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines
Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems
Tel [phone] • Fax [phone] • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: [e-mail]
© Gr ndmaster Corporat on, 2006
PRINTED IN USA
0806 Form # CC-240-08
